PRO-WCS-232V6Bluetooth Serial Adaptor

Model: WCS-232 V6.0 User Guide Version 1.0.0.0 2019-12-05 2 User Guide for the WCS-232 V6.0 Version 1.0.0.0 Firmware version 2.0.X Printed in Korea Copyright Copyright 2019,SystemBase Co., Ltd. All rights reserved. SystemBase reserves the right to make changes and improvements to its product without providing notice. Trademark Windows® is a registered trademark of Microsoft Corporation. Ethernet® is a registered trademark of XEROX Corporation. Notice to Users When a system failure may cause serious consequences, protecting life and property against such consequences with a backup system or safety device is essential. The user agrees that protection against consequences resulting from system failure is the user's responsibility. This device is not approved for life-support or medical systems. Changes or modifications to this device not explicitly approved by SystemBase will void the user's authority to operate this device. Precautions and Safety Electricity Use only the supplied AC adapter. Use of unauthorized power adapter is not recommended. Electrical shock may result. Do not kink or crease the power cable or place heavy objects on the power cable. Fire can result from damaged power cables. Do not handle power plug and adapter with wet hands. Electrical shock may result. Immediately power off the product and unplug the AC adapter if smoke or odors emit from the product and adapter. Fire can result from improper use. Immediately power off the product and unplug the AC adapter if water or other liquids are present. Fire can result from improper use. Product WCS-232 meets the RS-232 standards. Do not wire with non-standard products. Damage to your products may result from improper use. Do not drop or subject the device to impact. Damage to your products may result from improper use. 3 Keep away from harsh environments including humid, dusty, and smoky areas. Damage to your products may result from improper use. Do not use excessive force on the buttons or attempt to disassemble the device. Damage to your products may result from improper use. Do not place heavy objects on the product. Damage to your products may result from improper use. Contact Information SystemBase Co,. Ltd Website: http://www.sysbas.com 4 Revision History Revision Date Name Description V1.0.0.0 2019-12-05 yt Ji Initial Writing 5 Contents 1. Introduction 10 1.1. Overview ..................................................................................................................................10 1.2. Package Check List .................................................................................................................10 1.2.1. Single Unit Package .......................................................................................................10 1.2.2. Bulk-Pack Package ........................................................................................................ 11 1.3. Product Specification ............................................................................................................... 11 2. Getting Started 13 2.1. Panel Layout ............................................................................................................................13 2.2. Connecting the Hardware ........................................................................................................14 2.2.1. Connecting Power to WCS-232 .....................................................................................14 2.2.2. Connecting Device to WCS-232 ....................................................................................15 3. Configuration 16 3.1. Operation Modes ......................................................................................................................16 3.2. LED Indicators ..........................................................................................................................17 3.3. Serial Ports ...............................................................................................................................18 3.4. Data Bit .....................................................................................................................................18 3.5. Hardware Flow Control ............................................................................................................18 3.6. Reset to Factory Defaults .........................................................................................................19 3.7. Dipswitch ..................................................................................................................................19 3.8. Pairing Button ...........................................................................................................................20 3.9. Remote Configuration ..............................................................................................................24 3.10. Software and Utility ................................................................................................................25 3.11. WCSConfig .............................................................................................................................25 3.12. Terminal Program...................................................................................................................34 4. Multiple Connection Mode 36 4.1. Overview ..................................................................................................................................36 4.2. Configuration ............................................................................................................................37 4.3. AT Commands .........................................................................................................................38 4.3.1. AT+MULTI,n ...................................................................................................................38 4.3.2. AT+MLIST? .............................…

Text truncated - open the document above for the full version.

SystemBase Co.,Ltd. Feb 26 th , 2020 Applicant: SystemBase Co.,Ltd. FCC ID: PRO-WCS-232V6 We hereby declare that 1. Add the antennas which are lower than default antenna as R-AN2400-1901RS as shown next page. 2. Add the derived model name as below. There are no changes in the circuital and electronic feature, and in the technical data provided in the submitted document. Model name BasicWCS-232 V6.0 DerivedBT-232 V6.0 3. When equipped, the distance between antenna and own body is 20cm. Myunghyun Kim / CEO R-AN2400-1901RS (Dipole: 5.37dBi) R-AN2400-5801RS (Dipole: 3.09dBi) AN2400-3306RS (Dipole: 1.4dBi)

SystemBase Co.,Ltd. SystemBase Co.,Ltd. , Heolleung-ro 569-gil, Gangnam-gu, Seoul, South Korea Feb 26 th , 2020 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370a Newberry, Florida 32669 USA Letter of Authorization We, the undersigned, hereby authorize Kenneth Kim of NCT Co.,Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: PRO-WCS-232V6 including signing of all documents relating to these matters. Any and all acts carried out by Kenneth Kim of NCT Co.,Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from SystemBase Co.,Ltd. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Myunghyun Kim / CEO

SystemBase Co.,Ltd. Rev 11/20/07 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: PRO-WCS-232V6 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit T ype File Name Block Diagram Schematics Operational Description Part Lis t [WCS-232 V6.0] BLK [WCS-232 V6.0] SCH [WCS-232 V6.0] OpDes [WCS-232 V6.0] Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); Exhibit Type File Name External Photos Internal Photos Test Setup Photos Manual [WCS-232 V6.0] EXT Photo [WCS-232 V6.0] INT Photo [WCS-232 V6.0] Test Setup Photo [WCS-232 V6.0] Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. Sincerely, SystemBase Co.,Ltd. Rev 11/20/07 Myunghyun Kim / CEO

Systembase_WCS-232 V6.0_Label & Location

Electric Field strength (V/m) Magnetic field strength (A/m) Power Density (mW/cm2) Averageing time (minutes) 0.3~1.346141.63*10030 1.34~30824 / f2.19 / f*180 / f230 30~30027.50.0730.230 300~1,500f / 150030 1,500~100,000130 Model Name : FCC ID : (dBm)(dB)(dBm)(mW)(dBi)(numeric) (mW/cm2)(mW/cm2) 240211.6712.6718.49-1.320.740.00271.00PASS 244211.9212.9219.59-1.320.740.00291.00PASS 248012.2313.2321.04-1.320.740.00311.00PASS 24022.873.872.441.001.260.00061.00PASS 24422.203.202.091.001.260.00051.00PASS 24802.053.052.021.001.260.00051.00PASS 24022.963.962.491.001.260.00061.00PASS 24422.293.292.131.001.260.00051.00PASS 24802.153.152.071.001.260.00051.00PASS The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the user. Standalone SAR test exclusion considerations WCS-232 V6.0 PRO-WCS-232V6Separation distance (R) : 20.0 cm S = EIRP/(4R2π) S = Maximum power density (mW/cm2) P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna EIRP = Equivalent Isotropic Radiated Power(mW) (=P*G) Frequency range (MHz) π/4DQPSK ± 1.00 Result GFSK± 1.00 Modulation Frequency (MHz) Measured Maximum Average power Tune-up tolerance Max. Power with tune-up tolerance ( P) Max. Power with tune-up tolerance ( G) Power Density (S) Limit of Power Density (S) 8DPSK± 1.00

Test Repot No.: NW2003-F001 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 2 of 49 Table of contents 1. General Information -------------------------------------------------------------------------------- 2. Information’s about Test Item ------------------------------------------------------------------- 3. Test Report -------------------------------------------------------------------------------------------- 3.1 Test Summary ------------------------------------------------------------------------------------- 3.2 Test Report Version ----------------------------------------------------------------------------- 3.3 Transmitter Requirements 3.3.1 Antenna Requirement --------------------------------------------------------------------- 3.3.2 20 ㏈ Bandwidth --------------------------------------------------------------------------- 3.3.3 Number of Hopping Frequencies ------------------------------------------------------- 3.3.4 Time of Occupancy (Dwell Time) ------------------------------------------------------- 3.3.5 Carrier Frequencies Separation -------------------------------------------------------- 3.3.6 Peak Output Power ------------------------------------------------------------------------ 3.3.7 TX Radiated Spurious Emission and Conducted Spurious Emission --------- 3.3.8 Conducted Emission ----------------------------------------------------------------------- APPENDIX APPENDIX I TEST SETUP ---------------------------------------------------------------------- APPENDIX II TEST EQUIPMENT USED FOR TESTS ---------------------------------- 3 3 5 5 5 6 7 11 14 16 20 27 43 46 48 Test Repot No.: NW2003-F001 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 3 of 49 1. General Information’s 1.1 Test Performed Laboratory : NCT Co., Ltd. Address : 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, 18511, Korea Telephone : +82-31-323-6070 Facsimile : +82-31-323-6071 FCC Designation No. : KR0166 FCC Registration Number : 409631 2. Information’s about Test Item 2.1 Applicant Information Company name : SystemBase Co.,Ltd. Address : Daerung Post Tower-1 16F, 288, Digital-ro, Guro-gu, Seoul, Republic of Korea Telephone / Facsimile : +82-2-855-0501 / +82-2-855-0580 2.2 Equipment Under Test (EUT) description Test item particulars : Bluetooth Serial Adaptor Model and/or type reference : WCS-232 V6.0 Additional model name : BT-232 V6.0 Serial number : Identification Antenna type and gain : Dipole Antenna with Max gain : 5.37 ㏈i (M/N: R-AN2400-1901RS) Dipole Antenna with Max gain : 3.09 ㏈i (M/N: R-AN2400-5801RS) Dipole Antenna with Max gain : 1.40 ㏈i (M/N: AN2400-3306RS) Date (s) of performance of tests: : 2020-01-28 ~ 2020-02-05 Date of receipt of test item : 2020-01-10 EUT condition : Pre-production, not damaged Number of channel : 79 EUT Power Source : DC 3.7 V Type of Modulation : Basic Mode(GFSK), EDR Mode(Pi/4 DQPSK, 8DPSK) Fir㎽are version : 1.0 Hardware version : 1.0 Test software name(version) : CSR BlueSuite_BlueTest3(2.6.2) Test Repot No.: NW2003-F001 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 4 of 49 2.3 Tested Frequency Test Mode Test frequency (㎒) Low frequency Middle frequency High frequency GFSK 2 402 2 442 2 480 Pi/4 DQPSK 2 402 2 442 2 480 8DPSK 2 402 2 442 2 480 2.4 Worst-Case BDR GFSK(DH5) EDR 8DPSK(3-DH5) Note: The power measurement has been conducted to determine the worst-case mode from all possible combinations between available modulations, data rates. Test Repot No.: NW2003-F001 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 5 of 49 3. Test Report 3.1 Test Summary Applied Test Items Clause Test Condition Result Antenna Requirement 15.203 Conducted C 20 ㏈ Channel Bandwidth 15.247(a) C Number of Hopping Frequencies 15.247(a) C Time of Occupancy (Dwell Time) 15.247(a) C Carrier Frequencies Separation 15.247(a) C Peak Output Power 15.247(b) C Conducted Spurious Emission 15.247(d) C Radiated Spurious Emission 15.247(d) 15.205 & 15.209 Radiated C Conducted Emissions 15.207 AC Line Conducted C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable The sample was tested according to the following specification: ANSI C63.10:2013 Compliance was determined by specification limits of the applicable standard according to customer requirements. 3.2 Test Report Version Test Report No. Date Description NW2003-F001 2020-03-02 Initial issue Test Repot No.: NW2003-F001 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 6 of 49 3.3 Transmitter Requirements 3.3.1 Antenna Requirement Accoding to §15.203 An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator shall be considered sufficient to comply with the provisions of this section. The manufacturer may design the unit so that a broken antenna can be replaced by the user, but the use of a standard antenna jack or electrical connector is prohibited. Accoding to §15.247(b)(4) e conducted output power limit specified in paragraph (b) of this section is based on the use of antennas with directional gains that do not exceed 6 ㏈i. Except as shown in paragraph (c) of this section, if transmitting antennas of directional gain greater than 6 ㏈i are used, the conducted output power from the intentional radiator shall be reduced below the stated values in paragraphs (b)(1), (b)(2), and (b)(3) of this section, as appropriate, by the amount in ㏈ that the dire…

Text truncated - open the document above for the full version.

Below 30 MHz Below 1 GHz Above 1 GHz Conducted Emission
