PPD-AR5B197AR5B197 2x2 802.11n - BT Combo Card

Atheros Model AR5B197 AR5B197 2x2 802.11n - BT Combo Card March 2010 © 2000–2009 by Atheros Communications, Inc. All rights reserved. Atheros ® , Atheros Driven ® , Atheros XR ® , Driving the Wireless Future ® , ROCm ® , Super AG ® , Super G ® , Total 802.11n ® , and Wake on Wireless ® are registered by Atheros Communications, Inc. Atheros SST™, Signal-Sustain Technology™, the Air is Cleaner at 5-GHz™, XSPAN™, Wireless Future. Unleashed Now.™, and 5-UP™ are trademarks of Atheros Communications, Inc. The Atheros logo is a registered trademark of Atheros Communications, Inc. All other trademarks are the property of their respective holders. Notice The information in this document has been carefully reviewed and is believed to be accurate. Nonetheless, this document is subject to change without notice, and Atheros Communications, Inc. (Atheros) assumes no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update or to keep current the contained information, or to notify a person or organization of any updates. Atheros reserves the right to make changes, at any time, in order to improve reliability, function or design and to attempt to supply the best product possible. Atheros does not represent that products described herein are free from patent infringement or from any other third party right. No part of this document may be reproduced, adapted or transmitted in any form or by any means, electronic or mechanical, for any purpose, except as expressly set forth in a written agreement signed by Atheros. Atheros or its affiliates may have patents or pending patent applications, trademarks, copyrights, maskwork rights or other intellectual property rights that apply to the ideas, material and information expressed herein. No license to such rights is provided except as expressly set forth in a written agreement signed by Atheros. ATHEROS MAKES NO WARRANTIES OF ANY KIND WITH REGARD TO THE CONTENT OF THIS DOCUMENT. IN NO EVENT SHALL ATHEROS BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL SPECULATORY OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBLITY OF SUCH DAMAGES. IN PARTICULAR, ATHEROS SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA TRANSMITTED OR OTHERWISE USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE OR DATA. ATHEROS SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTIES OF MERCHANTIBILITY AND FITNESS FOR A PARTICULAR PURPOSE AS THEY MIGHT OTHERWISE APPLY TO THIS DOCUMENT AND TO THE IDEAS, MATERIAL AND INFORMATION EXPRESSED HEREIN. Atheros Communications, Inc. • 3 COMPANY CONFIDENTIAL June 2010 Document Conventions Text Conventions bold Bold type within paragraph text indicates commands, file names, directory names, paths, output, or returned values. Example: The DK_Client package will not function unless you use the wdreg_install batch file. italic Within commands, italics indicate a variable that the user must specify. Example: mem_alloc size_in_bytes Titles of manuals or other published documents are also set in italics. Courier The Courier font indicates output or display. Example: Error:Unable to allocate memory for transfer! Menu The Menu character tag is used for menu items. Example: Choose Edit > Copy. [ ] Within commands, items enclosed in square brackets are optional parameters or values that the user can choose to specify or omit. { } Within commands, items enclosed in braces are options from which the user must choose. | Within commands, the vertical bar separates options. ... An ellipsis indicates a repetition of the preceding parameter. > The right angle bracket separates successive menu selections. Example: Start > Programs > DK > wdreg_install. Notices NOTE: This message denotes neutral or positive information that calls out important points to the text. A note provides information that may apply only in special cases. 4 • Atheros Communications, Inc. COMPANY CONFIDENTIAL Revision History Revision Description of Changes March 2009 Initial Release Atheros Communications, Inc. • 5 COMPANY CONFIDENTIAL June 2010 Contents Introduction..........................................................................................................7 System Requirements....................................................................................7 Profile Management.............................................................................................7 Create or Modify a Configuration Profile....................................................7 Remove a Configuration Profile...................................................................8 Auto Profile Selection Management....................................................................8 Switching to a Different Configuration Profile..................................................9 Import and Export Profiles...................................................................................9 Importing a Profile................................................................................................9 Exporting a Profile................................................................................................9 TCP/IP Configuration.........................................................................................9 Configuring the TCP/IP Address for the network device:..................................9 General Tab.........................................................................................................10 Advanced Tab.....................................................................................................10 Security Tab........................................................................................................11 Using EAP-TLS Security..............................................................................12 Using EAP-TTLS Security..............…

Text truncated - open the document above for the full version.

Page 1 of 9 Atheros Modular Certification Instructions to OEM Integrators March 2009 © 2000–2009 by Atheros Communications, Inc. All rights reserved. Atheros ® , Atheros Driven ® , Atheros XR ® , Driving the Wireless Future ® , ROCm ® , Super AG ® , Super G ® , Total 802.11n ® , and Wake on Wireless ® are registered by Atheros Communications, Inc. Atheros SST™, Signal-Sustain Technology™, the Air is Cleaner at 5-GHz™, XSPAN™, Wireless Future. Unleashed Now.™, and 5-UP™ are trademarks of Atheros Communications, Inc. The Atheros logo is a registered trademark of Atheros Communications, Inc. All other trademarks are the property of their respective holders. Notice The information in this document has been carefully reviewed and is believed to be accurate. Nonetheless, this document is subject to change without notice, and Atheros Communications, Inc. (Atheros) assumes no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update or to keep current the contained information, or to notify a person or organization of any updates. Atheros reserves the right to make changes, at any time, in order to improve reliability, function or design and to attempt to supply the best product possible. Atheros does not represent that products described herein are free from patent infringement or from any other third party right. No part of this document may be reproduced, adapted or transmitted in any form or by any means, electronic or mechanical, for any purpose, except as expressly set forth in a written agreement signed by Atheros. Atheros or its affiliates may have patents or pending patent applications, trademarks, copyrights, maskwork rights or other intellectual property rights that apply to the ideas, material and information expressed herein. No license to such rights is provided except as expressly set forth in a written agreement signed by Atheros. ATHEROS MAKES NO WARRANTIES OF ANY KIND WITH REGARD TO THE CONTENT OF THIS DOCUMENT. IN NO EVENT SHALL ATHEROS BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL SPECULATORY OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBLITY OF SUCH DAMAGES. IN PARTICULAR, ATHEROS SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA TRANSMITTED OR OTHERWISE USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE OR DATA. ATHEROS SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTIES OF MERCHANTIBILITY AND FITNESS FOR A PARTICULAR PURPOSE AS THEY MIGHT OTHERWISE APPLY TO THIS DOCUMENT AND TO THE IDEAS, MATERIAL AND INFORMATION EXPRESSED HEREIN. Page 3 of 9 Revision History Revision Description of Changes Aug 2009 Initial Release Introduction This document describes mandatory steps required by the OEM integrator when designing and manufacturing any host PC system utilizing an Atheros radio module. Also refer to the Atheros Regulatory Compliance Guide available on the Atheros customer support site and from the Atheros customer support contact person. This document lists the mandatory responsibilities and actions of the OEM integrator. Failure to comply with all requirements and conditions in this document, may result in non-compliance of the host PC with FCC rules and invalidate the Atheros FCC certification for the module. This guide applies to Client modules that act under control of an Access Point. This document does not apply to a Client module or Access Point with radar detection feature. Allowed Antennas to be Used with the Radio Module The Integrator must request from Atheros sales or regulatory contact person the current list of allowable antennas for use with the specific radio module. This information is not available on the public FCC database but will be provided by Atheros. Atheros will provide a table of antenna type(s) models, cable lengths, and peak gain in each band. Generally, the list will include omnidirectional Inverted-F (PIFA) and stamped metal/film antennas for use inside laptops. In some cases, dipole antenna types may be included in the available list. Peak gain including cable losses are quoted in the table provided by Atheros. Use of any of the antennas in the list (identical or equivalent antenna with same gain, dimensions and cable lengths) is acceptable in the host device, without any further FCC testing or submission. However, use of an antenna that is Higher gain than those on the list or is a Different Type, requires additional testing and submission to the FCC. Also, if the host PC is certified as an FCC Portable device subject to RF Exposure (SAR) evaluation, then additional SAR testing per FCC rules may be required. Therefore, antennas with higher gain or different type than specified by Atheros, may not be used with the Atheros module until new testing and reporting is completed. You must contact the Atheros Regulatory Group to report any higher gain or new antenna type to be used with the module. Antenna Placement and RF Hazard (SAR) Compliance For host PCs certified as FCC Mobile Category devices, the FCC Grant of approval for the Atheros module is only valid when the Integrator ensures antenna placement in the host system that maintains at least 20 cm separation between any part of the antenna element(s) and any part of the end user’s body (considering their likely or usual operation position and grip). This spacing is naturally met by non-Mobile systems such as Access Points or Desktop PCs. Laptop PCs typically have integrated antennas placed high in the LCD display assembly. However, additional certification testing including RF Exposure (SAR) testing and an FCC certification submission are required to gain permission to place antennas closer than 20 cm to the end-user (e.g. a WLAN radio in a handheld personal organizer, Netbook or Tablet PC where the antennas will be close to the users hands or lap. Such host PCs will require …

Text truncated - open the document above for the full version.

Date:2010/5/10 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: PPD-AR5B197 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Pursuant to DA 04-1705 of the Commission’s Rules, we request short-term confidential treatment of 180 days for the following information. : External Ph otos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards --------------------------------------------------------------------------- Michael Green / Manager, Global Product Compliance Atheros Communications, Inc.

FCC ID: PPD-AR5B197 Report No. : RF990501E01 Modular Approval Request Letter Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Jun. 08, 2010 Dear Application Examiner, Atheros Communications, Inc., It’s AR5B197 2x2 802.11n - BT Combo Card, FCC ID: PPD-AR5B197 would like to have your authorization as a modular approval. The requirements of section 15.212 of FCC rules have been met and shown on the following statements. “The modular transmitter must have its own RF shielding.”: The radio portion of this module has been shielded, please see exhibition External Photo. 1. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip AR9287. 2. “The modular transmitter must have its own power supply regulation part no.: AR9287. 3. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 4. “The modular transmitter must be tested in a stand-alone configuration”. The EUT is tested in a stand-alone configuration via an extender. Please see section Photographs of Test Configuration in the test report. 5. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: PPD-AR5B197 Report No. : RF990501E01 6. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 7. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, Hank Chung Assistant Manager Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch

Power of Attorney 2010/5/10 To whom it may concern: We, the undersigned Atheros Communications, Inc. hereby authorize Bureau Veritas Consumer Product Service (Hong Kong) Limited, Taoyuan Branch of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15B+C approval and any communication needed with the national authority. Any and all acts carried out by BVCPS on our behalf shall have the same effects as acts of our own. This authorization is limited to the following products： FCC ID: PPD-AR5B197 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, --------------------------------------------------------------------------- Michael Green / Manager, Global Product Compliance Atheros Communications, Inc.

Page 1 CONSTRUCTION PHOTOS OF EUT

PROPOSED FCC ID LABEL AND LOCATION Printed Color： ：： ： Black 地色 地色地色 地色 ： ：： ：White 材質 材質材質 材質 ： ：： ：一般合成紙 一般合成紙一般合成紙 一般合成紙 粘著材 粘著材粘著材 粘著材 ： ：： ：樹脂系糊 樹脂系糊樹脂系糊 樹脂系糊 Bottom of EUT FCC / IC Label Location ATHEROS COMMUNICATIONS, INC. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: PPD-AR5B197 IC: 4104A-AR5B197 Model: AR5B197

Page 2 Page 3 Page 4 Page 5

Report No.: FD990501E01 1 Report Format Version 3.0.1 Reference No.: FCC DoC TEST REPORT REPORT NO. : FD990501E01 MODEL NO. : AR5B197 RECEIVED : May 03, 2010 TESTED : May 06 to 17, 2010 ISSUED: June 03, 2010 APPLICANT : Atheros Communications, Inc. ADDRESS : 5480 Great America Parkway, Santa Clara, CA 95054 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION (1): No.49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien, Taiwan (R.O.C.) LAB LOCATION (2): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 21 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced, except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: FD990501E01 2 Report Format Version 3.0.1 Reference No.: Table of Contents 1 CERTIFICATION.............................................................................................3 2 SUMMARY OF TEST RESULTS.....................................................................4 2.1 MEASUREMENT UNCERTAINTY..................................................................4 3 GENERAL INFORMATION.............................................................................5 3.1 GENERAL DESCRIPTION OF EUT................................................................5 3.2 ANTENNA SPECIFICATIONS........................................................................5 3.3 DESCRIPTION OF SUPPORT UNITS............................................................6 3.4 CONFIGURATION OF SYSTEM UNDER TEST.............................................6 4 EMISSION TEST.............................................................................................7 4.1 CONDUCTED EMISSION MEASUREMENT..................................................7 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT................................7 4.1.2 TEST INSTRUMENTS....................................................................................7 4.1.3 TEST PROCEDURE.......................................................................................8 4.1.4 DEVIATION FROM TEST STANDARD...........................................................8 4.1.5 TEST SETUP..................................................................................................9 4.1.6 EUT OPERATING CONDITIONS....................................................................9 4.1.7 TEST RESULTS............................................................................................10 4.2 RADIATED EMISSION MEASUREMENT.....................................................12 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...................................12 4.2.2 TEST INSTRUMENTS..................................................................................13 4.2.3 TEST PROCEDURE.....................................................................................14 4.2.4 DEVIATION FROM TEST STANDARD.........................................................14 4.2.5 TEST SETUP................................................................................................15 4.2.6 EUT OPERATING CONDITIONS..................................................................15 4.2.7 TEST RESULTS............................................................................................16 5 INFORMATION ON THE TESTING LABORATORIES..................................20 6 APPENDIX A - MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB.........................................................21 Report No.: FD990501E01 3 Report Format Version 3.0.1 Reference No.: 1 CERTIFICATION PRODUCT : AR5B197 2x2 802.11n - BT Combo Card BRAND NAME : Atheros MODEL NO.: AR5B197 TESTED : May 06 to 17, 2010 TEST SAMPLE : R&D SAMPLE APPLICANT : Atheros Communications, Inc. STANDARDS : FCC Part 15, Subpart B, Class B ANSI C63.4-2003 CISPR 22:1997, Class B ICES-003: 2004, Class B The above equipment (Model: AR5B197) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and was in compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: June 03, 2010 ( Midoli Peng, Specialist ) TECHNICAL ACCEPTANCE : , DATE: June 03, 2010 ( Hank Chung, Deputy Manager ) APPROVED BY : , DATE: June 03, 2010 (May Chen, Deputy Manager ) Report No.: FD990501E01 4 Report Format Version 3.0.1 Reference No.: 2 SUMMARY OF TEST RESULTS Standard Test Type Result Remarks Conducted Test PASS Meets Class B Limit Minimum passing margin is -16.35 dB at 0.209 MHz FCC Part 15, Subpart B, Class B Radiated Test PASS Meets Class B Limit Minimum passing margin is -3.6 dB at 177.10 MHz Note: The limit for radiated test was performed according to CISPR 22, which was specified in FCC PART 15 Subpart B 15.109(g). Also the limits of ICES-003: 2004 and CISPR 22 are same. 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Measurement Value Conducted emissions 2.45 dB Radiated emissions (30MHz-1GHz) 3.76 dB Radiated emissions (1GHz -18GHz) 2.19 dB Radiated emissions (18GHz -40GHz) 2.55 dB Report No.: FD990501E01 5 Report Format Version 3.0.1 Reference No.: 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT AR5B197 2x2 802.11n - BT Combo Card MODEL N…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST 3
