PRL-IWE100UWireless USB Adapter

InterEpoch Wireless USB Adapter Version: 2.01 --- - March 2001 Copyright Statement No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, recording or otherwise without the prior writing of the publisher. Windows 95/98 and Windows 2000 are trademarks of Microsoft Corp. Pentium is trademark of Intel. All copyright is reserved. Table of Contents REGULATORY INFORMATION -------------------------------------------------------------- 1. WELCOME----------------------------------------------------------------------------------------- 1.1 Kit Contents------------------------------------------------------------------------------------ 1.2 Advantages for Using Wireless Network -------------------------------------------------- 2. QUICK START TO WIRELESSS NETWORKING----------------------------------------- 3. STEP BY STEP INSTALLATION GUIDE -------------------------------------------------- 3.1 Install the InterEpoch 802.11b USB WLAN Utility / Driver---------------------------- 3.2 Install the USB Adapter--------------------------------------------------------------------- 3.3 InterEpoch 802.11b USB WLAN Utility--------------------------------------------------- 3.4 Remove your USB Adapter------------------------------------------------------------------- 3.5 Uninstall the InterEpoch 802.11b USB WLAN Utility / Driver------------------------- 4. APPLICATION------------------------------------------------------------------------------------- 4.1 File Sharing in Microsoft Windows 98------------------------------------------------------ 4.2 Printer Sharing in Windows 98-------------------------------------------------------------- 4.3 Using the shared folder------------------------------------------------------------------------ 4.4 Using the Shared Network printer----------------------------------------------------------- 5. TROUBLESHOOTING----------------------------------------------------------------------------- 5.1 Check the Various Properties of the Card--------------------------------------------------- 5.2 Microsoft Networking Checklist--------------------------------------------------------------- 5.3 Others--------------------------------------------------------------------------------------------- Regulatory Information The manufacturer is not responsible for any radio or television interference caused by unauthorized modification of this device or the substitution or attachment of connecting cables and equipment other than specified. The correction of interference caused by such unauthorized modification, substitution or attachment will be the responsibility of the user. Built-in antennas, whether installed indoors or out, should be installed only by experienced antenna installation professionals who are familiar with local building and safety codes and, wherever applicable, are licensed by the appropriate government regulatory authorities. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. USA – Federal Communications Commission (FCC) This equipment has been tested and found to comply with the limits for Class B Digital Devices, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communications, However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna - Increase the separation between the equipment and the receiver - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. EU Declaration of Conformity (Europe) USB adapter conforms to the specifications listed below, following the provisions of the Low Voltage Safety EN60950/IEC950 EMC ETS 300 328 ETS 300 826 1. Welcome Thank you for purchasing our InterEpoch Wireless USB Adapter. It will be interoperable among IEEE 802.11b standard compliant products from other manufacturers and allows you to build a wireless LAN. Besides, you can use your PC to connect with an access point wirelessly to share the wired network resource. After install InterEpoch Wireless USB Adapter, you can: a. Share your Internet access by using just one connection b. Share printers and other peripheral devices c. Share data and image files between networked PCs d. Play multi-player games InterEpoch 802.11b Wireless LAN can wirelessly transmit and receive data, minimizing the need for wired connections, at a speed of up to eleven megabit per second. With InterEpoch 802.11b Wireless LAN you can locate your PC wherever you want without wires and cables. InterEpoch 802.11b Wireless LAN provides LAN users with an access to real-time information anywhere in their organization. The mobility provides productivity and service, which are not available under wired networks. The InterEpoch 802.11b Wireless LAN configuration is easy to change from peer-to-peer networks, suitable for a small number of users, to full infrastructure networks of thousands of users that allow roaming around a broad area. Please read this manual to get familiar with the InterEpoch 802.11b Wireless LAN. This manual contains detailed instructions in operation of this product. Please keep this ma…

Text truncated - open the document above for the full version.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 August 1, 2001 RE: Interpoch Technology Inc. FCC ID: PRL-IWE100U There continues to be some minor problems with Exhibits associated with several of your spread spectrum reports. Please address. 1.) The only items which should be checked off as Confidential at the AmericanTCB website are those items which are noted in the Request for Confidentiality letter. When this procedure is not followed, extra processing time may be added to the application. 2.) Cover Letters can never be held Confidential. This flag will be removed from the POA and Confidentiality Letter before uploading to the FCC website. 3.) The photographs are a mix of Internal and External views. Please segregate the photos into one exhibit for Internal Photographs, and a second exhibit for External Photographs. Since Confidentiality is requested for Internal Photographs, the Grant cannot be issued until these are properly separated. 4.) Please provide better photographic views of the external ports on this device. 5.) Please make all photographs one to a page. 2.1033(b)(7) implies the preferred size is A4 (8” x 10”). 6.) Please shrink the total file sizes for photographs. There are very few instances where a complete set of internal or external views should be more than 1MB. William H. Graff Examining Engineer President and Director of Engineering mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

FCC ID: PRL-IWE100U Report No.: RF900606R03 1 Issued: July 16, 2001 ANNEX PHOTOGRAPHS OF EUT

FCC ID: PRL-IWE100U Report No.: RF900606R03 4 Issued: July 16, 2001 FCC ID: PRL-IWE100U Report No.: RF900606R03 5 Issued: July 16, 2001

FCC ID : Label Location

ADT Number: 900606R02 1 FCC TEST REPORT REPORT NO.: RF900606R03 MODEL NO.: IWE100U ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:Interepoch Technology Inc. ADDRESS: 7F, No. 3, Alley 6, Lane 235, Pao Chiao Rd., Hsin-Tien, Taipei Hsien, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 Lab Code: 200102-0 ADT Number: 900606R02 2 RF Exposure Measurement 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz ADT Number: 900606R02 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5 Climate Condition The temperature and related humidity: 30 deg. C and 60 % RH 6. Classification This device is not fixed inside the host equipment, it is connected with host through wire. So it is easy to be re-located in the place where at least 20 cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. ADT Number: 900606R02 4 7Test Results 7.1 Printed Antenna 7.1.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is –1dBi or 0.79 (numeric). 7.1.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) EIRP OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241214.830.97 624379.570.78 1124628.410.73 7.2 Dipole Antenna 7.2.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 1dBi or 1.26 (numeric). 7.2.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) EIRP OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241214.831.22 624379.570.98 1124628.410.92 The minimum allowable distance is very close to the enclosure of the antenna. So, the user has no need to worry about the harmfulness of radiation. But it is recommended to always keep, at least, 20cm separation distance with the antenna.

FCC ID: PRL-IWE100U Report No.: RF900606R03 1 Issued: July 16, 2001 FCC TEST REPORT REPORT NO.: RF900606R03 MODEL NO.: IWE100U RECEIVED: June 6, 2001 TESTED: June 5 ~ June 29, 2001 APPLICANT:INTEREPOCH TECHNOLOGY INC. ADDRESS: 7F, No.3, Alley 6, Lane 235, Pao Chiao Rd., Hsin-Tien City, Taipei Hsien, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsuen, Linko, Taipei, Taiwan, R.O.C. This test report consists of 62 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 Lab Code: 200102-0 FCC ID: PRL-IWE100U Report No.: RF900606R03 2 Issued: July 16, 2001 Table of Contents 1CERTIFICATION ........................................................................................... 4 2SUMMARY OF TEST RESULTS................................................................... 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................. 6 3.2DESCRIPTION OF TEST MODES ............................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS............................... 7 3.4DESCRIPTION OF SUPPORT UNITS.......................................................... 8 4TEST TYPES AND RESULTS ...................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT ................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................. 9 4.1.2TEST INSTRUMENTS .................................................................................. 9 4.1.3TEST PROCEDURES................................................................................. 10 4.1.4TEST SETUP .............................................................................................. 10 4.1.5EUT OPERATING CONDITIONS.................................................................11 4.1.6TEST RESULTS(A) ..................................................................................... 12 4.1.7TEST RESULTS(B) ..................................................................................... 18 4.2RADIATED EMISSION MEASUREMENT ................................................... 24 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ................................ 24 4.2.2TEST INSTRUMENTS ................................................................................ 25 4.2.3TEST PROCEDURES................................................................................. 26 4.2.4TEST SETUP .............................................................................................. 27 4.2.5EUT OPERATING CONDITIONS................................................................ 27 4.2.6TEST RESULTS(A) ..................................................................................... 28 4.2.7TEST RESULTS(B) ..................................................................................... 33 4.36DB BANDWIDTH MEASUREMENT.......................................................... 38 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT........................................ 38 4.3.2TEST INSTRUMENTS ................................................................................ 38 4.3.3TEST PROCEDURE ................................................................................... 39 4.3.4TEST SETUP .............................................................................................. 39 4.3.5EUT OPERATING CONDITIONS................................................................ 39 4.3.6TEST RESULTS.......................................................................................... 40 4.4MAXIMUM PEAK OUTPUT POWER .......................................................... 44 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ........... 44 4.4.2TEST INSTRUMENTS ................................................................................ 44 4.4.3TEST PROCEDURES................................................................................. 45 FCC ID: PRL-IWE100U Report No.: RF900606R03 3 Issued: July 16, 2001 4.4.4TEST SETUP .............................................................................................. 45 4.4.5EUT OPERATING CONDITIONS................................................................ 45 4.4.6TEST RESULTS.......................................................................................... 46 4.5POWER SPECTRAL DENSITY MEASUREMENT ..................................... 47 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ................... 47 4.5.2TEST INSTRUMENTS ................................................................................ 47 4.5.3TEST PROCEDURE ................................................................................... 48 4.5.4TEST SETUP .............................................................................................. 48 4.5.5EUT OPERATING CONDITIONS................................................................ 48 4.5.6TEST RESULTS.......................................................................................... 49 4.6BAND EDGES MEASUREMENT ................................................................ 53 4.6.1LIMITS OF BAND EDGES MEASUREMENT ............................................. 53 4.6.2TEST INSTRUMENTS ................................................................................ 53 4.6.3TEST PROCEDURE ................................................................................... 53 4.6.4EUT OPERATING CONDITION .................................................................. 54 4.6.5TEST RESULTS..............................…

Text truncated - open the document above for the full version.

FCC ID: PRL-IWE100U Report No.: RF900606R03 1 Issued: July 16, 2001 ANNEX PROCESSING GAIN OF DIRECT SEQUENCE SPREAD SPECTRUM MEASUREMENT 1. 1.1. 1. LIMITS OF PROCESSING GAIN OF A DIRECT SEQUENCE SPREAD SPECTRUM MEASUREMENT The limit of processing gain is 10dB 1.1 TEST INSTRUMENTS & SUPPORT UNIT Description & ManufacturerModel No.Serial No. Anritsu Spectrum Analyzer, 9kHz to 30GHz MS2667CM10281 Anritsu Signal Generator, 10kHz to 20GHz 68247B984703 Hewlett Packard Power Meter,HP438A2743A04416 Hewlett Packard Power Sensor, -30 to 20dBm 8485A2942A08387 Hewlett Packard Step Attenuator, 10dB steps HP8496B3247A18505 Mini-Circuits Power SplitterZN2PD-9GNA DELL Laptop ComputerInspiron 5000eNA Campaq Laptop ComputerPPX99125 FCC ID: PRL-IWE100U Report No.: RF900606R03 2 Issued: July 16, 2001 1.2 METHOD OF MEASUREMENT The processing gain may be measured using the CW jamming margin method. Section 4.7.4 shows the test configuration. The test consists of stepping a signal generator in 50 kHz increments across the passband of the system. At each point, the generator level required to produce the recommended Bit Error Rate (BER) is recorded. This level is jammer level. The output power of the transmitting unit is measured at the same point. The jammer to Signal (J/S) ratio is then calculated. Discard the worst 20% of the J/S data points. The lowest remaining J/S ratio is used when calculating the Process Gain. The reference PER is specified as 8%. The corresponding Es/No (signal to noise ratio per symbol) is 16.4 dB. The curve is attached as below. This value and the measured J/S ratio are used in the following equation to calculate the Process Gain (Gp) of the system. Where: (S/N) o : Signal to noise ratio for the chosen BER. Gp = (S/N) o +Mj+Lsys FCC ID: PRL-IWE100U Report No.: RF900606R03 3 Issued: July 16, 2001 Mj : Maximum jammer to Signal Ratio recorded at the detected BER. Lsys : System losses . For the purpose of this processing gain calculation, we assume Lsys at its minimum value of 2 dB. TEST SETUP 7 NOTEBOOK EUT ANRITSU SIGNAL GENERATOR EUT NOTEBOOK PWR SENSOR 8485A Power meter HP 438A Mini-Circuits 15542 ZNZPD-9G HP8496D STEP ATTN 110dB (10dB steps) Matched Cables RECEIVER Transmitter FCC ID: PRL-IWE100U Report No.: RF900606R03 4 Issued: July 16, 2001 1.3 TEST PROCEDURES Obtain the simplex link shown. Perform all independent instrumentation calibrations prior to this procedure. Set operating power levels using fixed and variable attenuators in system to meet the following objectives: Signal Power at receiver approximately –55dBm (above thermal sensitivity such that thermal noise does not cause bit errors. Signal Power at power meter between –20 and –30dBm for optimal linearity. Use spectrum analyzer to monitor test. Ensure that CW Jammer generator RF output is disabled and measure the power at the power meter port using the power meter. This is the relative signal power, Sr. Disable Transmitter, and set CW Jammer generator RF output frequency equal to the carrier frequency and enable generator output. Set reference CW Jammer power level at power meter port 8.4dB below Sr (minimum J/S, or 10dB processing gain reference level). Note the power level setting on the generator, this is the reference CW Jammer power setting, Jr. Disable CW Jammer, re-establish link. PER test should be operating essentially error -free. Enable CW Jammer at the reference power level and verify that the PER test indicates a PER of less than 8%. Alternatively, adjust the CW Jammer level to that which causes 8% PER and verify that the S/J is less than 8.4dB. Repeat step 7 for uniform steps in frequency increments of 50 kHz across the receiver passband with the CW Jammer. In this case the receiver passband is +/- 8.5 MHz. The numerical data associated with the following radio channel is tabulated and presented for Channel 1,6, and 11. Note:Since the jamming signal will be blocked by the IF filter if the jamming frequency is far form the center of the carrier frequency. So, only those frequencies around carrier frequency are shown here. FCC ID: PRL-IWE100U Report No.: RF900606R03 5 Issued: July 16, 2001 1.4 EUT OPERATING CONDITION The software provided by client to set the EUT to transmit at lowest, middle and highest channel. 1.5 TEST RESULTS EUTWireless USB AdapterModelIWE100U Environmental Conditions30°C, 60%RHTe s t e d B yGary Chang Although the theoretical processing gain is lower than 10 dB, but the CCK coding provides an extra coding gain of 2.2dB. 11Mbps CHANNEL 1 Processing Gain FrequencyGp(S/N)Mj = J/SLsys (GHz)(dB)(dB)(dB)(dB) 2.40800 12.9 16.4 -4.5 1 2.40805 13.3 16.4 -4.1 1 2.40810 13.4 16.4 -4.0 1 2.40815 12.7 16.4 -4.7 1 2.40820 12.9 16.4 -4.5 1 2.40825 12.4 16.4 -5.0 1 2.40830 12.9 16.4 -4.5 1 2.40835 13.1 16.4 -4.3 1 2.40840 12.4 16.4 -5.0 1 2.40845 12.0 16.4 -5.4 1 2.40850 12.8 16.4 -4.6 1 2.40855 12.6 16.4 -4.8 1 2.40860 12.7 16.4 -4.7 1 2.40865 12.0 16.4 -5.4 1 2.40870 11.9 16.4 -5.5 1 2.40875 11.9 16.4 -5.5 1 2.40880 12.0 16.4 -5.4 1 2.40885 12.4 16.4 -5.0 1 2.40890 12.0 16.4 -5.4 1 2.40895 12.1 16.4 -5.3 1 2.40900 12.0 16.4 -5.4 1 2.40950 11.0 16.4 -6.4 1 FCC ID: PRL-IWE100U Report No.: RF900606R03 6 Issued: July 16, 2001 11Mbps CHANNEL 1 Processing Gain FrequencyGp(S/N)Mj = J/SLsys (GHz)(dB)(dB)(dB)(dB) 2.40955 11.4 16.4 -6.0 1 2.40960 11.0 16.4 -6.4 1 2.40965 11.8 16.4 -5.6 1 2.40970 11.7 16.4 -5.7 1 2.40975 11.3 16.4 -6.1 1 2.40980 11.4 16.4 -6.0 1 2.40985 11.0 16.4 -6.4 1 2.40990 10.5 16.4 -6.9 1 2.40995 10.9 16.4 -6.5 1 2.41000 10.4 16.4 -7.0 1 2.41005 11.2 16.4 -6.2 1 2.41010 11.4 16.4 -6.0 1 2.41015 11.5 16.4 -5.9 1 2.41020 11.6 16.4 -5.8 1 2.41025 11.0 16.4 -6.4 1 2.41030 11.2 16.4 -6.2 1 2.41035 11.6 16.4 -5.8 1 2.41040 11.5 16.4 -5.9 1 2.41045 11.6 16.4 -5.8 1 2.41050 11.0 16.4 -6.4 1 2.41055 10.9 16.4 -6.5 1 2.41060 10.8 16.4 -6.6 1 2.41065 11.0 16.4 -6.4 1 2.41070 11.6 16.4 -5.8 1 2.41075 11.7 16.4 -5.7 1 2.41080 11.8 16.4 -5.6 1 2.41085 11.6 16.4 -5.8 1 2.41090 11.9 16.4 -5.5 1 2.41095…

Text truncated - open the document above for the full version.

FCC ID: PRL-IWE100U Report No.: RF900606R03 58 Issued: July 16, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (Printed Antenna) FCC ID: PRL-IWE100U Report No.: RF900606R03 59 Issued: July 16, 2001 CONDUCTED EMISSION TEST (Dipole Antenna) FCC ID: PRL-IWE100U Report No.: RF900606R03 60 Issued: July 16, 2001 RADIATED EMISSION TEST (Printed Antenna) FCC ID: PRL-IWE100U Report No.: RF900606R03 61 Issued: July 16, 2001 RADIATED EMISSION TEST (Dipole Antenna)
