PT5TSU9600WLAN Remote Control

Philips Consumer Lifestyle

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Sep 21, 2006
Application Purpose: Original Equipment
Date of Application: Sep 21, 2006
Equipment Note: WLAN Remote Control
Frequency Range: 2412.00000000 - 2462.00000000
Company: Philips Consumer Lifestyle
Country: Belgium

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

TSU9600 Starter’s Guide Manual de inicio Guide de démarrage FR ES EN ENGLISH TSU9600 Starter’s Guide ESPAÑOL FRANÇAIS Starter’s Guide Manual de inicio Guide de démarrage TSU9600 Using the Control Panel Uso del Panel de Control Utilisation du panneau de commande Getting to Know Your Pronto Control Panel Your TSU9600 Control Panelis designed and manufactured with great care to offer you a reliable and easy operation of your home theater system. It has been preprogrammed by your installer and contains a so-called configuration file that contains all the codes, graphical buttons and navigation behaviour. 1 TSU9600 Starter’s Guide TSU9600 Starter’s Guide Contents Getting to Know Your Pronto Control Panel......................................................................................1 Taking a First Look........................................................................................................................2 Charging the Control Panel............................................................................................................3 Enjoying Your Pronto Control Panel ..................................................................................................3 Controlling Your Home Theater......................................................................................................3 Changing the Pronto Settings........................................................................................................5 Support .............................................................................................................................................6 Maintaining the Control Panel.......................................................................................................6 Troubleshooting............................................................................................................................7 Specifications ...................................................................................................................................8 IFU Approbation / Safety Content TSU9600 .......................................................................................i FCC Compliancy............................................................................................................................i Regulations According to R&TTE....................................................................................................i 2 TSU9600 Starter’s Guide ENGLISH Power adapter VGA touch screen Firm keys Backlight keyStylus Hard keys Cursor keys Rotary wheel Docking connectorPower switch Speaker Control Panel Docking Station Panel connector USB connector This connector is used by the installer to configure the Control Panel. Taking a First Look 3 TSU9600 Starter’s Guide Charging the Control Panel When the Battery levelicon on your screen turns red, it is time to charge the Control Panel. Depending on how your installer has configured the Control Panel, it can be operated for one to several days. NoteThe lifetime of the battery depends on the timeout settings and the settings of the wireless network configured by your installer. If you notice that the battery is deteriorating, please contact your installer. When you place the Control Panel in the docking station, the red Charging LEDon the front of the docking station lights up. When the Charging LED fades out, the Control Panel is fully charged. This can take 3 to 4 hours. When the battery is low and the Charging LED does not light up, make sure that: •the power switch at the bottom of the Control Panel is switched to 1. •the docking station is plugged in the wall outlet. When it is plugged in, the docking station glows blue. •the Control Panel is placed properly in the docking station. •the connector in the docking station is clean and free of obstructions. TipIt is advised to place the Control Panel in the docking station after use. Even when the screen of the Control Panel turns black, the Control Panel is still using power. Enjoying Your Pronto Control Panel Controlling Your Home Theater Activating the screen of the Control Panel •Tap the touch screenwith the stylus enclosed or with your finger. -Or- •Press the Backlightkey. 5 TSU9600 Starter’s Guide Changing the Pronto Settings NoteIt is possible that your installer has blocked the access to the Settings pages. Normally, your installer has fully programmed your Control Panel and no changes are required. To open the Settings pages: •Press and hold the Settingsiconfor more than 3 seconds. General TipPress and hold the ‘-’ and ‘+’ buttons to increase or decrease the setting faster. On the Info Pageyou can find the version and network information and memory status. The General volume refers all the sounds you hear when you operate the Control Panel. The Button volume specifically refers to the default sound you hear when you press a button. Turning the Control Panel On/Off TipAlways switch off the Control Panel during transport to avoid the activation of the touchscreen and battery draining. To change Date & Time settings 1Tap the Month, Day, Year, or Time button. The button is highlighted. 2Tap the ‘-’ and ‘+’ buttons to adjust the date or time. To change the Volume settings •Tap the ‘-’ and ‘+’ buttons to adjust the volume settings. To access the other Settings pages: •Tap the different tabs. Power switch The Power switch on the bottom of the Control Panel turns the Control Panel on and off. 6 TSU9600 Starter’s Guide ENGLISH Screen NoteThe screen is calibrated in the factory. Do not use this function unless you experience problems with the touch screen. Support Maintaining the Control Panel Take care not to damage the touch screen •Do not drop the Control Panel or subject it to any strong impact. •Use the stylus enclosed or your finger to tap the touch screen. AttentionNever use an actual pen, pencil or other sharp object on the touch screen to avoid scratching the touch screen. Protect the Control Panel fro…

Text truncated - open the document above for the full version.

Attestation Statements

September 14, 2006 CONFIDENTIALITY REQUEST Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Re: Philips Industrial Activities submittal for Spread Spectrum System, FCC ID: PT5TSU9600 Gentlemen: Philips Industrial Activities, herein submits an Application for Equipment Authorization for certification of a digital transmitter under FCC Rules Part 15. Philips Innovative Applicatins requests, pursuant to 47CFR 0.459, post grant confidentiality for portions of the material contained in this application such that the identified material will be withheld from public inspection following the grant of this authorization. This material, as indicated by request for confidentiality of the item during the electronic submission process and further identified below, includes: 1. Circuit diagrams submitted as attachment: "schematics”. 2. Block diagram submitted as attachment “block diagram”. 3. Theory of operation submitted as attachment “operational description”. Specifically, these exhibits contain information relating to circuit function and complexity that could be of benefit to competitors. The material contains trade secrets and confidential information that Philips does not customarily release to the public and which is otherwise not generally available to the public. Please contact the undersigned by phone at 410-531-3439, by fax at 410-531-0807, by email at [email protected], or by correspondence at the address below if there are any further questions or additional information needed concerning this filing. Regards, (signed) Phillip Inglis, TRP/Cetracoms 14085 Howard Rd. Dayton, MD. 21036

Cover Letter(s)

TRP Inc. 14085 Howard Rd Dayton, MD 21036 September 14,2006 Federal Communications Commission Authorization & Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: Philips Industrial Activities Louvain FCC ID: PT5TSU9600 Gentlemen: Submitted herewith, on behalf of Philips Industrial Activities Louvain, is an application for Part 15 certification of the RF Transmitter, 802.11b, Remote Control. Attached are the authorization letter, measurement report (measurement data and test plots), FCC ID label and location, test setup photographs, internal and external photographs, block diagram, schematic diagram, operational description, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. Phillip Inglis TRP Inc. cc: Philips Industrial Activities Louvain

External Photos

ID Label/Location Info

3104 200 0712 Approbation sticker TSU9600/00 CLASS NO SCALE SCHAAL PROJ EUROP GENERAL ROUGHNESS ALGEMENE RUWHEID UNIT EENH. mm ITEM POST ASSEMBLY NO. SAMENSTELLINGSNR. QUANT. AANTAL NAME NAAM CHECK CONTR. DAT. SUPERS. VERV. Property of Eigendom van N.V. PHILIPS GLOEILAMPENFABRIEKEN EINDHOVEN - NEDERLAND 2822 100 02501 TOLERANCES UNLESS OTHERWISE STATED TOLERANTIES TENZIJ ANDERS VERMELD DIMENSION MAAT ANGLE HOEK MA TERIAL MA TERIAAL TREA TMENT BEHANDELING . . . . . . UN-D 28 . . R a in um , A A UN-D 603 PATTERN NO./MODELNR. ORDER NO./ORDERNR. QUANT. AANTAL PHILIPS TSU9600/00 Frans Michiels PL2005-12-12 01 110 0110 4 2006-08-03 ENVIRONMENTAL REQUIREMENT : NO BANNED SUBSTANCES ACC. TO UAW-0480/100 A4 ALL RIGHTS ARE RESER VED, REPRODUCTION IN WHOLE OR IN P AR T IS PROHIBITED WITHOUT THE WRITTEN CONSENT OF THE COPYRIGHT OWNER. R2 +/-0.2 Thickness inclusive adhesive = 0,4 max Front side Punching direction Rear side self adhesive < Outline artwork version to use for printing on the product. 3104-200-0712-4-110 (2006-08-03).eps Polypropylene Axprint Fine Sand. Thickness 0.3 mm. 6NE100 PRINTING REQUIREMENTS - Frontside : no printing - Rearside : acc. to UAN-D1235 : App30 - Clim1 -ADHESIVE REQUIREMENTS - Rearside has to be self adhesive and adhesive and protected with an easely removable layer - Adhesive specification equivalent to Mactac-Macband B1148 GENERAL REQUIREMENTS - PCB and PCT free acc. to UAN-D1675 - Cadmium free acc. to UAN-D1597 - Product must be free from scratches and damages PRINTING - Print on back side acc. to OUTLINE ARTWORK version on this drawing. color text : Black 80007 color background : Bright Silver acc to 11126 Color of rectangular area: No printing, it will be transparent. 2005-07-19 2004-06-01 2006-03-03 Transparent area ! 2004-07-13 2004-08-04 16 32 1,5 +/-0.2 This area free of self adhesive DELIVER - Approbation sticker to be delevered on sheet Prin ting changed .4 2 2006-03-03 = = 3 2006-05-19 T S U 9600 3. 7 V ____ _ _ _ 1A MADE IN B E L G IU M 30 +0,1 -0,2 60 +0,1 -0,2 P hilips C ons umer E lec tronic s C ompa ny , Ma rietta , G A 30006-0026 U . S . A . FCC ID : PT5TSU9600 IC: 135P-TSU9600 31 2 Z043 = = 4 2006-07-17 PHILIPS FCC ID: PT5TSU9600 EUT Photographs © 2006 PCTEST Lab. Pronto Control Panel Model: TSU9600

Internal Photos

PHILIPS FCC ID: PT5TSU9600 EUT Photographs © 2006 PCTEST Lab. Pronto Control Panel Model: TSU9600 PHILIPS FCC ID: PT5TSU9600 EUT Photographs © 2006 PCTEST Lab. Pronto Control Panel Model: TSU9600 PHILIPS FCC ID: PT5TSU9600 EUT Photographs © 2006 PCTEST Lab. Pronto Control Panel Model: TSU9600 PHILIPS FCC ID: PT5TSU9600 EUT Photographs © 2006 PCTEST Lab. Pronto Control Panel Model: TSU9600 PHILIPS FCC ID: PT5TSU9600 EUT Photographs © 2006 PCTEST Lab. Pronto Control Panel Model: TSU9600 PHILIPS FCC ID: PT5TSU9600 EUT Photographs © 2006 PCTEST Lab. Pronto Control Panel Model: TSU9600 PHILIPS FCC ID: PT5TSU9600 EUT Photographs © 2006 PCTEST Lab. Pronto Control Panel Model: TSU9600 PHILIPS FCC ID: PT5TSU9600 EUT Photographs © 2006 PCTEST Lab. Pronto Control Panel Model: TSU9600

RF Exposure Info

September 14, 2006 RF Exposure This transmitter has a nominal power output of 0.058 watts. In this application the card is inserted in a hand held banking terminal. Since the unit is only used while at arms length with a communications interval that is very short (sufficient to transfer credit card info only) the Commission considers the application to be mobile device. Information is provided to the user that he should operate the unit only at arm’s length. Compliance with the RF exposure limit for a distance of 20 cm (mobile device classification) for a power output of 53 mW EIRP can be calculated according to Pd = P/4piR 2 or 115/4x3.14x400 = 0.01 mW/cm 2 . This is below the FCC compliance limit. Phillip Inglis Consultant to Philips

Test Report

Reviewed by: FCC ID: PT5TSU9600 FCC Pt. 15.247 CERTIFICATION TEST REPORT (WLAN 802.11b/g) Quality Manager Test Report S/N: Test Dates: EUT Type: 0608040653 August 18 - 24, 2006 Pronto Remote Control Panel (802.11b/g) Page 1 of 35 © 2006 PCTEST Engineering Laboratory, Inc. Ver. 2.61 Applicant Name: Date of Testing: Philips Industrial Activities Louvain August 18 - 24, 2006 Interleuvenlaan 74-82 Test Site/Location: 3001, Leuven PCTEST Lab, Columbia, MD, USA Belgium Test Report Serial No.: 0608040653 FCC ID: PT5TSU9600 APPLICANT: Philips Industrial Activities Louvain Model(s): TSU9600 EUT Type: Pronto Remote Control Panel (802.11b/g) Max. RF Output Power: 17.63 dBm Conducted (b) 17.26 dBm Conducted (g) Frequency Range: 2412 - 2462 MHz (DSSS/OFDM) FCC Classification: Digital Transmission System (DTS) FCC Rule Part(s): Part 15.247 Test Device Serial No.: PL1A0629000162 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C-63.4-2003. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Listed output power is conducted. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC PART 15.247 Certification Reviewed by: FCC ID: PT5TSU9600 FCC Pt. 15.247 CERTIFICATION TEST REPORT (WLAN 802.11b/g) Quality Manager Test Report S/N: Test Dates: EUT Type: 0608040653 August 18 - 24, 2006 Pronto Remote Control Panel (802.11b/g) Page 2 of 35 © 2006 PCTEST Engineering Laboratory, Inc. Ver. 2.61 TABLE OF CONTENTS FCC PART 15.247 MEASUREMENT REPORT...................................................................................................3 1.0 INTRODUCTION ..................................................................................................................................................... 4 1.1 EVALUATION PROCEDURE ............................................................................................................................................... 4 1.2 SCOPE ................................................................................................................................................................................. 4 1.3 PCTEST TEST LOCATION .................................................................................................................................................. 4 2.0 PRODUCT INFORMATION ..................................................................................................................................... 5 2.1 EQUIPMENT DESCRIPTION ............................................................................................................................................... 5 2.2 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS............................................................................................................ 5 3.0 DESCRIPTION OF TEST ........................................................................................................................................ 6 3.1 CONDUCTED EMISSIONS .................................................................................................................................................. 6 3.2 RADIATED EMISSIONS ....................................................................................................................................................... 7 4.0 ANTENNA REQUIREMENTS.................................................................................................................................. 8 5.0 TEST EQUIPMENT CALIBRATION DATA .............................................................................................................. 9 6.0 TEST RESULTS .................................................................................................................................................... 10 6.1 6DB BANDWIDTH MEASUREMENT – 802.11B/G ............................................................................................................ 11 6.2 OUTPUT POWER MEASUREMENT – 802.11B ................................................................................................................ 15 6.3 OUTPUT POWER MEASUREMENT – 802.11G................................................................................................................ 16 6.4 POWER SPECTRAL DENSITY (802.11B/G) ..................................................................................................................... 17 6.5 OUT OF BAND EMISSIONS (BAND EDGE)...................................................................................................................... 21 6.6 RADIATED MEASUREMENTS .......................................................................................................................................... 23 6.7 RADIATED RESTRICTED BAND MEASUREMENTS ....................................................................................................... 27 6.8 LINE-CONDUCTED TEST DATA ....................................................................................................................................... 28 6.9 RECEIVER SPURIOUS MEASUREMENTS ...................................................................................................................... 30 7.0 CONCLUSION .........................................................................................................................…
