SerialGate User Guide Ver 2.1a 2012. 09.10 SerialGate User Guide 2 Revision History Revision Date Document Version Pages Description Apr. 10. 2012 2.0 All Initial release Jun. 26. 2012 2.1 All New Firmware release Sep. 10. 2012 2.1a All New Case of SG-1020(W)/ALL release Copyright 2009-2011 SystemBase Co., Ltd. All rights reserved. Website http://www.sysbas.com/ Tel 02-855-0501 Fax 02-855-0580 16F Daerung Post Tower-1, 212-8, Guro-dong, Seoul, Korea For any inquiries or comments, contact to [email protected] SerialGate User Guide 3 Contents Ch. 1 Introduction  About This Document  Who Should Read This Document  Manual Contents  SerialGate Documents  Technical Support Ch. 2 Getting Started  Overview  Features  Package Component  Applications Ch.3 Hardware Description  SerialGate-1010(W)ALL Exterior  SerialGate-1010(W)ALL LED/RESET  SerialGate-1020(W)ALL Exterior  SerialGate-1020(W)ALL LED/RESET  SerialGate-1010/1020 Exterior  SerialGate-1010/1020 LED/RESET  SerialGate-1040/1080 Exterior  SerialGate-1040/1080 LED/RESET  SerialGate-1160 Exterior  SerialGate-1160 LED/RESET  Pin Specification (SerialGate-1010/1020/1040/1080)  Pin Specification (SerialGate-1010(W)/ALL, SerialGate-1020(W)/ALL)  Pin Specification (SerialGate-1160) Ch.4 Installation  Connection Guide  First-Time Boot up SerialGate User Guide 4  Connecting to SerialGate Ch.5 Configuration via Web  Connection  Setup Menu  Network Settings  Serial Settings  Wireless Settings  SNMP Settings  Change Password  Update Firmware  Factory Default  Save & Reboot  System Log Ch.6 Configuration via Telnet  Connection  View Commands  Network Commands  Serial Commands  Username/Password Commands  System Commands Ch.7 Configuration via LCD  LCD & Key Control  Main Menu  Network Setup  Port Setup  Status  System  Verification Ch.8 Application  Com Port Redirector  TCP Server  TCP Client SerialGate User Guide 5  Pair Ch.9 Appendix  Troubleshooting  Firmware Update using FTP  Product Specification SerialGate User Guide 6 Ch. 1 Introduction This chapter is an introduction to SystemBase device server SerialGate series. About this document This guide is designed for users of SerialGate, for setting SerialGate’s configurations, status monitoring, firmware update, and other administration work. Who should read this document? This guide is designed for SerialGate users and administrators. It is strongly recommended that anyone trying to apply, use, and maintain SerialGate read this document. This guide deals with the hardware-level integration issues and software-level configuration tips. It will be a great starting point for any administrators who want to easily monitor and control SerialGate and its connected devices. SerialGate User Guide 7 Manual Contents Introduction (Chapter 1) is a preface with general information and introductory notices. Getting Started (Chapter 2) gives a brief introduction of SerialGate series, including features and applications. Hardware Descriptions (Chapter 3) explains the layout and pin specifications with block diagram and drawings. Installation (Chapter 4) helps you to connect SerialGate to serial and network environment. It ends up with first time boot-up and status check. Configuration via Web (Chapter 5) provides menu-by-menu guide for setting up the operation environment for SerialGate via web browser. Configuration via Telnet (Chapter 6) provides a list of commands for setting up the operation environment for SerialGate via Telnet. Configuration via LCD (Chapter 7) explains how to monitor status and working environment of device server. Application (Chapter 8) provides a variety of application examples widely used in industries. Appendix (Chapter 9) provides firmware update guides and technical specifications for detailed information. SerialGate User Guide 8 SerialGate Documents The following table summarizes documents included in the SerialGate document set. Document Name Description User Guide Integration, configuration, and management tasks are explained for the administrator Portview User Manual Guide for SystemBase device server management application Portview COM Port Redirector User Manual Guide for SystemBase COM Port Redirector TestView User Manual User Manual for testing Com port Redirector , TCP Server/Client , UDP Server/Client If you need brief information on SerialGate or device servers in general, please visit our company website at http://www.sysbas.com/ . You can view and/or download documents related to SerialGate as well as latest software and firmware updates. Available resources are as follows: Document Name Description SerialGate Spec Sheet Specifications for SerialGate products SerialGate White Paper An easy reading for anyone new to device server. Deals with background and technology Past, present, and future of device servers along with the overview of market environment All documents are updated promptly, so check for the recent document update. The contents in these documents are subject to change without any notice in advance. SerialGate User Guide 9 Technical Support There are three ways you can get a technical support from SystemBase. First, visit our website http://www.sysbas.com/ and go to ‘Technical Support’ menu. There you can read FAQ and ask your own question as well. Second, you can e-mail our technical support team. The mail address is [email protected] . Any kind of inquiries, requests, and comments are welcome. Lastly, you can call us at the customer center for immediate support. Our technical support team will kindly help you get over with the problem. The number to call is 82-2-855-0501 (Extension number 113). Do not forget to dial the extension number after getting a welcome message. SerialGate User Guide 10 Ch.2 Getting Started This chapter includes SerialGate overview, main and distinctive features, package contents for each product, and application fields. Overview SerialGate provides network connectivity to various se…

Text truncated - open the document above for the full version.

FCC INFORMATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. RF Exposure: A distance of 20 cm shall be maintained between the antenna and users, and the transmitter module may not be co-located with any other transmitter or antenna.
