PX9M140TGRugged Tablet PC

M140TG Rugged Tablet PC Intel Core i51135G7 @ 2.40GHz, up to 4.20GHz Quick Start Guide Version 1.0 Document Part No. 9152140K1003 https://dc.winmate.com Please read the instructions carefully before using this product, and save this annual for future use 1 Rugged Tablet PC M140TG Quick Start Guide 1. Read Me First Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. Note: A note is used to emphasize helpful information Important: An important note indicates information that is important for you to know. Caution A Caution alert indicates potential damage to hardware and explains how to avoid the potential problem. Attention Unealerted’attentionindique un dommage possible à l’équipement et explique comment éviter le problèmepotentiel. Warning! An Electrical Shock Warning indicates the potential harm from electrical hazards and how to avoid the potential problem. Avertissement! Un Avertissement de Choc Électriqueindique le potentiel de chocssur des emplacements électriques et comment évitercesproblèmes. 2 1. Read Me First Precaution on Battery Pack Précaution avec le bloc-pile Do Not Disassemble, Modify, or Insert Sharp Objects Into the Battery Pack. Electrolyte leakage, generation of heat, ignition, or rupture may result. [FR] Ne pas démonter, modifier, ou insérer des objets pointus à l'intérieur du bloc-pile. Une fuite d'électrolyte, la génération de chaleur, l'amorçage ou la rupture peuvent être occasionnés. Do Not Short the Positive (+) and Negative (-) Terminals of the Battery. Generation of heat, ignition, or rupture may result. When carrying or storing the device, do not place the battery pack with articles that may contact electricity. [FR] Ne pas court-circuiter les bornes Positive (+) et Négative (-) de la pile, la génération de chaleur, l'amorçage ou la rupture peuvent être occasionnés. Lors du transport et du rangement de l'appareil, ne pas placer le bloc- pile en même temps que des articles pouvant créer un contact électrique. Do Not Apply Shocks to the Battery by Dropping It or Applying Strong Pressure to It. Electrolyte leakage, generation of heat, ignition, or rupture of the battery may occur. [FR] Ne pas faire subir de choc à la pile en la laissant tomber ou en appliquant une forte pression dessus. Une fuite d'électrolyte, la génération de chaleur, l'amorçage ou la rupture peuvent être occasionnés. Do Not Charge the Battery Other Than Methods Those Specified In This Manual. If the battery is not charged using one of the specified methods, electrolyte leakage, generation of heat, ignition, or rupture may result. [FR] Ne pas charger la pile par d'autres méthodes que celles spécifiées dans ce manuel. Si la pile n'est pas chargée en utilisant l'une des méthodes spécifiées, une fuite d'électrolyte, la génération de chaleur, l'amorçage ou la rupture peuvent être occasionnés. When the Battery Pack Has Deteriorated, Replace It with a New Battery. Continued use of a damaged battery pack may result in heat generation, ignition, or battery rupture. [FR] Lorsque la pile est détériorée, la remplacer par une nouvelle pile. L'utilisation continue d'une pile endommagée peut occasionner une génération de chaleur, l'amorçage ou la rupture de la pile. Do Not Expose the Battery Pack to Excessive Heat or Extreme Heat (for example, Near Fire, in Direct Sunlight) Generation of heat, ignition, or rupture may result [FR] Ne pas exposer le bloc-pile à une Chaleur Excessive, ou une Chaleur Extrême (Près d'un feu, sous la lumière du soleil par exemple)Une production de chaleur, l'amorçage ou la rupture peuvent être occasionnés Do Not Use the Battery Pack With Any Other Products. The battery pack is rechargeable and is only designed for this specific product. Electrolyte leakage, generation of heat, ignition, or rupture may result if used with a product other than the specified product. [FR] Ne pas utiliser avec un autre produit La batterie est rechargeable et a été conçue pour un produit spécifique. Si elle est utilisée sur un produit différent de celui pour lequel elle a été conçue, des pertes d’électrolytes et une production de chaleur sont possibles, elle risque également de prendre feu ou de casser. Do Not Use This Product With Battery Other Than the One Specified. [FR] Ne pas utiliser ce produit avec une batterie autre que celle spécifiée Discontinue using the device immediately if you notice the battery is swelling or looks puffy or misshapen. Do not attempt to charge or use the device. Do not handle a damaged or leaking battery. Do not let leaking battery fluid come into contact with your eyes, skin, or clothing. [FR] Si vous remarquez une pile gonflée, élargie ou anormale, cesser l’utilisation de l’appareil immédiatement. N’essayez pas de recharger l’appareil ou de l’utiliser. Ne pas manipuler une pile qui fuit ou qui est endommagée. Ne laissez pas de liquide qui fuit entrer en contact avec vos yeux, votre peau ou vos vêtements. Safety Information 3 Rugged Tablet PC M140TG Quick Start Guide  This product should not be used near water such as bathtubs, sinks, swimming pools, wet basement, etc. [FR] Ce produit ne dois pas être utilisé près de l'eau comme les baignoires, les éviers, les piscines, les sous-sols humides, etc.  Use only with its transport carriage, stand, tripod, console, or table specified by the manufacturer or sold with the product. When using a carriage, move the carriage assembly with the product carefully to avoid damage from falling over.  [FR] Utiliser uniquement avec son chariot de transport, support, trépied, console ou table spécifiés par le fabricant ou vendu avec le produit. Lors de l'utilisation d'un charriot, déplacez l'ensemble chariot avec le produit avec soin pour éviter tout dommage de chute.  Unplug this apparatus during lig…

Text truncated - open the document above for the full version.

22-1167_EUT External Photos Page 1 of 12 External Photos Model Number: M140TG, M140TGXXXXXXXXXXXX (“X”= A~Z,a~z,0~9,"-" Blank or Slash for marketing purpose only, no impact safety related constructions or critical components) 22-1167_EUT External Photos Page 2 of 12 EUT Photo (1) EUT Photo (2) 22-1167_EUT External Photos Page 3 of 12 EUT Photo (3) EUT Photo (4) 22-1167_EUT External Photos Page 4 of 12 EUT Photo (5) EUT Photo (6) 22-1167_EUT External Photos Page 5 of 12 EUT Photo (7) EUT Photo (8) 22-1167_EUT External Photos Page 6 of 12 EUT Photo (9) EUT Photo (10) 22-1167_EUT External Photos Page 7 of 12 EUT Photo (11) EUT Photo (12) 22-1167_EUT External Photos Page 8 of 12 EUT Photo (13) EUT Photo (14) 22-1167_EUT External Photos Page 9 of 12 EUT Photo (15) EUT Photo (16) 22-1167_EUT External Photos Page 10 of 12 EUT Photo (17) EUT Photo (18) 22-1167_EUT External Photos Page 11 of 12 EUT Photo (19) EUT Photo (20) 22-1167_EUT External Photos Page 12 of 12 EUT Photo (21) EUT Photo (22)

22-1167_EUT Internal Photos Page 1 of 36 Internal Photos Model Number: M140TG, M140TGXXXXXXXXXXXX (“X”= A~Z,a~z,0~9,"-" Blank or Slash for marketing purpose only, no impact safety related constructions or critical components) 22-1167_EUT Internal Photos Page 2 of 36 EUT Photo (1) EUT Photo (2) 22-1167_EUT Internal Photos Page 3 of 36 EUT Photo (3) EUT Photo (4) 22-1167_EUT Internal Photos Page 4 of 36 EUT Photo (5) EUT Photo (6) WIFI Main ANT. WIFI/BT Aux ANT. 22-1167_EUT Internal Photos Page 5 of 36 EUT Photo (7) EUT Photo (8) 22-1167_EUT Internal Photos Page 6 of 36 EUT Photo (9) EUT Photo (10) 22-1167_EUT Internal Photos Page 7 of 36 EUT Photo (11) EUT Photo (12) 22-1167_EUT Internal Photos Page 8 of 36 EUT Photo (13) EUT Photo (14) 22-1167_EUT Internal Photos Page 9 of 36 EUT Photo (15) EUT Photo (16) 22-1167_EUT Internal Photos Page 10 of 36 EUT Photo (17) EUT Photo (18) 22-1167_EUT Internal Photos Page 11 of 36 EUT Photo (19) EUT Photo (20) 22-1167_EUT Internal Photos Page 12 of 36 EUT Photo (21) EUT Photo (22) 22-1167_EUT Internal Photos Page 13 of 36 EUT Photo (23) EUT Photo (24) 22-1167_EUT Internal Photos Page 14 of 36 EUT Photo (25) EUT Photo (26) 22-1167_EUT Internal Photos Page 15 of 36 EUT Photo (27) EUT Photo (28) 22-1167_EUT Internal Photos Page 16 of 36 EUT Photo (29) EUT Photo (30) 22-1167_EUT Internal Photos Page 17 of 36 EUT Photo (31) EUT Photo (32) 22-1167_EUT Internal Photos Page 18 of 36 EUT Photo (33) EUT Photo (34) 22-1167_EUT Internal Photos Page 19 of 36 EUT Photo (35) EUT Photo (36) 22-1167_EUT Internal Photos Page 20 of 36 EUT Photo (37) EUT Photo (38) 22-1167_EUT Internal Photos Page 21 of 36 EUT Photo (39) EUT Photo (40) 22-1167_EUT Internal Photos Page 22 of 36 EUT Photo (41) EUT Photo (42) 22-1167_EUT Internal Photos Page 23 of 36 EUT Photo (43) EUT Photo (44) 22-1167_EUT Internal Photos Page 24 of 36 EUT Photo (45) EUT Photo (46) 22-1167_EUT Internal Photos Page 25 of 36 EUT Photo (47) EUT Photo (48) 22-1167_EUT Internal Photos Page 26 of 36 EUT Photo (49) EUT Photo (50) 22-1167_EUT Internal Photos Page 27 of 36 EUT Photo (51) EUT Photo (52) 22-1167_EUT Internal Photos Page 28 of 36 EUT Photo (53) EUT Photo (54) 22-1167_EUT Internal Photos Page 29 of 36 EUT Photo (55) EUT Photo (56) 22-1167_EUT Internal Photos Page 30 of 36 EUT Photo (57) EUT Photo (58) 22-1167_EUT Internal Photos Page 31 of 36 EUT Photo (59) EUT Photo (60) 22-1167_EUT Internal Photos Page 32 of 36 EUT Photo (61) EUT Photo (62) 22-1167_EUT Internal Photos Page 33 of 36 EUT Photo (63) EUT Photo (64) 22-1167_EUT Internal Photos Page 34 of 36 EUT Photo (65) EUT Photo (66) 22-1167_EUT Internal Photos Page 35 of 36 EUT Photo (67) EUT Photo (68) 22-1167_EUT Internal Photos Page 36 of 36 EUT Photo (69) EUT Photo (70)

Appendix A - Conducted Power Measurements WLAN Conducted Power 1. As per FCC OET KDB 248227 D01, conducted output power and SAR testing are not required for 802.11g/n20/n40/ax channels when the highest reported SAR for DSSS is adjusted by the ratio of OFDM to DSSS specified maximum output power and the adjusted SAR is ≤ 1.2W/kg. 2. When the reported SAR of the initial test configuration is > 0.8 W/kg, SAR measurement is required for subsequent next highest measured output power channel(s) in the initial test configuration until reported SAR is ≤ 1.2 W/kg or all required channels are tested. 3. Additional conducted power measurement is required when reported SAR is > 1.2W/kg. In case the subsequent test configuration and the channel bandwidth is smaller than the initial test configuration, all channels that overlap with the larger channel bandwidth in the initial configuration should be tested. 4. The initial test configuration for 2.4 GHz and 5 GHz OFDM transmission modes is determined by the 802.11 configuration with the highest maximum output power specified for production units, including tune-up tolerance, in each standalone and aggregated frequency band. SAR for the initial test configuration is measured using the highest maximum output power channel determined by the default power measurement procedures. When multiple transmission modes (802.11a/g/n/ac/ax) have the same specified maximum output power, largest channel bandwidth, lowest order modulation and lowest data rate, lowest order 802.11 mode is selected (i.e. a, g, n, ac then ax) 5. When the highest reported SAR for the initial test configuration (when applicable, include subsequent highest output channels), according to the initial test position or fixed exposure requirements, is adjusted by the ratio of the subsequent test configuration to the initial test configuration specified maximum output power and the adjusted SAR is ≤1.2 W/Kg, SAR is not required for that subsequent test configuration. 6. For 802.11ax mode, maximum output powers for each RU size were measured to demonstrate that are no higher than other OFDM 802.11 modes. Power Measurement Setup Report Number: 2209FS21 Rev.00 Page 1 of 3 1241216.2416.5016.2216.5019.2419.50 6243716.1516.5016.1916.5019.1819.50 11246216.0816.5016.1316.5019.1219.50 1241215.8116.5015.9116.5018.8719.50 6243715.7516.5015.8416.5018.8119.50 11246215.6916.5015.8116.5018.7619.50 1241215.6216.5015.7916.5018.7219.50 6243715.6316.5015.7016.5018.6819.50 11246215.5516.5015.6616.5018.6219.50 3242215.7616.5015.9016.5018.8419.50 6243715.8016.5015.8616.5018.8419.50 9245215.6716.5015.7016.5018.7019.50 1241215.8616.5015.8716.5018.8819.50 6243715.7516.5015.9116.5018.8419.50 11246215.7416.5015.8616.5018.8119.50 3242215.9416.5016.0816.5019.0219.50 6243715.9716.5016.0516.5019.0219.50 9245215.8816.5015.9916.5018.9519.50 WLAN 2.4 GHz ModeChannel Frequency (MHz) MainAuxMIMO Average Power (dBm) Tune-Up Limit (dBm) Average Power (dBm) Tune-Up Limit (dBm) Average Power (dBm) Tune-Up Limit (dBm) 802.11n HT20 802.11b 802.11g 802.11n HT40 802.11ax HE20 802.11ax HE40 Report Number: 2209FS21 Rev.00 Page 2 of 3 8.00 8.00 1924407.918.00Bluetooth LE 2M 124047.93 3824787.54 8.00 1924407.888.00Bluetooth LE 1M 024027.92 3924807.51 6.50 BandChannel Frequency (MHz) Aux Average Power (dBm)Tune up Limit (dBm) 8.00 Bluetooth EDR 8DPSK 024026.126.50 3924416.406.50 7824805.70 Bluetooth EDR π/4-DQPSK 024026.006.50 3924416.306.50 7824805.626.50 10.00 3924419.5910.00 Bluetooth BR GFSK 024029.33 7824809.3610.00 BandChannel Frequency (MHz) Aux Average Power (dBm)Tune-Up Limit (dBm) Bluetooth BR / EDR Bluetooth LE Report Number: 2209FS21 Rev.00 Page 3 of 3

Report Number: 2209FS21 Rev.00 Page 1 of 2 Appendix B - System Performance Check Plots Report Number: 2209FS21 Rev.00 Page 2 of 2 Test Laboratory: A Test Lab Techno Corp. Date: 2022/9/29 System Performance Check at 2450 MHz DUT: Dipole 2450 MHz_SN712 Communication System: UID 0, CW (0); Frequency: 2450 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2450 MHz; σ = 1.847 S/m; ε r = 39.979; ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY5.2 Configuration:  Area Scan setting - Find Secondary Maximum Within:2.0dB and with a peak SAR value greater than 0.5 W/Kg  Probe: EX3DV4 - SN7647; ConvF(8.13, 8.13, 8.13) @ 2450 MHz; Calibrated: 2022/4/27  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1253; Calibrated: 2021/12/30  Phantom: ELI; Type: QD OVA 002 AA; Serial: 1133  Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7501) System Performance Check at 2450MHz/Area Scan (81x81x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 4.36 W/kg System Performance Check at 2450MHz/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 50.90 V/m; Power Drift = -0.04 dB Peak SAR (extrapolated) = 5.36 W/kg SAR(1 g) = 2.66 W/kg; SAR(10 g) = 1.27 W/kg Smallest distance from peaks to all points 3 dB below = 9.1 mm Ratio of SAR at M2 to SAR at M1 = 56.5% Maximum value of SAR (measured) = 4.39 W/kg 0 dB = 4.39 W/kg = 6.42 dBW/kg

Report Number: 2209FS21 Rev.00 Page 1 of 4 Appendix C - Highest Measurement Plots Report Number: 2209FS21 Rev.00 Page 2 of 4 Test Laboratory: A Test Lab Techno Corp. Date: 2022/9/29 1_WLAN 2.4 GHz_802.11b_Ch1_Side 3_0 mm_ANT Main DUT: M140TG Communication System: UID 0, IEEE 802.11b (0); Frequency: 2412 MHz;Duty Cycle: 1:1.002 Medium parameters used: f = 2412 MHz; σ = 1.81 S/m; ε r = 40.065; ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY5.2 Configuration:  Area Scan setting - Find Secondary Maximum Within:2.0dB and with a peak SAR value greater than 0.5 W/Kg  Probe: EX3DV4 - SN7647; ConvF(8.13, 8.13, 8.13) @ 2412 MHz; Calibrated: 2022/4/27  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1253; Calibrated: 2021/12/30  Phantom: ELI; Type: QD OVA 002 AA; Serial: 1133  Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7501) Area Scan (51x91x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 1.46 W/kg Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 18.50 V/m; Power Drift = -0.06 dB Peak SAR (extrapolated) = 1.94 W/kg SAR(1 g) = 0.854 W/kg; SAR(10 g) = 0.341 W/kg Smallest distance from peaks to all points 3 dB below = 7 mm Ratio of SAR at M2 to SAR at M1 = 46% Maximum value of SAR (measured) = 1.51 W/kg 0 dB = 1.51 W/kg = 1.79 dBW/kg Report Number: 2209FS21 Rev.00 Page 3 of 4 Test Laboratory: A Test Lab Techno Corp. Date: 2022/9/29 2_WLAN 2.4 GHz_802.11b_Ch6_Side 2_0 mm_ANT Aux DUT: M140TG Communication System: UID 0, IEEE 802.11b (0); Frequency: 2437 MHz;Duty Cycle: 1:1.002 Medium parameters used (interpolated): f = 2437 MHz; σ = 1.835 S/m; ε r = 40.008; ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY5.2 Configuration:  Area Scan setting - Find Secondary Maximum Within:2.0dB and with a peak SAR value greater than 0.5 W/Kg  Probe: EX3DV4 - SN7647; ConvF(8.13, 8.13, 8.13) @ 2437 MHz; Calibrated: 2022/4/27  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1253; Calibrated: 2021/12/30  Phantom: ELI; Type: QD OVA 002 AA; Serial: 1133  Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7501) Area Scan (51x91x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 0.696 W/kg Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 3.009 V/m; Power Drift = -0.07 dB Peak SAR (extrapolated) = 0.415 W/kg SAR(1 g) = 0.148 W/kg; SAR(10 g) = 0.052 W/kg Smallest distance from peaks to all points 3 dB below = 6.1 mm Ratio of SAR at M2 to SAR at M1 = 31.5% Maximum value of SAR (measured) = 0.320 W/kg 0 dB = 0.320 W/kg = -4.95 dBW/kg Report Number: 2209FS21 Rev.00 Page 4 of 4 Test Laboratory: A Test Lab Techno Corp. Date: 2022/9/29 3_Bluetooth_GFSK_Ch39_Side 2_0 mm_ANT Aux DUT: M140TG Communication System: UID 0, Bluetooth 3.0 (0); Frequency: 2441 MHz;Duty Cycle: 1:1.256 Medium parameters used (interpolated): f = 2441 MHz; σ = 1.839 S/m; ε r = 39.999; ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY5.2 Configuration:  Area Scan setting - Find Secondary Maximum Within:2.0dB and with a peak SAR value greater than 0.5 W/Kg  Probe: EX3DV4 - SN7647; ConvF(8.13, 8.13, 8.13) @ 2441 MHz; Calibrated: 2022/4/27  Sensor-Surface: 1.4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1253; Calibrated: 2021/12/30  Phantom: ELI; Type: QD OVA 002 AA; Serial: 1133  Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7501) Area Scan (51x91x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 0.0757 W/kg Zoom Scan (8x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 1.307 V/m; Power Drift = 0.19 dB Peak SAR (extrapolated) = 0.140 W/kg SAR(1 g) = 0.040 W/kg; SAR(10 g) = 0.012 W/kg Smallest distance from peaks to all points 3 dB below = 6.4 mm Ratio of SAR at M2 to SAR at M1 = 39.5% Maximum value of SAR (measured) = 0.109 W/kg 0 dB = 0.109 W/kg = -9.63 dBW/kg
