POUMTP41Wideband bodypack transmitter

MTP41 User Manual Wideband Wireless Professional Pocket Transmitter SN: ________________ Rev.01 (rif. FW 1.11_0D) Date: 10 October 2013 MTP40 E-series INTRODUCTION “MTP41 is an extremely small and light pocket transmitter especially designed for professional wireless microphone applications” Very easy and quick to use thanks to OLED display, dedicated buttons and a joggle selector. MTP41 benefits also of the latest Wisycom RF technology along with an enhanced robustness against noise and inter-modulation. Fig. 1 1. Fig. 2 ❶ Switch to enable wireless transmission it also indicates the battery status and peak/mute operation (with PTT) ❷ LED to show information on RF transmission/battery status/modulation peek/PTT status ❸ Oled display for transmitter setup ❹ <ch>, <gain> and 3 positions <selector> ❺ Battery holder ❻ Cover (to open push side buttons) Turn on wireless: Move the Wireless power switch in “I” position: A green blinking gives you indications on battery status. 1 Open MIC Body: Push the side buttons and flip down the cover, to access internal setup controls and batteries. Turn on display: Push <select switch> and hold it. 2 3 5 6 4 SAFETY INSTRUCTION  Read this safety instruction and the manual first  Follow all instructions and information.  Do not lose this manual.  Do not use this apparatus under the rain or near the water.  Do not install the apparatus near heaters or in hot environments, do not use outside the operating temperature range.  Do not open the apparatus, only qualified service technician are enabled to operate on it. The apparatus needs servicing when it is not properly working or is damaged by liquids, moisture or other objects are fallen in the apparatus.  Use only accessories or replacement parts authorized or specified by the manufacturer.  Clean the apparatus only with dry cloths, do not use liquids.  Report the serial number and the purchasing date in front of the manual. It is needed to have proper replacement parts or accessories from the manufacturer.  When replacement parts are needed, use only replacement parts authorized from the manufacturer. Substitution with not authorized parts could result in electric shock, hazards or fire.  Keep attention on all the labels with warnings or hazards on the apparatus. MTP41 TRANSMITTER FEATURES Led indications Led indication with bi-colour led (red & green) on front ❷: - Wireless transmission status: green when RF transmission power is on. - Battery status: green steady, slowly blinking (< 25%), quickly blinking (<12%). - Modulation peak (if activated): red. - PTT status: red if active (push to talk “pushed”). Batteries MTP41 is working with 1 AA alkaline or NiMH or Lithium battery (select correct type on setup controls). Battery status can be checked on internal OLED display or looking to LED status on front ❷. BATTERY SUBSTITUTION  Open transmitter cover and insert the battery following polarity indicated. A B C D Antennas MTP41 is supplied with a couple of antennas. According to the working band, different antenna models can be supplied. All the models have black cap and a black label with code in white colour. For more details see the below table. In order to help the user to connect the correct antenna, the display shows the antenna code during the switch on of the transmitter and during the tuning selection after a change of frequency range. (ex. if the user changes the frequency from 566 to 672 MHz, the display shows Ant. 732) Powering up Move the wireless power switch (see Fig. 1) in “I” position to activate wireless transmission: the front green LED ❷ lights up (blinking when battery is low!) Setup control Open transmitter Body to access the “display and controls” area (Fig. 3): A. Graphics Display (OLED) B. Channel selection buttons (ch) C. MIC gain setup buttons (gain) D. 3 position selector (up / down / click) Fig. 3 Band Range (MHz) Code 1 470-640 MHz 470-547 507 547-640 590 2 566-798 MHz 566-672 616 672-798 732 3 510-698 MHz 510-595 552 595-698 646 + - CLICK Antenna Code label + - CLICK OLED Power UP (OLED IS IN OFF CONDITION) Pushing down selector (click), oled turns on. A first menu with Serial Number and brand logo is displayed, then <status> menu enters automatically. Turn on the transmitter pushing and holding selector (click) > 2 sec, Serial Number menu is displayed till (-/+) is selected. OLED Power DOWN (OLED IS IN ON CONDITION) Pushing and holding selector (click) > 2 sec, display is turned off. Display turns off automatically after 15 sec, unless in <IRDA> menu or in <AUDIO> menu (with audio level < 5% from nominal). MENU NAVIGATION Setup menu are accessed in sequence: Using <+/-> selector all menus can be accessed in sequence, push <click> to enter edit mode: <+/-> to setup field <click> again to confirm changes and exit. exit without confirmation if no button is pressed after a few seconds time out. <START UP> menu These menus are displayed during power up for few seconds. First one gives information of antenna to be used. The number displayed is the center-band of the antenna to be used. The second menu gives indication on product: - product id (MTP41), - a number which identify the working band STATUS PRESET TUNING CH GR Freq AUDIO AF Gain AUDIO Phase Noise Reduction High Pass Filter RF/BATTERY RF Power Battery LED Led Light Led Mode MIC Mode PTT Mode IRDA Lock 1 470-640 2 566-798 3 510-698 - a number which identify the hardware version - the firmware release (ex. 110.0F), - the band in extended format and - the serial number. Keep selector pushed to hold this menu! <STATUS> menu This is the first menu displayed after power up. Major info are displayed: - Current channel/group (i.e. CH:00 GR:39) - Current frequency (i.e. 566.000 MHz) - Mic gain (i.e. AF: +00dB) and high pass filter (i.e. HP:60 Hz) - “RF 50” or “RF 10” on top right if RF transmission is on at high or low power respectively - On left side, the battery bar is displayed <PRESET> menu This menu can be entered by …

Text truncated - open the document above for the full version.

WISYCOM s.r.l.  Via Spin, 156  I-36060 Romano d’Ezzelino (VI)  Italy Tel. +39 0424 382605  Fax +39 0424 382733  www.wisycom.com  e-mail: [email protected] FCC-ID: POUMTP41 FCC IDENTIFIER Wisycom S.R.L. grants the following rules: - the FCC identifier is placed in the battery compartment and the batteries installed don’t compromise the visibility of the FCC label - the user doesn’t required any special tools for access to the battery compartment - the FCC label isn’t placed on a removable part - the user manual reports clear information where find the FCC label WISYCOM S.R.L. Unipersonale Amministratore Unico Franco Maestrelli

Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Page 1 of 3 EXTERNAL PHOTO Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Page 2 of 3 Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Page 3 of 3

Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Page 1 of 1 INTERNAL PHOTO

Independent Testing Laboratory CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Accredited by Ministry of Communications – Notified Body EMC Directive 2004/108/EC n° NB 2044 Test report R13122601 Rev. 1.0 Order M131226 page 1 of 58 TEST REPORT nr. R13122601 Federal Communication Commission (FCC) Test item Description .................... : Wideband bodypack transmitter Trademark ..................... : WISYCOM Model/Type ................... : MTP 41 Test Specification Standard ........................ : FCC Rules & Regulations, Title 47 - Part 74.861 (2011) Client’s name ............... : WISYCOM SRL Address ......................... : Via Spin,156 – 36060 Romano d'Ezzelino (VI) - Italy Manufacturer’s name . : Same ad client Address ......................... : Report Tested by ....................... : A. Bertezzolo - Technician Approved by .................. : R. Beghetto – Laboratory Manager Date of issue .................. : 22.10.13 Contents ........................ : 58 pages This test report shall not be reproduced except in full without the written approval of CMC. The test results presented in this report relate only to the item tested. CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) Test report R13122601 Rev. 1.0 Order M131226 page 2 of 58 Index 1. SUMMARY ............................................................................................................................................................. 3 2. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ................................................................................. 4 2.1 TEST SITE .............................................................................................................................................................. 4 3. TESTING AND SAMPLING ................................................................................................................................. 5 4. OPERATIVE CONDITIONS................................................................................................................................. 5 5. PHOTOGRAPH(S) OF EUT ................................................................................................................................. 6 6. EQUIPMENT LIST ................................................................................................................................................ 8 7. MEASUREMENT UNCERTAINTY .................................................................................................................... 9 8. REFERENCE DOCUMENTS ............................................................................................................................. 10 9. DEVIATION FROM TEST SPECIFICATION ................................................................................................. 11 10. TEST CASE VERDICTS...................................................................................................................................... 11 11. RESULTS............................................................................................................................................................... 11 11.1 PEAK OUTPUT POWER (CONDUCTED) ............................................................................................................. 12 11.2 FREQUENCY ERROR VS. VOLTAGE ................................................................................................................. 14 11.3 FREQUENCY ERROR VS. TEMPERATURE ......................................................................................................... 17 11.4 CHARACTERISTIC OF THE AUDIO MODULATION CIRCUITRY ........................................................................... 20 11.5 OCCUPIED BANDWIDTH .................................................................................................................................. 22 11.6 ATTENUATION POWER .................................................................................................................................... 23 11.7 RADIATED SPURIOUS (TRANSMITTER) ............................................................................................................ 24 12. GRAPHS AND TABLES ...................................................................................................................................... 28 CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) Test report R13122601 Rev. 1.0 Order M131226 page 3 of 58 1. Summary Standard: FCC Rules & Regulations, Title 47 part 74 Test specifications Environmental Phenomena Tests sequence Result FCC – Title 47 Part 74.861 Peak Output Power 1 Complies FCC – Title 47 Part 74.861 Frequency Error vs. Voltage 2 Complies FCC – Title 47 Part 74.861 Frequency Error vs. Temperature 3 Complies FCC – Title 47 Part 74.861 Characteristic of the Audio Modulation 4 Complies FCC – Title 47 Part 74.861 Occupied Bandwidth 5 Complies FCC – Title 47 Part 74.861 Attenuation Power 6 Complies FCC – Title 47 Part 74.861 Radiated Spurious 7 Complies The Test Report was given to the Client representatives for necessary documentation of ratification of the tested equipment and it is valid for the FCC certification. CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) Test report R13122601 Rev. 1.0 Order M131226 page 4 of 58 2. Description of Equipment under test (EUT) Power supply .......................................................................... : 1,5 Vdc from battery Type of equipment ............................................................... :  Transmitter Unit  Receiver Unit  Fixed station  Portable station  Mobile station Alignment range ..................................................................... : 470 - 608 MHz 614 - 698 MHz Switching frequency .............................…
