PUU-CSWDMXXBWF1NNCbyGE Dimmer Switch

Date: 2019-12-12 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding FCC ID: PUU-CSWDMXXBWF1NN To whom it may concern: We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Shenzhen Branch and Jing Song in SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Shenzhen Branch to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with GE Lighting. This authorization is valid until further written notice from the applicant. Print Name: Tom Stimac Title: Chief Innovation Manager Signature: On behalf of Company: GE Lighting Te l e p h o n e : 2 1 6 2 6 6 2 7 5 6 E-mail: [email protected]

To : Federal Communications Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd. Columbia MD 21046 Regarding: Confidentiality Request regarding application for FCC ID: PUU-CSWDMXXBWF1NN LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential for 180 days from the grant date, whichever is less. If the device is marketed within aforementioned days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. External Photos Internal Photos Test Setup Photos User manual(s) Sincerely, Print Name: Tom Stimac Title: Chief Innovation Manager Signature: On behalf of Company: GE Lighting Te l e p h o n e : 2162662756 E-mail: [email protected]

2.4G WLAN Channels used in US and/or Canada We , GE Lighting declare that this EUT (FCC ID: PUU-CSWDMXXBWF1NN) doesn’t have ad Hoc Mode function on non-US/Canada frequencies. In addition, the frequency selection feature is disabled by firmware for devices marketed to the US/ Canada. For DTS part of this device, only channels 1-11 will be used in North America. Country code selection is disabled. Should you have any questions or comments regarding this matter, Please have my best attention. Print Name: Tom Stimac Title: Chief Innovation Manager Signature: On behalf of Company: GE Lighting Telephone: 2162662756 E-mail: [email protected]

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 5 External Photos for SZEM1911020381CR FCC ID: PUU-CSWDMXXBWF1NN SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 5 1 EUT Constructional Details SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 5

Model: CSWDMOCBWF1NN Rating:120V AC 60Hz Max Load: Incandescent 450W LED 150W FCC ID: PUU-CSWDMXXBWF1NN IC: 10798A-CSWXXBWF1NN Designed in U.S.A. Made in China YYDDDTL LOAD/LINEGROUND 22.5mm Motion Dimmer LOAD/LINEGROUND 22.5mm Model: CSWDMBLBWF1NN Rating:120V AC 60Hz Max Load: Incandescent 450W LED 150W FCC ID: PUU-CSWDMXXBWF1NN IC: 10798A-CSWXXBWF1NN Designed in U.S.A. Made in China YYDDDTL Dimmer

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 3 Internal Photos for SZEM1911020381CR FCC ID: PUU-CSWDMXXBWF1NN SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 3 1 EUT Constructional Details SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 3 WIFI Antenna BT Antenna

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM191102038101 Page: 1 of 58 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZEM1911020381CR Applicant: GE Lighting Address of Applicant: 1975 Noble Road, Cleveland, Ohio 44112, United States. Manufacturer: GE Lighting Address of Manufacturer: 1975 Noble Road, Cleveland, Ohio 44112, United States. Factory: TCL Technoly Electronics (Huizhou) Co., Ltd. Address of Factory: Section 37, Zhongkai High-tech Development Zone, Huizhou City, Guangdong Province, P.R. China Equipment Under Test (EUT): EUT Name: CbyGE Dimmer Switch Model No.: CSWDMOCBWF1NN, CSWDMBLBWF1NN ♣ ♣ Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Trade mark: GE FCC ID: PUU-CSWDMXXBWF1NN Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2019-11-20 Date of Test: 2019-11-21 to 2019-12-16 Date of Issue: 2019-12-19 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM191102038101 Page: 2 of 58 Revision Record Version Chapter Date Modifier Remark 01 2019-12-19 Original Authorized for issue by: Damon Su /Project Engineer Eric Fu /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM191102038101 Page: 3 of 58 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Minimum 6dB Bandwidth 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Conducted Peak Output Power 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Power Spectrum Density 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.4,6.5,6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Remark: Model No.: CSWDMOCBWF1NN, CSWDMBLBWF1NN Only the model CSWDMOCBWF1NN was tested, these two models are identical on all circuitry design, PCB layout, electrical components used, internal wiring except that CSWDMOCBWF1NN have PIR sensor,light sensor and related components,But CSWDMBLBWF1NN do not have PIR sensor,light sensor and related components. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM191102038101 Page: 4 of 58 3 Contents Page 1 COVER PAGE ..................................................................................................................................... 1 2 TEST SUMMARY ................................................................................................................................. 3 3 CONTENTS ......................................................................................................................................... 4 4 GENERAL INFORMATION .................................................................................................................. 6 4.1 DETAILS OF E.U.T. ......................................................................................................................... 6 4.2 DESCRIPTION OF SUPPORT UNITS .................................................................................................... 6 4.3 MEASUREMENT UNCERTAINTY ......................................................................................................... 6 4.4 TEST LOCATION ............................................................................................................................. 7 4.5 TEST FACILITY ............................................................................................................................... 7 4.6 DEVIATION FROM STANDARDS ......................................................................................................... 7 4.7 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................. 7 5 EQUIPMENT LIST ............................................................................................................................... 8 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ............................................................................13 6.1 ANTENNA REQUIREMENT ................................................................................................................13 6.1.1 Test Requirement: ..................................................................................................................13 6.1.2 Conclusion ..............................................................................................................................13 7 RADIO SPECTRUM MATTER TEST RESULTS .................................................................................14 7.1 CONDUCTED EMISSIONS AT AC POW ER LINE (150KHZ-30MHZ) ........................................................14 7.1.1 E.U.T. Operation .....................................................................................................................14 7.1.2 Test Setup Diagram ..........…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM191102038102 Page: 1 of 134 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZEM1911020381CR Applicant: GE Lighting Address of Applicant: 1975 Noble Road, Cleveland, Ohio 44112, United States. Manufacturer: GE Lighting Address of Manufacturer: 1975 Noble Road, Cleveland, Ohio 44112, United States. Factory: TCL Technoly Electronics (Huizhou) Co., Ltd. Address of Factory: Section 37, Zhongkai High-tech Development Zone, Huizhou City, Guangdong Province, P.R. China Equipment Under Test (EUT): EUT Name: CbyGE Dimmer Switch Model No.: CSWDMOCBWF1NN, CSWDMBLBWF1NN ♣ ♣ Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Trade mark: GE FCC ID: PUU-CSWDMXXBWF1NN Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2019-11-20 Date of Test: 2019-11-21 to 2019-12-16 Date of Issue: 2019-12-19 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM191102038102 Page: 2 of 134 Revision Record Version Chapter Date Modifier Remark 01 2019-12-19 Original Authorized for issue by: Damon Su /Project Engineer Eric Fu /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM191102038102 Page: 3 of 134 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Minimum 6dB Bandwidth 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Conducted Peak Output Power 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Power Spectrum Density 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.209 & 15.247(d) Pass Radiated Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.4,6.5,6.6 47 CFR Part 15, Subpart C 15.209 & 15.247(d) Pass Remark: Model No.: CSWDMOCBWF1NN, CSWDMBLBWF1NN Only the model CSWDMOCBWF1NN was tested, these two models are identical on all circuitry design, PCB layout, electrical components used, internal wiring except that CSWDMOCBWF1NN have PIR sensor,light sensor and related components,But CSWDMBLBWF1NN do not have PIR sensor,light sensor and related components. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM191102038102 Page: 4 of 134 3 Contents Page 1 COVER PAGE ..................................................................................................................................... 1 2 TEST SUMMARY ................................................................................................................................. 3 3 CONTENTS ......................................................................................................................................... 4 4 GENERAL INFORMATION .................................................................................................................. 6 4.1 DETAILS OF E.U.T. ......................................................................................................................... 6 4.2 DESCRIPTION OF SUPPORT UNITS .................................................................................................... 6 4.3 MEASUREMENT UNCERTAINTY ......................................................................................................... 6 4.4 TEST LOCATION ............................................................................................................................. 7 4.5 TEST FACILITY ............................................................................................................................... 7 4.6 DEVIATION FROM STANDARDS ......................................................................................................... 7 4.7 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................. 7 5 EQUIPMENT LIST ............................................................................................................................... 8 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ............................................................................13 6.1 ANTENNA REQUIREMENT ................................................................................................................13 6.1.1 Test Requirement: ..................................................................................................................13 6.1.2 Conclusion ..............................................................................................................................13 7 RADIO SPECTRUM MATTER TEST RESULTS .................................................................................14 7.1 CONDUCTED EMISSIONS AT AC POW ER LINE (150KHZ-30MHZ) ........................................................14 7.1.1 E.U.T. Operation .....................................................................................................................14 7.1.2 Test Setup Diagram …

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM191102038103 Page: 1 of 7 Keny Xu EMC Laboratory Manager 1 Cover page RF Exposure Evaluation Report Application No.: SZEM1911020381CR Applicant: GE Lighting Address of Applicant: 1975 Noble Road, Cleveland, Ohio 44112, United States. Manufacturer: GE Lighting Address of Manufacturer: 1975 Noble Road, Cleveland, Ohio 44112, United States. Factory: TCL Technoly Electronics (Huizhou) Co., Ltd. Address of Factory: Section 37, Zhongkai High-tech Development Zone, Huizhou City, Guangdong Province, P.R. China EUT Name: CbyGE Dimmer Switch Model No.: CSWDMOCBWF1NN, CSWDMBLBWF1NN ♣ Please refer to section 4 of this report which indicates which model was actually tested and which were electrically identical. Trade mark: GE FCC ID: PUU-CSWDMXXBWF1NN Standards: 47 CFR Part 1.1307 47 CFR Part 1.1310 Date of Receipt: 2019-11-20 Date of Test: 2019-11-21 to 2019-12-16 Date of Issue: 2019-12-19 Test Result : Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM191102038103 Page: 2 of 7 2 Version Revision Record Version Chapter Date Modifier Remark 01 2019-12-19 Original Authorized for issue by: Damon Su /Project Engineer Eric Fu /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM191102038103 Page: 3 of 7 3 Contents Page 1 COVER PAGE ..................................................................................................................................................... 1 2 VERSION ............................................................................................................................................................. 2 3 CONTENTS ......................................................................................................................................................... 3 4 GENERAL DESCRIPTION OF EUT.................................................................................................................. 4 4.1 TEST LOCATION .................................................................................................................................................. 5 4.2 TEST FACILITY.................................................................................................................................................... 5 4.3 DEVIATION FROM STANDARDS ............................................................................................................................. 5 4.4 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................................... 5 4.5 OTHER INFORMATION REQUESTED BY THE CUSTOMER .......................................................................................... 5 5 RF EXPOSURE EVALUATION ......................................................................................................................... 6 5.1 RF EXPOSURE COMPLIANCE REQUIREMENT .......................................................................................................... 6 5.1.1 Limits ....................................................................................................................................................... 6 5.1.2 Test Procedure ....................................................................................................................................... 6 5.1.3 EUT RF Exposure Evaluation ............................................................................................................... 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM191102038103 Page: 4 of 7 4 General Description of EUT Power Supply: Input: AC 120V, 60Hz, 450W For BLE: Operation Frequency: 2402MHz~2480MHz Bluetooth Version: V4.2 Modulation Type: GFSK Number of Channel: 40 Antenna Type: PCB Antenna Antenna Gain: 2.27dBi For 2.4G wifi: Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz 802.11n(HT40): 2422MHz to 2452MHz Channel Numbers: 802.11b/g/n(HT20):11 802.11n(HT40):7 Channel Separation: 5MHz Type of Modulation: 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Antenna Type: PCB Antenna Antenna Gain: 2.73dBi Remark: Model No.: CSWDMOCBWF1NN, CSWDMBLBWF1NN Only the model CSWDMOCBWF1NN was tested, these two models are identical on all circuitry design, PCB layout, electrical components used, internal wiring except that CSWDMOCBWF1NN have PIR sensor,light sensor and related components,But CSWDMBLBWF1NN do not have PIR sensor,light sensor and related components. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM191102038103 Page: 5 of 7 4.1 Test Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen Branch No. 1 Workshop, M-10, Middle Section, Science & Technology Park, Shenzhen, Guangdong, China. 518057. Tel: +86 755 2601 2053 Fax: +86 755 2671 0594 No tests were sub-contracted. 4.2 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01. • VCCI The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz, Shielded Room for Mains Port Conducted Interference Measurement and Telecommunication Port Conducted Interference Measurement of SGS-CSTC Standards Technical Services Co., Ltd. have been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: G-20026, R-14188, C-12383 and T-11153 respectively. • FCC –Designation Number: CN1178 SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory has been recognized as an accredited testing laboratory. Designati…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 3 Setup Photos for SZEM1911020381CR FCC ID: PUU-CSWDMXXBWF1NN SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 3 1 Photographs 1.1 Conducted Emissions at AC Power Line (150kHz-30MHz) Test Setup SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 3 1.2 Radiated Spurious Emissions Test Setup
