POQWPE-1000WPE-1000

Modottel Co Ltd

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Aug 12, 2001
Application Purpose: Original Equipment
Date of Application: Jun 07, 2001
Equipment Note: WPE-1000
Frequency Range: 1851.25000000 - 1908.75000000
Company: Modottel Co Ltd
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Withus. Cdma UI. 2000. 10. - 1 - Make by Withus. Cdma Team WPE 1000 Menu Tree Main menu Sub. menu Sub. menu Remarks (Contents) 1.Phone Book 1. Find Entry 1. Find Name 200 memory 2. Find Location 3. Find Number 4. Find Group 2. Add Entry 7segmented name, home, office, mobile, other, e-mail, group 3. View Call List 4 Types of Number 20 calls (Outgoing call, Incoming call, Missed call, memo during calls) 4. Air Time 1. Last Call 2. Outgoing 3. Total (Add Emergency Call ) 3 calls 5. Edit Group 1. New group 2. Change group 3. Erase group (bell setting by group) 6. My Phone # 2. PIM 1. View schedule schedule/ anniversary 2. Add schedule Schedule Anniversary 3. Alarm One time/ daily / clear 4. World time 50 cities 5. Memo Add memo / memo contents 3. Ring 1. Ring type Bell / Lamp vibrator / vibrator + Bell / 2. Ring volume 4 steps 3. Ring tone General Ring tone (5 types) / Melody ( 15 types ) 20 types of bell sounds available 4. Sounds 1. Call volume 4 steps 2. Key beep 5 steps (* Adjustable in IDLE state ) 3. Connect Tone On/Off 4. 1-minute beep On/Off 5. Svc area On/Off 5. Display 1.Backlight Always off/ 10 sec Auto /Always On 2.Standby display Banner & time mode / Picture mode 3 Picture support 3.Banner 4. language English / Spanish 5. Version 6. Contrast 8 steps 6. Set up 1. Auto retry No setting/ In 10 sec./ 20 sec. Default : ‘No setting’. 2. Auto receive No setting/ In 5 sec. / 10 sec. / 20 sec. Default : ‘No setting’. 3. Auto Hyphen ON/OFF Withus. Cdma UI. 2000. 10. - 2 - Make by Withus. Cdma Team 4. Prepend dialing 7. Security 1. Lock Never /on power up / now 2. Lock code 3. Restrict 1. Phone book 2. Incoming 3. Outgoing 4. Clear Memory 1.call logs 2.Phone Book 3.PIM 5. Emergency 3 Numbers 8. Data Service 1.SIO mode select Packet Data Modem/fax mode 2. Incoming mode Modem/fax off Modem Always Fax Always SMS 1. SMS Inbox 1. Text 2. Voice 3. Erase all 2. SMS Outbox 1. Paging 2. Compose Msg New Msg / Sent Msg / Erase Msg 3. SMS Setup 1. New message alert Vib+Lamp / one Time / Every 2 min 2. Display Text Display part / Display all *Features during calls 1. Send my # 2. Block dial tone Memo Only figure editable Calling volume Same as 4.1 (call transfer service) (call holding service) * Speed key Manner mode setting/ clear Lock function setting/ clear Missed call check Caller ID receipt Withus. Cdma UI. 2000. 10. - 3 - Make by Withus. Cdma Team 1. Basic Phone Setup 1.1 Keypad Configuration 1.2 Key functions 1.3 Display 1.4 Icons 1.5 Power On/Off 1.6 Idle mode 1. Basic Functions 2.1 Processing in IDLE state 2.2 Answering a call 2.3 Making a call 2.4 Feature available during calls 2.5 SMS receipt 2.6 Missed call 2.7 Auto redialing 2.8 DTMF tone dialing 2.9 Speed key 2.10 Use restriction 3. Menu configuration 4. Phone Book 4.1 Find entry 4.2 Add entry 4.3 View call list 4.4 Air time 4.5 Edit group 4.6 My phone # 5. PIM 5.1 View scheduler 5.2 Add scheduler 5.3 Alarm 5.4 World time 5.5 Memo Withus. Cdma UI. 2000. 10. - 4 - Make by Withus. Cdma Team 6. Ring 6.1 Ring type 6.2 Ring volume 6.3 Ring tone 7. Sounds 7.1 Call volume 7.2 Key beep 7.3 Connect tone 7.4 1-minnute beep 7.5 Svc area 8. Display 8.1 Backlight 8.2 standby display 8.3 Banner 8.4 language 8.5 Version 8.6 Contrast 9. Setup 9.1 Auto retry 9.2 Auto receive 9.3 Auto Hyphen 9.4 Prepend Dialing 10. Security 10.1 Lock 10.2 Lock code 10.3 Restrict 10.4 Clear memory 10.5 Emergency 11. Data Service 11.1 SIO mode Select 11.2 Incoming mode Withus. Cdma UI. 2000. 10. - 5 - Make by Withus. Cdma Team 12. SMS 12. 1 SMS Inbox 12. 2 SMS Outbox 12. 3 SMS Setup * SAFETY INFORMATION Withus. Cdma UI. 2000. 10. - 6 - Make by Withus. Cdma Team 1. Basic Phone Setup 1.1 Keypad Configuration Diagram - The following illustrations shows the main elements of phone. 1.2 Key functions - : In the idle mode, enters the SMS menu. Upon character editing, this is used to enter special character, and upon figure editing, this is used for DTMF tone dialing. - : Adjusts voice volume during a conversation and key beep volume in the idle mode. In the menu mode, scrolls through the menu options. - Send : Makes or answers a call - End : Ends a call. Also, switches the phone on or off when pressed and held. In the menu facility, returns to the idle mode and cancels your input - CLR : Deletes characters from the display. In the menu facility, returns to the previous menu - Soft menu : Enters the menu facility. Also, scrolls through the menu options. In the menu facility, selects a menu function or stores information that you have entered. - * : In the idle mode, quickly changes to Manner mode when pressed and held. For SMS editing, cursor moves back. - # : In the idle mode, phone is locked/unlock when pressed and held. For SMS editing, cursor moves forwarder 1 CLR Send End 1 2 3 4 5 6 7 8 9 * 0 # Withus. Cdma UI. 2000. 10. - 7 - Make by Withus. Cdma Team Correspondin g Key State Active IDLE Used for SMS exclusively. SMS menu (MSG_K) Upon Korean Editing, this is used to select special character. IDLE Display Main Menu. CALL Select menu in busy state. Menu(PF1_K) MENU Move to the next menu. ( also press ‘#’ ) Operation according to Soft key. IDLE Nonevent CALL Memo during calls OK(PF2_K) MENU Used to choose corresponding menu and select and set each function. Operation according to Soft key. IDLE If pressing ‘Send’ key after entering phone number, a call is made. If no phone number, a call is made to the last dialed number in last call list. (if no list, Nonevent) Send CALL If pressing ‘Send’ key after entering phone number, a call is made. (3-way calling) IDLE Press and hold the button for PWR On. Press and hold the button in standby screen for PWR Off. CALL Used to end a call. End MENU Unconditional return to the initial menu. IDLE If pressing ‘CLR’ upon number input, number is erased one by one. Pres and hold the button to erase inputted numbers all at one time and return to idle mode. CALL Busy muting function. CLR MENU Cancels corresponding menu and function and returns to th…

Text truncated - open the document above for the full version.

Cover Letter(s)

Engineering and Testing for EMC and Safety Compliance 360 Herndon Parkway, Suite 1400 Herndon, VA 20170 Phone: 703-689-0368; Fax: 703-689-2056; Metro: 703-471-6441 Date Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 and/or American TCB 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Confidential Letter To Whom It May Concern: The following information is to be held confidential pursuant of 47 CFR Part 0 §0.457 and Section 552(b)(4) of the Freedom of Information Act, because the information provided contains trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. • Schematics • Product Description • Block Diagram • Bill of Materials (Parts List Best Regards, Melissa Carter [email protected] Rhein Tech Laboratories, Inc.

External Photos

ID Label/Location Info

Internal Photos

360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com FCC Certification Report FCC ID: POQWPE-1000 2001118 / QRTL01-091 WITHUS INFORMATION & TELECOMMUNICATION, CO. LTD. Page 26 APPENDIX E: INTERNAL PHOTOGRAPHS PHOTOGRAPH 5: LCD BOARD FRONT WITH CIRCUITS FOLDED DOWN 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com FCC Certification Report FCC ID: POQWPE-1000 2001118 / QRTL01-091 WITHUS INFORMATION & TELECOMMUNICATION, CO. LTD. Page 27 PHOTOGRAPH 6: LCD BOARD FRONT WITH LCD CIRCUITS FOLDED UP 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com FCC Certification Report FCC ID: POQWPE-1000 2001118 / QRTL01-091 WITHUS INFORMATION & TELECOMMUNICATION, CO. LTD. Page 28 PHOTOGRAPH 7: LCD BOARD REAR WITH SHIELDS 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com FCC Certification Report FCC ID: POQWPE-1000 2001118 / QRTL01-091 WITHUS INFORMATION & TELECOMMUNICATION, CO. LTD. Page 29 PHOTOGRAPH 8: LCD BOARD WITH OUT SHIELDS.JPEG LCD BOARD WITH OUT SHIELDS 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com FCC Certification Report FCC ID: POQWPE-1000 2001118 / QRTL01-091 WITHUS INFORMATION & TELECOMMUNICATION, CO. LTD. Page 30 PHOTOGRAPH 9: KEYBOARD FRONT 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com FCC Certification Report FCC ID: POQWPE-1000 2001118 / QRTL01-091 WITHUS INFORMATION & TELECOMMUNICATION, CO. LTD. Page 31 PHOTOGRAPH 10: KEYBOARD REAR 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com FCC Certification Report FCC ID: POQWPE-1000 2001118 / QRTL01-091 WITHUS INFORMATION & TELECOMMUNICATION, CO. LTD. Page 32 PHOTOGRAPH 11: REAR COVER INSIDE

RF Exposure Info

CELLTECH RESEARCH INC. Test Report S/N: 050701-106POQ 1955 Moss Court, Kelowna Date(s) of Tests: May 24, 2001 B.C. Canada V1Y 9L3 FCC Part 24/SAR Certification _________________________________________________________________________________________________________ © 2001 Celltech Research Inc. CERTIFICATE OF COMPLIANCE SAR EVALUATION This wireless portable device has been shown to be compliant for localized Specific Absorption Rate (SAR) for uncontrolled environment/general exposure limits specified in ANSI/IEEE Std. C95.1-1992 and has been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1999. I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Celltech Research Inc. certifies that no party to this application has been denied FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Shawn McMillen General Manager Celltech Research Inc. Test Lab: CELLTECH RESEARCH INC. Testing and Engineering Lab 1955 Moss Court Kelowna, B.C. Canada V1Y 9L3 Phone: 250 - 860-3130 Fax: 250 - 860-3110 Toll Free: 1-877-545-6287 e-mail: [email protected] web site: www.celltechlabs.com Applicant Information: WITHUS IT CO., LTD. 2F. DongNam Bldg. 448-16 Shingil-5Dong, YongDungPo-Ku, Seoul, Korea Contact: Mr. David Oh FCC ID: POQ-WPE-1000 Model(s): WPE-1000 Equipment Type: Single-Mode PCS CDMA Phone Classification: Part 24 Licensed Portable Transmitter Held to Ear (PCE) Tx Frequency Range: 1851.25 - 1908.75 MHz Max. RF Output Power: 24.5 dBm (Conducted) FCC Rule Part(s): 2.1093; ET Docket 96.326 CELLTECH RESEARCH INC. Test Report S/N: 050701-106POQ 1955 Moss Court, Kelowna Date(s) of Tests: May 24, 2001 B.C. Canada V1Y 9L3 FCC Part 24/SAR Certification _________________________________________________________________________________________________________ © 2001 Celltech Research Inc. TABLE OF CONTENTS 1.0 INTRODUCTION.................................................................. 1 2.0 DESCRIPTION OF EUT.......................................................... 1 3.0 SAR MEASUREMENT SYSTEM ............................................. 2 4.0 MEASUREMENT SUMMARY.................................................. 3-4 5.0 SAR LIMITS........................................................................ 5 6.0 DETAILS OF SAR EVALUATION........................................... 5 7.0 EVALUATION PROCEDURES................................................. 6 8.0 SYSTEM VALIDATION.......................................................... 6 9.0 SIMULATED EQUIVALENT TISSUES...................................... 7 10.0 TISSUE PARAMETERS......................................................... 7 11.0 SYSTEM SPECIFICATIONS.................................................... 8 12.0 TEST EQUIPMENT LIST........................................................ 9 13.0 MEASUREMENT UNCERTAINTIES........................................ 10 14.0 REFERENCES...................................................................... 11 APPENDIX A - SAR MEASUREMENT DATA........................................ 12 APPENDIX B - DIPOLE VALIDATION................................................ 13 APPENDIX C - PROBE CALIBRATION............................................... 14 APPENDIX D - SAR TEST SETUP PHOTOGRAPHS.............................. 15 CELLTECH RESEARCH INC. Test Report S/N: 050701-106POQ 1955 Moss Court, Kelowna Date(s) of Tests: May 24, 2001 B.C. Canada V1Y 9L3 FCC Part 24/SAR Certification _________________________________________________________________________________________________________ © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQ-WPE-1000 1 Single-Mode PCS CDMA Phone (1851.25-1908.75MHz) 1.0 INTRODUCTION This measurement report shows compliance of the WITHUS IT CO., LTD. Model: WPE-1000 Single-Mode PCS CDMA Phone FCC ID: POQ-WPE-1000 with FCC Part 2.1093, ET Docket 96-326 Rules for mobile and portable devices. The test procedures, as described in American National Standards Institute C95.1-1992 (1), FCC OET Bulletin 65-1997 were employed. A description of the product and operating configuration, detailed summary of the test results, methodology and procedures used in the evaluation, equipment used, and the various provisions of the rules are included within this test report. 2.0 DESCRIPTION of Equipment Under Test (EUT) Left Profile Front Profile Right Profile Rear Profile EUT Type Single-Mode PCS CDMA Phone FCC ID POQ-WPE-1000 Equipment Class Part 24 Licensed Portable Transmitter Held to Ear (PCE) Model No.(s) WPE-1000 FCC Rule Part(s) § 2.1093, Docket 96-326 Application Type Part 24 Certification Tx Frequency Range 1851.25-1908.75 MHz S/N No. Pre-production Rx Frequency Range 1931.25-1988.75 MHz Max. RF Output Power 24.5 dBm (Conducted) Modulation CDMA Battery Type(s) 3.7V Lithium Ion Battery Antenna Type Whip Antenna Length 68 mm CELLTECH RESEARCH INC. Test Report S/N: 050701-106POQ 1955 Moss Court, Kelowna Date(s) of Tests: May 24, 2001 B.C. Canada V1Y 9L3 FCC Part 24/SAR Certification _________________________________________________________________________________________________________ © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQ-WPE-1000 2 Single-Mode PCS CDMA Phone (1851.25-1908.75MHz) 3.0 SAR MEASUREMENT SYSTEM Celltech Research SAR measurement facility utilizes the Dosimetric Assessment System (DASY™) manufactured by Schmid & Partner Engineering AG (SPEAG™) of Zurich, Switzerland. The DASY system is comprised of the robot controller, computer, near-field probe, probe alignment sensor, and the generic twin phantom containing brain or muscle equivalent material. The robot is a six-axis industrial robot performing precise movements to position the probe to the locati…

Text truncated - open the document above for the full version.

Test Report

Engineering and Testing for EMC and Safety Compliance 360 Herndon Parkway, Suite 1400 Herndon, VA 20170 Phone: 703-689-0368; Fax: 703-689-2056; Metro: 703-471-6441 TYPE CERTIFICATION REPORT Withus Information & Telecommunication, CO. LTD. 2F. DongNam Bldg. 448-16 Shingil-5Dong, YongDungPo-Ku Seoul Korea Phone: +82-2-868-7013 Fax: +82-2-847-9992 Mr. David Oh MODEL: WPE-1000 FCC ID: POQWPE-1000 June 6, 2001 STANDARDS REFERENCED FOR THIS REPORT PART 2: 1999 FREQUENCY ALLOCATIONS AND RADIO TREATY MATTERS; GENERAL RULES AND REGULATIONS PART 15: 1999 §15.109: RADIATED EMISSIONS LIMITS PART 24 (E): 1998 PERSONAL COMMUNICATIONS SERVICES – BROADBAND PCS ANSI C63.4-1992 STANDARD FORMAT MEASUREMENT/TECHNICAL REPORT PERSONAL COMPUTER AND PERIPHERALS ANSI/TIA/EIA603- 1992 LAND MOBILE FM OR PM COMMUNICATIONS EQUIPMENT MEASUREMENT AND PERFORMANCE STANDARDS ANSI/TIA/EIA 603-1-1998 ADDENDUM TO ANSI/TIA/EIA 603-1992 RSS-118: Issue 2 Aug. 19, 1990, Supplement 1993-1 June 12, 1993, Amendment Issue 2 Aug. 24, 1996, Addendum Sept. 1, 1990 LAND AND SUBSCRIBER STATIONS: VOICE, DATA AND TONE MODULATED, ANGLE MODULATION RADIOTELEPHONE TRANSMITTERS AND RECEIVERS OPERATING IN THE CELLULAR MOBILE BANDS 824-849 MHz AND 869-894 MHz FCC Rules Parts Frequency Range Output Power (W) Freq. Tolerance Emission Designator 24(E) 1850-1910 MHz 0.815 EIRP 5 ppm 1M6F9W Industry Canada Frequency Range Output Power (W) Freq. Tolerance Emission Designator 24(E) 1850-1910 MHz 0.815 EIRP 5 ppm 1M6F9W REPORT PREPARED BY: EMI Technician: Daniel Baltzell Administrative Writer: Melissa Fleming Document Number: 2001118 No part of this report may be reproduced without the full written approval of Rhein Tech Laboratories, Inc. 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com FCC Certification Report FCC ID: POQWPE-1000 2001118 / QRTL01-091 WITHUS INFORMATION & TELECOMMUNICATION, CO. LTD. Page 2 TABLE OF CONTENTS 1 GENERAL INFORMATION.............................................................................................................................................4 1.1 TEST FACILITY.............................................................................................................................................................................................................4 1.2 RELATED SUBMITTAL(S)/GRANT(S).....................................................................................................................................................................4 1.3 FIELD STRENGTH CALCULATION..........................................................................................................................................................................5 2 CONFORMANCE STATEMENT..............................................................................................................................................6 3 TESTED SYSTEM DETAILS..................................................................................................................................................7 4 PART 2.1046 (A) RF POWER OUTPUT: RADIATED – EIRP PART 24.232................................................................................8 4.1 TEST PROCEDURE.....................................................................................................................................................................................................8 4.2 TEST DATA....................................................................................................................................................................................................................9 5 PART 24.229 AND PART 24.238 - BAND-EDGE COMPLIANCE........................................................................................10 5.1 TEST DATA.................................................................................................................................................................................................................10 6 FCC PART 2 §2.1053 (A): FIELD STRENGTH OF SPURIOUS RADIATION – PART 24.238............................................................12 6.1 TEST PROCEDURE..................................................................................................................................................................................................12 6.2 TEST DATA.................................................................................................................................................................................................................12 7 FCC RULES AND REGULATIONS PART 2 §2.1049 (C) (1): OCCUPIED BANDWIDTH – PART 24.238............................................15 7.1 `TEST PROCEDURE.................................................................................................................................................................................................15 7.2 TEST DATA.................................................................................................................................................................................................................15 8 FCC RULES AND REGULATION PART 2 §2.1055: FREQUENCY STABILITY – PART 24.235........................................................18 8.1 TEST PROCEDURE..................................................................................................................................................................................................18 9 FCC RULES AND REGULATIONS PART 2.202: NECESSARY BANDWIDTH AND EMISSION BANDWIDTH.........................................18 9.1 TEST DATA.................................................................................................................................................................................................................19 TABLE OF TABLES TABLE 3-1: EQUIPMENT UNDER TEST (EUT)...............................................................................................…

Text truncated - open the document above for the full version.

Test Report

6 FCC RULES AND REGULATIONS PART 2 §2.1053 (A): FIELD STRENGTH OF SPURIOUS RADIATION 6.1 TEST PROCEDURE ANSI/TIA/EIA-603-1992, section 2.2.12 The transmitter is terminated with a 50 Ω load and is modulated with a 2,500 Hz sine wave at an input level 16 dB greater than that required to produce 50% of the rated system deviation at 1000 Hz. Refer to section “Radiated Measurement” in this report for further information. 6.2 TEST DATA The worst-case emissions test data are shown. The magnitude of emissions attenuated more than 20 dB below the FCC limit need not be recorded. Radiated Emissions (Channel 25 at 1851.25 MHz) Substitution Method (limit = 42.1 dBc) Frequency (MHz) S/G level (dBm) Correction Factor (dB)* ERP (dBc) Margin 3702.50 -51.9 2.4 78.6 36.5 5553.75 -34.6 3.6 60.1 18.0 7405.00 NF 9256.25 NF 11107.50 NF 12958.75 NF 14810.00 NF 15551.25 NF 18512.50 NF *This insertion loss corresponds to the cable connecting the RF Signal Generator and the respective correction to a ½ wave dipole antenna. NF= Noise floor of spectrum analyzer 6.3 TEST EQUIPMENT Antenna: CHASE CBL6112 s/n 2099 Amplifier: HP8449B s/n 3008A00505 Spectrum analyzer: HP8564E s/n 3943A01719 RF Signal Generator HP8648C s/n 3537A01741 Synthesized Sweeper HP83752A s/n 3610A00846

Test Report

6 FCC RULES AND REGULATIONS PART 2 §2.1053 (A): FIELD STRENGTH OF SPURIOUS RADIATION 6.1 TEST PROCEDURE ANSI/TIA/EIA-603-1992, section 2.2.12 The transmitter is set in continuous transmitting mode and modulated with pseudo random data using the internal software. Refer to section “Radiated Measurement” in this report for further information. 6.2 TEST DATA The worst-case emissions test data are shown. The magnitude of emissions attenuated more than 20 dB below the FCC limit need not be recorded. Radiated Emissions (Channel 25 at 1851.25 MHz) Substitution Method (limit = 42.1 dBc) Frequency (MHz) S/G level (dBm) Correction Factor (dB)* EIRP (dBc) Margin 3702.50 -51.9 4.6 76.4 34.3 5553.75 -34.6 5.8 57.9 15.8 7405.00 NF 9256.25 NF 11107.50 NF 12958.75 NF 14810.00 NF 15551.25 NF 18512.50 NF *This insertion loss corresponds to the cable connecting the RF Signal Generator and the respective correction to a ½ wave dipole antenna. NF= Noise floor of spectrum analyzer 6.3 TEST EQUIPMENT Antenna: CHASE CBL6112 s/n 2099 Amplifier: HP8449B s/n 3008A00505 Spectrum analyzer: HP8564E s/n 3943A01719 RF Signal Generator HP8648C s/n 3537A01741 Synthesized Sweeper HP83752A s/n 3610A00846

Test Setup Photos
