chapter 2:Product Introduction A845E mainboard diagram page 3 M ainboard M anual Product Introduction chapter 2 Product Introduction A845DD mainboard *Support Intel 478pin Pentium4 FC-PGA *Support 400MHz System Bus *Intel 845 + ICH2 Chipset *Two 184pin DDR DIMM slots support up to 2G Memory Capacity *Support PC1600 and PC2100 DIMM(DDR200/DDR266) *6 x PCI slots, 1 x CNR slot *1 x 4X AGP expansion slot *4 x USB ports ( 2xRear USB, 2xFront) , 1 x IrDA port header *1 x FDD port, 1 x Parallel port with ESD/EMI protection, 2 x COMports *Dual IDE Channels support Four Ultra-DMA33/66/100 IDE Devices *Temperature, Fan speed and Voltage Hardware Monitor Support *ModemRing Wakeup for External Modem *WAKEUP-LINK Header to Support Wake-On-LAN *Integrated AC97 Audio Onboard *AC97 2.1 Compliant Codec with 3D Stereo Enhancement *1 x Line-out, 1 x Line-in, 1 x Mic-in *1 x CD-in, 1 x AUX-in, 1 x Game Port *Overcurrent protection over Keyboard & Mouse *Coloured Connectors : FDD, IDE, COMs etc. *Keyboard & PS/2 Mouse Wakeup *Suspend-to-RAM(STR) Technology to support Instant ON (Optional) *Phoenix BIOS PC99/ACPI/DMI Compliant *ATX Power Supply Interface *ATX form factor 305mm x 220mm page 4 M ainboard M anual chapter 2:Product Introduction A845DD mainboard diagram page 5 M ainboard M anual Product Introduction chapter 2:Product Introduction A845SDmainboard *Support Intel 478pin Pentium4 FC-PGA2 (Willamette/Northwood) *Support 400MHz Bus *Intel 845 + ICH2 Chipset *Suspend-to-RAM(STR) Technology to support Instant ON *Three DIMM slots support up to 3G Memory Capacity *Support 133MHz SDRAM DIMM *Jumperless for CPU Frequency setting *6x PCI slots, 1 x CNR slot *1 x 4X AGP expansion slot *4 x USB ports , 1 x IrDA port header *1 x FDD port, 1 x Parallel port with ESD/EMI protection, 2 x COMports *Dual IDE Channels support Four Ultra-DMA33/66/100 IDE Devices *Temperature, Fan speed and Voltage Hardware Monitor Support *ModemRing Wakeup for External Modem *WAKEUP-LINK Header to Support Wake-On-LAN *Integrated AC97 Audio Onboard *AC97 2.1 Compliant Codec with 3D Stereo Enhancement *1 x Line-out, 1 x Line-in, 1 x Mic-in *1 x CD-in, 1 x AUX-in, 1 x Game Port *Overcurrent protection over Keyboard & Mouse *Coloured Connectors : FDD, IDE, COMs etc. *Keyboard & PS/2 Mouse Wakeup *Phoenix BIOS PC99/ACPI/DMI Compliant *ATX Power Supply Interface *ATX form factor 305mmx 210mm page 6 M ainboard M anual chapter 2:Product Introduction A845SD mainboard diagram page 7 M ainboard M anual Product Introduction chapter 2:Product Introduction P845SD mainboard *Support Intel 478pin Pentium4 FC-PGA2 *Support 400MHz Bus *Intel 845 + ICH2 Chipset *Suspend-to-RAM(STR) Technology to support Instant ON *Two DIMMslots support up to 2G Memory Capacity *Support 133MHz SDRAM DIMM *Jumperless for CPU Frequency setting *3x PCI slots, 1 x CNR slot *1 x 4X AGP expansion slot *4 x USB ports , 1 x IrDA port header *1 x FDD port, 1 x Parallel port with ESD/EMI protection, 2 x COMports *Dual IDE Channels support Four Ultra-DMA33/66/100 IDE Devices *Temperature, Fan speed and Voltage Hardware Monitor Support *Modem Ring Wakeup for External Modem *WAKEUP-LINK Header to Support Wake-On-LAN *Integrated AC97 Audio Onboard *AC97 2.1 Compliant Codec with 3D Stereo Enhancement *1 x Line-out, 1 x Line-in, 1 x Mic-in *1 x CD-in, 1 x AUX-in, 1 x Game Port *Overcurrent protection over Keyboard & Mouse *Coloured Connectors : FDD, IDE, COMs etc. *Keyboard & PS/2 Mouse Wakeup *Phoenix BIOS PC99/ACPI/DMI Compliant *ATX Power Supply Interface *Micro ATX form factor 245mm x 211mm page 8 M ainboard M anual chapter 2:Product Introduction P845SD mainboard diagram page 9 M ainboard M anual Product Introduction

chapter 2:Product Introduction P845GL mainboard *Support Intel 478pin Pentium4 FC-PGA2 (Willamette/Northwood) *Support 400MHz Bus *Intel 845GL + ICH4 Chipset *Two DIMMslots support up to 2G Memory Capacity *Support PC1600 and PC2100 DDR DIMM(DDR200/DDR266) *Jumperless for CPU Frequency setting *3x PCI slots *6x USB2.0 ports (4xUSB2.0 in the Front panel,2xUSB2.0 in the rear panel) , 1x IrDA port header *1 x FDD port, 1 x Parallel port with ESD/EMI protection, 2 x COMports *Dual IDE Channels support Four Ultra-DMA33/66/100 IDE Devices *WAKEUP-LINK Header to Support Wake-On-LAN *Integrated 2D&3D Graphic Accelerate Port *Integrated AC97 Audio Onboard(Select 2ch,4ch,5.1ch)(optional) *AC97 2.1(or AC97 2.2) Compliant Codec with 3D Stereo Enhancement *1 xSpeaker(Front speaker), 1 x Mic-in(Center and Sub-woofer), 1 x Line- in(Rear-speaker) *1 x CD-in, 1 x Game Port *1xstandard Audio Front Panel Header *Overcurrent protection over Keyboard & Mouse *Coloured Connectors : FDD, IDE, COMs etc. *Phoenix BIOS PC99/ACPI/DMI Compliant *ATX Power Supply Interface *Micro ATX form factor 245mmx 190mm page 10 M ainboard M anual chapter 2:Product Introduction P845GLmainboard diagram page 11 M ainboard M anual Product Introduction chapter 2:Product Introduction P845GLP mainboard *Support Intel 478pin Pentium4 FC-PGA2 (Willamette/Northwood) *Support 400MHz Bus *Intel 845GL + ICH4 Chipset *Two DIMMslots support up to 2G Memory Capacity *Support PC1600 and PC2100 DDR DIMM(DDR200/DDR266) *Jumperless for CPU Frequency setting *3x PCI slots *6x USB2.0 ports (4xUSB2.0 in the Front panel,2xUSB2.0 in the rear panel) , 1x IrDA port header *1 x FDD port, 1 x Parallel port with ESD/EMI protection, 2 x COMports *Dual IDE Channels support Four Ultra-DMA33/66/100 IDE Devices *WAKEUP-LINK Header to Support Wake-On-LAN *Integrated 2D&3D Graphic Accelerate Port *Integrated AC97 Audio Onboard(Select 2ch,4ch,5.1ch)(optional) *AC97 2.1(or AC97 2.2) Compliant Codec with 3D Stereo Enhancement *1 xSpeaker(Front speaker), 1 x Mic-in(Center and Sub-woofer), 1 x Line- in(Rear-speaker) *1 x CD-in, 1 x Game Port *1xstandard Audio Front Panel Header *Overcurrent protection over Keyboard & Mouse *Coloured Connectors : FDD, IDE, COMs etc. *Phoenix BIOS PC99/ACPI/DMI Compliant *ATX Power Supply Interface *DIP mPGA 478 CPU Socket *Micro ATX form factor 245mmx 190mm page 12 M ainboard M anual chapter 2:Product Introduction P845GLPmainboard diagram page 13
  M ainboard M anual Product Introduction chapter 2:Product Introduction 2.1Connection Configuration PS/2 Keyboard and Mouse connector The Connector for the PS/2 Mouse & PS/2 Keyboard USBBus Connector A845E,P845GL,P845GS mainboard provide usb connector,support pnp function accord with spec of 2.0. Its data transmission rate support up to 480Mb/s. A845DD,A845SD,P845SD mainboard provideusb connector,support pnp function accord with spec of 1.1. Its data transmission rate support up to 12Mb/s. COM 1& COM 2 Connector The COM Connector for the COMDevices. Caution :COM2 in P845GL and P845GLP is a 9pin header. page 14 M ainboard M anual chapter 2:Product Introduction Parallel Port The port mainly use for Printer. Line-in,Microphone-in,Speaker-out MIDI/Joystick Line-in(Rear-speaker): It is the input that the audio port of tape or small recorder replay or record in 2ch stereo;but it is the output of rear-speaker(surround-out )when 4ch or 5.1ch Audio format is adopted on mainboard. Microphone-in(center and sub-woofer): It is the input of microphone in 2ch stereo;but it's the output of Bass sound box ( or Center-out) when 5.1ch Audio format is adopted on mainboard. Speaker(Front-speaker): It is the output of Two channel Audio.When 4ch or 5.1ch Audio format is adopted on mainboard,it's the output of Front speaker. MIDI/Joystick : It's connected a joystick or a MIDI device. Note: CS4299/ALC201support 2ch audio format; CMI9738 support 4ch audio format; CMI9739 support 5.1ch audio format. page 15
  M ainboard M anual Product Introduction Chapter 2:Product Introduction P4 Power Connector This is a simply diagram of P4 Power connector,which supply 5V and 12V standard Voltage and so on. COM2 header COM cable to connect with it.The red line of cable correspond with pin1 of the header. USB header use cable to connect with it. It support two usb port.The red line of cable correspond with pin1 of the header. IRDA connector The header pin-out is as follows PinSignal Name 1VCC,power source 2No Connection 3IRRX, infra-red receive 4Ground 5IRTX, infra-red transmit WOL Header The Wakeup-Link header used to connect an add-in NIC(Network Interface card) which has Wake-on-Lan capability. page 16 M ainboard M anual 1 (Only for A845E)

chapter 2:Production Introduction Front Panel Function Header The mainboard PANEL header has a standard set of switch and indicator connectors that are commonly found on ATX system cases.Use the illustration below to make the correct connections to the case switches and indicators.Front Panel Function Header include connections the following features: FunctionConnector Pin-Out Label System ResetRESET Power LEDPW-LED Hard Drive Activity LEDHD-LED Soft-Touch Button Power On/OffPW-BN External SpeakerSpeaker Audio Front Panel Header It provides the earphone output and microphone input in the Front panel of computer box. page 17 M ainboard M anual Product Introduction chapter 2:Product Introduction The header pin-out is as follows PinSignal Name 1mic-in 2Gnd 3Audio Vref-out 4+5V 5right channel output 6right channel return 7Hp-on 9left channel output 10left channel return Please add two jumper in 5-6 & 9-10 according to the picture when you don't need install Front Audio panel. CPU&SystemFAN Mainboard supply three FAN header with measure FAN speed function, which can be watched in BIOS. CautionAssure CPU FAN run in work state,or CPU will damage for overheat. CNR(Communication Audio Modem Riser) Support the CNR card with Audio/Modem/Lan function. Only for A845E / A845DD / A845SD / P845SD CDAudio connector It's connected to CD-ROM by a CD cable. AUX-IN Audio header It receive audio output from CD-ROM,TV or MPEG card. page 18 M ainboard M anual chapter 3:Setup Quickly Before you use this M/B,Please check chapter followas below! 3.1How to identify then product's mode? There is a bar-code that had adhibited on our product's box and mainboard.The bar-code follow as below(include serial number, production date ,classific -code,product's name and model). page 19 M ainboard M anual Setup Quickly Production date Classific code Serial number Mainboard name/model P815G-U chapter 3:Setup Quickly 3.2Set the jumper A845E A845DD A845SD jumper setting Notice:You must turn off the power of computer before you set the jumper or install hardware. page 20 M ainboard M anual chapter 3:Setup Quickly P845SD P845GL P845GLP jumper setting page 21 M ainboard M anual Setup Quickly chapter 3:Setup Quickly 3.3How to setup BIOS quickly? 1.Press "DEL" key inter BIOS setup when boot-strart. 2.Select "Load Optimized Defaults", press "Y",then "enter". 3.Enter "Advanced BIOS Feature""First Boot Device" to setup start-up order. 4.Enter "Save&Exit Setup",select "Y",then reboot. 3.4How to install mainboard driver Our driver CD supports Windows 98/98SE/ME/NT4.0/2000/XP OS.It's support Autosetup and Manualsetup model. A:Place the driver CD in your CD-ROM when you have installed the OS. And the CD will load device information ,the opening screen of CD appears. page 22 M ainboard M anual chapter 3:Setup Quickly After a while,appear following menu.(Accord different mainboardthe menu is different) etc:M/B:P845GL, with onboard sound(CMI9738,Four channel Audio). Click highlight itemand complete the driver install with the prompt Notice:If window appear introduction"You need not install this drive in Winxx" that means the OS has included the device driver and you don't need to install it. B:When your need to Manualsetup, please follow the list: First :You need to select the type of M/B which your purchased .We provide 3 types in our CD : ATX ,MICRO-ATX ,BABY-AT page 23 M ainboard M anual Setup Quickly

chapter 3:Setup Quickly Second: You need to select the OS type which you have installed. Third: Select the install item,shows as below: 1.Chipset driver: Outline the OS how the chipset components shall be configured. 2.Modem: If the M/B which you purchased integrated the Modem, you need to select this item to install the Modem driver.. 3.Sound chip drive: Our M/B integrated the onboard sound codec (AC97). If you want to use this onboard sound codec, you need to select the IC type which show as below, and install the driver. 4.UATA Driver: Intel Ultra ATA optimize program, increase the efficiency of IDE.(Option install) At the end of the installation of drive, we recommend to restart your computer and assure program setting. page 24 M ainboard M anual chapter 3:Setup Quickly THE SOUND CODEC IC (AC97) INTEGRATED ON YOU M/B ALC201ACS4299CMI9738CMI9739 3.5Howto enable 4ch or 5.1ch output This question will be explain by CMI9738 in Win2000. 1) Please select the logo,which shows"C-media Audio Configuration",click the mouse left button,and soon the dialog box will be shown. 2) In the dialog box ,select the itemof "4",which is the selection of four channel output.Click "ok",and four channel output is enabled. page 25 M ainboard M anual Setup Quickly chapter 3:Setup Quickly 3.6How to identity that Four channel output or 5.1 channel output is enabled? It's still explain by CMI9738. 1 First :install CMI9738 Four channel Audio driver and applications: a.Select the CMI9738 Audio installation in the Mainboard CD,and the dialog box will be shown: b. Select "Install Device Driver and Applications",The dialog boxes will be shown one by one in the list.Please click the "next" in picture 1--picture 5. Picture 1Picture2 page 26 M ainboard M anual chapter 3:Setup Quickly Picture3Picture 4 Picture5Picture6 page 27 M ainboard M anual Setup Quickly chapter 3:Setup Quickly c. At last the diagram will be shown.Click"Finish",and the installation of Audio Applications is over. d.Install Audio Driver.when the picture 2 is shown,click "ok",and restart your computer.The whole installation is over. picture 1 picture 2 page 28 M ainboard M anual Chapter 3:Setup Quickly 2Open the application of"Muti-channel audio demo"in the menu of " C-media Audio". 3 Next diagram. 4 Click "Demo1" or "Demo2"and Audio output should happen in the Front speaker and Rear speaker. page 29 M ainboard M anual Setup Quickly chapter 3:Setup Quickly 3.7Howto set Super password and User password Please follow the steps as belowto set the Super password and user password; 1)Press "DEL" key inter bios setup when boot-start; 2) In"Set Supervisor Password"set super password.Please enter according to the introduce. 3) In"Set User Password"set user password.Please enter according to the introduction. 4) After you finish the setting of password,you should set the option" Security Option",which lies in Advanced BIOS Features
item. If "System" is chosen, a user password prompt appears every time the computer is turned on. If "Setup" is chosen, the password prompt appears when you try to enter setup . 5) After finished your setting,please don't forget to save it and enable it effective. 6) When you forget your password for some reason,you can open you computer,clear CMOS in Power-off.(refer 3.2) page 30 M ainboard M anual chapter 4:BIOS Setting 4.1AWARD BIOS Description The BIOS (Basic Input/Output system) provides the low-level support for the standard devices such as disk drives,serial and parallel ports.It contains codes for advanced features found on the system board such as virus and password protection. it is very important to configure the BIOS correctly;otherwise the system board may not work properly.There are three situations for the user to configure the BIOS. * The hardware configuration data stored in the BIOSneed to be changed according to the new hardware installed. * To configure the provided special feature of the BIOS. * The CMOS RAM has lost the content due to out of battery. Starting AWARD BIOS setup The bios read the system information contained in the CMOS and begins the process of checking out the systemand configuring it. After the POST (Power On Self Test) has finished,it'll appear the following message on the screen: "Press DEL to enter SETUP" Press the <DEL>key to call up the Setup.When you invoke Setup,the CMOS SETUP main menu appears the following options.(Its option may have little difference for different model). page 31 M ainboard M anual B IO S S ettin g chapter 4:BIOS Setting Award BIOS Setup Standard CMOS FeatureSet time & date, hard disk drive type, type of floppy drive, Monitor type. Advanced CMOS FeatureSelect systemboot sequence, floppy control, CPU cache settings, Shadow RAM. Advanced Chipset FeatureConfigure chipset specific options and features Integrated PeripheralsConfigure onboard I/O device addresses and operatingmodes. Power Management SetupSelect various power saving options. PnP/PCI ConfigurationsSet PCI Plug and Play device options. PC health StatusReport system / CPU temperature and cooling fans status. Frequency/Voltage ControlSelect CPU' s Front Side Bus (FSB) frequency and core/bus frequency ratio. Load Fail-Safe DefaultsLoad settings that are more likely to configure a workable computer when something is wrong. If you cannot boot the computer successfully, select the Fail-Safe option and try to diagnose the problem after the computer boots. These settings do not provide optional performance. Load Optional DefaultsLoad settings that provide best performance characteristic. (Default factory settings) Setup Supervisor PasswordChange / Add / Remove supervisor password. Setup User PasswordChange / Add / Remove user password. page 32 M ainboard M anual chapter 4:BIOS Setting 4.2 Standard CMOS Features Time / Date These fields provide you with the current date and time. Note that the hour is displayed as a 24-hour clock. For example, 1:00 PM is 13:00:00. Floppy Drive A, Floppy Drive B(A845DD,…

Text truncated - open the document above for the full version.

chapter 4:BIOS Setting 4.5Integrated Peripherals On-Chip Primary PCI IDE Enabled / Disabled on-chip primary PCI IDE. Default setting is "Enabled". On-Chip Secondary PCI IDE Enabled / Disabled on-chip Secondary PCI IDE. Default setting is "Enabled". IDE Primary Master / Slave PIO IDE Secondary Master / Slave PIO Specify the IDE mode for the system. IDE Primary Master / Slave UDMA IDE Secondary Master / Slave UDMA Auto / Disabled IDE UDMA function feature. Default setting is "Auto", which lets BIOS determine. USB Controller Enabled / Disabled USB Controller. Default setting is "Enabled". USB Keyboard Support Enabled / Disabled USB Keyboard Support in DOS. Default setting is "Disabled" AC97 Audio Default setting is "Auto", BIOS will automatically detect onboard AC97 Audio. AC97 Modem Default setting is "Auto", BIOS will automatically detect onboard AC97 Modem. page 38 M ainboard M anual chapter 4:BIOS Setting Onboard /CNR LAN selection Select "onboard" to enable the optional onboard LAN function.Selects "Ext.CNR " to disable onboard LAN function and uses LAN function on CNR card. Init Display First Default setting is "PCI Slot", sets Init Display First to PCI Slot. Onboard AC97 Control IDE HDD Block Mode Enabled / Disabled IDE HDD Block Mode. Default setting is "Enabled". Power On Function Specifies the keyboard hot key, mouse button, power button to wakeup the computer from S3-S5 state. Available options are Button only: Password, Hot key, Mouse left, Mouse right, Any key, keyboard 98. Default setting is Button only. KB Power On Password Sets Keyboard Power on Password. Hot Key Power On Sets power on Hot key. Default setting is "Ctrl-F1". On-board FDC Controller Enabled / Disabled on-board FDC controller. Default setting is "Enabled". Onboard Serial Port 1 & 2 Specify the I/O port addresses of serial port 1 and 2. Available settings are Aut o, Disabled, 3F8h, 2F8h, 3E8h and 2E8h. Default setting is "Auto". UART Mode Select Specifies the operation mode of onboard Serial Port 2. The onboard Serial Port 2 can be configured as an Infrared(IR) port or an ordinary RS-232 serial port. Available settings are Normal, IrDA and ASKIR. Default is "Normal". RxD,TxD Active Options are "Hi,Hi","Hi,Lo","Lo,Lo","Lo,Hi". IR Transmission Delay Enabled / Disabled IR Transmission Delay. UR2 Duplex Mode This option is not available when UART is set to "Normal". Available options are Half Duplex and Full Duplex. Default setting is "Half Duplex" page 39 M ainboard M anual B IO S S ettin g chapter 4:BIOS Setting Use IR pins Setting IR mode.Default is IR_Rx2Tx2. Onboard Parallel Port Specifies the I/O port address of the onboard parallel port. Available settings are Auto, Disable, 378h, 278h and 3BCh. Default is "Auto". Parallel Port Mode Specifies the onboard parallel port mode. Available options are Normal, Bi-Dir, ECP and EPP. Default is "ECP". EPP Mode Select Specifies the Enhanced Parallel Port specification version number. This option only appears if the Parallel Port Mode is set to "EPP". The settings are 1.7 or 1. 9. Default is N/A because the default setting for the Parallel Port Mode option is not EPP. ECP Mode USE DMA This option only appears if the Parallel Port Mode option is set to ECP. It assigns a DMA channel to the onboard parallel port. Available settings are 1, 3. Default is "3". Game Port Address Specifies the Onboard Game Port I/O address. Available settings are 201, 209, and Disabled. Default is "201". Midi Port Address Specifies the I/O address of the MIDI interface on the Onboard Game Port. Available options are 300, 330 ,290 and Disabled. Default is "330". Midi Port IRQ Assigns the IRQ line to the MIDI interface. Available options are 5 and 10. Default setting is "10". This option is not available if the Onboard Midi Port is disabled S-232 serial port. page 40 M ainboard M anual chapter 4:BIOS Setting 4.6Power Management Setup ACPI Function Enabled/disabled ACPI Function. Default setting is "Disabled". ACPI Suspend Type Specifies ACPI Suspend type. Default setting is "S1(POS)" Power Management Specifies Power Management Mode. Default setting is "User Define". Video Off Method Specifies Video off Method. Default setting is "DPMS". Video Off In Suspend Specifies Video off in Suspend. Suspend Type Specifies Suspend Type. Default setting is "Stop Grant". Suspend Mode Specifies Suspend Mode. Default setting is "Disabled". HDD Power Down Specifies HDD Power Down Mode. Default setting is "Disabled". Soft Off by PWR_BTTN Sets Power Down Mode by PWR_BTTN. Default setting is "Instant-off". CPU THRM-Throttling Monitor CPU Temperature, slow down CPU Speed. page 41 M ainboard M anual B IO S S ettin g chapter 4:BIOS Setting 4.7PnP/PCI Configurations Reset configuration Data Enabled \ Disabled Reset configuration Data. Default setting is "Disabled". Resources Controlled by Sets the allocation of PCI resources. Available options are Manual and Auto (ESCD). Default setting is "Auto"(ESCD). BIOS automatically assigns resources. IRQ Resources When resources are controlled manually,assign each system interrupt a type, depending on the type of device using the interrupt. PCI/VGA Palette Snoop Enabled / Disabled PCI / VGA Palette Snoop, sets Enabled for having Video card on ISA Bus and VGA card on PCI Base, sets "Disabled" for VGA card only. page 42 M ainboard M anual chapter 4:BIOS Setting 4.8PC Health Status Current SystemTemperature Current CPU Temperature Detect System and CPU temperature automatically. System Fan Speed CPU Fan Speed Detect Fan Speed Status automatically. Vcore/VDDQ/VCC3-3/+5V/+12V/-12V Detect System Voltage status automatically. page 43 M ainboard M anual B IO S S ettin g chapter 4:BIOS Setting 4.9Frequency Control -9
 CPU Clock Ratio Select CPU core/bus frequency ratio. This setting has no effect on processors with frequency ratio locked. Auto Detect PCI CLK Enabled \ Disabled Auto detect PCI CLOCK. Default setting is "Enabled". Spread Spectrum This option turns on/off the Spread…

Text truncated - open the document above for the full version.

chapter 5:Hardware Installation Please followthese steps in order to assure that your series of mainboard installation is successful. Please refer to the back chapters …
