PROEDDY-WIFIEmbedded WiFi Module

1 Eddy Serial User Guide Ver 2.1.1.1 2010. 06.25 2 Revision History Revision Date Document Version Pages Description Feb-5-2009 2.1.0.1 All Initial release by shlee Sep-10-2009 2.1.0.2 4,5,6 Added WiFi Nov-11-2009 2.1.0.3 2,3,5 Append Eddy-S4M Jun-06-2010 2.1.1.1 All Open Linux Version Added Eddy-BT 3 Table of Contents Chapter 1. Introduction...............................................................................................................................5 1.1 About this manual....................................................................................................................................................5 1.2 Who should read this manual.....................................................................................................................................5 1.3 Contents.................................................................................................................................................................5 1.4 Eddy Documents.....................................................................................................................................................6 1.5 Technical Support.....................................................................................................................................................7 Chapter 2. Getting Started...........................................................................................................................8 2.1 Overview...............................................................................................................................................................8 2.2 Eddy-CPU v2.1........................................................................................................................................................8 2.3 Eddy-DK v2.1 (Development Kit)................................................................................................................................9 2.4 Eddy-S4M v2.1.......................................................................................................................................................11 2.5 Eddy-S4M-DK v2.1 (Development Kit)........................................................................................................................13 2.6 Eddy-S4M-JiG v2.1 (Testing Board)...........................................................................................................................14 2.7 Eddy-WiFi v 2.1......................................................................................................................................................15 2.8 Eddy-BT v2.1..........................................................................................................................................................17 2.9 Eddy Software Architecture......................................................................................................................................18 2.10 Main Features.......................................................................................................................................................18 2.11 Applications............................................................................................................................................................19 Chapter 3. Hardware Description..................................................................................................................20 3.1 Eddy-CPU.............................................................................................................................................................20 3.2 Eddy-DK v2.1.........................................................................................................................................................21 3.3 Eddy-S4M v2.1......................................................................................................................................................23 3.4 Eddy-S4M-DK v2.1.................................................................................................................................................24 3.5 Eddy-S4M-JIG v2.1.................................................................................................................................................25 3.6 Eddy WiFi v2.1.......................................................................................................................................................26 3.7 Eddy BT v2.1.........................................................................................................................................................28 Chapter 4. Integration...............................................................................................................................30 4.1 Connection Guide....................................................................................................................................................30 4.2 First-time Bootup..................................................................................................................................................30 4.3 Connecting to Eddy with IP address...........................................................................................................................30 4.4 Using MCI slot & USB Host Port...............................................................................................................................33 4 Chapter 5. Configuration via Web..................................................................................................................36 5.1 Connection............................................................................................................................................................36 5.2 Setup Menu..........................................................................................................................................................37 5…

Text truncated - open the document above for the full version.

Daerung Post Tower-1 16F, 212-8, Guro-dong, Guro-gu, Seoul, Korea Eddy-WiFi August 16, 2010 Telefication B.V. Attn.: Dept. FCC TCB Edisonstraat 12a 6902 PK Zevenaar The Netherlands To whom it may concern: We, the undersigned, hereby authorize IST Co.,Ltd. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by IST Co.,Ltd. on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing IST Co.,Ltd. as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Won Kyu Yeon / project manager

Daerung Post Tower-1 16F, 212-8, Guro-dong, Guro-gu, Seoul, Korea Eddy-WiFi August 16 2010 Telefication B.V. Attn.: Dept. FCC TCB Edisonstraat 12a 6902 PK Zevenaar The Netherlands Pursuant to 47 CFR Part 0, section 0.459, we herewith submit a request for non-disclosure of the following exhibits, related to this application for FCC ID : PROEddy-WiFi The contents of the exhibits as listed below under 1-4 may not be disclosed to any other party than company name and must be temporary with held from public inspection under 5 U.S.C552 (b)(4) and must be temporary kept confidential. 1. External photographs 2. Inter photographs 3. User manual 4. Test-setup photographs The short-term confidentiality is scheduled to terminate on 12. 01. 2010. The reason for this request for short-term confidentiality is that the information contained in the exhibits as listed above has been classified as being temporary company confidential (with reference to 47 CFR Part 0, section 0.457(d)). Disclosure of any portion of this information to other parties prior to the date of the actual marketing of the device would cause substantial competitive harm. I, as the applicant, understand and have taken notice of the following. (a) The maximum period for short-term confidentiality is 180 days, counting from the date of issue of the Grant (b) The applicant shall inform the TCB about the date on which the device will be actually marketed. Such a notification must be received by the TCB before the date of actual marketing. The short-term confidentiality will then terminate before or on the date of the actual marketing of the device. (c) If no request from the applicant is received by the TCB for releasing the short- term confidentiality, it will terminate automatically after 180 days, counting from the date of issue of the Grant Your sincerely, Won Kyu Yeon / project manager

Daerung Post Tower-1 16F, 212-8, Guro-dong, Guro-gu, Seoul, Korea Tel. No. : 82-02-855-0501 Fax. No. : 82-02-855-0580 August 17, 2010 Federal Communications Commission Authorization and Evaluation Division FCC ID: PROEddy-WiFi Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1. Schematics 2. Operational Description 3. Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, (Won Kyu Yeon / project manager) (SystemBase CO., LTD. )

ID Label/Location Information

IST Co., Ltd EMC LABORATORY 1 of 2 RF Exposure According 15.247(b)(4) and 1.307(b)(1) Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to 1.1310 and 2.1093 RF exposure is calculated. Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electronic Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minute) Limits for General Population/Uncontrolled Exposure 0.3 – 1.34 614 1.63 *(100) 30 1.34 – 30 824/f 2.19/f *(180/f 2 ) 30 30 – 300 27.5 0.073 0.2 30 300 – 1500 / / f/1500 30 1500 - 15000 / / 1.0 30 F = frequency in MHz * = Plane-wave equivalent power density IST Co., Ltd EMC LABORATORY 2 of 2 RF exposure calculations EUT Eddy-WiFi Operating Frequency Band 2412 ~ 2462 Exposure Classification General Population / Uncontrolled exposure ( S = 1 mW/cm 2 ) Max. Output Power 12.86 dBm ( 19.32 mW ) Antenna Gain(Max) 3.3 dBi ( Numeric Gain : 2.138 ) Evaluation Applied MPE Evaluation Note : 1. The maximum output power is 12.86 dBm ( 19.23 mW ) at 2462 MHz. 2. For mobile or fixed location transmitters, no SAR consideration applied. The minimum separation generally be used is at least 20 cm, even if the calculations indicate that the MPE distance would be lesser. S = (P*G)/4πR 2 Where, S = Power Density ( mW/cm 2 ) P = Output Power to Antenna ( mW ) G = Gain of antenna in numeric R = Distance between radiating structure and observation point ( cm ) Then, the power density ( S ) = (19.23 * 2.138) / 4 * 3.1416 * 20 2 ) = 0.008179 ( mW/cm 2 ) Note : The power density at 20 cm does not exceed the 1 mW/cm 2 limit. Therefore, the exposure condition is compliant with FCC rules.
