Q2O-QCC5151Bluetooth Module

QCC5151 Bluetooth Module operating/installation instruction Product Description: Bluetooth Module Model / HVIN: QCC5151 The module device FCC ID: Q2O-QCC5151 / IC: 152B-QCC5151 Processors QCC5151 WLCSP includes an application-dedicated Developer Processor and a system Firmware Processor that run code from an external quad serial peripheral interface (QSPI) flash Both processors have tightly coupled memory (TCM) and an on-chip cache for performance while executing from external flash memory. The system Firmware Processor provides functions developed by Qualcomm Technologies International, Ltd. (QTIL). The Developer Processor provides flexibility to the product designer to customize their product. Audio subsystem The Audio subsystem contains two programmable Kalimba cores running Qualcomm® Kymera™ system DSP architecture framework from read only memory (ROM). A range of audio processing capabilities are provided from ROM, which are configurable in fully flexible audio graphs. Capabilities executed from random access memory (RAM), including those provided by QTIL, the product designer or third parties may complement or replace built-in capabilities in ROM. IDE/Software Development Tools QCC5151 WLCSP is driven by a flexible software platform with integrated development environment (IDE) support. This enables deployment of a broad range of consumer electronic products including headphones, headsets, and Qualcomm TrueWireless stereo earbuds. 1.1 List of applicable FCC rules/RSS: The module complies with FCC Part 15.249/15.247/RSS-210 Issue 10/RSS-247 Issue 2 1.2 Summarize the specific operational use conditions: The module has been certified for Mobile applications. This transmitter must not be collocated or operating in conjunction with any other antenna or transmitter The manual provides guidance to the host manufacturer will be included in the documentation that will be provided to the OEM. The OEM integrators, host manufacturers are responsible for ensuring that the end-user has no manual or instructions to remove or install module. Important notes to third party user, host manufacturer for transceiver module: The transceiver Module complies with Part15 of the FCC rules and regulations. Compliance with the labeling requirements, FCC notices and antenna usage guidelines is required. To fulfill FCC Certification, the third-party user must comply with the following regulations: 1. The third-party user must ensure that the text on the external label provided with this device is placed on the outside of the final product. Contains FCC ID: Q2O-QCC5151 (example) / IC: 152B-QCC5151 (example) .The enclosed device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2. The transceiver Module may only be used with the antenna (internal, integral) that have been tested and approved for use with this module. 3. The transmitter is certified as a module, it may be integrated or used inside another device (host). No further approval is required when the module is used in accordance with the FCC grant conditions, and any limitations or usage conditions required by the manufacturer's instructions. Modifications not approved by grantee could void the user's authority to operate the equipment. 4. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. 5. Third party users, host manufacturer must test final product to comply with unintentional radiators before declaring compliance of their final product to Part 15 of the FCC Rules. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 1.3 Limited module procedures Not Applicable. 1.4 Trace Antenna Designs: Not Applicable. 1.5 RF exposure considerations: The module has been certified for Mobile applications. End-user product Manual shall contain below RF exposure statements. This module complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.". The antenna(s) used for this transmitter must not be collocated or operating in conjunction with any other antenna or transmitter. If RF exposure statements and use conditions are not provided, then the host product manufacturer is required to take responsibi…

Text truncated - open the document above for the full version.

Lenbrook Industries Limited 633 Granite Court, Pickering, Ontario L1W 3K1 (905) 831-6333 Fax: (905) 831-6936 Modular Approval Request Letter Date: 27 June, 2022 Dear Application Examiner, Lenbrook Industries Limited, FCC ID: Q2O-QCC5151 would like to have your authorization as a modular approval. The requirements of Public Notice DA00-1407 have been met and shown on the following statements. Items to be covered Answer from applicant 1.The modular transmitter must have its own RF shielding.The RF portions of the module are completely contained within a metal shielding can. The modules does not depend on any other shielding 2.The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. All inputs to the module are buffered through logic or microprocessor inputs 3. The modular transmitter must have its own power supply regulation. The modular transmitter has its own power supply regulation. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The module and antenna design is not user serviceable. It utilizes non-standard micro-coaxial connectors and antennas with approximate gain of 2 dBi. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. The EUT was tested stand-alone with a test-jig. Please refer to setup configuration photos. 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. The FCC ID label format is included in the filing. The product will always be inside another enclosure during actual use. A label will be placed on the outside of the product if the FCC ID is not visible. Lenbrook Industries Limited 633 Granite Court, Pickering, Ontario L1W 3K1 (905) 831-6333 Fax: (905) 831-6936 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. For example, there are very strict operational and timing requirements that must be met before a transmitter is authorized for operation under Section 15.231. For instance, data transmission is prohibited, except for operation under Section 15.231(e), in which case there are separate field strength level and timing requirements. Compliance with these requirements must be assured. The module complies with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee. Please refer to report and user manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. The transmitter meets the requirements. Date: June 27, 2022 __________________ By Printed Name: Taresh Vadgama __________________ Title: VP, Product Development & Manufacturing __________________

Lenbrook Industries Limited 633 Granite Court, Pickering, Ontario L1W 3K1 (905) 831-6333 Fax: (905) 831-6936 Date : 24 Jun e, 2022 Attention: Application Examiner R e: Request for confidentiality A pplicant: Lenbrook Industries Limited FCC ID: Q2O-QCC5151 T o whom it may concern, P ermanent Confidentiality R equest is hereby submitted by Lenbrook Industries Limited to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) & 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: •S chematics •Detailed Block diagrams •Detailed Operational/Functional Description Sho rt -term Confidentiality R equest is hereby submitted by Lenbrook Industries Limited to withhold from public review for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) & 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept confidential for a period of 180 days from the date of Authorization: •T est setup photos •External photos •Internal photos •User manual Lenbrook Industries Limited 633 Granite Court, Pickering, Ontario L1W 3K1 (905) 831-6333 Fax: (905) 831-6936 Rationale for request for confidentiality: Lenbrook Industries Limited has invested considerable time and materials in research and development to produce the referenced product. [Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us.][Short term confidentiality: Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development.] [For FCC certification; delete for TCB certification: The fee for confidentiality has been submitted along with the fee for certification.] If you have questions or need further information, please contact the undersigned. Sincerely, Taresh Vadgama VP, Product Development & Manufacturing Lenbrook Industries Limited Lenbrook Industries Limited 633 Granite Court, Pickering, Ontario L1W 3K1 (905) 831-6333 Fax: (905) 831-6936

INTERTEK TESTING SERVICE Report No.: HK22030405 Equipment Photographs (External) INTERTEK TESTING SERVICE Report No.: HK22030405 Equipment Photographs (External)

FCC ID:Q2O-QCC5151IC: 152B-QCC5151Model HVIN:QCC5151 1. 2. n

INTERTEK TESTING SERVICE Report No.: HK22030405 Equipment Photographs (Internal) INTERTEK TESTING SERVICE Report No.: HK22030405 Equipment Photographs (Internal)

INTERTEK TESTING SERVICE FCC ID: Q2O-QCC5151 IC: 152B-QCC5151 MPE Analysis Report The Equipment-Under-Test (EUT) QCC5151 is Bluetooth Module. The EUT is powered by 5VDC. Antenna Type: Integral Antenna Gain: 2dBi For Maximum Permissible Exposure (MPE) evaluation of the unit, the maximum power density at 20 cm from this transmitter shall be less than the General Population / Uncontrolled MPE limit in OET Bulletin 65 and meet the requirement listed in KDB447498. For the Bluetooth portion of the unit, the measured powers among all the measured channels were within its production tolerance. The antenna gain is 2 dBi = 1.58 (num gain) and its maximum source-based time-averaging duty factor is 100%. From these data and its operating configuration, the exposed power density at a distance (R) of 20 cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: The EIRP radiated power = 15dBm + 2dBi = 17 dBm (50 mW) The radiated (EIRP) source-based time-averaging output power = (50 * 1) mW = 50 mW The power density at 20 cm = 50 / 4πR 2 = 0.01 mW cm -2 In the frequency range of 1,500 - 100,000MHz, the MPE limit is 1.0 mWcm-2 for general population and uncontrolled exposure. As the measured power density at 20cm from the transmitter is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structures and body of the user or nearby persons. The following RF exposure statement is proposed to be included in the user manual: “ FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the unit at least 20cm from nearby persons.”

TEST REPORT 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong SAR, China. Telephone: (852) 2173 8888 Facsimile: (852) 2785 5487 www.intertek.com Intertek’s standard Terms and Conditions can be obtained at our website http://www.intertek.com/terms/. The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. © 2017 Intertek Page 1 of 24 Report No.: 22030405HKG-002 Lenbrook Industries Limited Application For Certification (Original Grant) FCC ID: Q2O-QCC5151 IC: 152B-QCC5151 Transceiver Prepared and Checked by: Approved by: Signed on File Wong Cheuk Ho, Herbert Lead Engineer Wong Kwok Yeung, Kenneth Assistant Supervisor Date: June 30, 2022 TEST REPORT Lenbrook Industries Limited Intertek Report No: 22030405HKG-002 Page 2 of 24 GENERAL INFORMATION Grantee: Lenbrook Industries Limited Grantee Address: 633 Granite Court, Pickering, ON, L1W 3K1, Canada. Contact Person: Taresh Vadagma Tel: +1 905 8310799 EXT. 4326 E-mail: [email protected] Manufacturer: Dongguan Kwan Hong Electronics Co., Ltd. Manufacturer Address: No.5, Shichangxiang, Chang'an Town, Dongguan City, Guangdong Province, China. Brand Name: LENBROOK INDUSTRIES LIMITED Model / HVIN: QCC5151 PMN: Bluetooth Module Type of EUT: Transceiver Description of EUT: Bluetooth Module FCC ID / IC: Q2O-QCC5151 / 152B-QCC5151 Date of Sample Submitted: March 08, 2022 Date of Test: March 08, 2022 to June 20, 2022 Report No.: 22030405HKG-002 Report Date: June 30, 2022 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% Conclusion: Test was conducted by client submitted sample. The submitted sample as received complied with the 47 CFR Part 15 / RSS-210 Issue 10 Certification. TEST REPORT Lenbrook Industries Limited Intertek Report No: 22030405HKG-002 Page 3 of 24 SUMMARY OF TEST RESULT Test Specification Reference Results Transmitter Power Line Conducted Emissions 15.207 / RSS-Gen 8.8 Pass Radiated Emission Radiated Emission on the Bandedge 15.249, 15.209 / RSS-210 B.10, RSS-Gen 8.9 Pass Radiated Emission in Restricted Bands 15.205 / RSS-Gen 8.10 Pass For all technical data, which can be referred to Annex B – Report cover sheet. For electronic filing, the Annex B – Report cover sheet is saved with filename: Annex B.pdf. The equipment under test is found to be complying with the following standards: FCC Part 15, October 1, 2020 Edition RSS-210 Issue 10 Amendment 1, April 2020 RSS-Gen Issue 5 Amendment 2, February 2021 Note: 1. The EUT uses a permanently attached antenna which, in accordance to section 15.203, is considered sufficient to comply with the pervisions of this section. 2. Pursuant to FCC part 15 Section 15.215(c), the 20 dB bandwidth of the emission was contained within the frequency band designated (mentioned as above) which the EUT operated. The effects, if any, from frequency sweeping, frequency hopping, other modulation techniques and frequency stability over excepted variations in temperature and supply voltage were considered. TEST REPORT Lenbrook Industries Limited Intertek Report No: 22030405HKG-002 Page 4 of 24 TABLE OF CONTENTS 1.0 GENERAL DESCRIPTION ................................................................................................ 5 1.1 Product Description ................................................................................................... 5 1.2 Related Submittal(s) Grants ....................................................................................... 5 1.3 Test Methodology ...................................................................................................... 5 1.4 Test Facility ................................................................................................................ 5 2.0 SYSTEM TEST CONFIGURATION ..................................................................................... 6 2.1 Justification ................................................................................................................ 6 2.2 EUT Exercising Software ............................................................................................. 6 2.3 Special Accessories .................................................................................................... 6 2.4 Measurement Uncertainty ......................................................................................... 6 2.5 Support Equipment List and Description .................................................................... 6 3.0 EMISSION RESULTS ....................................................................................................... 7 3.1 Field Strength Calculation .......................................................................................... 7 3.2 Radiated Emission Configuration Photograph ............................................................ 8 3.3 Radiated Emission Data ............................................................................................. 8 3.4 Conducted Emission Configuration Photograph ...................................................…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICE Report No: HK22030405 i Configuration Photographs Worst-Case Line-Conducted Emissions (Front View) INTERTEK TESTING SERVICE Report No: HK22030405 ii Configuration Photographs Worst-Case Line-Conducted Emissions (Rear View) INTERTEK TESTING SERVICE Report No: HK22030405 iii Configuration Photographs Worst-Case Line-Conducted Emissions (Side View)

INTERTEK TESTING SERVICE Report No: HK22030405 Configuration Photographs Worst-Case Radiated Emissions (Front View) INTERTEK TESTING SERVICE Report No: HK22030405 Configuration Photographs Worst-Case Radiated Emissions (Rear View) Configuration Photographs INTERTEK TESTING SERVICE Report No: HK22030405 Worst-Case Radiated Emissions (Front View) INTERTEK TESTING SERVICE Report No: HK22030405 Configuration Photographs Worst-Case Radiated Emissions (Rear View)
