POQWPE-2000Dual Band CDMA PCS/Cellular Handset

Modottel Co Ltd

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Jan 15, 2002
Application Purpose: Original Equipment
Date of Application: Jan 15, 2002
Equipment Note: Dual Band CDMA PCS/Cellular Handset
Frequency Range: 824.70000000 - 848.31000000
Company: Modottel Co Ltd
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna. Body-worn Operation This device has been tested for body-worn operation and meets FCC RF exposure guidelines when used with an accessory that contains no metal components, and positions the handset at a minimum of 1.5cm from the body. Use of other body-worn accessories may not ensure compliance with FCC RF exposure guidelines and should be avoided. For more information about RF exposure, please visit the FCC website at www.fcc.gov Read this information before using your phone

Cover Letter(s)

Celltech Research Inc. 1955 Moss Court, Kelowna, B.C. Canada V1Y 9L3 Tel. 250-860-3130 •• Fax. 250-860-3110 •• e-mail: [email protected] www.celltechlabs.com January 14, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 SUBJECT: Withus IT Co., Ltd. FCC ID: POQWPE-2000 FCC Parts 24 & 22 Certification Gentlemen: On behalf of Withus IT Co., Ltd. is an application for Parts 24 & 22 Certification of WPE-2000 Dual-Band Cellular/PCS CDMA handset as follows: FCC ID: POQWPE-2000 Model(s): WPE-2000 Equipment Class: Part 24 Licensed Portable Transmitter Held to Ear (PCE) Equipment Type: Dual-Band Cellular & PCS CDMA Handset Tx Freq. Range: 1851.25 - 1908.75 MHz (PCS CDMA) 824.70 - 848.31 MHz (Cellular CDMA) Max. RF Output Power: 0.267 Watts EIRP (PCS CDMA) 0.243 Watts ERP (Cellular CDMA) Emission Designator: 1M25F9W Attached is the Authorization Letter, Confidentiality Request, ESN Affidavit, Parts 24 & 22 measurement report test data and photographs, SAR RF exposure measurement report test data and photographs, FCC ID label and location, internal and external photographs, block diagrams (confidential), circuit diagrams (confidential), circuit description (confidential), parts list (confidential), tune-up procedure (confidential), antenna specifications (confidential), operational description (confidential), and the user's manual. If you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Shawn McMillen General Manager Celltech Research Inc. Testing & Engineering Lab cc: Withus IT Co., Ltd.

External Photos

ID Label/Location Info

Internal Photos

CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQWPE-2000 Dual-Band Cellular/PCS CDMA Phone (800MHz/1900MHz) INTERNAL EUT PHOTOGRAPHS CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQWPE-2000 Dual-Band Cellular/PCS CDMA Phone (800MHz/1900MHz) INTERNAL EUT PHOTOGRAPHS CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQWPE-2000 Dual-Band Cellular/PCS CDMA Phone (800MHz/1900MHz) INTERNAL EUT PHOTOGRAPHS CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQWPE-2000 Dual-Band Cellular/PCS CDMA Phone (800MHz/1900MHz) INTERNAL EUT PHOTOGRAPHS CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQWPE-2000 Dual-Band Cellular/PCS CDMA Phone (800MHz/1900MHz) INTERNAL EUT PHOTOGRAPHS CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQWPE-2000 Dual-Band Cellular/PCS CDMA Phone (800MHz/1900MHz) INTERNAL EUT PHOTOGRAPHS CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQWPE-2000 Dual-Band Cellular/PCS CDMA Phone (800MHz/1900MHz) INTERNAL EUT PHOTOGRAPHS

RF Exposure Info

CELLTECH RESEARCH INC. Test Report S/N: 111601-182POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 22-23, 2001 B.C. Canada V1Y 9L3 FCC SAR Evaluation _________________________________________________________________________________________________________ © 2001 Celltech Research Inc. CERTIFICATE OF COMPLIANCE SAR EVALUATION Celltech Research Inc. declares under its sole responsibility that this device was found to be in compliance with the Specific Absorption Rate (SAR) RF exposure requirements specified in OET Bulletin 65, Supplement C, Edition 01-01 (General Population/Uncontrolled Exposure), and was tested in accordance with the appropriate measurement standards, guidelines, and recommended practices specified in American National Standards Institute C95.1-1992. I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. This test report shall not be reproduced partially, or in full, without the prior written approval of Celltech Research Inc. The results and statements contained in this report pertain only to the device(s) evaluated. Shawn McMillen General Manager Celltech Research Inc. Test Lab: CELLTECH RESEARCH INC. Testing and Engineering Lab 1955 Moss Court Kelowna, B.C. Canada V1Y 9L3 Phone: 250 - 860-3130 Fax: 250 - 860-3110 Toll Free: 1-877-545-6287 e-mail: [email protected] web site: www.celtechlabs.com Applicant Information: WITHUS IT CO., LTD. 2F. DongNam Bldg. 448-16 Shingil-5Dong, YongDungPo-Ku, Seoul, Korea FCC ID: POQWPE-2000 Model(s): WPE-2000 Equipment Type: Dual-Band Cellular/PCS CDMA Phone Classification: Part 24 Licensed Portable Transmitter Held to Ear (PCE) Tx Frequency Range: 1851.25 - 1908.75 MHz (PCS CDMA) 824.70 - 848.31 MHz (Cellular CDMA) Rx Frequency Range: 1931.25 - 1988.75 MHz (PCS CDMA) 869.70 - 893.31 MHz (Cellular CDMA) Max. RF Output Power: 0.267 Watts EIRP (PCS CDMA) 0.243 Watts ERP (Cellular CDMA) FCC Rule Part(s): 2.1093; ET Docket 96.326 CELLTECH RESEARCH INC. Test Report S/N: 111601-182POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 22-23, 2001 B.C. Canada V1Y 9L3 FCC SAR Evaluation _________________________________________________________________________________________________________ © 2001 Celltech Research Inc. TABLE OF CONTENTS 1.0 INTRODUCTION.................................................................. 1 2.0 DESCRIPTION OF EUT.......................................................... 1 3.0 SAR MEASUREMENT SYSTEM ............................................. 2 4.0 MEASUREMENT SUMMARY.................................................. 3-8 5.0 DETAILS OF SAR EVALUATION........................................... 9-10 6.0 EVALUATION PROCEDURES................................................. 11-12 7.0 SAR LIMITS........................................................................ 13 8.0 SYSTEM VALIDATION.......................................................... 13 9.0 TISSUE PARAMETERS......................................................... 14 10.0 SIMULATED EQUIVALENT TISSUES...................................... 15 11.0 SYSTEM SPECIFICATIONS.................................................... 16 12.0 SAM PHANTOM.................................................................... 17 13.0 DEVICE HOLDER................................................................. 17 14.0 PROBE SPECIFICATION....................................................... 17 15.0 TEST EQUIPMENT LIST........................................................ 18 16.0 MEASUREMENT UNCERTAINTIES........................................ 19 17.0 REFERENCES...................................................................... 20 APPENDIX A - SAR MEASUREMENT DATA........................................ 21 APPENDIX B - DIPOLE VALIDATION................................................ 22 APPENDIX C - PROBE CALIBRATION............................................... 23 APPENDIX D - MEASURED TISSUE DIELECTRIC PARAMETERS......... 24 APPENDIX E - SAR TEST SETUP PHOTOGRAPHS.............................. 25 CELLTECH RESEARCH INC. Test Report S/N: 111601-182POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 22-23, 2001 B.C. Canada V1Y 9L3 FCC SAR Evaluation _________________________________________________________________________________________________________ © 2001 Celltech Research Inc. Withus IT Co., Ltd. FCC ID: POQWPE-2000 1 Dual-Band Cellular/PCS CDMA Phone (800MHz/1900MHz) 1.0 INTRODUCTION This measurement report shows that the WITHUS IT CO., LTD. Model: WPE-2000 Dual-Band Cellular/PCS CDMA Phone FCC ID: POQWPE-2000 complies with FCC Part 2.1093, ET Docket 96-326 Rules for mobile and portable devices. The test procedures, as described in American National Standards Institute C95.1-1992 (see reference [1]), and FCC OET Bulletin 65, Supplement C, Edition 01-01 (see reference [2]) were employed. A description of the product and operating configuration, detailed summary of the test results, methodology and procedures used in the evaluation, equipment used, and the various provisions of the rules are included within this test report. 2.0 DESCRIPTION of Equipment Under Test (EUT) EUT Type Dual-Band Cellular/PCS CDMA Phone FCC ID POQWPE-2000 Equipment Class Part 24 Licensed Portable Transmitter Held to Ear (PCE) Model No.(s) WPE-2000 FCC Rule Part(s) § 2.1093, Docket 96-326 Application Type FCC Part 24 Certification Tx Frequency Range (MHz) 1851.25-1908.75 (PCS CDMA) 824.70-848.31 (Cellular CDMA) Serial No. Pre-production Unit Rx Frequency Range (MHz) 1931.25-1988.75 (PCS CDMA) 869.70-893.31 (Cellular CDMA) Battery Type(s) 3.7V 950mA/h Lithium-Ion Battery Max. RF Output Power 0.267 W EIRP (PCS CDMA) 0.243 W ERP (Cellular CDMA) Antenna Type Retractable Whip (1/4λ) Modulation(s) PCS CDMA Cellular CDMA Antenna Length 113 mm CELLTECH RESEARCH IN…

Text truncated - open the document above for the full version.

RF Exposure Info

1900MHz PCS CDMA SAR TEST PLOTS – BODY Withus IT Co., Ltd. FCC ID: POQWPE-2000 SAM Phantom; Flat Section; Position: (270°,270°) Probe: ET3DV6 - SN1590; ConvF(5.36,5.36,5.36); Crest factor: 1.0 1800 MHz Muscle: σ = 1.52 mho/m ε r = 53.4 ρ = 1.00 g/cm 3 Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Cube 5x5x7 Powerdrift: -0.05 dB SAR (1g): 0.326 mW/g, SAR (10g): 0.193 mW/g Body-Worn SAR at 1.5 cm Separation Distance Antenna In Withus Model: WPE-2000 PCS CDMA Mode Channel 25 [1851.25 MHz] Conducted Power: 24.53 dBm Date Tested: Nov. 23, 2001 SAR Tot [mW/g] 2.36E-2 9.46E-2 1.66E-1 2.36E-1 3.07E-1 Celltech Research Inc. Celltech Research Inc. Withus IT Co., Ltd. FCC ID: POQWPE-2000 SAM Phantom; Flat Section; Position: (270°,270°) Probe: ET3DV6 - SN1590; ConvF(5.36,5.36,5.36); Crest factor: 1.0 1800 MHz Muscle: σ = 1.52 mho/m ε r = 53.4 ρ = 1.00 g/cm 3 Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Cube 5x5x7 Powerdrift: -0.20 dB SAR (1g): 0.331 mW/g, SAR (10g): 0.197 mW/g Body SAR at 1.5 cm Separation Distance Antenna Out Withus Model: WPE-2000 PCS CDMA Mode Channel 25 [1851.25 MHz] Conducted Power: 24.50 dBm Date Tested: Nov. 23, 2001 SAR Tot [mW/g] 2.59E-2 1.03E-1 1.81E-1 2.59E-1 3.36E-1 Celltech Research Inc. Celltech Research Inc. Withus IT Co., Ltd. FCC ID: POQWPE-2000 SAM Phantom; Flat Section; Position: (270°,270°) Probe: ET3DV6 - SN1590; ConvF(5.36,5.36,5.36); Crest factor: 1.0 1800 MHz Muscle: σ = 1.52 mho/m ε r = 53.4 ρ = 1.00 g/cm 3 Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Cube 5x5x7 Powerdrift: -0.17 dB SAR (1g): 0.252 mW/g, SAR (10g): 0.149 mW/g Body-Worn SAR at 1.5 cm Separation Distance Antenna In Withus Model: WPE-2000 PCS CDMA Mode Channel 600 [1880.00 MHz] Conducted Power: 24.53 dBm Date Tested: Nov. 23, 2001 SAR Tot [mW/g] 1.99E-2 7.97E-2 1.40E-1 1.99E-1 2.59E-1 Celltech Research Inc. Celltech Research Inc. Withus IT Co., Ltd. FCC ID: POQWPE-2000 SAM Phantom; Flat Section; Position: (270°,270°) Probe: ET3DV6 - SN1590; ConvF(5.36,5.36,5.36); Crest factor: 1.0 1800 MHz Muscle: σ = 1.52 mho/m ε r = 53.4 ρ = 1.00 g/cm 3 Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Cube 5x5x7 Powerdrift: -0.18 dB SAR (1g): 0.586 mW/g, SAR (10g): 0.345 mW/g Body SAR at 1.5 cm Separation Distance Antenna Out Withus Model: WPE-2000 PCS CDMA Mode Channel 600 [1880.00 MHz] Conducted Power: 24.50 dBm Date Tested: Nov. 23, 2001 SAR Tot [mW/g] 4.54E-2 1.82E-1 3.18E-1 4.54E-1 5.91E-1 Celltech Research Inc. Celltech Research Inc. Withus IT Co., Ltd. FCC ID: POQWPE-2000 SAM Phantom; Flat Section; Position: (270°,270°) Probe: ET3DV6 - SN1590; ConvF(5.36,5.36,5.36); Crest factor: 1.0 1800 MHz Muscle: σ = 1.52 mho/m ε r = 53.4 ρ = 1.00 g/cm 3 Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Cube 5x5x7 Powerdrift: -0.15 dB SAR (1g): 0.273 mW/g, SAR (10g): 0.149 mW/g Body-Worn SAR at 1.5 cm Separation Distance Antenna In Withus Model: WPE-2000 PCS CDMA Mode Channel 1175 [1908.75 MHz] Conducted Power: 24.50 dBm Date Tested: Nov. 23, 2001 SAR Tot [mW/g] 2.07E-2 8.29E-2 1.45E-1 2.07E-1 2.69E-1 Celltech Research Inc. Celltech Research Inc. Withus IT Co., Ltd. FCC ID: POQWPE-2000 SAM Phantom; Flat Section; Position: (270°,270°) Probe: ET3DV6 - SN1590; ConvF(5.36,5.36,5.36); Crest factor: 1.0 1800 MHz Muscle: σ = 1.52 mho/m ε r = 53.4 ρ = 1.00 g/cm 3 Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Cube 5x5x7 Powerdrift: -0.11 dB SAR (1g): 0.318 mW/g, SAR (10g): 0.188 mW/g Body SAR at 1.5 cm Separation Distance Antenna Out Withus Model: WPE-2000 PCS CDMA Mode Channel 1175 [1908.75 MHz] Conducted Power: 24.50 dBm Date Tested: Nov. 23, 2001 SAR Tot [mW/g] 2.31E-2 9.23E-2 1.62E-1 2.31E-1 3.00E-1 Celltech Research Inc. Celltech Research Inc. 800MHz CELLULAR CDMA SAR TEST PLOTS – BODY Withus IT Co., Ltd. FCC ID: POQWPE-2000 SAM Phantom; Flat Section; Position: (270°,270°) Probe: ET3DV6 - SN1590; ConvF(6.70,6.70,6.70); Crest factor: 1.0 835 MHz Muscle: σ = 0.97 mho/m ε r = 55.1 ρ = 1.00 g/cm 3 Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Cube 5x5x7 Powerdrift: 0.13 dB SAR (1g): 0.617 mW/g, SAR (10g): 0.421 mW/g Body-Worn SAR at 1.5 cm Separation Distance Antenna In Withus Model: WPE-2000 CDMA Mode Channel 1013 [824.70 MHz] Conducted Power: 24.05 dBm Date Tested: Nov. 23, 2001 SAR Tot [mW/g] 4.74E-2 1.90E-1 3.32E-1 4.74E-1 6.17E-1 Celltech Research Inc. Celltech Research Inc. Withus IT Co., Ltd. FCC ID: POQWPE-2000 SAM Phantom; Flat Section; Position: (270°,270°) Probe: ET3DV6 - SN1590; ConvF(6.70,6.70,6.70); Crest factor: 1.0 835 MHz Muscle: σ = 0.97 mho/m ε r = 55.1 ρ = 1.00 g/cm 3 Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Cube 5x5x7 Powerdrift: 0.11 dB SAR (1g): 1.10 mW/g, SAR (10g): 0.759 mW/g Body-Worn SAR at 1.5 cm Separation Distance Antenna Out Withus Model: WPE-2000 CDMA Mode Channel 1013 [824.70 MHz] Conducted Power: 24.05 dBm Date Tested: Nov. 23, 2001 SAR Tot [mW/g] 8.28E-2 3.31E-1 5.80E-1 8.28E-1 1.08E+0 Celltech Research Inc. Celltech Research Inc. Withus IT Co., Ltd. FCC ID: POQWPE-2000 SAM Phantom; Flat Section; Position: (270°,270°) Probe: ET3DV6 - SN1590; ConvF(6.70,6.70,6.70); Crest factor: 1.0 835 MHz Muscle: σ = 0.97 mho/m ε r = 55.1 ρ = 1.00 g/cm 3 Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Cube 5x5x7 Powerdrift: -0.05 dB SAR (1g): 0.706 mW/g, SAR (10g): 0.479 mW/g Body-Worn SAR at 1.5 cm Separation Distance Antenna In Withus Model: WPE-2000 CDMA Mode Channel 363 [835.89 MHz] Conducted Power: 24.05 dBm Date Tested: Nov. 23, 2001 SAR Tot [mW/g] 5.40E-2 2.16E-1 3.78E-1 5.40E-1 7.02E-1 Celltech Research Inc. Celltech Research Inc. Withus IT Co., Ltd. FCC ID: POQWPE-2000 SAM Phantom; Flat Section; Position: (270°,270°) Probe: ET3DV6 - SN1590; ConvF(6.70,6.70,6.70); Crest factor: 1.0 835 MHz Muscle: σ = 0.97 mho/m ε r = 55.1 ρ = 1.00 g/cm 3 Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Cube 5x5x7 Powerdrift: -0.07 dB SAR (1g): 1.26 mW/g, SAR (10g): 0.856 mW/g Body-Worn SAR at 1.5 cm Separation Distance Antenna Out Withus Model: WPE-2000 CDMA Mode Channel 363 [835.89 MHz] Conducted Power: 24.07 dBm Date Tested: Nov. 23, 2001 SAR Tot [mW/g] 9.36E-2 3.75E-1 6.55…

Text truncated - open the document above for the full version.

RF Exposure Info

Test Report

CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification _________________________________________________________________________________________________________________ © 2001 Celltech Research Inc. CERTIFICATE OF COMPLIANCE FCC PARTS 24(E) & 22.901(d) CERTIFICATION This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. This test report shall not be reproduced partially, or in full, without the prior written approval of Celltech Research Inc. The results and statements contained in this report pertain only to the device(s) evaluated. Shawn McMillen General Manager Celltech Research Inc. Test Lab: CELLTECH RESEARCH INC. Testing and Engineering Services 1955 Moss Court Kelowna, B.C. Canada V1Y 9L3 Phone: 250 - 860-3130 Fax: 250 - 860-3110 Toll Free: 1-877-545-6287 e-mail: [email protected] web site: www.celltechlabs.com Applicant Information: WITHUS IT CO., LTD. 2F. DongNam Bldg. 448-16 Shingil-5Dong, YongDungPo-Ku, Seoul, Korea FCC Classification: Part 24 Licensed Portable Transmitter Held to Ear (PCE) FCC Rule Part(s): §24(E), §22.901(d), §2 FCC ID: POQWPE-2000 Model(s): WPE-2000 Equipment Type: Dual-Band Cellular/PCS CDMA Phone Tx Frequency Range: 1851.25 - 1908.75 MHz (PCS CDMA) 824.70 - 848.31 MHz (Cellular CDMA) Rx Frequency Range: 1931.25 - 1988.75 MHz (PCS CDMA) 869.70 - 893.31 MHz (Cellular CDMA) Max. RF Output Power: 0.267 Watts EIRP (PCS CDMA) 0.243 Watts ERP (Cellular CDMA) Frequency Tolerance(s): 150 Hz (PCS CDMA), 300 Hz (Cellular CDMA) Emission Designator(s): 1M25F9W CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification _________________________________________________________________________________________________________ © 2001 Celltech Research Inc. TABLE OF CONTENTS 1.1 SCOPE 1 1.2 GENERAL INFORMATION (2.1033(a)) 1 2.1 MEASUREMENT PROCEDURES 2 RF Output Power (2.1046) 2 Occupied Bandwidth (2.1049(c)) 2 Occupied Bandwidth (24.238) 2 Spurious Emissions at Antenna Terminal (2.1051) 3 Field Strength of Spurious Emissions (2.1053) 3 Radiated Measurement Test Setup Photographs 4 Frequency Stability/Temperature Variation (2.1055, 24.235) 5 Emission Designator (2.202) 5 3.1 TEST DATA 6 Effective Isotropic Radiated Power Output (24.232(b)) 6 Effective Radiated Power Output (2.1046) 7 Field Strength of Spurious Radiation (2.1053) 8-13 Frequency Stability (24.235) 14 Frequency Stability (2.1055) 15 4.1 TEST EQUIPMENT 16 5.1 CONCLUSION 17 CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification _________________________________________________________________________________________________________ © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQWPE-2000 1 Dual-Band Cellular/PCS CDMA Phone (800MHz/1900MHz) APPLICANT: WITHUS IT CO., LTD. 2F. DongNam Bldg. 448-16 Shingil-5Dong, YongDungPo-Ku, Seoul, Korea MEASUREMENT REPORT - FCC PARTS 24(E) & 22.901(d) 1.1 SCOPE Measurement and determination of electromagnetic emissions (EME) from radio frequency devices for compliance with the technical rules and regulations of the Federal Communications Commission. 1.2 GENERAL INFORMATION - §2.1033(a) FCC ID POQWPE-2000 Model(s) WPE-2000 EUT Type Dual-Band Cellular/PCS CDMA Phone Classification Part 24 Licensed Portable Transmitter Held to Ear (PCE) Rule Part(s) §24(E), §22.901(d), §2 Max. RF Output Power 0.267 Watts EIRP (PCS CDMA) 0.243 Watts ERP (Cellular CDMA) Tx Freq. Range(s) 1851.25 - 1908.75 MHz (PCS CDMA) 824.70 - 848.31 MHz (Cellular CDMA) Rx Freq. Range(s) 1931.25 - 1988.75 MHz 869.70 - 893.31 MHz Emission Designator(s) 1M25F9W Modulation(s) PCS CDMA / Cellular CDMA Frequency Tolerance(s) ±± 150 Hz (PCS) / ±± 300 Hz (Cellular) Battery Type(s) 3.7 V 950mA/h Lithium Ion Antenna Type Retractable Whip (1/4λλ) CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification _________________________________________________________________________________________________________ © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQWPE-2000 2 Dual-Band Cellular/PCS CDMA Phone (800MHz/1900MHz) 2.1 MEASUREMENT PROCEDURES 2.2 RF OUTPUT POWER MEASUREMENT - 2.1046 The conducted power was measured using a Gigatronics 8650A Universal Power Meter in modulated average power mode. An offset value in dB was entered into the power meter to correct for the losses of the attenuator and cable installed before the sensor input. The transmitter terminal was coupled to the power meter and the EUT was placed into test mode via keypad access at a full data rate in the “always up” power control mode. All subsequent tests were performed using the same tune up procedures. 2.3 OCCUPIED BANDWIDTH - §2.1049(c) The antenna output terminal of the EUT was connected to the input of a 50Ω spectrum analyzer through a matched 30dB attenuator. The radio transmitter was operating at maximum output power. 100% of the in-band modulation was below the specified mask per §22.917. (a) On any frequency removed from the assigned carrier frequency by more than 20kHz, up to and including 45kHz, the sideband was at least 26dB below the carrier. (b) On any frequency removed from the assigned carrier frequency by more than 45kHz, up to and incl…

Text truncated - open the document above for the full version.

Test Setup Photos

CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQWPE-2000 Dual-Band Cellular/PCS CDMA Phone (800MHz/1900MHz) RADIATED TEST SETUP PHOTOGRAPHS Cellular CDMA CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQWPE-2000 Dual-Band Cellular/PCS CDMA Phone (800MHz/1900MHz) RADIATED TEST SETUP PHOTOGRAPHS Cellular CDMA CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQWPE-2000 Dual-Band Cellular/PCS CDMA Phone (800MHz/1900MHz) RADIATED TEST SETUP PHOTOGRAPHS Cellular CDMA CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQWPE-2000 Dual-Band Cellular/PCS CDMA Phone (800MHz/1900MHz) RADIATED TEST SETUP PHOTOGRAPHS Cellular CDMA CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQWPE-2000 Dual-Band Cellular/PCS CDMA Phone (800MHz/1900MHz) RADIATED TEST SETUP PHOTOGRAPHS PCS CDMA CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQWPE-2000 Dual-Band Cellular/PCS CDMA Phone (800MHz/1900MHz) RADIATED TEST SETUP PHOTOGRAPHS PCS CDMA CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQWPE-2000 Dual-Band Cellular/PCS CDMA Phone (800MHz/1900MHz) RADIATED TEST SETUP PHOTOGRAPHS PCS CDMA CELLTECH RESEARCH INC. Test Report S/N: 111601-181POQ 1955 Moss Court, Kelowna Dates of Tests: Nov. 20-23, 2001 B.C. Canada V1Y 9L3 FCC Part 24/22 Certification © 2001 Celltech Research Inc. WITHUS IT CO., LTD. FCC ID: POQWPE-2000 Dual-Band Cellular/PCS CDMA Phone (800MHz/1900MHz) RADIATED TEST SETUP PHOTOGRAPHS PCS CDMA

Contact Information

Applicant

David Oh(General Manager)

[email protected]82-2-829-7013Fax: 82-2-847-9992

Technical Contact

Celltech Research Inc.Jon Hughes

[email protected]250 860 3130

1955 Moss Court · Kelowna BC · Canada

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	22	824.7 MHz - 848.31 MHz	243.00 mW	1M25F9W	300 Hz

Confidentiality

Long Term

Grant Notes

Power Output is EIRP for PCS band and ERP for Cellular band. SAR compliance for body-worn operating conditions is limited to the specific configuration tested for this filing. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 1.5 cm separation between the device and the user�s body. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR values are: Head: .587W/kg in PCS band; 1.21W/kg in Cellular band; Body- worn: .586W/kg in PCS band; 1.26W/kg in Cellular band. 1.26W/kg
