PUU90001Wireless Outdoor Lighting Controller

Letter of Agency I appoint Intertek Testing Services NA Inc. to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under the FCC rules until further notice. I further certify that no party (as defined in 1.2002 of CFR 47, 1995) to this application, including myself, is subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.,853A. Equipment: _____Wireless Outdoor Lighting Controller PUU90001________________ Dated this 12day of November _, 20 12 . _ Mark Wilbur ____________________ Signature Mark Wilbur __________________________ Name Design Manager _______________________ Title GE Lighting __________________________ Company 216-266-3769_________________________ Telephone

GE Lighting Controls Appropriate Legal Entity Mark Wilbur Design Manager 1975 Noble Road Cleveland Ohio 44077 1-216-266-3769 1-216-533-5144 C Mark.wilbur2@@ge.com Attention: Application Examiner Re: Request for confidentiality Applicant: General Electric Lighting FCC ID: PUU90001 To whom it may concern, Permanent Confidentiality Request is hereby submitted by General Electric Lighting to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential:  Schematics  Detailed Block diagrams  Detailed Operational/Functional Description  Internal photos Non-consumer device inaccessible to general public. The device is mounted on top of a Roadway Lighting Support that is only serviceable by Professional Lighting personnel.  User Manual professional installation is required the user manual is not provided to the consumer since the consumer cannot service the device. Short-term Confidentiality Request is hereby submitted by General Electric Lighting to withhold from public review for a period of 45 days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept confidential for a period of 45 days from the date of Authorization:  Test setup photos  External photos Rationale for request for confidentiality: General Electric Lighting has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development The fee for confidentiality has been submitted along with the fee for certification. If you have questions or need further information, please contact the undersigned. Sincerely, Mark Wilbur Design Manager General Electric Lighting

GE Lighting / Control 11/20/2012 Controller

PAGE REV. GE Part Number: GE2020-6740 1 of 3 4 TITLE: LABEL, WIRELESS OUTDOOR LIGHTING CONTROLLER, 120-277V LED GE LIGHTING NELA PARK This document contains proprietary and confidential information of General Electric Lighting (GEL). The information contained herein shall be disclosed to others only after written consent of GEL. The recipient must limit the utilization of the information contained therein to GEL directed work only. Latest Revision Record: Revision Description Date Approved 1 New 6/19/2012 Yun Hua 2 Updated to conform with FCC labeling Requirements 6/27/2013 Mark Wilbur 3 Update for FCC (removing GE conf) Add location 7/25/2013 Yun Hua 4 Updated per FCC requirement (adding words and label size) 8/27/2013 Yun Hua Reduction of Hazardous Substances: Article or Material must not contain any of the substances restricted by the "Restriction of Hazardous Substances" Directive, citation 2002/95/EC (RoHS), beyond the limits defined in SI 900000 Section 13. Article or Material Must Conform to RoHS Procedure SI900000 Sec 13 Part must conform to SI 900000 section 4 Toxicity Procedure PAGE REV. GE Part Number: GE2020-6740 2 of 3 4 TITLE: LABEL, WIRELESS OUTDOOR LIGHTING CONTROLLER, 120-277V LED Product Label Requirement:  Size: approx. 12mm x 24mm.  Thickness: no more than 0.005”  Material: white Polyester with adhesive on backside. (under UL rec Recognized Marking & Labeling System for outdoor use)  Artwork: as below: - Serial Number should be 16 digits from 0~9; - The date code has a 6 digit (X XX XXX) alphanumeric configuration, which is defined below. a. X – Production Location b. XX – Year (Ex. 11) c. XXX – Julian Date. WOLC NODE S13127 120V-277VAC 50-60HZ 01:23:45:67:89:AB:CD:EF Serial Number Date Code PAGE REV. GE Part Number: GE2020-6740 3 of 3 4 TITLE: LABEL, WIRELESS OUTDOOR LIGHTING CONTROLLER, 120-277V LED Compliance Label Requirement:  Size: approx. 14mm x 24mm.  Thickness: no more than 0.005”  Material: white Polyester with adhesive on backside. (under UL rec Recognized Marking & Labeling System for outdoor use)  Artwork: as below: - FCC contents will be provided by GE technology team a. Trade name: PC b. Model number: XXXXX will be 5 digits from 0~9; c. FCC ID: AAAXXXXX. AAA=3 Character Grantee Code; XXXXX = Applicant's unique Equipment Product Code (14 characters or less). Label Location:  Applied at the bottom of controller node base;  Applied upon below instruction location: WOLC NODE FCC ID: PUU90001 IC ID: 10798A-PUU90001 FCC contents Compliance label Product label This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

TEST REPORT Report Number: 100928878MIN-011A Project Number: G100928878 Testing performed on the WOLC Node FCC ID: PUU90001 Industry Canada ID: 10798A- PUU90001 to 47 CFR Part 15. 247:2010 RSS- 210, Issue 8, 2010 For GE Lighting Test Performed by: Test Authorized by: Intertek Testing Services NA, Inc. 7250 Hudson Blvd., Suite 100 Oakdale, MN 55128 USA GE Lighting 1975 Noble Rd, Bldg 338 Cleveland, OH 44112 USA Prepared by: Date: August 16, 2013 Uri Spector Reviewed by: Date: August 16, 2013 Simon Khazon This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. EMC Report No: 100928878MIN-011A Rev.2 FCC ID: PUU90001 IC ID: 10798A-PUU90001 Page 2 of 54 TABLE OF CONTENTS 1.0 GENERAL DESCRIPTION.......................................................................................................... 3 1.1 Product Description; Test Facility ....................................................................................... 4 1.3 Environmental conditions.................................................................................................... 5 1.4 Measurement uncertainty ................................................................................................... 6 1.5 Field Strength Calculation................................................................................................... 6 2.0 TEST SUMMARY.......................................................................................................................... 7 3.0 TEST CONDITIONS AND RESULTS........................................................................................ 8 3.1 Maximum peak output power.............................................................................................. 8 3.2 Hopping channel carrier frequencies separation.............................................................. 12 3.3 20dB bandwidth of the hopping channel .......................................................................... 14 3.4 Number of hopping frequencies ....................................................................................... 18 3.5 Average time of occupancy of hopping frequency ........................................................... 20 3.6 Antenna conducted spurious emissions ........................................................................... 23 3.6.1 Antenna conducted band edge compliance................................................................... 30 3.7 Radiated spurious emissions............................................................................................ 35 3.8 RF Exposure Compliance ................................................................................................. 43 3.9 Transmitter power line conducted emissions ................................................................... 44 3.10 Receiver/digital device radiated emissions....................................................................... 47 3.11 Digital device conducted emissions.................................................................................. 51 4.0 TEST EQUIPMENT..................................................................................................................... 54 EMC Report No: 100928878MIN-011A Rev.2 FCC ID: PUU90001 IC ID: 10798A-PUU90001 Page 3 of 54 1.0 GENERAL DESCRIPTION Model: WOLC Node Type of EUT: Light Controller Intertek Sample ID: MIN1212041500-002 FCC ID: PUU90001 Industry Canada ID: 10798A- PUU90001 Related Submittal(s) Grants: None Company: GE Lighting Customer: Mr. Mark Wilbur Address: GE Lighting 1975 Noble Rd, Bldg 338 Cleveland, OH 44112 Phone: (216) 266-3769 Fax: (216) 606-6599 e-mail: [email protected] Test Standards: 47 CFR, Part 15:2010, §15.247 RSS–210, Issue 8, 2010 RSS-Gen, Issue 3, 2010 47 CFR, Part 15:2010, §15.107 and §15.109, Class A ICES-003, Issue 5:2012 Other Type of radio: Stand -alone Module Hybrid Date Sample Submitted: December 10, 2012 Test Work Started: December 10, 2012 Test Work Completed: July 15, 2013 Test Sample Conditions: Damaged Poor (Usable) Good EMC Report No: 100928878MIN-011A Rev.2 FCC ID: PUU90001 IC ID: 10798A-PUU90001 Page 4 of 54 1.1 Product Description; Test Facility Product Description: Light Controller Transmitter Type: FHSS Digital Modulation WiFi Blue Tooth Operating Frequency Range(s): From 902 to 928MHz Number of Channels: 50 Modulation: GFSK Emission Designator: 492K5F1D Antenna(s) Info: Type: Pigtail Gain: 2 dBi Connector Type: Soldered to the board Antenna Installation: User Professional Factory Transmitter power configuration: Internal battery External power source 120VAC 230VAC 400VAC VDC Other: Amp. 50Hz 60Hz Special Test Arrangement: None Test Facility Accreditation: A2LA (Certificate No. 1427.01) Test Methodology: Measurements performed according to the procedures in ANSI C63.10- 2009 and FCC Public Notice DA 00-705 EMC Report No: 100928878MIN-011A Rev.2 FCC ID: PUU90001 IC ID: 10798A-PUU90001 Page 5 of 54 1.2 EUT Configuration The equipment under test was operated during the measurement under the following conditions: - Standby - Continuous transmissions with hopping function enabled - Continuous transmissions wit…

Text truncated - open the document above for the full version.

TEST REPORT Report Number: 100928878LEX-001 Project Number: G100928878 Testing performed on the WOLC Node FCC ID: PUU90001 Industry Canada ID: 10798A- PUU90001 to 47 CFR Part 15. 247:2010 RSS- 210, Issue 8, 2010 For GE Lighting Test Performed by: Test Authorized by: Intertek 731 Enterprise Drive Lexington, KY 40510 GE Lighting 1975 Noble Rd, Bldg 338 Cleveland, OH 44112 USA Prepared by: Date: September 27, 2013 Toby Carrier Reviewed by: Date: September 27, 2013 Jason Centers This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no li ability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample t ested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TABLE OF CONTENTS 1.0 GENERAL DESCRIPTION .......................................................................................................... 3 1.1 Product Description; Test Facility ....................................................................................... 4 1.3 Environmental conditions .................................................................................................... 5 1.4 Measurement uncertainty ................................................................................................... 6 1.5 Field Strength Calculation ................................................................................................... 6 2.0 TEST SUMMARY .......................................................................................................................... 7 3.0 TEST CONDITIONS AND RESULTS ........................................................................................ 8 3.1 Maximum peak output power .............................................................................................. 8 3.2 Hopping channel carrier frequencies separation .............................................................. 15 3.3 20dB bandwidth of the hopping channel .......................................................................... 18 3.4 Number of hopping frequencies ....................................................................................... 25 3.5 Average time of occupancy of hopping frequency ........................................................... 28 3.6 Antenna conducted spurious emissions ........................................................................... 33 3.6.1 Antenna conducted band edge compliance ................................................................... 40 3.7 Radiated spurious emissions ............................................................................................ 50 3.8 RF Exposure Compliance ................................................................................................. 52 3.9 Transmitter power line conducted emissions ................................................................... 53 4.0 TEST EQUIPMENT ..................................................................................................................... 57 EMC Report No: 100928878LEX-001 FCC ID: PUU90001 IC ID: 10798A-PUU90001 Page 2 of 54 1.0 GENERAL DESCRIPTION Model: WOLC Node Type of EUT: Light Controller Sample ID: D8:28:C9:00:10:00:01:E6 - +15dBm Radiated Sample D8:28:C9:00:10:00:01:FA - +15dBm Conducted Sample D8:28:C9:00:10:00:02:55 - +26dBm Radiated Sample D8:28:C9:00:10:00:02:3C - +26dBm Conducted Sample FCC ID: PUU90001 Industry Canada ID: 10798A- PUU90001 Related Submittal(s) Grants: None Company: GE Lighting Customer: Mr. Mark Wilbur Address: GE Lighting 1975 Noble Rd, Bldg 338 Cleveland, OH 44112 Phone: (216) 266-3769 Fax: (216) 606-6599 e-mail: [email protected] Test Standards: 47 CFR, Part 15:2010, §15.247 RSS–210, Issue 8, 2010 RSS-Gen, Issue 3, 2010 47 CFR, Part 15:2010, §15.107 and §15.109, Class A ICES-003, Issue 5:2012 Other Type of radio: Stand -alone Module Hybrid Date Sample Submitted: September 23, 2013 Test Work Started: September 23, 2013 Test Work Completed: September 26, 2013 Test Sample Conditions: Damaged Poor (Usable) Good EMC Report No: 100928878LEX-001 FCC ID: PUU90001 IC ID: 10798A-PUU90001 Page 3 of 54 1.1 Product Description; Test Facility Product Description: Light Controller Transmitter Type: FHSS Digital Modulation WiFi Blue Tooth Operating Frequency Range(s): From 902 to 928MHz Number of Channels: 50 Modulation: GFSK Emission Designator: 492K5F1D Antenna(s) Info: Type: Pigtail Gain: 2 dBi Connector Type: Soldered to the board Antenna Installation: User Professional Factory Transmitter power configuration: Internal battery External power source 120VAC 230VAC 400VAC VDC Other: Amp. 50Hz 60Hz Special Test Arrangement: None Test Methodology: Measurements performed according to the procedures in ANSI C63.10- 2009 and FCC Public Notice DA 00-705 EMC Report No: 100928878LEX-001 FCC ID: PUU90001 IC ID: 10798A-PUU90001 Page 4 of 54 1.2 EUT Configuration The equipment under test was operated during the measurement under the following conditions: - Standby - Continuous transmissions with hopping function enabled - Continuous transmissions with hopping function disabled (modulated signal) - Continuous transmissions with hopping function disabled (un-modulated signal) - Continuous receiving - Test program (customer specific) - Operating modes of the EUT: No. Description 1 Test was performed at low …

Text truncated - open the document above for the full version.
