RF Mini Optical Mouse RECEIVER TRANSMITTER USB/PS2 CABLE Power from pc supply MCU RECEIVER BLOCK DIAGRAM BA TTER Y MCU BUTT ON AND SCROLL OPTICAL SENSOR ENTER MOUSE TRANSMITTER BLOCK DIAGRAM

Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan Tel: 886-3-4987684 Fax:: 886-3-4986528 PHOTOS OF EUT (Transmitter Part)

Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan Tel: 886-3-4987684 Fax:: 886-3-4986528 PHOTOS OF EUT (Transmitter Part) Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan Tel: 886-3-4987684 Fax:: 886-3-4986528 PHOTOS OF EUT (Transmitter Part)

1 2 3 4 56 ABCD 6 5 4 3 2 1 D CBA Title Number Revision Size B Date: 10-Jun-2002 Sheet of File: K:\sch \o-mouse\RX\clk-009G-03.sch Drawn By: P0.0 1 P0.1 2 P0.2 3 P0.3 4 P1.0 5 VSS 6 VPP 7 VREG 8 XTALIN/P2.1 9 XTALOUT 10 VCC 11 D- / SDATA 12 D+ /SCLK 13 P1.1 14 P0.7 15 P0.6 16 P0.5 17 P0.4 18 U2CY7C63723 VCC D13MM R6330R VCC R510K Q12N3906 Receiver RFVcc S1ID C14104 1234 CON14 HEADER C15 47uF/ 袒質電容 VCC R71K3 C13104 GND 1 VCC 8 GND 2 GND 7 GND 3 CLK 6 GND 4 DATA 5 U3 24C02 VCC L1 磁珠 L2 磁珠 CLK-009H-03 RF VCC C16104 O-MOUSEMINI USB RECEIVER X126.56MHz C127pF C233pF RF VCC X2455E C4104 C5105C3104 X3C28 RF VCC R1 33K C7105 C627pF 12345678 9 10111213141516 U13361C R210K C8102 R31M RF VCC C9104 ananlgy out R41M VCC C1082pF C1156pF C12300pF LOOP ANTENNA C17 100uF/16V C1847uF/16V D+D- VCCGND

1 2 3 4 56 ABCD 6 5 4 3 2 1 D CBA Title Number Revision Size B Date: 10-Jun-2002 Sheet of File: K:\sch\mini_2051\clk-021D-03.sch Drawn By: S1Microswitch S3Microswitch S4Microswitch R1710K R2410K R2610K 3.6V 3.6V 3.6V M KEY R KEY L KEY S2 Rubber (Reset) R1010K 3.6V COM BA S5ENCODER 3.6V C16104 C12DNF C13DNF C14DNF C15 104 X26MHz R2510K Q52N3906 BATTERY R9100R CLK-010C-03 P52 1 P51 18 P53 2 P50 17 TCC 3 OSCI 16 RESET 4 OSCO 15 VSS 5 VDD 14 P60.INT 6 P67 13 P61 7 P66 12 P62 8 P65 11 P63 9 P64 10 U1 78P156E C10104 C24104 C21102 C20 102 R7 100K R4100K 3.6V TP1 TP3 C23 20pF C2220pF OPTICAL-MOUSE Low Batter detect Q11N3904 L20.47uH X113.5075MHz R282K R310R R51K5 C1150pF C2150pF C433pF R6100K L4 1.5uH L30.47uH Q2 1N3904 R1 1K VD11SV270 C633pF C547pF R810R L12.7uH C333pF Loop Antenna C8120pF C9DNF TP2 TP4 C1133pF R27 6k8 Q61N3904 R2868K 123 U4DNF R14DNF C7180pF BC E 2002/1/9 SCLK 1 XA 2 XB 3 YB 4 YA 5 XY_LED 6 REFA 7 REFB 8 OSC_IN 9 GND 10 OSC_OUT 11 GND 12 Vdd 13 R_BIN 14 PD 15 SDIO 16 U3A2051 X3KBR-18-43-MSA 3.6V C244.7uF C25104 HLMP ED80 R2933K C264.7uF C27104 3.6v C19100uF/16V 2.4V Vin 1 GND 2 Vout 3 U29261-36CX (SOT-89) D2LGL34-20 L5 150uH +3.6V BATTERY Dip TYPE D3 DNF RX CHARGER + D4 DNF Solar CHARGER + 2051 VERSION R30100K 3.6V S6 SW DPDT R131M 1346 2 5

Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan TEST REPORT Reference No.:A02070405 Report No.:FCCA02070405 Page: 1 of 11 Date: Aug. 05, 2002 Product Name: Mini Optical Mouse (Tx ) Model Number: OPM-602 Applicant: CELLINK CO., LTD. 11F, NO.102, SEC.1, HSIN TAI WU RD., HIS-CHIC, TAIPEI, TAIWAN, R.O.C. Date of Receipt: Jul. 04, 2002 Finished date of Test: Aug. 02, 2002 Applicable Standards: 47 CFR Part 15, Subpart C ANSI C63.4:1992 We, Spectrum Research & Testing Laboratory Inc. , hereby certify that one sample of the above was tested in our laboratory with positive results according to the above-mentioned standards. The records in the report are an accurate account of the results. Details of the results are given in the subsequent pages of this report. Lab Code: 200099-0 FCC ID : PQY-4710874200104 Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan TEST REPORT Reference No.:A02070405 Report No.: FCCA02070405 Page: 2 of 11 Date: Aug. 05, 2002 Table of Contents 1. DOCUMENT POLICY AND TEST STATEMENT................................................3 1.1 DOCUMENT POLICY.........................................................................................3 1.2 TEST STATEMENT.............................................................................................3 2. DESCRIPTION OF EUT AND TEST MODE......................................................4 2.1 GENERAL DESCRIPTION OF EUT...................................................................4 2.2 DESCRIPTION OF EUT INTERNAL DEVICE.....................................................4 2.3 DESCRIPTION OF TEST MODE........................................................................4 2.4 DESCRIPTION OF SUPPORT UNIT..................................................................5 3. DESCRIPTION OF APPLIED STANDARDS......................................................6 4. RADIATED EMISSION TEST.............................................................................6 4.1 RADIATED EMISSION LIMIT..............................................................................6 4.2 TEST EQUIPMENT.............................................................................................7 4.3 TEST SET-UP.....................................................................................................8 4.4 TEST PROCEDURE...........................................................................................9 4.5 EUT OPERATING CONDITION..........................................................................9 4.6 RADIATED EMISSION TEST RESULT.............................................................10 5. TERMS OF ABRIVATION..................................................................................11 FCC ID : PQY-4710874200104 Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan TEST REPORT Reference No.:A02070405 Report No.: FCCA02070405 Page: 3 of 11 Date: Aug. 05, 2002 1. DOCUMENT POLICY AND TEST STATEMENT 1.1 DOCUMENT POLICY - The report shall not be reproduced except in full, without the written approval of SRT Lab, Inc. - The report must not be used by the applicant to claim that the product is endorsed by NVLAP. - The NVLAP logo applies only to the applicable standards specified in this report. 1.2 TEST STATEMENT - The test results in the report apply only to the unit tested by SRT Lab. - There was no deviation from the requirements of test standards during the test. - DC power source, 3V from battery, was used during the test. FCC ID : PQY-4710874200104 Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan TEST REPORT Reference No.:A02070405 Report No.: FCCA02070405 Page: 4 of 11 Date: Aug. 05, 2002 2. DESCRIPTION OF EUT AND TEST MODE 2.1 GENERAL DESCRIPTION OF EUT PRODUCT Mini Optical Mouse (Tx) MODEL NO. OPM-602 POWER SUPPLY DC 3V from Battery CABLE N/A I/O PORT N/A FREQUENCY BAND 26.96 ~ 27.28 MHz CARRIER FREQUENCY 27.015 MHz NUMBER OF CHANNEL 1 CHANNEL SPACING 25 kHz RF OUTPUT POWER 0 dBm I.F. & L.O. I.F. 0.455 MHz, L.O. 26.56 MHz MODULATION TYPE FSK BIT RATE OF TRANSMISSION 4.8k bps ANTENNA TYPE Printed loop antenna NOTE The EUT is the transmitter part of a Mini optical mouse. For more detailed features, please refer to the User’s Manual of EUT. 2.2 DESCRIPTION OF EUT INTERNAL DEVICE DEVICE BRAND / MAKER MODEL # FCC ID/DOC REMARK N/A 2.3 DESCRIPTION OF TEST MODE N/A (It is only applicable to more than one test mode.) FCC ID : PQY-4710874200104 Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan TEST REPORT Reference No.:A02070405 Report No.: FCCA02070405 Page: 5 of 11 Date: Aug. 05, 2002 2.4 DESCRIPTION OF SUPPORT UNIT The EUT was configured by the requirement of ANSI C63.4. All interface ports were connected to the appropriate support units via specific cables. The support units and cables are listed below. NO DEVICE BRAND MODEL # FCC ID / DOC CABLE N/A NOTE For the actual test configuration, please refer to the photos of testing. FCC ID : PQY-4710874200104 Spectrum Research & Testing Lab., Inc. No. 101-10, Ling 8, Shan-Tong Li, Chung-Li City, Taoyuan, Taiwan TEST REPORT Reference No.:A02070405 Report No.: FCCA02070405 Page: 6 of 11 Date: Aug. 05, 2002 3. DESCRIPTION OF APPLIED STANDARDS The EUT is a kind of ITE and according to the specifications provided by the applicant, it must comply with the requirements of the following standards: 47 CFR Part 15, Subpart C ANSI C63.4:1992 All tests have been performed and recorded as per the above standards. 4. RADIATED EMISSION TEST 4.1 RADIATED EMISSION LIMIT All emission from EUT, including any network of conductors and apparatus connected thereto, shall not exceed the level of field strength specified below FCC Part 15, Subpart C Section 15.227. FIELD STRENGTH (dBμV/m) FREQUENCY (MHz) DISTANCE (m) PEAK AV…

Text truncated - open the document above for the full version.

PHOTOS OF TESTING - Radiated test
