PPQ-WM6321WM6321

User Guide 1 Confidential WPX8988 QCA9886 Model: WM6321 User Guide User Guide 2 Confidential Wifi Normal mode setting 1.1.1. Radio3(wifi3 or ath3) 5g(11ac 2x2) for QCA9886 root@OpenWrt:/# uci set wireless.wifi3.disabled='0' root@OpenWrt:/# uci set wireless.wifi3.channel='36' root@OpenWrt:/# uci set wireless.wifi3.htmode=HT20 root@OpenWrt:/# uci set wireless.wifi3.hwmode='11ac' root@OpenWrt:/# uci set wireless.wifi3.country=FR root@OpenWrt:/# uci set wireless.@wifi-iface[3].ssid=MFG_TEST_5G_2 root@OpenWrt:/# uci commit wireless root@OpenWrt:/# wifi 1.1.2. Radio enable/disable Enable wifiX: root@OpenWrt:/# uci set wireless.wifi3.disabled='0' Disable wifiX: root@OpenWrt:/# uci set wireless.wifi3.disabled='1' 1.1.3. Radio mode settings Set mode to 11ac for 2x2 radio: root@OpenWrt:/# uci set wireless.wifi3.hwmode='11ac' 1.1.4. Band setting Set band to HT20 for wifiX: root@OpenWrt:/# uci set wireless.wifi3.htmode='HT20' Set band to HT40: root@OpenWrt:/# uci set wireless.wifi3.htmode='HT40' Set band to HT80 for wifiX: root@OpenWrt:/# uci set wireless.wifi3.htmode='HT80' 1.1.5. Channel setting Set wifiX channel to CH149: root@OpenWrt:/# uci set wireless.wifi3.channel='149' 1.1.6. Country settingn root@OpenWrt:/# uci set wireless.wifi3.country=US 1.1.7. Save settinigs root@OpenWrt:/# uci commit wireless 1.1.8. Apply root@OpenWrt:/# wifi User Guide 3 Confidential 1.1.9. Set to Factory default root@OpenWrt:/# firstboot -y && reboot User Guide 4 Confidential FCC Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. User Guide 5 Confidential This module is intended for OEM integrators under the following conditions: 1. This module is certified pursuant to Part 15 rule section 15.407. 2. This module has been approved to operate with the antenna types listed below, with the maximum permissible gain indicated. Frequency Band Model Antenna Type Gain(dBi) 5150-5850MHz MLX20X-126AA0-B PIFA 5.3 MLX20X-126AA0-B 5.6 3. Label and compliance information Label of the end product: The host product must be labeled in a visible area with the following " Contains FCC ID: PPQ-WM6321". The end product shall bear the following 15.19 statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. If the labelling area is considered too small and therefore it is impractical (smaller than the palm of the hand) to display the compliance statement, then the statement may be placed in the user manual or product packaging. 4. Information on test modes and additional testing requirements This module has been approved under stand-alone configuration. The separate approval is required for all other operating configurations, including portable configurations with respect to Part 2.1093 and different antenna configurations The information on how to configure test modes for host product evaluation for different operational conditions for a stand-alone modular transmitter in a host, versus with multiple, simultaneously transmitting modules or other transmitters in a host can be found at KDB Publication 996369 D04. 5. Additional testing, Part 15 Subpart B disclaimer Appropriate measurements (e.g. FCC 15 B compliance) and if applicable additional equipment authorizations (e.g. SDoC) of the host product to be addressed by the integrator/manufacturer. This module is only FCC authorized for the specific rule part 15.407 listed on the grant, and the host product manufacturer is responsible for compliance to any other FCC rules that apply to the host product as being Part 15 Subpart B compliant. 6. The user manual of the end product should include: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference rec…

Text truncated - open the document above for the full version.

Confidentiality Request Letter Date: December 15, 2021 Federal Communications Commission Authorization and Evaluation Division Subject: Request for confidentiality FCC ID: PPQ-WM6321 To whom it may concern: Short-term Confidentiality Pursuant to Public Notice DA 04-1705, and in order to comply with the marketing regulations in 47 C.F.R. §2.803 and the importation rules in 47 C.F.R. §2.1204 while ensuring that business-sensitive information remains confidential until the actual marketing of newly authorized devices, we are request the Commission grant temporary confidential treatment and not release the following attachments for routine public disclosure until 180 days after the grant date. 1. Internal Photographs 2. External Photographs 3. User’s manual 4. Test Set up photos Permanent Confidentiality Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure indefinitely. 1. Block Diagram 2. Schematics 3. Operational Description / Software Security For U-NII Devices It is our understanding that test measurement reports and correspondence during the certification review process cannot be granted confidential treatment, and such information will be available for public review once the grant of equipment authorization is issued. Sincerely, Applicant : LITE-ON TECHNOLOGY CORP. Address : Bldg. C, 90, Chien 1 Rd., Chung-Ho, New Taipei City, 23585 Taiwan Signature : ________________________________ Name and Job Title. : TC Wu, Deputy Director(R & D Division) E-mail : [email protected] Tel. : +886-2-2222-6181 ext.8301

Letter of Authorization Date: December 15, 2021 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCC ID: PPQ-WM6321 Product Name: WM6321 To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization to the FCC Rules and Regulations. Sporton International Inc. Address : No.52, Huaya 1st Rd., Guishan Dist., Taoyuan City 333, Taiwan Name : Leo Huang Job Title : Manager e-mail : [email protected] We further certify that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862. This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Applicant : LITE-ON TECHNOLOGY CORP. Address : Bldg. C, 90, Chien 1 Rd., Chung-Ho, New Taipei City, 23585 Taiwan Signature : _________________________________ Name and Job Title. : TC Wu, Deputy Director(R & D Division) E-mail : [email protected] Tel. : +886-2-2222-6181 ext.8301

Single Modular Approval Request Letter Date: December 15, 2021 Subject: Single Modular Approval Attestation FCC ID: PPQ-WM6321 Dear Reviewer, We, Sporton International Inc., are authorized by Lite-On Technology Corp., to have the WM6321 approved under single modular approval authorization. The requirements regulated in 47 CFR 15.212 have been fulfilled and clearly explained below. 1. The requirement of RF shielding: The shielding of the radio portion can be demonstrated in exhibition External Photo. 2. The requirement of buffered inputs: Buffered data inputs stage has been integrated in chip QCA9886. 3. The requirement of power supply regulation: The part number of the power regulator is QCA9886. 4. The requirements of section 15.203 and 15.204(C): The requirements of antenna connector and spurious emission have been fulfilled. Please reference the exhibition Test Report. 5. The requirement of stand-alone test configuration: Please reference exhibition Test Configuration Photo for the stand-alone test configuration. 6. The requirement of labeling: The instruction on the labeling rule of the end product has been stated in the user manual of this module. Please also see the exhibition Label Sample. 7. The requirement of compliance on specific rule or operating requirements: The required FCC rule has been fulfilled and all the instructions for maintaining compliance has been clearly stated in the Users Manual. 8. The requirement of RF exposure: Please refer exhibition RF Exposure for the compliance of RF exposure rule. Please do not hesitate to contact me for any questions of this request letter. Thank you. Signature : Name and Job Title. : Leo Huang, Manager E-mail : [email protected]

Date: December 15, 2021 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Professional Installation Attestation FCC ID: PPQ-WM6321 Product Name: WM6321 To whom it may concern: We, Sporton International Inc., are authorized by Lite-On Technology Corp., hereby declares that the device will be distributed through a controlled distribution channels. This device is not intended for sale to the general public. Professional training and support is provided as part of the Authorized Partner programs. Sincerely, Signature : _________________________________ Name and Job Title. : Leo Huang, Manager E-mail : [email protected]

Date: December 15, 2021 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Declaration of composite/rated equipment for FCC ID: PPQ-WM6321 To Whom it may concern, We, the undersigned, would like to declare that the composite portion catagorized as Other Class B digital devices & peripherals has been authorized under the Supplier's Declaration of Conformity (SDoC) procedures. Sincerely, Applicant : LITE-ON TECHNOLOGY CORP. Address : Bldg. C, 90, Chien 1 Rd., Chung-Ho, New Taipei City, 23585 Taiwan Signature : _________________________________ Name and Job Title. : TC Wu, Deputy Director(R & D Division) E-mail : [email protected] Tel. : +886-2-2222-6181 ext.8301

UNII Declaration Letter Date: December 15, 2021 We have declared below featured for FCC equipment authorization, Device FCC ID: PPQ-WM6321 (1) DFS Device -- Master, Client with Radar detection capability , Client without radar detection capability, N/A (2) Active/Passive Scanning , adhoc mode access point capability Frequency Band (MHz) Active Scanning (the device can transmit a probe (beacon)) Passive scanning (where the device is can listen only with no probes) Ad Hoc Mode capability Access point capability 5150 - 5850 Yes , No Yes , No Yes , No Yes , No (3) Meet 15.202 requirement - Yes , No , Please check below A master device is defined as a device operating in a mode in which it has the capability to transmit without receiving an enabling signal. In this mode it is able to select a channel and initiate a network by sending enabling signals to other devices A client device is defined as a device operating in a mode in which the transmissions of the device are under control of the master. A device in client mode is not able to initiate a network. Sincerely, Applicant : LITE-ON TECHNOLOGY CORP. Address : Bldg. C, 90, Chien 1 Rd., Chung-Ho, New Taipei City, 23585 Taiwan Signature : _________________________________ Name and Job Title. : TC Wu, Deputy Director(R & D Division) E-mail : [email protected] Tel. : +886-2-2222-6181 ext.8301

Photographs of EUT Report No. : EP192716-01 SPORTON International Inc. Page No. : 1 of 8 EP Report Version : Rev. 01 Issued Date : Dec. 14, 2021 Photographs of EUT Report No. : EP192716-01 SPORTON International Inc. Page No. : 5 of 8 EP Report Version : Rev. 01 Issued Date : Dec. 14, 2021 Photographs of EUT Report No. : EP192716-01 SPORTON International Inc. Page No. : 6 of 8 EP Report Version : Rev. 01 Issued Date : Dec. 14, 2021 Photographs of EUT Report No. : EP192716-01 SPORTON International Inc. Page No. : 7 of 8 EP Report Version : Rev. 01 Issued Date : Dec. 14, 2021 Photographs of EUT Report No. : EP192716-01 SPORTON International Inc. Page No. : 8 of 8 EP Report Version : Rev. 01 Issued Date : Dec. 14, 2021 ─────THE END─────

Label Location Information EUT (Affix to the Shielding Case) Label Location

Photographs of EUT Report No. : EP192716-01 SPORTON International Inc. Page No. : 1 of 8 EP Report Version : Rev. 01 Issued Date : Dec. 14, 2021 Photographs of EUT Report No. : EP192716-01 SPORTON International Inc. Page No. : 2 of 8 EP Report Version : Rev. 01 Issued Date : Dec. 14, 2021 Photographs of EUT Report No. : EP192716-01 SPORTON International Inc. Page No. : 3 of 8 EP Report Version : Rev. 01 Issued Date : Dec. 14, 2021

Radio Exposure Evaluation Report Report No. : FA192716-01 TEL : 886-3-327-3456 Page Number : 1 of 7 FAX : 886-3-327-0973 Issued Date : Dec. 14, 2021 Report Template No.: HE1-A1 Ver4.0 Report Version : 01 FCC ID: PPQ-WM6321 Radio Exposure Evaluation Report FCC ID : PPQ-WM6321 Equipment : WM6321 Brand Name : LITEON Model Name : WM6321 Applicant : LITE-ON Technology Corp Bldg. C, 90, Chien 1 Rd., Chung-Ho, New Taipei City, 23585 Taiwan Manufacturer : LITE-ON Network Communication (Dongguan) Limited 30#Keji Rd.,Yin Hu Industrial Area,Qingxi Town,DongGuan City,Guangdong,China Standard : 47 CFR FCC Part 2 Subpart J, section 2.1091 The product was received on Oct. 18, 2021, and testing was started from Oct. 25, 2021 and completed on Nov. 06, 2021. We, SPORTON INTERNATIONAL INC. Hsinhua Laboratory, would like to declare that the tested sample has been evaluated in accordance with the procedures given in 47 CFR FCC Part 2 Subpart J, section 2.1091 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC. Hsinhua Laboratory, the test report shall not be reproduced except in full. ___________________________________________ Approved by: Allen Lin __________________________________________ SDoC by: XXXXX SPORTON INTERNATIONAL INC. Hsinhua Laboratory No.52, Huaya 1st Rd., Guishan Dist., Taoyuan City 333411, Taiwan (R.O.C.) Radio Exposure Evaluation Report Report No. : FA192716-01 TEL : 886-3-327-3456 Page Number : 2 of 7 FAX : 886-3-327-0973 Issued Date : Dec. 14, 2021 Report Template No.: HE1-A1 Ver4.0 Report Version : 01 FCC ID: PPQ-WM6321 Table of Contents HISTORY OF THIS TEST REPORT .................................................................................................................. 3 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Testing Location ..................................................................................................................................... 5 2 MAXIMUM PERMISSIBLE EXPOSURE ............................................................................................... 6 2.1 Limit of Maximum Permissible Exposure ............................................................................................... 6 2.2 MPE Calculation Method ........................................................................................................................ 6 2.3 Calculated Result and Limit .................................................................................................................... 7 Photographs of EUT V01 Radio Exposure Evaluation Report Report No. : FA192716-01 TEL : 886-3-327-3456 Page Number : 3 of 7 FAX : 886-3-327-0973 Issued Date : Dec. 14, 2021 Report Template No.: HE1-A1 Ver4.0 Report Version : 01 FCC ID: PPQ-WM6321 History of this test report Report No. Version Description Issued Date FA192716-01 01 Initial issue of report Dec. 14, 2021 Radio Exposure Evaluation Report Report No. : FA192716-01 TEL : 886-3-327-3456 Page Number : 4 of 7 FAX : 886-3-327-0973 Issued Date : Dec. 14, 2021 Report Template No.: HE1-A1 Ver4.0 Report Version : 01 FCC ID: PPQ-WM6321 Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 2 - Exposure evaluation PASS - Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: None Reviewed by: Sam Tsai Report Producer: Jenny Yang Radio Exposure Evaluation Report Report No. : FA192716-01 TEL : 886-3-327-3456 Page Number : 5 of 7 FAX : 886-3-327-0973 Issued Date : Dec. 14, 2021 Report Template No.: HE1-A1 Ver4.0 Report Version : 01 FCC ID: PPQ-WM6321 1 General Description 1.1 Information 1.1.1 EUT General Information RF General Information Evaluation Mode Frequency Range (MHz) Operating Frequency (MHz) Modulation Type 5GHz WLAN 5150-5250 5250-5350 5470-5725 5725-5850 5180-5240 5260-5320 5500-5700 5745-5825 802.11a/n: OFDM (BPSK, QPSK, 16QAM, 64QAM) 802.11ac: OFDM (BPSK, QPSK, 16QAM, 64QAM, 256QAM) 1.1.2 Antenna Information Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 LYNwave MLX20X-126AA0-B PIFA I-Pex 5.3 2 LYNwave MLX20X-126AA0-B PIFA I-Pex 5.6 Note 1: The EUT has two antennas. For 5GHz function: For IEEE 802.11 a/n/ac mode (2TX/2RX) Ant. 1 and Ant. 2 could transmit/receive simultaneously. 1.2 Testing Location Test Lab.：Sporton International Inc. Hsinhua Laboratory Hsinhua ADD: No.52, Huaya 1st Rd., Guishan Dist., Taoyuan City 333411, Taiwan (R.O.C.) (TAF: 3785) TEL: 886-3-327-3456 FAX: 886-3-327-0973 Test site Designation No. TW3785 with FCC. Wen 33rd.St. ADD: No.14-1, Ln. 19, Wen 33rd St., Guishan Dist., Taoyuan City 333010, Taiwan (R.O.C.) (TAF: 3785) TEL: 886-3-318-0787 FAX: 886-3-318-0287 Test site Designation No. TW0008 with FCC. Radio Exposure Evaluation Report Report No. : FA192716-01 TEL : 886-3-327-3456 Page Number : 6 of 7 FAX : 886-3-327-0973 Issued Date : Dec. 14, 2021 Report Template No.: HE1-A1 Ver4.0 Report Version : 01 FCC ID: PPQ-WM6321 2 Maximum Permissible Exposure 2.1 Limit of Maximum Permissible Exposure (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f 2 )* 6 30-300 61.4 0.163 1.0 6 300-1500 - - F/300 6 1500-100,000 - - 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power…
