PQC-867216AAccess Point

DRAFT - 03 JUN 2022 13:32 Smart-hopping 2.0 Access Point 1.4 GHz Installation Guide Part Number: 453464900911 Printed in the U.S.A. June 2022 First Edition *453564900911* DRAFT - 03 JUN 2022 13:32 Chapter 1: Proprietary Information This document contains proprietary information that is protected by copyright. Copyright Copyright © 2022 Koninklijke Philips N.V. All Rights Reserved. Manufacturer Philips Medizin Systeme Böblingen GmbH Hewlett-Packard-Str 2 71034, Böblingen, Germany United States Address Philips Medical Systems North America Company 222 Jacobs Street Cambridge, MA 02141 http://healthcare.philips.com This document was published in the United States of America. Trademark Acknowledgments All trademarks, trade names and company names referenced herein are used for identification purposes only and are the property of their respective owners. Warranty The information contained in this document is subject to change without notice. Philips Medical Systems Nederland B.V. reserves the right to make changes in specifications and/or to discontinue any product at any time without notice or obligation and will not be liable for any consequences resulting from the use of this publication. Printing History New editions of this document will incorporate all material updated since the previous edition. The documentation printing date and part number indicate its current edition. The printing date and edition number change when a new edition is printed. The document part number changes when extensive technical changes are incorporated. First Edition ............................................................................................................................................................................................... June 2022 1-ii DRAFT - 03 JUN 2022 13:32 Contents About This Guide Chapter 1: Overview Introduction ................................................................................................................................................................. 1-2 A General Description of the Smart-hopping Access Point .............................................................................. 1-3 Access Point Mounting Options ....................................................................................................................... 1-4 Power Source ...................................................................................................................................................... 1-4 Synchronization Signal ...................................................................................................................................... 1-4 Wireless Client Mobility ....................................................................................................................................... 1-4 Technical Alerts ................................................................................................................................................... 1-5 Firmware Updates .............................................................................................................................................. 1-5 Management Interfaces .................................................................................................................................... 1-5 Connectors and Status Indicators ............................................................................................................................ 1-7 Smart-hopping Access Point Connectors ........................................................................................................ 1-7 Smart-hopping Access Point Status LEDs ...................................................................................................... 1-8 Front Panel ....................................................................................................................................................... 1-8 Specifications ........................................................................................................................................................... 1-10 Ordering Information .............................................................................................................................................1-12 Regulatory Information ..........................................................................................................................................1-12 FCC Compliance.................................................................................................................................................. 1-12 Symbol Definitions ............................................................................................................................................. 1-13 Warnings ................................................................................................................................................................... 1-15 Chapter 2: Mount and Install the Smart-hopping 2.0 Access Point 1.4 GHz Access Point Placement Guidelines ........................................................................................................................ 2-2 Fixed Mounting the Smart-hopping Access Point to a Wall ............................................................................. 2-3 Installation ........................................................................................................................................................... 2-4 Fixed Mounting the Smart-hopping Access Point to a Wall (With Cosmetic Cover) .................................. 2-7 Installation ........................................................................................................................................................... 2-8 Flush Ceiling Mount (with Cosmetic Ring) ......................................................................................................... 2-12 Installation .....................................................…

Text truncated - open the document above for the full version.

Philips Medical Systems North America Co. Agent Authorization Company: Philips Medical Systems North America Co. Address: 3000 Minuteman Road Andover, MA 01810-1099 USA Product Name: Access Point Model Number(s): ITS867216A Product Description: Access Point We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023.01.03 Name: Delroy Smith Title: Company: Philips Medical Systems North America Co.

Philips Medical Systems North America Co. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023.01.03 Subject; Request for Confidentiality FCC ID: PQC-867216A To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations i n Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Delroy Smith Title: 文件名: FCC Short & Long Term Confidentiality Request Rev4 目录: \\192.168.1.31\01-进行中的案件\LGT22K037_香港 BV_Access Point_ITS867216A_FCC SDOC+FCC ID(递交)\3. 提交的资 料\Letter 模板: C:\Users\杏子 Cindy\AppData\Roaming\Microsoft\Templates\Normal.dotm 标题: <COMPANY HEADER> 主题: 作者: Fiona Ffuellenbach 关键词: 备注: 创建日期: 2017/8/11 3:12:00 修订号: 44 上次保存日期: 2023/1/5 13:52:00 上次保存者: [email protected] 编辑时间总计: 12 分钟 上次打印时间: 2023/1/5 13:58:00 打印最终结果 页数: 1 字数: 293 (约) 字符数: 1,675 (约)

Page 1 of 7 Report No.: LGT22K037 Appendix - External Photographs of EUT Constructional Details FCC ID: PQC-867216A Model Name: ITS867216A Photo 1 Photo 2 Remote antenna ANT 1 Remote antenna ANT 2 coaxial and unshielded twisted pair (UTP) cable Remote antenna Access Point Page 2 of 7 Report No.: LGT22K037 Photo 3 Photo 4 Page 3 of 7 Report No.: LGT22K037 Photo 5 Photo 6 Page 4 of 7 Report No.: LGT22K037 Photo 7 Photo 8 Page 5 of 7 Report No.: LGT22K037 Photo 9 Photo 10 Page 6 of 7 Report No.: LGT22K037 Photo 11 Photo 12 Page 7 of 7 Report No.: LGT22K037 Photo 13 Photo 14

Page 1 of 6 Report No.: LGT22K037 Appendix - Internal Photographs of EUT Constructional Details FCC ID: PQC-867216A Model Name: ITS867216A Photo 1 Photo 2 Page 2 of 6 Report No.: LGT22K037 Photo 3 Photo 4 Page 3 of 6 Report No.: LGT22K037 Photo 5 Photo 6 Page 4 of 6 Report No.: LGT22K037 Photo 7 Photo 8 Access Point 1.4GHz ANT 1 Access Point 1.4GHz ANT 2 Access Point BLE ANT BLE module 1.4GHz module Page 5 of 6 Report No.: LGT22K037 Photo 9 Photo 10 Page 6 of 6 Report No.: LGT22K037 Photo 11

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China RF TEST REPORT Product Name: Access Point Model Name: ITS867216A FCC ID: PQC-867216A Issued For : Philips Medical Systems North America Co. 3000 Minuteman Road Andover, MA 01810-1099 USA Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Report Number: LGT22K037H01 Sample Received Date: Nov. 14, 2022 Date of Tested: Nov. 14, 2022 – Dec. 06, 2022 Date of Issue: Dec. 06, 2022 Report No.: LGT22K037H01 Page 2 of 8 TEST REPORT CERTIFICATION Applicant Philips Medical Systems North America Co. Address 3000 Minuteman Road Andover, MA 01810-1099 USA Manufacturer RTX A/S Address Stroemmen 6 DK-9400 Noerresundby Denmark Product Name Access Point Trademark PHILIPS Model Name ITS867216A Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47CFR §2.1091 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT22K037H01 Page 3 of 8 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 EUT OPERATION CONDITION 6 2.4 CLASSIFICATION 6 2.5 TEST RESULT 7 Report No.: LGT22K037H01 Page 4 of 8 Revision History Rev. Issue Date Contents 00 Dec. 06, 2022 Initial Issue Report No.: LGT22K037H01 Page 5 of 8 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name Access Point Brand Name PHILIPS Model Name ITS867216A Series Model N/A Model Difference N/A Product Description The EUT is Access Point Operation Frequency: 1.4GHz: 1390-1400 MHz, 1427-1435 MHz BLE: 2402-2480 MHz Modulation Type: 1.4GHz: GFSK, DBPSK, DQPSK, D8PSK BLE: GFSK Antenna gain: 1.4GHz Access Point ANT 1: 1 dBi Access Point ANT 2: 1 dBi Remote antenna ANT 1: 2 dBi Remote antenna ANT 2: 2 dBi BLE 0 dBi Antenna Designation: 1.4GHz Access Point: metal antenna Remote antenna: rod antenna BLE metal antenna Power input DC 48V from LAN Port Hardware Version N/A Software Version N/A 1.2 TEST FACTORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Accreditation Certificate A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 Report No.: LGT22K037H01 Page 6 of 8 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 300 - 1500 -- -- F/300 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 300 - 1500 -- -- F/1500 1500 – 100000 -- -- 1.0 F= Frequency in MHz Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. 2.3 EUT OPERATION CONDITION EUT was enabled to transmit and receive at lowest, middle and highest channels. 2.4 CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance from the antenna should be included in the User manual. So, this device is classified as Mobile device. Report No.: LGT22K037H01 Page 7 of 8 2.5 TEST RESULT Turn up Frequency (MHz) Detector Turn up Power (dBm) SH 2.0 E-WMTS CH11 1391.452 Peak 15±1 CH12 1393.180 Peak 15±1 CH13 1394.908 Peak 15±1 CH19 1433.697 Peak 15±1 CH18 1431.969 AV 10±1 SH 1.0 WMTS CH1 1395.8977 AV 12±1 CH4 1427.8979 AV 12±1 CH6 1431.0965 AV 11±1 SH 2.0 WMTS CH14 1428.513 AV 11±1 CH16 1430.241 AV 9±1 CH18 1428.513 AV 9±1 BLE 2440 Peak 6±1 Antenna Gain (dBi) Mode Log scale Numeric scale 1.4GHz 2 1.585 BLE 0 1 Report No.: LGT22K037H01 Page 8 of 8 The max MPE of BLE & 1.4GHz simultaneous transmission: 0.005(BLE) + 0.01255(1.4GHz) = 0.01755 ＜ 1 ※※※※※END OF THE REPORT※※※※※ Protocol Max Turn up Power (dBm) Max Turn up Power (mW) ANT Gain (numeric scale) Power Density (mW/cm²) Limit (mW/cm²) Result SH 2.0 E-WMTS CH11 1391.452 16 39.811 1.585 0.01255 0.928 Pass CH12 1393.180 16 39.811 1.585 0.01255 0.929 Pass CH13 1394.908 16 39.811 1.585 0.01255 0.930 Pass CH19 1433.697 16 39.811 1.585 0.01255 0.956 Pass CH1…

Text truncated - open the document above for the full version.

Date: 09-Nov-2022 RTX3481 File: RTX3481 Technical Description _1_0.docx Ref.: FAJCM Page: 13 of 15 This document and the information contained is property of RTX A/S, Denmark, and should be regarded as confidential. Unauthorized copying is not allowed. The information in this document is believed to be correct at the time of writing. RTX A/S reserves the right at any time to change said content, circuitry and specifications. 8 Antenna Information The RTX3481 contains a total of 3 antennas. The WMTS uses two 1.4 GHz antennas in order to facilitate antenna diversity. The last antenna is an 2.4 GHz antenna for the BTLE 8.1 WTMS antennas The two WMTS antennas are metal antennas mounted on the PCB. They have similarities with an Inverted F structure. The have an intended even antenna pattern into the front of AP. The antenna polarization for the two antennas are mainly vertical. During operation the AP will from slot to slot choose the best antenna to used based on the measured signal strength. The peak antenna gains are approx. 1 dBi Figure 8 Antenna plot WMTS Antenna 1 Date: 09-Nov-2022 RTX3481 File: RTX3481 Technical Description _1_0.docx Ref.: FAJCM Page: 14 of 15 This document and the information contained is property of RTX A/S, Denmark, and should be regarded as confidential. Unauthorized copying is not allowed. The information in this document is believed to be correct at the time of writing. RTX A/S reserves the right at any time to change said content, circuitry and specifications. Figure 9Antenna plot WMTS Antenna 2 8.2 BTLE antenna The BTLE antenna is a metal antennas mounted on the PCB. It has similarities with an Inverted F structure. It has an intended even antenna pattern into the front of AP. The antenna polarization for the antenna is mainly vertical. The peak antenna gains is approx. 0 dBi Date: 09-Nov-2022 RTX3481 File: RTX3481 Technical Description _1_0.docx Ref.: FAJCM Page: 15 of 15 This document and the information contained is property of RTX A/S, Denmark, and should be regarded as confidential. Unauthorized copying is not allowed. The information in this document is believed to be correct at the time of writing. RTX A/S reserves the right at any time to change said content, circuitry and specifications. Figure 10Antenna Plot BTLE

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China RF TEST REPORT Product Name: Access Point Model Name: ITS867216A FCC ID: PQC-867216A Issued For : Philips Medical Systems North America Co. 3000 Minuteman Road Andover, MA 01810-1099 USA Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Report Number: LGT22K037RF02 Sample Received Date: Nov. 14, 2022 Date of Tested: Nov. 14, 2022 – Dec. 06, 2022 Date of Issue: Dec. 06, 2022 Report No.: LGT22K037RF02 Page 2 of 60 TEST REPORT CERTIFICATION Applicant Philips Medical Systems North America Co. Address 3000 Minuteman Road Andover, MA 01810-1099 USA Manufacturer RTX A/S Address Stroemmen 6 DK-9400 Noerresundby Denmark Product Name Access Point Trademark PHILIPS Model Name ITS867216A Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2013 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT22K037RF02 Page 3 of 60 Table of Contents 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 11 2.5 EQUIPMENTS LIST 12 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 TEST PROCEDURE 14 3.3 TEST SETUP 14 3.4 EUT OPERATING CONDITIONS 14 4. RADIATED EMISSION MEASUREMENT 16 4.1 RADIATED EMISSION LIMITS 16 4.2 TEST PROCEDURE 18 4.3 TEST SETUP 19 4.4 EUT OPERATING CONDITIONS 19 4.5 FIELD STRENGTH CALCULATION 20 4.6 TEST RESULTS 21 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 32 5.1 LIMIT 32 5.2 TEST PROCEDURE 32 5.3 TEST SETUP 32 5.4 EUT OPERATION CONDITIONS 32 5.5 TEST RESULTS 32 6. POWER SPECTRAL DENSITY TEST 33 6.1 LIMIT 33 6.2 TEST PROCEDURE 33 6.3 TEST SETUP 33 6.4 EUT OPERATION CONDITIONS 33 6.5 TEST RESULTS 33 Report No.: LGT22K037RF02 Page 4 of 60 Table of Contents 7. BANDWIDTH TEST 34 7.1 LIMIT 34 7.2 TEST PROCEDURE 34 7.3 TEST SETUP 34 7.4 EUT OPERATION CONDITIONS 34 7.5 TEST RESULTS 34 8. PEAK OUTPUT POWER TEST 35 8.1 LIMIT 35 8.2 TEST PROCEDURE 35 8.3 TEST SETUP 35 8.4 EUT OPERATION CONDITIONS 35 8.5 TEST RESULTS 35 9. ANTENNA REQUIREMENT 36 9.1 STANDARD REQUIREMENT 36 9.2 EUT ANTENNA 36 APPENDIX I - TEST RESULTS 37 DUTY CYCLE 37 MAXIMUM PEAK CONDUCTED OUTPUT POWER 40 -6DB BANDWIDTH 41 OCCUPIED CHANNEL BANDWIDTH 44 MAXIMUM POWER SPECTRAL DENSITY LEVEL 47 BAND EDGE 50 CONDUCTED RF SPURIOUS EMISSION 54 APPENDIX II - PHOTOS OF TEST SETUP 59 Report No.: LGT22K037RF02 Page 5 of 60 Revision History Rev. Issue Date Contents 00 Dec. 06, 2022 Initial Issue Report No.: LGT22K037RF02 Page 6 of 60 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Report No.: LGT22K037RF02 Page 7 of 60 1.1 TEST FACTORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Accreditation Certificate A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. Parameter Uncertainty Occupied Channel Bandwidth ±3.2 % RF Output Power, Conducted ±0.71dB Power Spectral Density, Conducted ±1.57 dB Unwanted Emission, Conducted ±0.63dB Conducted emission ±2.80dB All Emissions, Radiated (0.009-30MHz) ±2.16dB All Emissions, Radiated (30MHz-1GHz) ±4.40dB All Emissions, Radiated (1GHz-18GHz) ±5.49dB Temperature ±0.5°C Humidity ±2% Duty Cycle ±2.3% Report No.: LGT22K037RF02 Page 8 of 60 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Access Point Trademark PHILIPS Model Name ITS867216A Series Model N/A Model Difference N/A Product Description The EUT is a Access Point Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Radio Technology: BLE Bluetooth Configuration: BLE (1M PHY and 2M PHY) Number Of Channel: 40 Antenna Designation: Please refer to the Note 3. Antenna Gain (dBi) 0 Channel List Please refer to the Note 2. Power Input DC 48V from LAN Port Battery N/A Hardware version number N/A Software version number N/A Connecting I/O Port(s) Please refer to the Note 1. Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User Manual. Report No.: LGT22K037RF02 Page 9 of 60 2. Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequenc y (MHz) 00 2402 10 2422 20 2442 30 2462 01 2404 11 2424 21 2444 31 2464 02 2406 12 2426 22 2446 32 24…

Text truncated - open the document above for the full version.

Page 1 of 2 Report No.: LGT22K038 Appendix - Test Setup photos FCC ID: PQC-867216A Model Name: ITS867216A Radiated Spurious Emission Test Setup Photo - Below 1GHz Radiated Spurious Emission Test Setup Photo - Above 1GHz Page 2 of 2 Report No.: LGT22K038 Conducted Emission Test Setup Photo
