PPQ-WCBN3610L802.11 b/g/n, 1T1R 2.4G Wireless IoT Module

Page 1/6 USER MANUAL 802.11 b/g/n, 1T1R 2.4GHz Wireless IOT Module Model Name: WCBN3610L Page 2/6 PRODUCT FEATURES  WiFi operate at ISM frequency bands (2.4GHz)  Compact Form Factor: 18 x 20.5 x 3.2 mm ±0.1mm  Bunch of UART/ SPI/ I2C interfaces for peripheral controllers  Standards support: 802.11b, 802.11g, 802.11n, 802.11d, 802.11e, 802.11i  Enterprise level security complying with WPA/WPA2 certification  Light weight TCP/IP protocol suite  One transmitter and one receiver 802.11n WLAN transceiver supports up to 150 Mbps downstream and 150 Mbps upstream PHY rates  ARM Cortex-M development environment for customer applications  HF/RoHS compliance Page 3/6 ENVIRONMENTAL Operating Operating Temperature: -20 to 85 C Relevant Humidity: 5-90% (non-condensing) Storage Temperature: -40 to 85 C Relevant Humidity: 5-95% (non-condensing) Frequency Range 802.11bg 2.412 ~ 2.462 GHz Page 4/6 WARNINGS FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. ISED Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1.This device may not cause interference. 2.This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1.L’appareil ne doit pas produire de brouillage; 2.L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. ISED Radiation Exposure Statement: This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20cm de distance entre la source de rayonnement et votre corps. The transmitter module may not be co-located with any other transmitter or antenna. Le module émetteur peut ne pas être coïmplanté avec un autre émetteur ou antenne. For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible. Pour les produits disponibles aux États-Unis / Canada du marché, seul le canal 1 à 11 peuvent être exploités. Sélection d'autres canaux n'est pas possible. This module is intended for OEM integrators under the following conditions: 1. Ensure that the end-user has no manual instructions to remove or install module. 2.This module is certified pursuant to Part 15 rules section 15.247 and RSS-247. 3.This module has been approved to operate with the antenna types listed below, with the maximum permissible gain indicated. Antenna Number Brand Name Model Name Ant. Type Connector Support Max Peak Gain Antenna 1 LITEON WCBN3610L Printed Ant Murata 2.4G 0.5 Page 5/6 4 Label and compliance information Label of the end product: FCC The host product must be labeled in a visible area with the following " Contains FCC ID: PPQ-WCBN3610L". The end product shall bear the following 15.19 statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. ISED This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains transmitter module IC: 4…

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: June 7, 2023 Ref: Attestation Statements Part 2.911(d)(7) Filing Grantee Code: PPQ LITE-ON TECHNOLOGY CORP. (“the applicant”) certifies that, as of the date of the filing of the application, LITE-ON TECHNOLOGY CORP. is our designated U.S. agent for service of process for the above referenced Grantee Code. LITE-ON TECHNOLOGY CORP. accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges their responsibility to inform the FCC whenever the designated agent information changes. LITE-ON TECHNOLOGY CORP. accepts the designation by the applicant as the U.S. agent to accept service of process includes, but is not limited to, delivery of any correspondence, notices, orders, decisions, and requirements of administrative, legal, or judicial process related to Commission proceedings. Designated U.S. Agent Information: FRN: 0033411521 Name: LITE-ON TECHNOLOGY CORP. Address: 3001 Summit Avenue Ste. 400, Plano, TEXAS 75074, USA Contact Person: Joshua Winkler Tel.: (480) 422-4548 Email: [email protected] Sincerely, Applicant U.S. Agent LITE-ON TECHNOLOGY CORP. LITE-ON TECHNOLOGY CORP. TC Wu, Director / Network Access S.B.U. Joshua Winkler Signature: Signature:

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: June 14, 2023 FCC ID: PPQ-WCBN3610L RE: Attestation Statements Part 2.911(d)(5)(i) Filing LITE-ON TECHNOLOGY CORP. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. RE: Attestation Statements Part 2.911(d)(5)(ii) Filing LITE-ON TECHNOLOGY CORP. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List ( as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Applicant : LITE-ON TECHNOLOGY CORP. Address : Bldg. C, 90, Chien 1 Rd., Chung-Ho, New Taipei City 23585, Taiwan Signature : _________________________________ Name and Job Title. : TC Wu, Director / Network Access S.B.U. E-mail : [email protected] Tel. : +886-2-2222-6181 #8301

Confidentiality Request Letter Date: June 14, 2023 Federal Communications Commission Authorization and Evaluation Division Subject: Request for confidentiality FCC ID: PPQ-WCBN3610L To whom it may concern: Short-term Confidentiality pursuant to Public Notice DA 04-1705, and in order to comply with the marketing regulations in 47 C.F.R. §2.803 and the importation rules in 47 C.F.R. §2.1204 while ensuring that business-sensitive information remains confidential until the actual marketing of newly authorized devices, we are request the Commission grant temporary confidential treatment and not release the following attachments for routine public disclosure until 180 days after the grant date. 1. Internal Photographs 2. External Photographs 3. User’s manual 4. Test Set up photos Permanent Confidentiality Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure indefinitely. 1. Block Diagram 2. Schematics 3. Operational Description It is our understanding that test measurement reports and correspondence during the certification review process cannot be granted confidential treatment, and such information will be available for public review once the grant of equipment authorization is issued. Sincerely, Applicant : LITE-ON TECHNOLOGY CORP. Address : Bldg. C, 90, Chien 1 Rd., Chung-Ho, New Taipei City 23585, Taiwan Signature : _________________________________ Name and Job Title. : TC Wu, Director / Network Access S.B.U. E-mail : [email protected] Tel. : +886-2-2222-6181 #8301

Letter of Authorization Date: June 14, 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCC ID: PPQ-WCBN3610L Product Name: 802.11 b/g/n, 1T1R 2.4G Wireless IoT Module To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization to the FCC Rules and Regulations. Sporton International Inc. Address : No.52, Huaya 1st Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) Name : Leo Huang Job Title : VP e-mail : [email protected] We further certify that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862. This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Applicant : LITE-ON TECHNOLOGY CORP. Address : Bldg. C, 90, Chien 1 Rd., Chung-Ho, New Taipei City 23585, Taiwan Signature : _________________________________ Name and Job Title. : TC Wu, Director / Network Access S.B.U. E-mail : [email protected] Tel. : +886-2-2222-6181 #8301

Modular Approval Request Letter Date: July 21, 2023 Subject: Modular Approval Attestation FCC ID: PPQ-WCBN3610L Dear Reviewer, We, Sporton International Inc., are authorized by LITE-ON TECHNOLOGY CORP., to have their 802.11 b/g/n, 1T1R 2.4G Wireless IoT Module approved under single module approval authorization. The requirements regulated in 47 CFR 15.212 have been fulfilled and clearly explained below. 1. The requirement of RF shielding: The shielding of the radio portion can be demonstrated in exhibition External Photo. 2. The requirement of buffered inputs: Buffered data inputs stage has been integrated in chip RTL8720CM 3. The requirement of power supply regulation: The part number of the power regulator is TPS562201DDCR, TLV62568DBVR. 4. The requirements of section 15.203 and 15.204(C): The requirements of antenna connector and spurious emission have been fulfilled. Please reference the exhibition Test Report. 5. The requirement of stand-alone test configuration: Please reference exhibition Test Configuration Photo for the stand-alone test configuration. 6. The requirement of labeling: The instruction on the labeling rule of the end product has been stated in the users manual of this module. Please also see the exhibition Label Sample. 7. The requirement of compliance on specific rule or operating requirements: The required FCC rule has been fulfilled and all the instructions for maintaining compliance has been clearly stated in the Users Manual. 8. The requirement of RF exposure: Please refer exhibition RF Exposure for the compliance of MPE and SAR RF exposure rule. Please do not hesitate to contact me for any questions of this request letter. Thank you. Signature : _________________________________ Name and Job Title. : Leo Huang, VP E-mail : [email protected]

PHOTOGRAPHS OF EUT EP350416 Sporton International Inc. Page No. : 1 of 6 Report Template No.: SE Ver 1.0_EP Issued Date : 21/Jul/2023 Report Version : 01 PHOTOGRAPHS OF EUT EP350416 Sporton International Inc. Page No. : 2 of 6 Report Template No.: SE Ver 1.0_EP Issued Date : 21/Jul/2023 Report Version : 01 PHOTOGRAPHS OF EUT EP350416 Sporton International Inc. Page No. : 3 of 6 Report Template No.: SE Ver 1.0_EP Issued Date : 21/Jul/2023 Report Version : 01

MM11325470DA1 WI-CQES-002 2023.02.21 Bing Li Blank WCBN3610L-GPAC LABEL 1,條碼使用ECC200等級為B級以上，尺寸為5*5mm 顯示內容為XXXXXXXXXXXX BD=MAC+1 MAC ( 由業務提供） 50900011753D 15*13mm MAC:XXXXXXXXXXXX FCC ID:PPQ-WCBN3610L IC:4491A-WCBN3610L Model: WCBN3610L Made in China 15mm 13mm GPAC 3 MAC:XXXXXXXXXXXX FCC ID:PPQ-WCBN3610L IC:4491A-WCBN3610L Model: WCBN3610L Made in China 15mm 13mm GPAC

PHOTOGRAPHS OF EUT EP350416 Sporton International Inc. Page No. : 4 of 6 Report Template No.: SE Ver 1.0_EP Issued Date : 21/Jul/2023 Report Version : 01 PHOTOGRAPHS OF EUT EP350416 Sporton International Inc. Page No. : 5 of 6 Report Template No.: SE Ver 1.0_EP Issued Date : 21/Jul/2023 Report Version : 01 PHOTOGRAPHS OF EUT EP350416 Sporton International Inc. Page No. : 6 of 6 Report Template No.: SE Ver 1.0_EP Issued Date : 21/Jul/2023 Report Version : 01 ______________THE END______________

Radio Exposure Evaluation Report Report No. : FA350416 TEL : 886-3-327-3456 Page Number : 1 of 11 FAX : 886-3-327-0973 Issued Date : Jul. 21, 2023 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: PPQ-WCBN3610L Radio Exposure Evaluation Report FCC ID : PPQ-WCBN3610L Equipment : 802.11 b/g/n, 1T1R 2.4G Wireless IoT Module Brand Name : LITEON Model Name : WCBN3610L Applicant : LITE-ON Technology Corp. Bldg. C, 90, Chien 1 Road, Chung Ho, New Taipei City 23585, Taiwan, R.O.C Manufacturer : LITE-ON Technology (Changzhou) CO.LTD A9 Building,No.88 Yanghu Road, Wujin Hi-Tech Industrial Development Zone ,Changzhou City, Jiangsu Province 213100 China Standard : 47 CFR FCC Part 2 Subpart J, section 2.1091 The product was received on May 09, 2023, and testing was started from May 11, 2023 and completed on May 29, 2023. We, SPORTON INTERNATIONAL INC. Hsinhua Laboratory, would like to declare that the tested sample has been evaluated in accordance with the procedures given in 47 CFR FCC Part 2 Subpart J, section 2.1091 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC. Hsinhua Laboratory, the test report shall not be reproduced except in full. ___________________________________________ Approved by: Jackson Tsai __________________________________________ SDoC by: XXXXX SPORTON INTERNATIONAL INC. Hsinhua Laboratory No.52, Huaya 1st Rd., Guishan Dist., Taoyuan City 333411, Taiwan (R.O.C.) Radio Exposure Evaluation Report Report No. : FA350416 TEL : 886-3-327-3456 Page Number : 2 of 11 FAX : 886-3-327-0973 Issued Date : Jul. 21, 2023 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: PPQ-WCBN3610L Table of Contents HISTORY OF THIS TEST REPORT .................................................................................................................. 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Applicable Standards ............................................................................................................................. 6 1.3 Testing Location ..................................................................................................................................... 6 2 MAXIMUM PERMISSIBLE EXPOSURE ............................................................................................... 7 2.1 Limit of Maximum Permissible Exposure ............................................................................................... 7 2.2 RF Exposure Exempt Measurement ...................................................................................................... 8 2.3 Multiple RF Sources Exposure ............................................................................................................... 9 2.4 MPE Calculation Method ...................................................................................................................... 10 2.5 Calculated Result and Limit .................................................................................................................. 11 Photographs of EUT V01 Radio Exposure Evaluation Report Report No. : FA350416 TEL : 886-3-327-3456 Page Number : 3 of 11 FAX : 886-3-327-0973 Issued Date : Jul. 21, 2023 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: PPQ-WCBN3610L History of this test report Report No. Version Description Issued Date FA350416 01 Initial issue of report Jul. 21, 2023 Radio Exposure Evaluation Report Report No. : FA350416 TEL : 886-3-327-3456 Page Number : 4 of 11 FAX : 886-3-327-0973 Issued Date : Jul. 21, 2023 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: PPQ-WCBN3610L Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 2 - Exposure evaluation PASS - Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: None Reviewed by: Ryan Hsiao Report Producer: Debby Hung Radio Exposure Evaluation Report Report No. : FA350416 TEL : 886-3-327-3456 Page Number : 5 of 11 FAX : 886-3-327-0973 Issued Date : Jul. 21, 2023 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: PPQ-WCBN3610L 1 General Description 1.1 Information 1.1.1 EUT General Information RF General Information Evaluation Mode Frequency Range (MHz) Operating Frequency (MHz) Modulation Type 2.4GHz WLAN 2400-2483.5 2412-2462 802.11b: DSSS (DBPSK, DQPSK, CCK) 802.11g/n: OFDM (BPSK, QPSK, 16QAM, 64QAM) 1.1.2 Antenna Information Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 LITEON WCBN3610L Printed antenna Murata 0.5 Note 1: The EUT has one antenna. For 2.4GHz function: For IEEE 802.11 b/g/n mode (1TX/1RX) Ant. 1 (port 1) could transmit/receive. Radio Exposure Evaluation Report Report No. : FA350416 TEL : 886-3-327-3456 Page Number : 6 of 11 FAX : 886-3-327-0973 Issued Date : Jul. 21, 2023 Report Template No.: HE1-A1 Ver5.0 Report Version : 01 FCC ID: PPQ-WCBN3610L 1.2 Applicable Standards According to the specifications of the manufacturer, the EUT must comply with the requirements of the following standards: ⬧ 47 CFR FCC Part 2 Subpart J, section 2.1091 ⬧ KDB 447498 D04 Interim General RF Exposure Guidance v01 The following reference test guidance is not within the scope of accreditation of TAF. ⬧ 47 CFR Part 1.1307 ⬧ 47 CFR Part 1.1310 1.3 Testing Location Test Lab.：Sporton International Inc. Hsinhua Laboratory Hsinhua ADD: No…

Text truncated - open the document above for the full version.

FCC Radio Test Report Report No. :FR350416AC TEL : 886-3-3273456 Page Number : 1 of 21 FAX : 886-3-3270973 Issued Date : Jul. 21, 2023 Report Template No.: HE1-C8 Ver4.4 Report Version : 01 FCC ID: PPQ-WCBN3610L FCC Radio Test Report FCC ID : PPQ-WCBN3610L Equipment : 802.11 b/g/n, 1T1R 2.4G Wireless IoT Module Brand Name : LITEON Model Name : WCBN3610L Applicant : LITE-ON Technology Corp. Bldg. C, 90, Chien 1 Road, Chung Ho, New Taipei City 23585, Taiwan, R.O.C Manufacturer : LITE-ON Technology (Changzhou) CO.LTD A9 Building,No.88 Yanghu Road, Wujin Hi-Tech Industrial Development Zone ,Changzhou City, Jiangsu Province 213100 China Standard : 47 CFR FCC Part 15.247 The product was received on May 09, 2023, and testing was started from May 11, 2023 and completed on May 29, 2023. We, SPORTON INTERNATIONAL INC. Hsinhua Laboratory, would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI C63.10-2013 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC. Hsinhua Laboratory, the test report shall not be reproduced except in full. ___________________________________________ Approved by: Jackson Tsai SPORTON INTERNATIONAL INC. Hsinhua Laboratory No.52, Huaya 1st Rd., Guishan Dist., Taoyuan City 333411, Taiwan (R.O.C.) FCC Radio Test Report Report No. :FR350416AC TEL : 886-3-3273456 Page Number : 2 of 21 FAX : 886-3-3270973 Issued Date : Jul. 21, 2023 Report Template No.: HE1-C8 Ver4.4 Report Version : 01 FCC ID: PPQ-WCBN3610L Table of Contents HISTORY OF THIS TEST REPORT .................................................................................................................. 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Testing Applied Standards ..................................................................................................................... 7 1.3 Testing Location Information .................................................................................................................. 7 1.4 Measurement Uncertainty ...................................................................................................................... 7 2 TEST CONFIGURATION OF EUT......................................................................................................... 8 2.1 Test Channel Mode ................................................................................................................................ 8 2.2 The Worst Case Measurement Configuration ........................................................................................ 9 2.3 Support Equipment ............................................................................................................................... 10 2.4 Test Setup Diagram ............................................................................................................................. 11 3 TRANSMITTER TEST RESULT .......................................................................................................... 12 3.1 DTS Bandwidth..................................................................................................................................... 12 3.2 Maximum Conducted Output Power .................................................................................................... 13 3.3 Power Spectral Density ........................................................................................................................ 15 3.4 Emissions in Non-restricted Frequency Bands .................................................................................... 16 3.5 Emissions in Restricted Frequency Bands ........................................................................................... 17 4 TEST EQUIPMENT AND CALIBRATION DATA ................................................................................ 21 APPENDIX A. TEST RESULTS OF DTS BANDWIDTH APPENDIX B. TEST RESULTS OF MAXIMUM CONDUCTED OUTPUT POWER APPENDIX C. TEST RESULTS OF POWER SPECTRAL DENSITY APPENDIX D. TEST RESULTS OF EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS APPENDIX E. TEST RESULTS OF EMISSIONS IN RESTRICTED FREQUENCY BANDS APPENDIX F. TEST PHOTOS PHOTOGRAPHS OF EUT V01 FCC Radio Test Report Report No. :FR350416AC TEL : 886-3-3273456 Page Number : 3 of 21 FAX : 886-3-3270973 Issued Date : Jul. 21, 2023 Report Template No.: HE1-C8 Ver4.4 Report Version : 01 FCC ID: PPQ-WCBN3610L History of this test report Report No. Version Description Issued Date FR350416AC 01 Initial issue of report Jul. 21, 2023 FCC Radio Test Report Report No. :FR350416AC TEL : 886-3-3273456 Page Number : 4 of 21 FAX : 886-3-3270973 Issued Date : Jul. 21, 2023 Report Template No.: HE1-C8 Ver4.4 Report Version : 01 FCC ID: PPQ-WCBN3610L Summary of Test Result Report Clause Ref. Std. Clause Test Items Result (PASS/FAIL) Remark 1.1.2 15.203 Antenna Requirement PASS - - 15.207 AC Power-line Conducted Emissions Not Required Only employ DC power. 3.1 15.247(a) DTS Bandwidth PASS - 3.2 15.247(b) Maximum Conducted Output Power PASS - 3.3 15.247(e) Power Spectral Density PASS - 3.4 15.247(d) Emissions in Non-restricted Frequency Bands PASS - 3.5 15.247(d) Emissions in Restricted Frequency Bands PASS - Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and explanations: None Reviewed by: Ryan Hsiao Re…

Text truncated - open the document above for the full version.

Liteon Confidential WCBN3610L Antenna Specification Antenna Information  Antenna model name: WCBN3610L  Antenna manufacturer address: Bldg. C, 90, Chien 1 Road, Chung Ho, New Taipei City 23585, Taiwan, R.O.C. Liteon 2 Antenna S11 Test  Antenna test: Check printed antenna s-parameters w/ motherboard. Frequency (MHz) S-Parameter (dB) 2400 -12 2450 -23 2500 -10 Liteon 3 2.4GHz Band Function Test  Antenna test: Check printed antenna efficiency w/ motherboard. Liteon 4 Frequency (MHz) Efficiency (%) Peak Gain (dBi) 2400 40% -0.1 2450 48% 0.5 2500 44% 0.2 Radiation Pattern

Test Photos Appendix F Sporton International Inc. Page No. : F1 of F2 1. Photographs of Radiated Emissions Test Configuration For radiated emissions 30MHz~1GHz Front view Rear view Test Photos Appendix F Sporton International Inc. Page No. : F2 of F2 For radiated emissions above 1GHz Front view Rear view ─────THE END─────
