FCC ID: PQY-4710874204195 Operational Description of the equipment Bluetooth USB Adapter is a Bluetooth enabler, that enables your desktop or notebook computer to connect wirelessly to any other Bluetooth enabled computers and devices. It allows a working range of up to 10 meters (33 feet) with a 723 Kbps data rate transmission, and complies with Bluetooth 1.1 and USB 1.1 specifications. Bluetooth USB Adapter is an ideal solution for home and mobile networking needs. It is easy to install and use for wireless connectivity to such as cellular phones, PDAs, printers, computers, keyboards, mice etc. PRODUCT Mini Bluetooth 2.0 EDR USB Adapter MODEL NO. BTA-5020 POWER SUPPLY DC 5V, 100A FREQUENCY BAND 2400 ~ 2483.5MHz NUMBER OF CHANNEL 79 CHANNEL SPACING 1MHz RATED RF OUTPUT POWER 0dBm MODULATION TYPE GFSK BIT RATE OF TRANSMISSION 721dpi ANTENNA TYPE PCB antenna ANTENNA GAIN 0dBi DUTY CYCLE 50%
