PY9OM30QRF Wireless Optical Mouse

Using Instruction Getting Started Guide 1. Install the battery: (1) Remove the battery cover on the top. (2) Insert the Alkaline Batteries enclosed in the box into the battery compartment, and follow the direction mark to insert battery. (3) Replace the cover carefully. Note: Once the battery is placed correctly, the mouse optical LED located at the bottom will be lighted up. If the LED don’t light up, please remove the batteries, make sure the battery direction and install anew. 2. Connect the receiver: Using USB port user: Please connect the receiver to the USB port on the computer. For USB-port installation, Windows 98 or higher or Macintosh® OS 8.6 or higher is required. Under Windows environment, you may be prompted to insert the Windows software CD. Please insert this CD into the computer’s CDROM when you are asked to do so and follow the onscreen instructions. Using PS/2 port user: (a) To connect to a PS/2 port, please turn off your computer. (b) Connect the PS/2 adapter to the receiver or USB cable. And USB cable connect to receiver (c) Insert the adapter into the PS/2 port on the computer. (d) Turn on the computer. 3. Establish communication link After you insert the receiver to your computer, the LED on the receiver will light up. Press the ID button on receiver, and then press the ID button on the mouse bottom. If the receiver links with the mouse successfully, the LED on the receiver will blink quickly and then stop blinking. 4. Important Note ??To optimize the performance of your RF reception, please make your receiver away from electrical devices. Avoid using your RF optical mouse on a metal surface. That may slow down the response of the mouse or cause the mouse fail to response. ??Please use Alkaline Batteries only. Do not mix different brand batteries or mix old and new batteries in the mouse. ??Advice to use in light-color surface. This will save battery’s life. White ,bright surfaces are recommended. ??If you will not use the mouse for a long time, please take the batteries apart to extend its using life. ??If someone use wireless product nearby, please keep 1.5 meters at least to avoid the interference. 5. Troubleshooting The mouse does not work or not detected. ??Check the USB or PS/2 port, make sure receiver is connected correctly. ??When the battery power is low, please exchange new batteries. ??R eset the ID button of mouse and receiver.(follow the “Establish communication link ” step or Unplugged the receiver and re-connect to PC ??This RF mouse have power saving design, if you don’t use your mouse about 8 minutes, it will enter a suspend mode. In suspend mode Please press right or left button to wake up the mouse. ??If the mouse is disturbed by other electronic device, please insert the receiver to the USB extension cable and let the receiver near to your mouse. Packing contents RF Wireless Optical Mouse Receiver USB Extension Cable PS/2 Adapter ( option) AA size Alkaline Batteries x 2 Using instruction This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions. 1) This device may not cause harmful interference, and 2) This device must accept any interference received, including interference that may cause undesired operation. Per FCC 15.21, you are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user's authority to operate the equipment.

Compliance Certification Services Inc. Report No: C30827405 Date of Issue: September 24, 2003 Page 1 Total Page: 6 Rev. 00 PHOTOGRAPHS OF EUT

FCC ID LABEL FORMAT AND LOCATION Applicant: ELELUX INTERNATION LTD. FCC ID: PY9OM30Q FCC ID: PY9OM30Q This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID LABEL AREA

Compliance Certification Services Inc. Report No: C30827405 Date of Issue: September 24, 2003 Page 2 Rev. 00 Compliance Certification Services Inc. Report No: C30827405 Date of Issue: September 24, 2003 Page 3 Rev. 00

Compliance Certification Services Inc. Report No: C30827405-RP FCC ID : PY9OM30Q Date of Issue: September 30, 2003 Page 1 Total Page: 19 Rev. 00 FCC CFR 47 PART 15 SUBPART C TEST REPORT For ELELUX INTERNATION LTD. RF WIRELESS OPTICAL MOUSE Model: MARS Trade Name: ELELUX INTERNATION Issued for ELELUX INTERNATION LTD. 3F., NO.103, CHOW TZE STREET, NEI-HU DISTRICT 114, TAIPEI, TAIWAN Issued by Compliance Certification Services Inc. Hsintien Lab. No. 165, Chunghsen Road, Hsintien City Taipei Hsien, Taiwan TEL: (02) 2217-0894 FAX: (02) 2217-1029 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Lab. Code: 200617-0 Compliance Certification Services Inc. Report No: C30827405-RP FCC ID : PY9OM30Q Date of Issue: September 30, 2003 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION......................................................................................3 2. EUT DESCRIPTION............................................................................................................4 3. TEST METHODOLOGY.....................................................................................................5 3.1 EUT CONFIGURATION...............................................................................................5 3.2 EUT EXERCISE...........................................................................................................5 3.3 GENERAL TEST PROCEDURES.................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS.......................................6 3.5 DESCRIPTION OF TEST MODES................................................................................6 4. INSTRUMENT CALIBRATION..........................................................................................7 5. FACILITIES AND ACCREDITATIONS..............................................................................7 5.1 FACILITIES.................................................................................................................7 5.2 EQUIPMENT................................................................................................................7 5.3 LABORATORY ACCREDITATIONS AND LISTINGS.................................................7 5.4 TABLE PF ACCREDITATIONS AND LISTINGS.........................................................8 6. SETUP OF EQUIPMENT UNDER TEST............................................................................9 6.1 SETUP CONFIGURATION OF EUT.............................................................................9 6.2 SUPPORT EQUIPMENT...............................................................................................9 7. FCC PART 15.227 REQUIREMENTS................................................................................10 7.1 26 DB BANDWIDTH..................................................................................................10 7.2 RADIATED EMISSIONS............................................................................................12 7.3 POWERLINE CONDUCTED EMISSIONS..................................................................18 APPENDIX 1 - PHOTOGRAPHS OF TEST SETUP...............................................................19 Compliance Certification Services Inc. Report No: C30827405-RP FCC ID : PY9OM30Q Date of Issue: September 30, 2003 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: ELELUX INTERNATION LTD. 3F., NO.103, CHOW TZE STREET, NEI-HU DISTRICT 114, TAIPEI, TAIWAN Equipment Under Test: RF WIRELESS OPTICAL MOUSE Trade Name: ELELUX INTERNATION LTD. Model: MARS Model Difference N/A Report Number: C30827405-RP Date of Test: August 29- September 2, 2003 APPLICABLE STANDARDS STANDARD TEST RESULT FCC Part 15 Subpart C No non-compliance noted The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (1992) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.227. The test results of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: David Wang Vince Chiang Manager of Hsintien Laboratory Section Manager of Hsintien Laboratory Compliance Certification Services Inc. Compliance Certification Services Inc. Compliance Certification Services Inc. Report No: C30827405-RP FCC ID : PY9OM30Q Date of Issue: September 30, 2003 Page 4 Rev. 00 2. EUT DESCRIPTION Product RF WIRELESS OPTICAL MOUSE Trade Name ELELUX INTERNATION Model MARS Power Supply DC From Battery AA size X 2 pcs. Operate Frequency 27.045 MHz Transmit Power N/A Modulation Technique Frequency Shift Keying (FSK) Number of Channels 1 Channel Antenna Designation Fixed Antenna, which is built in EUT Note: The product is a composite system which includes Transmitter and Receiver. This submittal(s) (test report) is intended for FCC ID: PY9OM30Q filing to comply with Section 15.227 of the FCC Part 15 Subpart C Rules. The composite system (digital device) is compliance with Subpart B is authorized under a DoC procedure. Compliance Certification Services Inc. Report No: C30827405-RP FCC ID : PY9OM30Q Date of Issue: September 30, 2003 Page 5 Rev. 00 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 Part 15 Subpart C. 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuou…
