PRB-MB-A815EP-11Mainboard

USER’S MANUAL More compatible, more functional and more competitive. Excellent quality and faster response. Supporting Intel Pentium III ® FCPGA, Celeron ® PPGA, Celeron ® FCPGA or Cyrix ® III Socket 370 Processors, UDMA33/66/100, PC100/133 SDRAM Quality, Performance Mainboards No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of MANUFACTURER. MANUFACTURER PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL MANUFACTURER, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF MANUFACTURER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THlS MANUAL OR PRODUCT. Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their respective companies, and are used only for identification or explanation and to the owners benefit, without intent to infringe. AMD, Duron, Thunderbird are registered trademark of AMD Corporation. VIA is a registered trademark of VIA Technologies, Incorporated. IBM, IBM PC, IBM PC/AT, PC-DOS, OS/2 and OS/2 WARP are registered trademarks of International Business Machines Corporation. Ms-DOS, Windows, Windows NT, Windows 95, Windows 98, Windows 2000 and WindowsME are registered trademarks of Microsoft Corporation. AMI BIOS is a product of American Megatrends, Inc. AWARD BIOS is a product of Award Software Inc. Third-party brands and names mentioned in this User’s Manual are the property of their respective owners. The product name and revision number are both printed on the board itself. Manual revisions are released for each board design represented by the digit before and after the period of the manual revision number. Manual updates are represented by the third digit in the manual revision number. SPECIFlCATlONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATION USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY MANUFACTURER. MANUFACTURER ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT. Copyright © 2001 Manufacturer All Rights Reserved. Manual Revision: 1.00 Release Date: January 2001 Part No: 90-A815E1-00-00 Page 2 Mainboard User's Manual Contents Table Of Contents Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 Fast Start Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 Checking the Package Contents . . . . . . . . . . . . . . . . . . . . .7 Mainboard Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 Jumper Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 7 Quick Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Installing the CPU . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Installing the Memory . . . . . . . . . . . . . . . . . . . . . . . . . .13 Attaching ATX Power Supply . . . . . . . . . . . . . . . . . . . .14 Floppy Disk Drive Connector . . . . . . . . . . . . . . . . . . . .15 IDE Device Connector . . . . . . . . . . . . . . . . . . . . . . . . .15 Mounting Mainboard to chassis . . . . . . . . . . . . . . . . . .16 Installing Add-in Boards . . . . . . . . . . . . . . . . . . . . . . . .17 BIOS Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40 CD Driver & Software Installation Guide . . . . . . . . . . . . . .49 Norton AntiVirus OEM Version Setup Guide . . . . . . . . .. 50 INSTANT ON Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52 Mainboard User's ManualPage 3 Table of Contents

Overview Thank You for purchasing our High Performance Mainboard. Our advanced technology mainboard is designed for processing speeds of 933MHz or above and is upgradeabled for future processors. The Intel Mainboard Utilizes 815E/815EP and ICH2 chipset provide an Integrated Bus Mastering IDE controller with two high performance IDE interfaces for up to four UDMA IDE devices (hard drives, or CD-ROM's). The LPC(Low-pin count) I/O controller integrates a floppy drive interface, two enhanced 16C550 compatible serial ports, one parallel port and one consumer infra red compatible interface.The ICH2 I/O controller integrates two USB 1.1 compliant controllers with a total of 4 ports. Intel 815E chipset support Intel Celeron,Intel Pentium III and Cyrix III processors on socket 370 with 100/133 SDRAM DIMM. Three DIMM slots support up to 512MB Memory Capacity. WAKEUP-LINK Header supports Wake-On-LAN. Integrated AC97 2.1 Compliant Codec with 3D Stereo enhancement (optional). Award 4M bits Firmware Hub compliant with PC99,ACPI//DMI power management. ATX 305mm x 210mm. Mainboard User's ManualPage 5 Overview Page 6 Mainboard User's Manual Fast Start Installation This section will aid you in quickly setting up the Mainboard. Be sure to take caution to avoid personal injury or damage to wiring due to sharp pins on connectors, printed circuit assemblies, rough edges and corners and hot components. Your Location Requirements Are: • A sturdy, level surface for placement • Space allowance around mainboard • A stable environment with no abrupt temperature or humidity changes • No exposure to chemicals or direct sunlight • Line voltage and frequency not varying more than + or -10% from the value stated on the package or nameplate (located on the back, opposite the power plug) Checking The Package Contents Remove the items from the box and make sure you have the following items before beginning. If any of the items below are missing, please contact the representative for part replacement. ATX Box Standard Package 1) Mainboard 2) Driver CD with Norton AntiVirus 2001 OEM Version 3) User Manual 4) IDE Hard Drive Ribbon Cable 5) Floppy Drive Ribbon Cable 6) USB Cable for onboard USB Header ( Optional ) 7) Modem Cable for Modem Header ( Optional ) Installation Mainboard User's ManualPage 7 Page 8 Mainboard User's Manual Mainboard Diagram Before we begin installing your series Mainboard, we have provided you with a diagram of the Mainboard to help you locate the appropriate “connectors”. The letters below describe the key Mainboard components. Page number in the right hand column will direct you to detailed description of the component. A815E / A815EP Option : AC97 2.1 Compliant 3D Audio Software 56K Modem Onboard COMPONENT PAGE A- PS/2 Mouse & Keyboard Connector . . . . . . . . . . . . . . . . . .41 B- ATX Power Supply Connector . . . . . . . . . . . . . . . . . . . . . .41 C- Universal Serial Bus (USB) Connector . . . . . . . . . . . . . . .42 D- Serial (COM1 & 2) Connector . . . . . . . . . . . . . . . . . . . . . . .42 E- Infra-Red (IR) Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42 F- Memory Module Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . .43 G- Parallel Port Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . .43 H- Accelerated Graphics Port (AGP) Connector . . . . . . . . . .43 I- Lithium Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44 J- PCI Add-in Board Connector . . . . . . . . . . . . . . . . . . . . . . .44 L- Modem Connector (Optional) . . . . . . . . . . . . . . . . . . . . . . .44 M- Front Panel Function Connector . . . . . . . . . . . . . . . . . . . . .44 N- Flash BIOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45 O- Floppy Drive Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45 P- IDE Device Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45 Q- WAKEUP-LINK Header . . . . . . . . . . . . . . . . . . . . . . . . . . . .46 R- Universal Serial Bus Header . . . . . . . . . . . . . . . . . . . . . . . .46 r- CNR Add-in Board Connector . . . . . . . . . . . . . . . . . . . . . . .46 S- CPU Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46 T- CPU / SYSTEM & AUXILIARY FAN Connector . . . . . . . . .47 U- Audio & Joystick Connectors . . . . . . . . . . . . . . . . . . . . . . .47 V- VGA Header (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . .48 W-Temperature Sensor Header . . . . . . . . . . . . . . . . . . . . . . . .48 X- CD Audio Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48 Y- Auxiliary Audio Connector . . . . . . . . . . . . . . . . . . . . . . . . . .48 z- Case Detect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48 Mainboard User's ManualPage 9 Installation

Jumper settings Set the Jumper JP1 default setting is [1-2], to (2-3) to clear CMOS. JP4 default setting is [1-2] to Panel speaker out, to (2-3) to mix out AC97 codec . JP6 default setting is OPEN, to Enable AC97 CODEC, to CLOSE to Disable AC97 CODEC. JP7 default setting is OPEN, to Enable MC97 CODEC, to CLOSE to Disable MC97 CODEC. Page 1090-A815E1-A2-00 7 Quick Steps Please follow these steps in order to assure that your series of Mainboard installation is successful. Please refer to the back chapters for further information regarding boot-up and configurations. An anti-static wrist band is recommended when handling electronic components, be sure your work area is static free before you begin this section. Page 11 Mainboard User's Manual The Mainboard provides a 370 pins, Socket 370. The CPU should have a fan attached to prevent overheating. If a fan is not present, user should purchase a fan prior to turning on the system. The recommended heatsinks for the Socket 370 processor are those with three-pin fans that can be connected to the fan connectors on the Mainboard. It provides the +12 Volts DC for your CPU cooling fan. Installing the CPU 7 Quick Steps CAUTION! Be sure that sufficient air circulation must be available across the processor’s heatsink. Without sufficient circulation, the processor could overheat and damage both the processor and the mainboard. You may install an auxiliary fan if necessary. Mainboard User's ManualPage 12 7 Quick Steps Page 13 Mainboard User's Manual After you have set the DIMM firmly into its socket, snap the white chip holders up to lock in the DIMM. Installing the Memory Memory is installed in DIMM Sockets 1-3 (F Mainboard in diagram) as follows : Mainboard User's ManualPage 14 ATX Power Supply Connector (20-pin ATXPWR) The single 20-pin connector (B in mainboard diagram) incorporates standard +/-5V and +/-12V, with a standby 5V. With a power supply that supports remote power on/off, the mainboard can turn off the system power through the software control, such as the shutdown in Windows 95 Start Menu. The BIOS system will turn the system power off when it receives the proper APM command from the OS. APM must be enabled in the BIOS and OS systems in order for the soft-off feature to work properly. Attaching the power supply wire IMPORTANT: Wire should always be connected with the red stripe on the Pin 1 side of the connector. The four corners of the connector's are labeled on the mainboard. ATX Power Connector Attaching ATX Power Supply. 7 Quick Steps Page 15 Mainboard User's Manual Floppy Disk Drive Connector (34-pin FLOPPY). This is a 34-pin connector that supports the provided floppy drive ribbon cable. After connecting the single end to the on-board “FLOPPY” connector, (O in mainboard diagram) connect the remaining plugs on the other end to the corresponding floppy drives. IDE Device Connector. The on-board IDE connectors (P in mainboard diagram) support the provided 40/80-pin IDE hard disk ribbon cable. After connecting the single end to the mainboard, connect the remaining plugs at the other end of your hard disk(s). If you install hard disks, you must configure the drives by setting its jumpers according to the documentation of your hard disk. Also, you may connect the hard disk drives so that both become Masters, using one ribbon cable on the primary IDE- connector, and the other on the secondary IDE connector. NOTE: For the flat ribbon cable connection, please make sure that the pin 1 of the ribbon cable (the red wire side of the cable) is correctly connected to the on-board connector's pin 1 as shown on the “mainboard diagram”. Floppy connection IDE connection Mainboard User's ManualPage 16 Mounting Mainboard to chassis Snap black mounting pins onto the mainboard as shown. Carefully install the mainboard into the computer chassis and align the corresponding mounting holes on the mainboard with the holes on you chassis. While chassis design varies you may need to refer to the chassis manual for the mainboard mounting area. Insert white pins through the chassis and through the mounting holes on the mainboard into the black pin making sure they are snapped fully into place. Black mounting pin Insert into chassis Insert white mounting pin 7 Quick Steps Page 17 Mainboard User's Manual PCI Board Installation Installing Add-in Boards First read your expansion card documentation for hardware and software settings that may be required to set up your specific card. Set any necessary jumpers on your expansion card and remove the cover plate on your computer case at the slot you intend to use. Keep the plate for possible future use. Carefully align the card's connector and press firmly. Secure the card on the slot with the screw you removed from the cover plate. Mainboard User's ManualPage 18 I/O connectors aligned with openings Make sure to align rear external I/O connector's with the corresponding openings in chassis shown below (A,C & G in mainboard diagram) You can now attach the Front Panel Function Connector (M in mainboard diagram) wires and Keyboard, Mouse and Monitor cables to the appropriate ports. Connect the main power cable and boot your system. Press the DEL key when prompted and continue BIOS configurations discussed in the next chapter.

BIOS Setup Mainboard User's ManualPage 20 Standard CMOS Feature Advanced CMOS Feature Advanced Chipset Feature Integrated Peripherals Power Management Setup PnP/PCI Configurations PC health Status Frequency/Votlage Control Load Fail-Safe Defaults Load Optional Defaults Setup Supervisor Password Setup User Password Set time & date, hard disk drive type, type of floppy drive, Monitor type. Select system boot sequence, floppy control, CPU cache settings, Shadow RAM. Configure chipset specific options and features. Configure onboard I/O device addresses and operating modes. Select various power saving options. Set PCI Plug and Play device options. Report system / CPU temperature and cooling fans status. Select CPU’s Front Side Bus (FSB) frequency and core/bus frequency ratio. Load settings that are more likely to configure a workable computer when something is wrong. If you cannot boot the computer successfully, select the Fail-Safe option and try to diagnose the problem after the computer boots. These settings do not provide optimal performance. Load settings that provide best performance characteristic. (Default factory settings) Change / Add / Remove supervisor password. Change / Add / Remove user password. Award BIOS Setup

BIOS Setup Page 21 Mainboard User's Manual Time / Date These fields provide you with the current date and time. Note that the hour is displayed as a 24-hour clock. For example, 1:00 PM is 13:00:00. Floppy Drive A, Floppy Drive B This option selects the type of floppy drives installed. Primary Master, Primary Slave, Secondary Master, Secondary Slave Standard CMOS Features Advanced CMOS Features Virus Warning Enabled / Disabled Virus Warning function. Default setting is "Disabled". CPU Internal Cache External Cache Enables processor on-chip L1 and L2 cache memory. Available settings are WriteBack, Write-Thru and Disabled. Default is "WriteBack". CPU L2 Cache ECC Cheeking This option enables Error Checking and Correction (ECC) on the processor’s L2 cache bus. Default is "Disabled". Quick Power on Self Test When Enabled, BIOS will skip certain power-on self-test (POST) procedures (such as memory test above 1MB) to speed up the boot process. Default setting is "Disabled". First / Second / Third Boot Device Assign the priority of each storage device to be the boot-up drive. Supported devices are IDE, Floppy, LS-120, ATAPI ZIP, CDROM, SCSI, NETWORK. Default boot sequence is Floppy -> IDE-0 -> CDROM. Mainboard User's ManualPage 22 Mainboard User's ManualPage 23 BIOS Setup Boot Other Devices Specifies whether BIOS to boot from other device not listed in the 1st/2nd/3rd Boot Device options when BIOS fail to boot from those devices. Default setting is "YES". Swap Floppy Drive Set this option to "Enabled" to permit drives A: and B: to be swapped. Default is "Disabled". Boot Up Floppy Seek Specify whether floppy drive A: will perform a Seek operation at system boot. Default setting is "Disabled". Boot Up NumLock Status Set this option to "OFF" to turn the Num Lock key off when the computer is booted so you can use the arrow keys on both the numeric keypad and the keyboard. Default is "ON". Gate A20 Option Sets "Fast", lets chipset control Gate A20; Sets "Normal", lets a pin in the keyboard controller control Gate A20. Default setting is "Fast". Typematic Rate setting Enabled / Disabled Typematic Rate setting, when enabled,the typematic rate and typematic delay can be selected. Default setting is "Disabled". Security Option Enables password checking every time the computer is powered on or every time BIOS Setup is executed. If System is chosen, a user password prompt appears every time the computer is turned on. If "Setup" is chosen, the password prompt appears if BIOS Setup is executed. Default is "Setup". OS Select For Dram > 64MB Set to "Enabled" if running OS/2 operating system and using more than 64MB system memory. Default is "Disabled". Page 24 Mainboard User's Manual SDRAM CAS Latency Time Specifies the number of SCLKs between the time when the Read command is sampled by SDRAM and the Whitney Sample reads data from SDRAM. Available settings are 3(SCLKs) or 2. Default is "3". DRAM Cycle Time Tras/Trc Specifies the length of the SDRAM cycle time in SCLKs. Available options are 7/9, and 5/7. Default is "7/9". SDRAM RAS-to-CAS Delay Specifies the length of the delay inserted between the RAS and CAS signals of the SDRAM system memory access cycle. The settings are Auto, 2 SCLKs or 3 SCLKs. Default setting is "3". SDRAM RAS Precharge Time Specifies the length of the RAS precharge part of the SDRAM system memory access. Available settings: Auto, 2 SCLKs, or 3 SCLKs. Default setting is "3". System BIOS Cacheable Enabled / Disabled System BIOS cache. Default setting is "Enabled". Video BIOS Cacheable Enabled / Disabled Video BIOS cache. Default setting is "Enabled". Memory Hole At 15M-16M Enabled / Disabled Memory Hole at 15M-16M. Default is "Disabled". Advanced Chipset Features Mainboard User's ManualPage 25 BIOS Setup CPU Latency Timer Enables CPU BIST. Default is "Disabled". Delayed Transaction Enables / Disables ICH2 (I/O Controller Hub 2) delayed transactions for internal register, Firmware Hub (FWH) and Low Pin Count (LPC) interface accesses. Default is "Disabled". AGP Graphics Aperture Size Sets maximum memory aperture for onboard AGP port. Available settings are 32MB and 64MB. Default is "64MB". System Memory Frequency Sets frequency of DIMM memory. Default is "AUTO". On-Chip Video Window Size Specifies amount of cache available for the graphics local memory window. Available settings are 32MB and 64MB. Default is "64MB". (815E only) CAS# Latency Sets number of SCLKs between the time when Read command is sampled by DRAM and the Whitney Sample reads data from SDRAM. Default is "Slow". (815E only) Paging Mode Control Enable / Disable Paging Mode. Default is "Closed". (815E only) RAS-to-CAS Override Sets delay override. Default is "Default". (815E only) RAS# Timing Sets clock frequency for RAS and RC. Default is "Slow". (815E only) Page 26 Mainboard User's Manual Power Management Setup ACPI Function Enabled/disabled ACPI Function. Default setting is "Disabled". ACPI Suspend Type Specifies ACPI Suspend type. Default setting is "S1(POS)" Power Management Specifies Power Management Mode. Default setting is "User Define". Video Off Method Specifies Video off Method. Default setting is "DPMS". Video Off In Suspend Specifies Video off in Suspend. Suspend Type Specifies Suspend Type. Default setting is "Stop Grant". Modem Use IRQ Sets Modem use IRQ Suspend Mode Specifies Suspend Mode. Default setting is "Disabled". Mainboard User's ManualPage 27 BIOS Setup HDD Power Down Specifies HDD Power Down Mode. Default setting is "Disabled". Soft Off by PWR_BTTN Sets Power Down Mode by PWR_BTTN. Default setting is "Instant-off". Wake-Up by PCI card Enabled / Disabled Wake-up by PCI card. Default setting is "Disabled". Power On by Ring Enabled / Disabled Power on by Ring. Default setting is "Enabled". USB KB Wake-up From S3 Enabled / Disabled USB KB Wake-up from S3. Default setting is "Disabled". CPU Thermal-Throttling Monitor CPU Temperature, slow down CPU Speed. Resume by Alarm Enabled / Disabled Resume by alarm.…

Text truncated - open the document above for the full version.

BIOS Setup Page 31 Mainboard User's Manual Auto Detect DIMM/PCI CLK Enabled \ Disabled Auto detect DIMM\PCI CLOCK. Default setting is "Enabled". Spread Spectrum This option turns on/off the clock generator’s Spread Spectrum feature to reduce Electromagnetic Interference (EMI) generated by high speed clock signals. Default setting is "Disabled". CPU Host/PCI Clock/PC133 Select the clock generator’s Front Side Bus frequency for CPU over-clocking. Default setting is "Default". CPU Clock Ratio Select CPU’s core/bus frequency ratio. This setting has no effect on processors with frequency ratio locked. Available settings are between 2x and 8x of the CPU BUS Speed. The ratio increases with 0.5 step. Default setting is "3x" (Safe). Frequency / Voltage Control PnP/PCI Configurations Reset configuration Data Enabled \ Disabled Reset configuration Data. Default setting is "Disabled". Resources Controlled by Sets the allocation of PCI resources. Available options are Manual and Auto(ESCD). Default setting is "Auto"(ESCD). BIOS automatically assigns resources. IRQ Resources When resources are controlled manually,assign each system interrupt a type,depending on the type of device using the interrupt. PCI/VGA Palette Snoop Enabled / Disabled PCI / VGA Palette Snoop, sets Enabled for having Video card on ISA Bus and VGA card on PCI Base, sets "Disabled" for VGA card only. Mainboard User's ManualPage 32 BIOS Setup Page 33 Mainboard User's Manual CPU Warning Temperature Specifies CPU warning temperature value. Available options are 50°C/122°F, 53°C/127°F,56°C/133°F, 60°C/140°F, 63°C/145°F, 66°C/151°F, 70°C/158°F and Disabled. Default setting is "Disabled". Current System Temperature Current CPU Temperature Detect System and CPU temperature automatically. System Fan Speed CPU Fan Speed Chassis Fan speed Detect Fan Speed Status automatically. Vcore/Vft/VCC3-3/+5V/+12V/-12V Detect System's Voltage status automatically. Shutdown Temperature This function will be effective only for the operating systems that support ACPI Function. Specifies Shutdown Temperature Value. Available option are 60°C/140°F, 65S°C/149°F, 70°C/158°F, 75°C/167°F and Disabled. Default setting is "Default". PC Health Status Fail-safe defaults contain the most appropriate values of the system parameters that allow minimum system performance. Load Fail-safe Defaults Mainboard User's ManualPage 34 Load Optimized Defaults Selecting this field loads the factory defaults for BIOS and Chipset Features which the system automatically detects. BIOS Setup Page 35 Mainboard User's Manual Set Supervisor / User password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. Type the password, up to eight characters and press<Enter>. The new password will clear the previously entered password from CMOS Memory, you will be asked to confirm the Password. Type the password again and press <Enter>, you may also press <ESC> to about the selection and not enter a password. Mainboard User's ManualPage 36 To disable password, just press <Enter> when you are prompted to enter password. A Message <<PASSWORD DISABLED!!!>> will appear to confirm the password being disabled. Once the password is disabled, the system will boot and you can enter setup freely. If you select "System" at "Security Option" in BIOS Features Setup Menu, you will be prompted for the password every time. If you select "Setup" at "Security option" in BIOS Features Setup Menu, you will be prompted only when you try to enter Setup. BIOS Setup Page 37 Mainboard User's Manual Type "Y" will quit the Setup Utility and Save the user setup value to RTC CMOS. Type "N" will return to Setup Utility. Save & Exit Setup Mainboard User's ManualPage 38 Type "Y" will quit the Setup Utility and Without Saving the User setup Value. Type "N" will return to Setup Utility. Exit Without Saving BIOS Setup Page 39 Mainboard User's Manual Glossary A PS/2 Mouse & Keyboard Connector The Mainboard provides two on-board PS/2 connectors, one for the keyboard, and one for the mouse. PS/2 devices all have a standard 6-pin round shape connector. If you are already using a PS/2 mouse or keyboard, simply plug them into the corresponding connector. No jumper settings are necessary. B ATX Power Supply Connector The Mainboard provides a single 20-pin ATX power supply connector, which incorporates standard +5V and +12V, 3.3V and soft-on/off signals. With a power supply that supports remote power on/off, the mainboard can turn off the system power through software control, such as the shutdown command in the Windows 95 / Windows 98 Start Menu. The BIOS system will turn the system power off when it receives the proper APM command from the OS. APM must be enabled in the BIOS and OS systems in order to set the soft-off feature working properly. Pin Signal Name Pin Signal Name 1 +3.3V 11 +3.3V 2 +3.3V 12 -12V 3 Ground 13 Ground 4 +5V 14 PW_ON 5 Ground 15 Ground 6 +5V 16 Ground 7 Ground 17 Ground 8 PWRGOOD 18 -5V 9 +5VSB 19 +5V 10 +12V 20 +5V Glossary Page 41 Mainboard User's Manual Glossary Mainboard User's ManualPage 42 About the Soft Touch Power Button In an ATX based system, the new soft touch power button replaces the main power switch that turns your system on and off. From an OFF state, you can switch the system ON by simply pressing the power button. From an ON state, the system can be turned OFF by pressing and holding the power button for four (4) seconds OR shut down instantly. The functions of the power button can also be altered in the Power Management section of the CMOS setup. C Universal Serial Bus (USB) Connector The Mainboard provides four 4-pin Universal Serial Bus (USB) connectors. USB is a new interface standard for adding external Plug-and-Play (PnP) devices to the computer system. Peripherals that support USB PnP capabilities can operate at up to a 12Mb/sec data transfer rate. Eventually, all external devices connected to your computer will …

Text truncated - open the document above for the full version.

Norton Anti-Virus OEM Version Setup Guide Step 1 : Load the Driver CD in CDROM and find the "Norton AntiVirus 2001 Install" Option. Step 2 : When CD finishes loading, press " Install Norton AntiVirus" to install the software. Mainboard User's ManualPage 50 Norton Anti-Virus Setup Guide Step 3 : Follow the installation procedures on screen. Step 4 : Select "Yes" and press "Finish" button to reboot computer. Page 51 Mainboard User's Manual Guide Introduce INSTANT ON function: INSTANT ON is a Windows 98 ACPI sleep mode function. When recovering from sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state. The “state” is stored in memory (RAM) before the system goes to sleep. During sleep mode, your system uses only enough energy to maintain critical information and system functions, primarily the system state and the ability to recognize various “wake up” triggers or signals, respectively. INSTANT ON function Installation Please follow the steps to complete the INSTANT ON function installation. There are two ways : 1. Setup with Windows 98 CD: A. Insert the Windows 98 CD into your CD-ROM drive, select Start, and then Run. B. Type (without quotes) “D:\setup /p j” in the window provided. Hit the enter key or click OK. C. After setup completes, remove the CD, and reboot your system (This manual assumes that your CD-ROM device drive letter is D:). For using the INSTANT ON function, the system must be in Windows 98 ACPI mode. Putting Windows 98 into ACPI mode is fairly easy. Mainboard User's ManualPage 52 INSTANT ON GUIDE A. When Windows 98 finishes loading, open the “Control Panel” in Windows 98 “My Computer” area. B. Double click the “System” item. C. Select the “Device Manager” tab and then the “System Devices” item. Double click the “Plug and Play BIOS” item or select “Properties” 2. Update from Windows98 (Advance Power Management) APM mode: If your Windows 98 system is in APM mode, please follow the steps to update your system to ACPI mode. Page 53 Mainboard User's Manual D. Select the “Driver” item and “Update Driver” E. The “Update Device Driver Wizard” will appear. Press the “Next” button F. In the “Up…
