PWGAIRPOINTPROWireless AirPointPRO

APPENDIX C - EUT EXTERNAL PHOTOGRAPHS Chassis - Front View Chassis - Rear View Power Adapter - Top View

APPENDIX A - FCC PRODUCT LABELING AND WARNING STATEMENT FCC ID Label Specifications : Text is black or white in color and is left justified. Labels are silk-screened and shall be “permanently affixed” at a conspicuous location on the EUT. Proposed Label Location on EUT Rear View of EUT FCC ID Label Location FCC ID: PWGAIRPOINTPRO This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2.1875" 1.0"

APPENDIX C - EUT INTERNAL PHOTOGRAPHS Main Board - Component View I Main Board - Solder View I Main Board - Component View II Main Board - Solder View II

Appendices zAppendix A - Specifications of airPoint-pro zAppendix B - Warranty Information zAppendix C - Declaration of Conformity and Regulatory Information Appendix A Specifications : airPoint-PRO General Characteristics Radio Characteristics Type Wireless Access Point and Bridge Compatibility IEEE 802.11b (High Rate) Wi-Fi IEEE 802.3 10/100MBps Media Access Protocol CSMA/CA with ACK & RTS/CTS (Carrier Sense Multiple Access / Collision Avoidance with Acknowledgment) Data Rates High Rate: 11Mbps (CCK) Medium Rate: 5.5Mbps (CCK) Standard Rate: 2Mbps (DQPSK) Low Rate: 1Mbps (DBSK) Network Operating System Microsoft Windows Networking Novell Client 3.x, 4.x Host Operating SystemWindows 98SE, ME, 2000, XP LEDsPower, Eth, Transmission Frequency Band2.4 GHz ISM Band (2.4 - 2.4835 GHz) Number of Selectable Channels (Overlapping) North America (FCC)11 Europe (ETSI)13 France (FR)4 Japan (JP)14 Singapore (iDA)13 Other CountriesFCC 11, ETSI 13 Modulation Techniques DSSS (Direct Sequence Spread Spectrum): zCCK (Complimentary Code Keying), for High and Medium Transmit Rates zDQPSK (Differential Quadrature Phase Shift Keying) for Standard Transmit Rate zDBPSK (Differential Binary Phase Shift Keying) for Low Transmit Rate Security 64-bit & 128-bit WEP encryption Spreading Sequence11 chip Barker Sequence Frame Error RateBetter than 8% Output Power100mW Max with 2.5dBi/5dBi antenna Regulations EuropeETSI 300-328, CE Marked USA FCC 47 CFR Part 15C, Section 15.247 - FCC Certification- ID: PWG AIRPOINTPRO Power Characteristics Physical Characteristics Supported Frequency sub-bands (in MHz) Regulations CanadaRSS 139 JapanMPT Radio Regulations SingaporeiDA approved Power Consumption350 mA at 12V DC Power Supply z12 to 50V DC z12 V DC External Adapter provided.(100 V ~ 264 V / 50 ~60 Hz AC IN 12V DC OUT) zPower Injector Provided. DimensionsL 150mm; W 128mm; H 28mm Weight250 gms Operating Temperature0° to 40° C Storage Temperature-25° to 60° C Humidity Operating: 0 to 70% (non-condensing) Storage: 10 to 90% (non-condensation) Channel number FCC countriesETS countriesFranceJapanSingapore 124122412Not Allocated24122412 224172417Not Allocated24172417 324222422Not Allocated24222422 424272427Not Allocated24272427 524322432Not Allocated24322432 624372437Not Allocated24372437 724422442Not Allocated24422442 824472447Not Allocated24472447 924522452Not Allocated24522452 1024572457245724572457 1124622462246224622462 12Not Allocated2467246724672467 13Not Allocated2472247224722472 NOTE: FCC countries adhere to the regulations as defined by the U.S. Federal Communications Commission (FCC). ETSI countries adhere to the regulations as defined by the European Telecommunications Standards Institute (ETSI). Range NOTE: The range of values listed in the table above are typical distances measured at smartBridges’ premises. These represent indicative values and may vary according to actual radio conditions at the location where the airPoint-PRO will be used. The range of your wireless devices can be affected when they are placed near metal surfaces and solid high- density materials like concrete walls, wood constructions, steel structures etc. Range is also affected by “obstacles” in the signal path of radio. These obstacles may either absorb or reflect the radio signal. Environments can be described as follows: zOutdoor Open Space environment: Devices are in Radio Line of Sight (RLOS) and there is no physical obstruction between them. zSemi-Open Office environment: Workspace is divided by shoulder-height, hollow (glass, plastic) wall elements; airPoint-PRO is placed at desktop level. zClosed Office environment: Workspace is divided by high-density solid wall structures. 14Not AllocatedNot AllocatedNot Allocated2484Not Allocated Distance in meters11Mbps5Mbps2Mbps1Mbps Outdoor Open Space800100013001600 Semi-Open Office7080100120 Closed Office 40507080 Appendix B Warranty Information smartBridges warrants product to be free of defects, and agrees to repair or replace the product that proves defective. airPoint-PRO is warranted for one year from date of purchase. This warranty does not cover accidents, misuse, neglect, unauthorized product modification, or acts of nature. Please visit customer support area of smartBridges web site for making warranty claims. smartBridges may elect to exchange the product or refund the full purchase price of the unit. Except as expressly provided above, smartBridges makes no warranties or conditions, express, implied, or statutory, including without limitation, the implied warranties of merchantability and fitness for a particular purpose or infringement of any patent, copyright or other intellectual property right. smartBridges shall not be liable for damage to other property caused by any defects in this product, damages based upon inconvenience, loss of use of the product, loss of time or data, commercial loss, or any other damages, whether special, incidental, consequential, or otherwise, whether under theory of contract, tort (including negligence), indemnity, product liability, or otherwise. smartBridges products are not intended for use in medical, life saving, or life sustaining applications. In no event shall smartBridges' liability exceed the normal purchase price for this product. Software License No license, express or implied, by estoppels or otherwise, to any intellectual property rights is granted by this document. The setup software is licensed for use with the airPoint-PRO Wireless Access Point only. The software may be copied only for backup purpose. Copyright & Trademarks Copyright © 2001 smartBridges. All Rights Reserved. airPoint-PRO and simpleMonitor are trademarks of smartBridges. Microsoft Windows 98SE, Windows ME, Windows 2000, and Windows XP are trademarks of Microsoft Corporation. All other trademarks and brand names mentioned in this Manual are registered trademarks or trademarks of their respective owners. Appendix C Declaration of Conformity and Regulatory Information DECL…

Text truncated - open the document above for the full version.

Note: This test report is specially limited to the above client company and the product sample only. It may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC PART 15 SUBPART C EMI MEASUREMENT AND TEST REPORT For smartBridges Pte Ltd 10 Anson Road #22-14 International Plaza Singapore 079903 FCC ID: PWGAIRPOINTPRO April 17, 2002 This Report Concerns: Original Report Equipment Type: Wireless AirPointPRO Test Engineer: Jeff Lee Report No.: R0203252 Test Date: April 15 2002 Reviewed By: John Y. Chan – Engineering Manager Prepared By: Bay Area Compliance Laboratory Corporation 230 Commercial Street Sunnyvale, CA 94085 Tel: (408) 732-9162 Fax: (408) 732 9164 smartBridges Pte Ltd FCC ID: PWGAIRPOINTPRO Report # R0203252 FCC Part 15.247 Test Report Page 2 of 38 TABLE OF CONTENTS 1 - GENERAL INFORMATION .................................................................................................................................4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..............................................................................4 1.2 OBJECTIVE.............................................................................................................................................................4 1.3 RELATED SUBMITTAL(S)/GRANT(S).......................................................................................................................4 1.4 TEST METHODOLOGY............................................................................................................................................4 1.5 TEST FACILITY.......................................................................................................................................................5 1.6 TEST EQUIPMENT LIST AND DETAILS.....................................................................................................................5 1.7 LOCAL SUPPORT EQUIPMENT LIST AND DETAILS..................................................................................................6 1.8 HOST SYSTEM CONFIGURATION LIST AND DETAILS..............................................................................................6 1.9 EXTERNAL I/O CABLING LIST AND DETAILS.........................................................................................................6 2 - SYSTEM TEST CONFIGURATION ....................................................................................................................7 2.1 JUSTIFICATION.......................................................................................................................................................7 2.2 EUT EXERCISE SOFTWARE....................................................................................................................................7 2.3 SPECIAL ACCESSORIES...........................................................................................................................................7 2.4 SCHEMATICS / BLOCK DIAGRAM...........................................................................................................................7 2.5 EQUIPMENT MODIFICATIONS.................................................................................................................................7 2.6 CONFIGURATION OF TEST SYSTEM........................................................................................................................8 2.7 TEST SETUP BLOCK DIAGRAM...............................................................................................................................8 3 - SUMMARY OF TEST RESULTS..........................................................................................................................9 4 - CONDUCTED OUTPUT POWER MEASUREMENT......................................................................................10 4.1 STANDARD APPLICABLE......................................................................................................................................10 4.2 MEASUREMENT PROCEDURE...............................................................................................................................10 4.4 TEST RESULT.......................................................................................................................................................10 5 - SPURIOUS EMISSION.........................................................................................................................................13 5.1 STANDARD APPLICABLE......................................................................................................................................13 5.2 MEASUREMENT PROCEDURE...............................................................................................................................13 5.3 MEASUREMENT DATA.........................................................................................................................................13 6 - POWER DENSITY ................................................................................................................................................20 6.1 STANDARD APPLICABLE......................................................................................................................................20 6.2 MEASUREMENT PROCEDURE...............................................................................................................................20 6.3 TEST RESULTS.....................................................................................................................................................20 7 - 6DB BANDWIDTH................................................................................................................................................23 7.1 STANDARD APPLICABLE.................…

Text truncated - open the document above for the full version.

APPENDIX B - CONDUCTED AND RADIATED SETUP PHOTOGRAPHS Conducted Emission - Front View Conducted Emission - Rear View Radiated Emission - Front View Radiated Emission - Rear View
