(2) Mounting Screws (2) Eyehole Brackets (2) V-Hooks (2) Drywall Anchors Power Drill with Drill Bits Safety Goggles Measuring Tape Ladder Shop Light (2) Hanging Hooks Use toggle bolts (not included) to replace drywall anchors, hanging hooks and screws if desired. ©2026 Savant Technologies, LLC. GE is a trademark of General Electric Company. Used under trademark license.Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc. or its affiliates. Google and other related marks and logos are trademarks or Google, LLC. INCLUDED YOU’LL NEED ALTERNATIVE MOUNTING OPTION (1) Pull Chain Extension (1) Cable Tie (2) Hanging Chains Determine location, complete installation and power on the Shop Light Add the Shop Light to the Cync App, powered by Savant or Matter- compatible smart home app Set up your Amazon Alexa or Google Home voice assistant (optional) For set up help, call 1-844-302-2943 or visit cyncsupport.gelighting.com Getting Started Let’s Do It Specifications PREPARE ELECTRICAL WIRING ModelInput Voltage (Vac, Hz) Current (mA) Wattage (W) Direct Connect 46” Shop Light 120/6075085 Before you begin: Read these instructions completely and carefully. Before installing, ensure all parts are present. This product must be installed in accordance with the applicable installation code by a person familiar with the construction and operation of the product and the hazards involved. ELECTRICAL REQUIREMENTS The LED fixture must be supplied with 120V AC 60Hz power. GROUNDING INSTRUCTIONS The grounding and bonding of the overall system shall be done in accordance with National Electric Code (NEC) and local codes. WARNING • Risk of shock. • House electric current can cause painful shock or serious injury unless handled properly. • Turn off the main power at the circuit breaker before installing the fixture, in order to prevent possible shock. • The luminaire is non-dimmable. • The luminaire is for residential use only. • Suitable for damp location. • Linkable up to 4 units. All electrical connections must be in accordance with local National Electrical Code (N.E.C.) standards. If you are unfamiliar with proper electrical wiring connections obtain the service of a qualified electrician. This fixture is intended to be only installed directly beneath a ceiling-mounted receptacle. Remove the fixture and the mounting package from the box and make sure that no parts are missing by referencing the illustrations on the installation instruction. Note: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference; (2) this device must accept any interference received, including interference that may cause undesired operation. Risk of Damage: Must use UL approved conduit fittings for all enclosure box connections to prevent wire cuts by sharp edges and excessive strain on wiring. Before beginning assembly, installation and operation of the product, make sure all parts are present. Compare parts with package contents list and hardware contents. If any part is missing or damaged, do not attempt to assemble, install or operate the product. Contact customer service. Check your installation location to make sure there is a receptacle on the ceiling. If not, consult a qualified electrician to install a correct branch circuit receptacle. Remove protective film on the plastic lens before installation. PRE-INSTALLATION Warning: Before wiring the fixture to the house power supply, ensure the electricity is TURNED OFF at the main circuit breaker or fuse box. DO NOT ATTEMPT TO INSTALL FIXTURE WITH THE POWER ON. All wiring connections must be made with the POWER OFF to avoid personal injury and/or damage to the fixture. Verify power is OFF at the junction box using AC voltage tester before installation. If using ladder for installation, ensure ladder base is secure and stable before attempting light fixture installation. Caution: Do not install on radiant-heat ceilings. Do not use hooks to engage electric cord. Hooks are to engage the chain only and not the electric cord. INSTALLATION SURFACE MOUNT INSTALLATION EYEHOLE BRACKET Mark two points on the desired mounting location with 46.5 inches / 118.3cm distance between them. Insert the eyehole bracket onto the screw with the bent edges facing downward. Hold the Shop Light up to the screws and slide the eyehole bracket into the fixture’s end cap opening. Repeat on other side of the fixture. Plug the power cord into the outlet. Hard Wood Installation Locate the two marked positions. If necessary, pre-drill a small pilot hole using a 1/8-inch / 3mm drill bit. Tighten 2 screws. Drywall Installation Locate the two marked positions. Drill a 1/4-inch / 6mm hole and insert a drywall anchor. Insert the mounting screw and tighten, leaving approximately 1/8 inch of space between the ceiling and the screw head. 1.2.3. 46.5 inch 118.3 cm SUSPENDED INSTALLATION CHAIN & HOOKFINISH OPTIONS Mark two points on the desired mounting location with 43.7 inches / 111cm distance between them. LINKING Link Multiple Shop Lights Connect the connect the power cord into the other fixture’s receptacle. Connect up to 4 Smart Shop Lighting to a single power outlet. Hard Wood Installation Locate the two marks. Pre-drill a small pilot hole using 1/8-inch / 3mm bit if necessary. Insert the hanging hook and screw until the bottom of the eye hole is flush with the ceiling. Drywall Installation Locate the two marks. Drill a 1/4-inch / 6mm hole and insert drywall anchor. Insert the hanging hook into the drywall anchor and screw until the bottom of the eye hole is flush with the ceiling. Use the cable tie to attach the power cord to the hanging chain. Plug the power cord into the outlet. EXTENDING PULL CHAIN Extend ON/OFF Pull Chain Connect the extension chain to the end of the pull chain. Attach the chain to the V-hook by inserting the end of the hook through the opening in the bottom chain link. Insert both end…

Text truncated - open the document above for the full version.

Savant Technologies LLC, dba GE Lighting, a Savant company 1975 Noble Road, East Cleveland, OH 44112 USA Covered Equipment Certification Attestation Letter 6/22/2026 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: PUU-CFIXSHP46 Savant Technologies LLC, dba GE Lighting, a Savant company (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Savant Technologies LLC, dba GE Lighting, a Savant company (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Savant Technologies LLC, dba GE Lighting, a Savant company (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti- virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Signed: Printed name: Paul Smith Title: Lead Systems Engineer – Safety & Regulatory Company Name: Savant Technologies LLC, dba GE Lighting, a Savant compan Date: 7/1/2026

Savant Technologies LLC, dba GE Lighting, a Savant company 1975 Noble Road, East Cleveland, OH 44112 USA * the applicant must designate a contact located in the United States for purposes of acting as the appli cant’s agent for service of process, regardless of whether the applicant is a domestic or fo reign entity. An app licant located in the United States may designate itself as the agent for servic e of p rocess. U.S. Agent Designation for Service of Process - Certification Attestation Letter 6/22/2026 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: PUU-CFIXSHP46 Per section 2.911(d)(7) of the FCC rules, Savant Technologies LLC, dba GE Lighting, a Savant company (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. Designated agent* for service of process: Compan y Name: Savant Technologies LLC, dba GE Lighting, a Savant company Ph ysical U.S. Company Address: 1975 Noble Road, East Cleveland, OH 44112 USA Agent name: Paul Smith Agent Email Address: [email protected] FRN:0022026876 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant/Designated Agent Signed: Signed: Printed nam e: Paul Smith Title: Lead Systems Engine er – Safety & Regulatory Company Name: Savant Technologies LLC, dba GE Li ghting, a Savant company Date: Jul y 1, 2026 FRN Code: 0022026876

Savant Technologies LLC, dba GE Lighting, a Savant company 1975 Noble Road, East Cleveland, OH 44112 USA 6/22/2026 Nemko North America, Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 AUTHORITY TO ACT AS AGENT - FCC On our behalf, I appoint Kathy Wang (Audix Technology (Shanghai) Co., Ltd.), to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in FCC regulations will have affixed to it a label identical to that submitted for approval with this application. In signing this letter, Applicant certifies that neither the applicant nor any party to the application is not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti- Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko North America Inc., still resides still resides with us. Sincerely, Printed name: Paul Smith

Savant Technologies LLC, dba GE Lighting, a Savant company 1975 Noble Road, East Cleveland, OH 44112 USA July 1, 2026 Nemko North America, Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 REQUEST FOR CONFIDENTIALITY - FCC FCC ID: PUU-CFIXSHP46 Pursuant to Sections 0.457(d) and 0.459 of the Commission’s Rules and FCC Guidance document 726920, we hereby request permanent confidential treatment of exhibits identified as such in the table below and request they are permanently withheld from public review based on the documents containing trade secrets and proprietary information not customarily released to the public. The public disclosure of this information might be harmful to the applicant and provide unjustified benefits to its competitors. Exhibit Type of Confidentiality Requested Block Diagrams ☒ Permanent ☐ Short Term External Photos ------------------ ☐ Short Term Internal Photos ☐ Permanent* ☐ Short Term Operation Description ☒ Permanent ☐ Short Term Parts List & Placement/BOM ☐ Permanent ☐ Short Term Tune-Up Procedure ☐ Permanent ☐ Short Term Schematic Diagrams ☒ Permanent ☐ Short Term Test Setup Photos ------------------ ☐ Short Term User’s Manual ☐ Permanent* ☐ Short Term The asterisked items (*) require further information to be provided in this justification letter before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. Note: any documents held under the Short-Term confidentiality will automatically become public after the requested time if an appropriate extension request has not been received. Any exhibits (i.e., schematic diagrams) that may have already been requested to have “Permanent” confidentiality as shown above need not be repeated under Short-Term confidentiality request. Sincerely, Signed : Printed name: Paul Smith Title: Lead Systems Engineer – Safety & Regulatory Company Name: Savant Technologies LLC, dba GE Lighting, a Savant company

Appendix II Page 1 of 9 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F26133 APPENDIX II P HOTOGRAPHS OF EUT Appendix II Page 2 of 9 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F26133 FIGURE 1 CYNC SHOPLIGHT (M/N: CFIXSHP46CDMAT) OUT-1 F IGURE 2 CYNC SHOPLIGHT (M/N: CFIXSHP46CDMAT) OUT-2 Appendix II Page 3 of 9 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F26133 FIGURE 3 CYNC SHOPLIGHT (M/N: CFIXSHP46CDMAT) OUT-3 F IGURE 4 CYNC SHOPLIGHT (M/N: CFIXSHP46CDMAT) OUT-4 Appendix II Page 4 of 9 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F26133 FIGURE 5 CYNC SHOPLIGHT (M/N: CFIXSHP46CDMAT) OUT-5 F IGURE 6 CYNC SHOPLIGHT (M/N: CFIXSHP46CDMAT) OUT-6

Label position CFIXSHP46CDMAT 120Vac 60Hz 85W Made in China YYDDD FL GM FCC ID:PUU-CFIXSHP46 IC:10798A-CFIXSHP46 CONFORMS TO UL STD.153 1.6mm 7mm14mm 12mm 1.6mm HVIN:CFIXSHP46

Appendix II Page 5 of 10 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F26134 FIGURE 7 CYNC SHOPLIGHT (M/N: CFIXSHP46CDMAT) COVER REMOVED FIGURE 8 CYNC SHOPLIGHT (M/N: CFIXSHP46CDMAT) LED BOARD FRONT Appendix II Page 6 of 10 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F26134 FIGURE 9 CYNC SHOPLIGHT (M/N: CFIXSHP46CDMAT) LED BOARD BACK FIGURE 10 CYNC SHOPLIGHT (M/N: CFIXSHP46CDMAT) POWER BOARD FRONT Appendix II Page 7 of 10 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F26134 FIGURE 11 CYNC SHOPLIGHT (M/N: CFIXSHP46CDMAT) POWER BOARD BACK FIGURE 12 CYNC SHOPLIGHT (M/N: CFIXSHP46CDMAT) RF BOARD FRONT 1 Appendix II Page 8 of 10 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F26134 FIGURE 13 CYNC SHOPLIGHT (M/N: CFIXSHP46CDMAT) RF BOARD FRONT 2 FIGURE 14 CYNC SHOPLIGHT (M/N: CFIXSHP46CDMAT) RF BOARD BACK Appendix II Page 9 of 10 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F26134 FIGURE 15 CYNC SHOPLIGHT (M/N: CFIXSHP46CDMAT) CHIP&CRYSTAL&ANTENNA Appendix II Page 10 of 10 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F26134 ---END OF APPENDIX II---

Savant Technologies LLC, dba GE Lighting, a Savant company FCC ID: PUU-CFIXSHP46 Page 1 of 3 Audix Technology (Shanghai) Co., Ltd. JAREY LU / Deputy Assistant Manager HUIMIN YAN / Assistant RADIO FREQUENCY EXPOSURE EVALATION General Information Applicant : Savant Technologies LLC, dba GE Lighting, a Savant company EUT Description : CYNC Shoplight Model No. : CFIXSHP46CDMAT Radio Tech : BLE, WIFI2.4G Frequency : 2402MHz-2480MHz, 2412MHz-2462MHz Description of Test Facility Name of Firm : Audix Technology (Shanghai) Co., Ltd. Site Location : 3F, Building 34, No. 680 Guiping Rd., Caohejing, Hi-Tech Park, Shanghai 200233, China NVLAP, Lab Code : 200371-0 FCC Designation Number : CN5027 Test Firm Registration Number: 954668 Results The EUT is operated as one mobile device with separation distance is 20 cm, and it is compliant with the RF Exposure Exemption. Producer : Savant Technologies LLC, dba GE Lighting, a Savant company FCC ID: PUU-CFIXSHP46 Page 2 of 3 Audix Technology (Shanghai) Co., Ltd. Evaluation Method KDB 447498 D04 Interim General RF Exposure Guidance v01 Applicable Standard: FCC CFR 47 §1.1307(b)(3)(i)(B): A single RF source is exempt if the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). P th is given by: Savant Technologies LLC, dba GE Lighting, a Savant company FCC ID: PUU-CFIXSHP46 Page 3 of 3 Audix Technology (Shanghai) Co., Ltd. RF Exposure Evaluation: Mode Frequency Max output power Ant. Gain Max E.I.R.P P th Verdict MHz dBm mW dBi dBm mW mW BLE 2442 4.157 2.60 0.5 4.657 2.922 3060 Compliant 802.11b 2462 15.51 35.56 0.5 16.01 39.902 3060 Compliant 802.11g 2462 13.28 21.28 0.5 13.78 23.878 3060 Compliant 802.11n20 2462 12.46 17.62 0.5 12.96 19.770 3060 Compliant 802.11n40 2452 11.57 14.35 0.5 12.07 16.106 3060 Compliant Note1: For this EUT, and the separation distance is 20 cm. And the Bluetooth and WIFI can not transmit at the same time. Note2: The Conducted output power and Maximum EIRP both no greater than the threshold P th , that meets the exemption, the RF exposure evaluation is not required. -END-

ANTENNASPECIFICATIONS ItemSpecifications Antenna FrequencyRange2400~2483.5MHz PolarizationLinear PeakGain0.5dBi V.S.W.R ＜ 2.0 Impedance50Ω ReturnLoss-10dB ConnectorMicrostriplineconnection Efficiency 25% Type Onboard：ANT0 Size 12.5x6.5mm Manufacturer ShenzhenJingxunTechologyLimited Co.,Ltd Manufactureraddress 3/F,A5BuildingZhiyuanCommunityNo.1001, XueyuanRoad,NanshanDistrict,Shenzhen City,China EnvironmentalOperatingTemperature-40°C~+105°C ANTENNAPATTERN AntennaPicture ：
