PUU-QOPWX20120120 Vac Dual 20 A Wiser Control Relay

Instruction Bulletin Boletín de instrucciones Directives d'utilisation NNZ90049 Rev. 04, 12/2023 120 Vac Dual 20 A Wiser™ Control Relay Relevador de control doble Wiser™ de 120 VCA 20 A Relais de commande Wiser MC 120 Vca à deux entrées Retain for future use. / Conservar para uso futuro. / À conserver pour usage ultérieur. ™ Replaces / Reemplaza / Remplace NNZ90049, 01/2023 ContentsContenidoContenu (1) Dual 20 A Wiser control relay QO200PWX120 (1) Relevador de control doble Wiser de 20 A QO200PWX120 (1) Relais de commande Wiser à deux entrées 20 A QO200PWX120 DANGER / PELIGRO / DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH • Apply appropriate personal protective equipment (PPE) and follow safe electrical work practices. See NFPA 70E, NOM-029-STPS or CSA Z462 or local equivalent. • This equipment must only be installed and serviced by qualified electrical personnel. • Turn off all power supplying this equipment before working on or inside equipment. • Always use a properly rated voltage sensing device to confirm power is off. • Circuit breaker must only be supplied by grounded neutral electrical systems. • Replace all devices, doors and covers before turning on power to this equipment. PELIGRO DE DESCARGA ELÉCTRICA, EXPLOSIÓN O DESTELLO POR ARQUEO • Utilice equipo de protección personal (EPP) apropiado y siga las prácticas de seguridad en trabajos eléctricos establecidas por su Compañía. Consulte las normas 70E de NFPA, NOM-029-STPS, CSA Z462 o su equivalente local. • Solo el personal eléctrico calificado deberá instalar y prestar servicios de mantenimiento a este equipo. • Desenergice el equipo antes de realizar cualquier trabajo dentro o fuera de él. • Siempre utilice un dispositivo detector de tensión de valor nominal adecuado para confirmar la desenergización del equipo. • El interruptor automático solo debe estar alimentado por sistemas eléctricos neutros conectados a tierra. • Reemplace todos los dispositivos, las puertas y las cubiertas antes de volver a energizar el equipo. RISQUE D’ÉLECTROCUTION, D’EXPLOSION OU D’ARC ÉLECTRIQUE • Porter un équipement de protection individuelle (EPI) approprié et observer les méthodes de travail électrique sécuritaires. Voir NFPA 70E, NOM-029- STPS, CAN/CSA Z4 62 ou équivalent local. • Seul un personnel qualifié doit effectuer l’installation et l’entretien de cet appareil. • Couper toutes les alimentations à cet équipement avant d’y travailler. • Toujours utiliser un dispositif de détection de tension à valeur nominale appropriée pour s'assurer que l’alimentation est coupée. • Le disjoncteur ne doit être alimenté que par des systèmes électriques avec neutre mis à la terre. • Replacer tous les dispositifs, les portes et les couvercles avant de mettre l’appareil sous tension. Failure to follow these instructions will result in death or serious injury. El incumplimiento de estas instrucciones causará la muerte o lesiones graves. Le non-respect de ces directives entraînera la mort ou des blessures graves. WARNING:This product can expose you to chemicals including Styrene, which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm.For more information go to www.P65Warnings.ca.gov . ADVERTENCIA: Este producto puede exponerle a químicos incluyendo Estireno, que es conocido por el Estado de California como causantes de cáncer, y Bisfenol A (BPA), que es conocido por el Estado de California como causante de defectos de nacimiento u otros daños reproductivos. Para mayor información, visite www.P65Warnings.ca.gov . AVERTISSEMENT: Ce produit peut vous exposer à des agents chimiques, y compris Styrène, identifiés par l'État de Californie comme pouvant causer le cancer, et Bisphénol A (BPA), reconnu par l'État de Californie comme pouvant causer des malformations congénitales ou autres troubles de l'appareil reproducteur. Pour de plus amples informations, prière de consulterwww.P65Warnings.ca.gov . Table / Tabla / Tableau 1: Specifications / Especificaciones / Spécifications Power / Alimentación / Alimentation Inputs / Entradas / Entrées 120 Vac @ 60 Hz, 20A max upstream single pole circuit breaker (each input) / 120 VC A a 60 Hz , interruptor automático del lado de la fuente de máx. 20 A (cada entrada) / Disjoncteur unipolaire 120 Vc a à 60 Hz , 20 A maximum en amont (chaque entrée) Load Power / Alimentación de carga / Puissance de charge1920 VA max (each input) / 1920 VA máx. (cada entrada) / 1920 VA max. (par entrée) Features of Automatic Action / Características de acción automática / Caractéristiques d’action automatique Type 1.B action / Acción de tipo 1B / Action de type 1. B Purpose of Control / Propósito del control / Objectif du contrôle Operating Control, Smart Relay Control Module / Control de funcionamiento, Módulo inteligente de control de relevadores / Contrôle de fonctionnement, module de contrôle de relais intelligent Open Type / Tipo abierto / Type ouvert Independently mounted for flush mounting / Montado de manera independiente para montaje empotrado / Montage indépendant pour montage encastré Pollution Degree / Grado de contaminación / Degré de pollution2 / 2 / 2 Rated Impulse Voltage / Tensión nominal de impulso / Tension assignée d’impulsion 2500 V / 2500 V / 2500 V Software Class / Clase de software / Classe logicielleClass A / Clase A / Classe A O perating Temperature Range / Rango de temperatura de funcionamiento / Plage de températures de service -22–122°F (-30–50°C) / -30–50 °C (-22–122 °F ) / De –30 à 50 °C Terminals / Terminales / Bornes Screw Tighten Torque / Par de apriete de tornillos / Couple de serrage des vis 1.34 N•m /1,34 N•m / 1,34 N•m Wire / Conductor Type/ Tipo alambre / conductor / Type de fil / conducteur #14 – #8 AWG Copper only / Cobre solamente / Cuivre seulement 120 Vac Dual 20 A Wiser™ Control Relay Relevador de control doble Wiser™ de 120 VCA 20 ANNZ90049 Relais de commande Wiser MC 120 Vca …

Text truncated - open the document above for the full version.

Savant Technologies LLC, dba GE Lighting, a Savant company 1975 Noble Road, East Cleveland, OH 44112 USA U.S. Agent Designation for Service of Process - Certification Attestation Letter January 25, 2024 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: PUU-QOPWX20120 Per section 2.911(d)(7) of the FCC rules, Savant Technologies LLC, dba GE Lighting, a Savant company (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. Designated agent* for service of process: Company Name: Savant Technologies LLC, dba GE Lighting, a Savant company Physical U.S. Company Address: 1975 Noble Road, East Cleveland, OH 44112 USA Agent name: Paul Smith Agent Email Address: [email protected] FRN: 0022026876 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Designated Agent Signed: (Required, if different to Applicant): Signed: Signed: Printed name: Paul Smith Printed name: Click here to enter text. Title: Lead Systems Engineer – Safety & Regulatory Title: Click here to enter text. Company Name: Savant Technologies LLC, dba GE Lighting, a Savant company Company Name: Click here to enter text. Date: January 25, 2024 Date: Click here to enter a date. FRN Code: 0022026876 FRN Code:

Savant Technologies LLC, dba GE Lighting, a Savant company 1975 Noble Road, East Cleveland, OH 44112 USA Covered Equipment Certification Attestation Letter DATE 1/25/2024 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: PUU-QOPWX20120 Savant Technologies LLC, dba GE Lighting, a Savant company (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Savant Technologies LLC, dba GE Lighting, a Savant company (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Paul Smith Title: Lead Systems Engineer – Safety & Regulatory Company Name: Savant Technologies LLC, dba GE Lighting, a Savant company Date: 1/25/2024

Savant Technologies LLC, dba GE Lighting, a Savant company 1975 Noble Road, East Cleveland, OH 44112 USA 5/25/2023 Nemko North America, Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 AUTHORITY TO ACT AS AGENT - FCC On our behalf, I appoint Kamp Chen (Audix Technology (Shanghai) Co., Ltd.), to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in FCC regulations will have affixed to it a label identical to that submitted for approval with this application. In signing this letter, Applicant certifies that neither the applicant nor any party to the application is not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko North America Inc., still resides still resides with us. Sincerely, Printed name: Paul Smith

Savant Technologies LLC, dba GE Lighting, a Savant company 1975 Noble Road, East Cleveland, OH 44112 USA January 25, 2024 Nemko North America, Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 REQUEST FOR CONFIDENTIALITY - FCC FCC ID: PUU-QOPWX20120 Pursuant to Sections 0.457(d) and 0.459 of the Commission’s Rules and FCC Guidance document 726920, we hereby request permanent confidential treatment of exhibits identified as such in the table below and request they are permanently withheld from public review based on the documents containing trade secrets and proprietary information not customarily released to the public. The public disclosure of this information might be harmful to the applicant and provide unjustified benefits to its competitors. We also request short-term confidentiality on certain exhibits until the intended date of marketing as outlined below. We request the exhibits be withheld from public view for a period of 180 days. We attest marketing of the product will only commence after the period of short-term confidentiality expires, or if marketing is to commence before the requested number of days listed above, the grantee will inform Nemko to release the Short-Term Confidentiality information withheld on the FCC equipment authorization website. Exhibit Type of Confidentiality Requested Block Diagrams ☒Permanent ☐Short Term External Photos ------------------ ☐Short Term Internal Photos ☐Permanent*☐Short Term Operation Description ☒Permanent ☐Short Term Parts List & Placement/BOM ☐Short Term Tune-Up Procedure ☐Permanent☐Short Term Schematic Diagrams ☒Permanent ☐Short Term Test Setup Photos ------------------ ☐Short Term User’s Manual ☐Permanent*☐Short Term The asterisked items (*) require further information to be provided in this justification letter before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. Note: any documents held under the Short-Term confidentiality will automatically become public after the requested time if an appropriate extension request has not been received. Any exhibits (i.e., schematic diagrams) that may have already been requested to have “Permanent” confidentiality as shown above need not be repeated under Short-Term confidentiality request. Sincerely, Signed: Printed name: Paul Smith Title: Lead Systems Engineer – Safety & Regulatory Company Name: Savant Technologies LLC, dba GE Lighting, a Savant company ☐Permanent

Appendix II Page 1 of 9 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F24022 APPENDIX II P HOTOGRAPHS OF EUT Appendix II Page 2 of 9 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F24022 FIGURE 1 120 VAC DUAL 20 A WISER CONTROL RELAY (QO200PWX120) F RONT APPEARANCE F IGURE 2 120 VAC DUAL 20 A WISER CONTROL RELAY (QO200PWX120) BACK APPEARANCE Appendix II Page 3 of 9 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F24022 FIGURE 3 120 VAC DUAL 20 A WISER CONTROL RELAY (QO200PWX120) L EFT F IGURE 4 120 VAC DUAL 20 A WISER CONTROL RELAY (QO200PWX120) RIGHT Appendix II Page 4 of 9 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F24022 FIGURE 5 120 VAC DUAL 20 A WISER CONTROL RELAY (QO200PWX120) T OP F IGURE 6 120 VAC DUAL 20 A WISER CONTROL RELAY (QO200PWX120) BOTTOM

Label Location: Label CC G F E D B A H I J D E F G H I J 12345678 ANY PRINTED COPY OF THIS DOCUMENT USED WITHIN SCHNEIDER ELECTRIC IS CONSIDERED UNCONTROLLED. PRINTS State: Number: Revision: Sheet: Scale: Tolerancing Standard : Units of measure : The information is highly confidential and is the exclusive property of Schneider Electric Group copyright reserved. This drawing must not be used for any purpose other than that expressly permitted in writing by the owners and must not be disclosed or reproduced in any way without permission from the owners in writing. This drawing must be returned to the owners when the purpose has ceased. [mm] IN 1:1 S1A1793900 FACEPLATE LABEL FACEPLATE LABEL NNZ9369501 04 1/1 QO200PWX120 LISTED 120 VAC 60Hz Dual Relay, 20A Max #14-8 AWG Min. 90°C CU ONLY -30°C to 50°C SQUARE D Control Relay S3 E523609 Type QO FCC ID: PUU-QOPWX20120 IC: 10798A-QOPWX20120 Module Input: 120VAC 60Hz Per Channel Max Load : 120VAC 60 Hz RES 20A Motor 1HP Home Automation Equipment Indoor use unless installed in a NEMA 3R rated enclosure Load InLoad Out CUT LINE BLACKWHITE [34.1] 1.34 [46.3] 1.82 Released for Manufacturing Printed on 2024/01/26

Appendix II Page 5 of 9 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F24022 FIGURE 7 120 VAC DUAL 20 A WISER CONTROL RELAY (QO200PWX120) C OVER REMOVE F IGURE 8 120 VAC DUAL 20 A WISER CONTROL RELAY (QO200PWX120) POWERBOARD FRONT Appendix II Page 6 of 9 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F24022 FIGURE 9 120 VAC DUAL 20 A WISER CONTROL RELAY (QO200PWX120) POWERBOARD BACK F IGURE 10 120 VAC DUAL 20 A WISER CONTROL RELAY (QO200PWX120) CHIP&CRYSTAL ON POWERBOARD Appendix II Page 7 of 9 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F24022 FIGURE 11 120 VAC DUAL 20 A WISER CONTROL RELAY (QO200PWX120) RF BOARD FRONT F IGURE 12 120 VAC DUAL 20 A WISER CONTROL RELAY (QO200PWX120) RF BOARD BACK Appendix II Page 8 of 9 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F24022 FIGURE 13 120 VAC DUAL 20 A WISER CONTROL RELAY (QO200PWX120) RF BOARD VIEW F IGURE 14 120 VAC DUAL 20 A WISER CONTROL RELAY (QO200PWX120) CHIP&C RY S TAL O N RF BOARD Appendix II Page 9 of 9 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F24022 FIGURE 15 120 VAC DUAL 20 A WISER CONTROL RELAY (QO200PWX120) A NTENNA -END-

Savant Technologies LLC, dba GE Lighting, a Savant company FCC ID: PUU-QOPWX20120 Page 1 of 2 Audix Technology (Shanghai) Co., Ltd. RADIO FREQUENCY EXPOSURE EVALATION Evaluation Method KDB 447498 D04 Interim General RF Exposure Guidance v01 Applicable Standard: FCC CFR 47 §1.1307(b)(3)(i)(B): A single RF source is exempt if the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). P th is given by: Savant Technologies LLC, dba GE Lighting, a Savant company FCC ID: PUU-QOPWX20120 Page 2 of 2 Audix Technology (Shanghai) Co., Ltd. SAR evaluation: <Passed> Mode Frequency Max output power Ant. Gain Max E.I.R.P P th MHz dBm mW dBi dBm mW mW Zigbee 2405 -0.427 0.91 1.49 1.063 1.277 3060 Note1: For this EUT, that is a mobile devices, and the separation distance is 20 cm. Note2: The Conducted output power and Maximum EIRP both no greater than the threshold P th , that meets the exemption, the RF exposure evaluation is not required. -END-

Savant Technologies LLC, dba GE Lighting, a Savant company FCC ID: PUU-QOPWX20120 Page 1 of 48 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F24022 Prepared For: Savant Technologies LLC, dba GE Lighting, a Savant company 1975 Noble Road, Cleveland, OH 44112 Prepared By: Audix Technology (Shanghai) Co., Ltd. 3F, Building 34, No. 680 Guiping Rd., Caohejing, Hi-Tech Park, Shanghai 200233, China Tel: +86-21-64955500 File No. : C1D2401011 Report No. : ACI-F24022 Date of Test : 2024.01.15-26 Date of Report : 2024.01.31 TEST REPORT On behalf of Savant Technologies LLC, dba GE Lighting, a Savant company Product Name: 120 Vac Dual 20 A Wiser Control Relay Model No.: QO200PWX120 FCC ID: PUU-QOPWX20120 The statement is based on a single evaluation of one sample of the above-mentioned products. It does not imply an assessment of the whole production and does not permit the use of the test lab logo. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S. government. Savant Technologies LLC, dba GE Lighting, a Savant company FCC ID: PUU-QOPWX20120 Page 2 of 48 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F24022 TABLE OF CONTENTS Page 1 SUMMARY OF STANDARDS AND RESULTS .......................................................................... 5 1.1 Description of Standards and Results ......................................................................................... 5 2 GENERAL INFORMATION .......................................................................................................... 6 2.1 Description of Equipment Under Test ........................................................................................ 6 2.2 EUT Specifications Assessed in Current Report ........................................................................ 7 2.3 Test Information ......................................................................................................................... 7 2.4 Duty Cycle Check ...................................................................................................................... 7 2.5 Sample Description .................................................................................................................... 8 2.6 Supported equipment .................................................................................................................. 8 2.7 Description of Test Facility ........................................................................................................ 8 3 CONDUCTED EMISSION TEST .................................................................................................. 9 3.1 Test Equipment ........................................................................................................................... 9 3.2 Block Diagram of Test Setup ..................................................................................................... 9 3.3 Conducted Emission Limits (§15.207) ..................................................................................... 10 3.4 Test Configuration .................................................................................................................... 10 3.5 Operating Condition of EUT .................................................................................................... 10 3.6 Test Procedures ........................................................................................................................ 10 3.7 Test Results .............................................................................................................................. 11 4 RADIATED EMISSION TEST ..................................................................................................... 14 4.1 Test Equipment ......................................................................................................................... 14 4.2 Block Diagram of Test Setup ................................................................................................... 15 4.3 Radiated Emission Limit (§15.209) ......................................................................................... 16 4.4 Test Configuration .................................................................................................................... 16 4.5 Operating Condition of EUT .................................................................................................... 16 4.6 Test Procedures ........................................................................................................................ 16 4.7 Test Results .............................................................................................................................. 18 5 6 DB BANDWIDTH MEASUREMENT ...................................................................................... 31 5.1 Test Equipment ......................................................................................................................... 31 5.2 Block Diagram of Test Setup ................................................................................................... 31 5.3 Specification Limits (§15.247(a)(2)) ........................................................................................ 31 5.4 Operating Condition of EUT .................................................................................................... 31 5.5 Test Procedure .......................................................................................................................... 31 5.6 Test Results .............................................................................................................................. 32 6 MAXIMUM PEAK OUTPUT POWER MEASUREMENT ...................................................... 34 6.1 Test Equipment ......................................................................................................................... 34 6.2…

Text truncated - open the document above for the full version.

Antenna Specification Manufacture Savant Technologies LLC, dba GE Lighting, a Savant company Address 1975 Noble Road, Cleveland, OH 44112 Model GEL_52840 Operating Band 2400~2483.5MHz Antenna Type inverted F PCB antenna Polarization Linear Impedance 50Ω Antenna peak gain 1.49dBi Antenna picture (unit: mm) Antenna pattern (2D/3D)

Appendix I Page 1 of 5 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F24022 APPENDIX I P HOTOGRAPHS OF TEST Appendix I Page 2 of 5 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F24022 Test Set-Up Photos 1. Conducted Te s t FRONT VIEW B ACK VIEW Appendix I Page 3 of 5 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F24022 2. Radiated Test (BELOW 1GHZ) FRONT (B ELOW 1GHZ) BACK Appendix I Page 4 of 5 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F24022 (A BOVE 1GHZ) FRONT (ABOVE 1GHZ) BACK Appendix I Page 5 of 5 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F24022 3. Antenna-port Conducted Test
