PM8ANYDRIVEUSB Memory Device

FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures : - Reorient of relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. CAUTION : Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the user’s authority to operate the equipment. In the package 1. AnyDrive 1EA 2. USB extension cable 1EA 3. Driver CD 1EA 4. Neckless line 1EA 5. User manual and warranty card Specification 1. Size and weight : 852010mm, 21g 2. A Kind : 32MB 3. Interface : Supported USB 1.1 standard(12Mbps), USB 2.0 compatible Using environment 1. Notebook, desktop or Macintosh with USB port 2. Windows 98, ME, 2000, XP, Linux 2.4.X and Mac OS 9.0 Special feature 1. Wide compatible : Windows 98, ME, 2000, XP, Linux and Mac OS compatible. 2. Simple use : Need not special power, install driver. (Only Windows 98 use special install driver) 3. Easy movement : Light weight, small size can easily move at pocket or neck. 4. Good design : Good design and neat color product looks like decoration. 5. Fast transfer rate and large storage size : 10 time faster then FDD, faster than ZIP drive and large storage size Max 512MB Install product (1) Install driver 1. Windows ME upper, Mac – OS Automatically install by OS. 2. Windows 98(SE) 1) When AnyDrive connect USB port, appear ‘Find new hardware’ message and follow window. 2) Select ‘Search for the best driver for your drive. (Recommended)’ and click ‘Next’. 3) Check ‘Specify a location’, click ‘Browse..’ and select driver folder of driver CD. 4) After search driver, click ‘Next’. 5) After install driver, follow windows appear, USB Mass Storage Drive. 6) If driver is install normally, three factors are added as follow image. (2) Connect computer 1. When using USB extension cable – First connect USB extension cable to USB port, And connect USB drive to USB extension cable. 2. When directly connect – Connect directly USB drive to USB port. Product performance 1. Read rate : Avg. 1MB/sec 2. Write rate : Avg. 642KB/sec *. Read/Write rate is different according to using OS and specification of computer. Caution 1. Do not disconnect when red LED light rapidly up. Red LED means data are transferring now. So if you disconnect when red LED light rapidly up, USB drive may have damage.

USB Connector Controller Memory 8 USB Data Clock 14.31818MHz Reset ANY DRIVE BLOCK DIAGRAM

CERTiTEK Standards Laboratory Co., Ltd. 386-1, Ho-Dong, Yongin-City, Kyungki-Do, Korea 449-100 Tel: +82-31-339-9970 Fax: +82-31-339-9855 http://www.certitek.com/ Test Report No.: CTK02-F054 Date: April 23, 2002 Page 1 of 1 This Report shall not be reproduced except in full without the written approval of CERTiTEK Form No.: CTK-FF1.1 CERTiTEK EUT External Photographs

CERTiTEK Standards Laboratory Co., Ltd. 386-1, Ho-Dong, Yongin-City, Kyungki-Do, Korea 449-100 Tel: +82-31-339-9970 Fax: +82-31-339-9855 http://www.certitek.com/ Test Report No.: CTK02-F054 Date: April 23, 2002 Page 1 of 1 This Report shall not be reproduced except in full without the written approval of CERTiTEK Form No.: CTK-FF1.1 CERTiTEK Photographs related to Label

CERTiTEK Standards Laboratory Co., Ltd. 386-1, Ho-Dong, Yongin-City, Kyungki-Do, Korea 449-100 Tel: +82-31-339-9970 Fax: +82-31-339-9855 http://www.certitek.com/ Test Report No.: CTK02-F054 Date: April 23, 2002 Page 1 of 2 This Report shall not be reproduced except in full without the written approval of CERTiTEK Form No.: CTK-FF1.1 CERTiTEK EUT Internal Photographs CERTiTEK Standards Laboratory Co., Ltd. 386-1, Ho-Dong, Yongin-City, Kyungki-Do, Korea 449-100 Tel: +82-31-339-9970 Fax: +82-31-339-9855 http://www.certitek.com/ Test Report No.: CTK02-F054 Date: April 23, 2002 Page 2 of 2 This Report shall not be reproduced except in full without the written approval of CERTiTEK Form No.: CTK-FF1.1 CERTiTEK PCB

CERTiTEK Standards Laboratory Co., Ltd. 386-1, Ho-Dong, Yongin-City, Kyungki-Do, Korea 449-100 Tel: +82-31-339-9970 Fax: +82-31-339-9855 http://www.certitek.com/ Test Report No.: CTK02-F054 Date: April 23, 2002 Page 1 of 14 This Report shall not be reproduced except in full without the written approval of CERTiTEK Form No.: CTK-FF1.1 CERTiTEK EMC TEST REPORT For FCC Test Report No. : CTK02-F054 Date of Issue : April 23, 2002 Model/Type No: : ANY DRIVE Kind of Product : USB MEMORY Applicant : AL Tech, Inc. Applicant Address : Haesung Bldg. 1F, 747-2, Yoksam-Dong, Kangnam-Gu, Seoul, Korea, 153-080 Manufacturer : AL Tech, Inc. Manufacturer Address : Haesung Bldg. 1F, 747-2, Yoksam-Dong, Kangnam-Gu, Seoul, Korea, 153-080 Contact Person : Mr. J. W. Kim Telephone : +82-2-566-5093 Received Date : April 17, 2002 Test period : Start: Apr. 17, 2002 End: Apr. 23, 2002 Test Results : In Compliance Not in Compliance The test results presented in this report relate only to the object tested. CERTiTEK Standards Laboratory Co., Ltd. is accredited by Korea Laboratory Accreditation Scheme (KOLAS) which signed the International Laboratory Accreditation Cooperation (ILAC) Mutual Recognition Arrangement (MRA) for the above test item(s) and test method(s). Tested by Reviewed by Michael Jang EMC Test Engineer James Hong EMC Technical Manager Date: April 23, 2002 Date: April 23, 2002 CERTiTEK Standards Laboratory Co., Ltd. 386-1, Ho-Dong, Yongin-City, Kyungki-Do, Korea 449-100 Tel: +82-31-339-9970 Fax: +82-31-339-9855 http://www.certitek.com/ Test Report No.: CTK02-F054 Date: April 23, 2002 Page 2 of 14 This Report shall not be reproduced except in full without the written approval of CERTiTEK Form No.: CTK-FF1.1 CERTiTEK REPORT REVISION HISTORY Date Revision Page No Apr. 23, 2002 (CTK02-F054) Issued All This report shall not be reproduced except in full, without the written approval of CERTiTEK Standards Laboratory Co., Ltd. This document may be altered or revised by CERTiTEK Standards Laboratory Co., Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by CERTiTEK Standards Laboratory Co., Ltd. will constitute fraud and shall nullify the document. CERTiTEK Standards Laboratory Co., Ltd. 386-1, Ho-Dong, Yongin-City, Kyungki-Do, Korea 449-100 Tel: +82-31-339-9970 Fax: +82-31-339-9855 http://www.certitek.com/ Test Report No.: CTK02-F054 Date: April 23, 2002 Page 3 of 14 This Report shall not be reproduced except in full without the written approval of CERTiTEK Form No.: CTK-FF1.1 CERTiTEK TABLE OF CONTENTS 1.0 General Product Description...................................................................................4 1.1 Model Differences.................................................................................................4 1.2 Device Modifications..............................................................................................4 1.3 EUT Configuration(s).............................................................................................5 1.4 Test Software.......................................................................................................5 1.5 EUT Operating Mode(s)..........................................................................................5 1.6 Calibration Details of Equipment Used for Measurement..............................................6 1.7 Test Facility.........................................................................................................6 1.8 Measurement Procedure........................................................................................6 1.9 Laboratory Accreditations and Listings......................................................................7 2.0 Emissions Test Regulations.....................................................................................8 2.1 Conducted Voltage Emissions..................................................................................9 2.2 Radiated Electric Field Emissions...........................................................................10 Configurations.........................................................................................................11 APPENDIX A - TEST DATA..........................................................................................12 Conducted Voltage Emissions (Quasi-Peak reading)..................................................12 Radiated Electric Field Emissions (Quasi-Peak reading)..............................................14 CERTiTEK Standards Laboratory Co., Ltd. 386-1, Ho-Dong, Yongin-City, Kyungki-Do, Korea 449-100 Tel: +82-31-339-9970 Fax: +82-31-339-9855 http://www.certitek.com/ Test Report No.: CTK02-F054 Date: April 23, 2002 Page 4 of 14 This Report shall not be reproduced except in full without the written approval of CERTiTEK Form No.: CTK-FF1.1 CERTiTEK 1.0 General Product Description The product is an USB MEMORY. 1.0.1 Tested Equipment Unless otherwise indicated, all tests were conducted on Model ANY DRIVE. Tests performed on Model were considered to be representative of Model(s) . 1.0.2 Equipment Size, Mobility and Identification Dimensions: 85 by 20 by 10 mm in Mobility: Hand-Held Table-top Floor-standing Stationary Serial No.: - 1.0.3 Electrical Ratings Input: Supplied by PC’s USB port Output: Not applicable 1.0.4 Test Voltage & Frequency Unless indicated otherwise on the individual data sheet or test results, the test voltage and frequency was as indicated below. Voltage: Supplied by PC’s USB port Frequency: Not applicable * During the EMI and EMS tests, PC Voltage/Frequency put 230VAC/50Hz to use. 1.0.5 Clock & Other Frequencies Utilized Switching frequency : 14.31818MHz 1.1 Model Differences Not applicable 1.2 Device Modifications The following modifications were necessary for compliance: Not applicable CERTiTEK Standards Laboratory Co., Ltd. 386-1, Ho-Dong, Yongin-City, Kyungki-Do, Korea 449-100 Tel: +82-31-339-9970 …

Text truncated - open the document above for the full version.

CERTiTEK Standards Laboratory Co., Ltd. 386-1, Ho-Dong, Yongin-City, Kyungki-Do, Korea 449-100 Tel: +82-31-339-9970 Fax: +82-31-339-9855 http://www.certitek.com/ Test Report No.: CTK02-F054 Date: April 23, 2002 Page 1 of 2 This Report shall not be reproduced except in full without the written approval of CERTiTEK Form No.: CTK-FF1.1 CERTiTEK APPENDIX B - Test Setup Photos and Configuration Conducted Voltage Emissions CERTiTEK Standards Laboratory Co., Ltd. 386-1, Ho-Dong, Yongin-City, Kyungki-Do, Korea 449-100 Tel: +82-31-339-9970 Fax: +82-31-339-9855 http://www.certitek.com/ Test Report No.: CTK02-F054 Date: April 23, 2002 Page 2 of 2 This Report shall not be reproduced except in full without the written approval of CERTiTEK Form No.: CTK-FF1.1 CERTiTEK Radiated Electric Field Emissions
