PT5RC9200RC9200 Touch Screen Remote Control

User Guide To the RC9200/RC5200 Touch Screen Remote Controls Automating Your Home Theater With Marantz Automating Your Home Theater With The Marantz RC9200/5200 RC9200/5200 Remote Control User Guide The information in this manual is copyright-protected. No part of this manual may be copied or reproduced in any form without prior written consent from Marantz America, Inc. MARANTZ AMERICA, INC. CORPORATION SHALL NOT BE LIABLE FOR OMIS- SIONS OR FOR TECHNICAL OR EDITORIAL ERRORS CONTAINED IN THIS MANUAL. MARANTZ AMERICA, INC. SHALL NOT BE HELD LIABLE FOR INCIDEN- TAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE SUPPLYING OR USE OF THIS INFORMATION. MARANTZ AMERICA, INC. SHALL NOT BE HELD LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE PERFORMANCE OR USE OF THE MATERIALS DESCRIBED IN THIS MANU- AL. The information in this manual may be subject to change without prior notice. All other brand or product names are trademarks or registered trademarks of their respective companies or organizations. FCC NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rule. These limits are designed to provide reasonable protection against harmful interference in residential installation. This equipment generates, uses, and can radiate radio frequency energy and , if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is not guarantee that interferen- ce will not occur in a particular installation. If this equipment does cause harmful inter- ference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: nReorient or relocate the receiving antenna. nIncrease the separation between the equipment and receiver. nConnect the equipment into an outlet on a different circuit from the receiver. nConsult the dealer or an experienced radio/TV technician for help. NoteIf serial or parallel ports are configured, a filtered/shielded serial or paral- lel cable is recommended to minimize EMI and ensure FCC class B compliance. User Guide 1 Introduction 2 1. The Marantz RC9200/5200 2 2. Battery 3 Getting Started 6 1. Activating the RC9200/5200 6 2. Navigating Control Panels 7 3. Operating a Device 12 4. Adjusting the Settings 13 5. The Mode Menus 15 6. Managing Memory17 Customizing Your RC9200/5200 18 1. Introduction 18 2. Programming Remote Codes 18 3 Deciding between Macros or Help Lists 20 4. Programming Help Lists 22 5. Macro/Panel Jump Capabilities 23 6. Programming Macros & Panel Jumps 24 7. Programming Macros as a Device Action 26 8. Protecting Your Work from Changes 27 Reference 28 1. Programming Buttons 28 2. Labeling Buttons, Frames and Menu Items 32 3. Working with Device and Macro Groups 35 4. Deleting and Restoring 40 5. Recording Macros 43 6. RC5000 Setup 47 Troubleshooting49 Frequently Asked Questions52 Overview of Symbols54 Specifications56 The Revert Configuration57 Index58 Table of Contents User Guide 2 The RC9200/5200 is designed to control most devices that understand infrared remote control signals. Its easy-to-use touchscreen and its intuiti- ve interface make it a perfect remote control for every user. The RC9200/5200 is completely customizable and programmable. You can add devices and functions, relabel buttons, record macros and animate your macros. Although the RC9200/5200 is pre-programmed for Marantz components, a vast collection of built-in tab guided panels with pre-arran- ged button art enables you to easily choose the perfect interface for any non-Marantz component. The RC9200/5200 easily learns commands from the vast majority of manufacturers remote controls. Introduction 1.The Marantz RC9200/5200 The Volume, Channel and Mute buttons are typically programmed to always work the same way regardless of what panel is displayed. The Infrared Eye transmits to your devices and learns from your existing remotes. The Touchscreen The INFO button enables you to check batte- ry life. Scroll Up and Scroll Dn but- tons duplicate the function of the scroll arrows and are easier to find in the dark (they navigate between panels when there are more than one panel for control- ling a specific devicde). \Menu, Enter, Exit and 4 way navigator buttons will change their function depending on what device you are controlling. The Contrast Dial adjusts the appe- arance of the screen. The Backlight but- ton lights up the screen (you can adjust the length of time it stays on, see page 13). The Serial Port ena- bles you to program the RC9200/5200 on a Windows PC. The Home B utton always takes you back to the Main Home Panel Control Screen (think of it as the Start button). User Guide 3 Introduction Tap the Mode Button: to access the Mode Menus. They are diffe- rent based on the type of panel you last dis- played. Use the Mode Menus to customize your remote. Devices Macros Home Tap the Scroll Arrows: to scroll to other panels within the active group. Tap the Macro menu Bar: to use your one touch Macro buttons. Tap again and a menu of all of your Macro groups appears. Tap again to select: Tap the Device menu bar: to operate devices. Tap again and a menu of all your devices appears. Tap again to select: Panel number: shows active control panel Tap the Scroll Arrows: to scroll to other panels within the acti- ve group. 2.The Battery When you use the Remote Control for the first time, you will have to: ¥ install the battery pack; ¥ place the Remote Control in the docking station and charge the Remote Control. ¥ tap the INFO button on the Home Panel to check battery life. Warning Use the docking station only with the Philips NiMH rechargeable battery pack. We strongly advise you not to plug other appliances (like mobile phones, PDA s, ) into the docking station. This will damage both the connector and the appliance.…

Text truncated - open the document above for the full version.

Page 1 Rev.No 1.0 ATTESTATION STATEMENT GENERAL REMARKS: PHILIPS INDUSTRIAL ACTIVITIES LOUVAIN Interleuvenlaan 74-82 3001 Leuven Belgium RC9200, Model 3104 207 1236 SUMMARY: All tests were performed per FCC Part 15, Paragraphs 15.231(c), (e); 15.107(a); 15.109(a). The Equipment Under Test ! - Fulfills the requirements of FCC Part 15, Paragraphs 15.231(c), (e); 15.107(a); 15.109(a) . - TÜV PRODUCT SERVICE, INC. - Responsible Engineer: Dave Bernardin (EMC Engineer)

LCD Controller (SED 1735) (8 MHz Clock) Touch-screen controller switchmatrix ADC - V BAT Color LCD module LCD screen 320x240 Touch-screen CCFL-backlight (75 kHz) 24V Convertor MicroController MC68328 Flash memory 8 MB (4M x 16-bit) SRAM 512 KB (256K x 16-bit) Address(A22-A1) Internal Memory Controller Control Clock synthesiser 16.67 MHz Crystal 32.768 kHz Control & Data Voltage Regulator Power Management V BAT V CC IO PWM Interrupt Controller SPI interface Glue logic, IR driver, multiplexer IR LED’s IR Receiver RF Transm. (418 MHz) Piezo Buzzer (1 kHz) Key Matrix UART (115200 bps) RS232 level shifter To PC Data (D15 - D0) CCFL 300V Convertor (75 kHz)

CONTRAST WHEEL SIDE GSMCONRC9200 SIDE TOP TOP BATTERY COMPARTMENT BATTERY LID

RC 9200 Batterydoor colour 351 D 5 Graphic printing colour Gold K 82068 3104 207 7905

BACK OF CONTROLLER BOARD BOTTOM OF CONTROLLER BOARD BOTTOM RF BOARD CONTROLLER BOARD TOP BACK OF CONTROLLER BOARD BOTTOM OF CONTROLLER BOARD BOTTOM RF BOARD CONTROLLER BOARD TOP CONTROL INTERFACE BOARD CONTROLLER BOARD CONTROLLER BOARD RF BOARD RF BOARD CONTROL INTERFACE BOARD CONTROLLER BOARD CONTROLLER BOARD RF BOARD RF BOARD

RF EXPOSURE STATEMENT: The EUT is categorically excluded from routine evaluation because it is a low power device.

TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 106386-03 Page 1 Rev.No 1.0 MEASUREMENT AND TECHNICAL REPORT PHILIPS INDUSTRIAL ACTIVITIES LOUVAIN Interleuvenlaan 74-82 3001 Leuven Belgium DATE: 12 October 2001 This Report Concerns: Original Grant: XClass II Change: Equipment Type: RC9200, Model 3104 207 1236 Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes: Defer until: No: X Company Name agrees to notify the Commission by: N/A of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes:*No: X (*) FCC Part 15, Paragraphs 15.231(c), (e); 15.107(a); 15.209(a) Report Prepared by: TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 546 3999 Fax: 858 546 0364 TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 106386-03 Page 2 Rev.No 1.0 TABLE OF CONTENTS Pages 1 GENERAL INFORMATION 3 1.1Product Description3 1.2Related Submittal Grant5 1.3Tested System Details5 1.4Test Methodology5 1.5Test Facility5 5 2 SYSTEM TEST CONFIGURATION 6 2.1Justification6 2.2EUT Exercise Software6 2.3Special Accessories6 2.4Equipment Modifications6 2.5Configuration of Tested System6 3RADIATED EMISSION EQUIPMENT/DATA 7 Field Strength Calculation 12 4 CONDUCTED EMISSION EQUIPMENT/DATA 13 5Attestation Statement 23 TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 106386-03 Page 3 Rev.No 1.0 1 GENERAL INFORMATION 1.1Product Description: IR/RF touch screen remote with docking station and dongle EUT Name RC9200 Model No.: 3104 207 1236 Power Requirements Voltage: 4.8V Battery pack # of Phases: NA Current (Amps/phase(max)): 120mA Other Special Requirements The RC9200 will be used in combination of a docking station (DS9200 ) and a dongle(RX-77).The docking station charges the battery inside the TS5200.The dongle converts the RF power into IR. The docking station will be connected to an AC adaptor (12 V DC, 400 mA). The AC adaptor is UL listed EUT Power Cable PermanentORRemovableLength (in meters): ShieldedORUnshielded Not Applicable EUT Interface Ports and Cables InterfaceShielding TypeTypeTermination Connector TypePort Termination RS2321 Shield DE9S with AL-foil shield UL listed 2464 Metallized 9 - pin D-sub female Compliance to RS232 2 Emmiter Cable 4 standard copper tinned cable 3.5 mm mono pin connector 2 EUT Software . Description:EMC software It sends on a certain interval IR or RF. It turns on the LCD and the backlight. It also communicate with the PC via the RS232 The RX-77 translates the RF signal into IR codes TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 106386-03 Page 4 Rev.No 1.0 EUT System Components -- DescriptionModel #Serial #FCC ID # Touch screen remoteRC9200 see EUT Docking stationDS9200 see EUT Serial Cable RS232 AC/DC Adaptor AC/DC adaptor ITE 120V-60Hz- 100 mA Output 12V DC 400 mA. 3104 200 51192 Dongle RF extender RX-77 see EUT Support Equipment DescriptionModel #Serial #FCC ID # Test PC TUV Oscillator Frequencies Frequency Derived FrequencyComponent # / LocationDescription of Use 16 MHz Dragon Ball Main Processor 32.768kHZ Grystal Used by PLL to generate 16.67 MHZ 418 Mhz RF module RF transmitter 416.7 HzLCD UnitUsed in EL backlight Critical EMI Components (Capacitors, ferrites, etc.) DescriptionManufacturerPart # or ValueQtyComponent # / Location ferrit bead murata 100 Mhz;120R3 Serial comm. circuit ferrit bead murata 100 Mhz;120R 3 Mp;memory - in power supply TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 106386-03 Page 5 Rev.No 1.0 1 GENERAL INFORMATION (continued) 1.2Related Submittal/Grant None 1.3Tested System Details The FCC IDs for all equipment, plus descriptions of all cables used in the tested system are: None 1.4Test Methodology Purpose of Test:To demonstrate compliance with the ANSI C63.4 setup. TESTFCC CFR 47 #PASS/FAIL Radiated Deactivation Emission Bandwidth Duty Cycle Measurements Conducted Emissions Radiated Emissions 15.231(e) 15.231(e) 15.231(c) ANSI C63.4, Appendix 14, Para. 10 15.107(a) 15.109(a) Pass Pass Pass Pass Pass Pass Both Conducted and radiated testing were performed according to the procedures in FCC/ANSI C63.4 and CSA 108.8 - M1983. Radiated testing was performed at an antenna-to-EUT distance of 3 meters (1 - 25 GHz). 1.5Test Facility The open area test site and conducted measurement data were tested by: TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 546 3999 Fax: 858 546 0364 The Test Site Data and performance comply with ANSI 63.4 and are registered with the FCC, 7435 Oakland Mills Rd, Columbia Maryland 21046. All Measurement Data is acquired according to the content of FCC Measurement Procedure and ANSI C63.4, unless supplemented with additional requirements as noted in the test report. TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 106386-03 Page 6 Rev.No 1.0 2 .SYSTEM TEST CONFIGURATION 2.1Justification The EUT was initially tested for FCC emission in the following configuration: See Block Diagram. 2.2EUT Exercise Software None 2.3Special Accessories None 2.4Modification None 2.5Configuration of Tested System See Block Diagram. TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 106386-03 Page 7 Rev.No 1.0 3RADIATED/DEACTIVATION EMISSION EQUIPMENT/DATA The following data lists the significant emission frequencies, measured levels, correction factor (which includes cable and antenna corrections), the corrected reading, and the limit. See following page(s). TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 858 546 3999 FAX 858 546 0364 Report No. 106386-03 Page 8 Rev.No 1.…
