EX5500 Controller Installation & Configuration Guide 0981-029 Rev A Disclaimer The information and know-how included in this document are the exclusive property of Stanley Healthcare. and are intended for the use of the addressee or the user alone. The addressees shall not forward to another their right of using the information, know-how or document forwarded herewith, in whole or in part in all matters relating or stemming from or involved therein, whether for consideration or without consideration, and shall not permit any third party to utilize the information, know-how or the documents forwarded herewith or copies or duplicates thereof, unless at the company’s consent in advance and in writing. Any distribution, advertisement, copying or duplication in any form whatsoever is absolutely prohibited. The Company reserves the right to sue the addressee, user and/or any one on their behalves, as well as third parties, in respect to breaching its rights pertaining to the intellectual rights in particular and its rights of whatever kind or type in the information, know-how or the documents forwarded by them herewith in general, whether by act or by omission. This document is confidential and proprietary to Stanley Healthcare and is not to be distributed to any persons other than licensed AeroScout Visibility System users or other persons appointed in writing by Stanley Healthcare. Trademark Acknowledgements AeroScout is a trademark of Stanley Black & Decker. Other brand products and service names are trademarks or registered trademarks of their respective holders. Below is a partial listing of other trademarks or registered trademarks referenced herein: Cisco™ is a trademark of Cisco Systems, Inc. Sun, Sun Microsystems, the Sun Logo, Java, JRE and all other Sun trademarks, logos, product names, service names, program names and slogans that are referred to or displayed in this document are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and other countries. This product includes software developed by the Apache Software Foundation (http://www.apache.org/). This product includes code licensed from RSA Data Security Skype, SkypeIn, SkypeOut, Skype Me, the Skype Logo and the S logo and other marks indicated on Skype’s website are trademarks of Skype Limited or other related companies. ESper is a trademark of EsperTech, Inc. Jboss is a trademark of Red Hat Middleware, LLC. Oracle 10G is a registered trademark of Oracle Corporation and/or its affiliates. MS SQL Server 2005 is a registered trademark of Microsoft Corporation in the United States and/or other countries. JasperSoft, the JasperSoft Logo, JasperReports, the JasperReports logo, JasperIntelligence, JasperDecisions, JasperAnalysis, Scope Center, Scope Designer, and JasperServer are trademarks or registered trademarks of JasperSoft, Inc. in the United States and other countries. 2013 Stanley Healthcare. All rights reserved. Table of Contents 3 Table of Contents Introduction ......................................................................................................................... 4 EX5500 Controller Applications and Industry Examples ............................................. 5 EX5500 Controller Features ............................................................................................... 6 EX5500 LED Status Indicators .......................................................................................... 7 Network and Power Connections to EX5500 ............................................................... 10 Chaining the EX5500 Controllers ................................................................................... 13 Resetting the EX5500 Controller IP Address ................................................................ 15 Configuring the EX5500 Controller ............................................................................... 16 Configuring the Controller via Cisco MSE ................................................................... 22 Mounting the Controller and External LF Antenna .................................................... 24 Mounting the Controller or External LF using the Exciter Mounting Clip .............. 25 EX5500 and Accessories Model Numbers ..................................................................... 27 EX5500 Specifications ....................................................................................................... 28 EX5500 Controller Installation & Configuration Guide 4 Introduction The EX5500 Controller is a component of the Stanley Healthcare suite of enterprise- level visibility solutions based on standard Wi-Fi communication for security and safety applications. The EX5500 Controller provides sophisticated RFID detection, monitoring, and control capabilities. The EX5500 Controller triggers Hugs Tags as they pass through an Egress or as they approach the Controller. Tags in turn transmit a message to either the Location Receivers or to compatible Access Points within range. The Controller can activate or deactivate Tags, program them, or even instruct Tags to operate in a specific way (for example, to blink). This provides instant acknowledgment that a tagged asset has passed through a gate, doorway, or other specifically defined area. Figure 1: Stanley Healthcare EX5500 Controller EX5500 Controller Installation & Configuration Guide 5 EX5500 Controller Applications and Industry Examples Theft Prevention Healthcare organizations or enterprises with expensive and mission-critical equipment can tag valuable assets that are intended to remain within a specified area. The Stanley Healthcare S ystem can track the location of such items and trigger an alert when they pass through an exit point or enter a restricted area. Automatic Inventory Management Logistics organizations can update inventory records by automatically determining assets within defined areas, ensuring real-time knowledge of inventory levels…
Text truncated - open the document above for the full version.
10 Oppenheimer St. Park Tamar, Rehovot, Israel, 76701 Tel: 972-8-936-3136 Fax: 972-8-936-5977 www.aeroscout.com Date: September 11, 2013 To: Federal Communications Commission Confidentiality Request regarding application for certification of FCC ID: Q3HEX5500 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: a. CONF APPENDIX EX-5500 Schem.pdf b. CONF APPENDIX EX-5500 PartsLst.pdf c. CONF APPENDIX EX-5500 BlkDia.pdf d. CONF APPENDIX EX-5500 Revised BlkDia.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Signature: Reuven Amsalem VP HW R&D
10 Oppenheimer St. Park Tamar, Rehovot, Israel, 76701 Tel: 972-8-936-3136 Fax: 972-8-936-5977 www.aeroscout.com Date: 03/04/2013 To: Timco Engineering Inc. To Whom It May Concern We hereby authorize Mr. Shaike Raz of I.T.L. (Product Testing) Ltd (ITL) to act on our behalf regarding the FCC Certification Process for the following application: Model:EX-5500 FCC: Q3HEX5500 Thank you, Sincerely, Signature: Reuven Amsalem VP HW R&D
-– - The AeroScout EX5500 Exciter is a component of the AeroScout suite of enterprise visibility solutions that enables location-based applications. The EX5500 extends the AeroScout suite to provide robust and sophisticated RFID detection capabilities, using the same AeroScout tags that can also be accurately located in real time by the AeroScout system. The EX5100 triggers AeroScout’s tags as they pass through a choke point or when they are located near the Exciter and the tags in turn transmit Wi-Fi message to Internal Receivers or compatible Access Points in range. The Exciter can activate/deactivate the tags, program the tags or even cause tag reaction such as blinking. This provides instant acknowledgment that a tagged asset passed through a gate, doorway or some other well-defined area. The EX5500 Exciter has built in Wi-Fi receiver which enables it to receive AeroScout tag messages. The Exciter also has an embedded Wi-Fi transmitter which is utilized by the Exciter for self-health monitoring. These capabilities make the Exciter ideal for security applications. The detection capabilities of the EX5500, combined with the location features of the AeroScout Visibility System, make the AeroScout suite the most sophisticated enterprise visibility solution for a wide variety of industries. Figure 1: EX5100 positioned at choke point triggering a tag RFID detection of AeroScout Tags The EX5500 Exciter triggers Tags to transmit as they pass through a defined area, within a range of up to 6.5 meters (21.3 feet). This is typically enough to cover door or gate areas. The EX5500 also supports a chained configuration, thus enabling an increased RFID detection range for larger areas. Tag behavior modification: The EX5500 Exciter can wirelessly activate and deactivate Tags. Tag battery life can be extended by switching them off when they leave a defined tracking area through a gate or doorway. The Exciter can also be configured to change the tag transmission rate temporarily or indefinitely to accommodate different usage patterns in different environments. Message Programming functions The EX5500 Exciter can to store messages on the Tag for subsequent transmission. The message transmission can subsequently be triggered by other EX5500s, enabling sophisticated process control functions. The EX5500 Exciter can trigger a Tag to: • Transmit up to 15 bytes of data sent to it by the EX5500 • Transmit one of 15 pre-stored messages • Store up to 15 bytes of data sent to it by the EX5500 Network connectivity The EX5500 Exciter enables remote programming, monitoring, and software updates by the AeroScout Engine. In addition, the EX5500 can work in an offline mode, thus eliminating the need for a physical network connection. In the offline mode however, remote configuration and monitoring is not available.
Date: 6/20/2013 Ref: EX-5500 FCC ID: Q3HEX5500 Tune up procedure To: Federal Communications Commission Subject: EX5500 FCC ID: Q3HEX5500 - Tune up procedure No manual tune-up procedure required. Thank you, Signature: Printed Name: Reuven Amsalem VP HW R&D AeroScout Ltd.
Test Report E128021.01 AeroScout Ltd. Page 1 of 35 FCC ACC M Ver 1.2 28 February 2011 DATE: 22 September 2013 I.T.L. (PRODUCT TESTING) LTD. FCC Radio Test Report for AeroScout Ltd. Equipment under test: LF Exciter with Internal Wi-Fi Receiver 125 kHz Transmitter EX-5500 Written by: _____________________________ R. Pinchuck, Documentation Approved by: _____________________________ A. Sharabi, Test Engineer Approved by: _____________________________ I. Raz, EMC Laboratory Manager This report must not be reproduced, except in full, without the written permission of I.T.L. (Product Testing) Ltd. This report relates only to items tested. Test Report E128021.01 AeroScout Ltd. Page 2 of 35 FCC ACC M Ver 1.2 28 February 2011 Measurement/Technical Report for AeroScout Ltd. LF Exciter with Internal Wi-Fi Receiver EX-5500 FCC ID: Q3HEX5500 IC: 5115A-EX5500 03 September 2013 This report concerns: Original Grant: X Class I Change: Class II Change: Equipment type: Part 15 Low Power Transmitter Below 1705 kHz LF Exciter with Internal Wi-Fi Receiver Limits used: 47CFR15 Section 15.209 Measurement procedure used is KDB 558074 D01 April 9, 2013 and ANSI C63.4: 2003. Application for Certification Applicant for this device: prepared by: (different from "prepared by") Ishaishou Raz Reuven Amsalem ITL (Product Testing) Ltd. 3 Pekeris St., Einstein Entrance Kfar Bin Nun Rechovot 76702 D.N. Shimshon 99780 Israel Israel Tel: +972-8- 936-9393 e-mail [email protected] Fax: +972-8- 936-5977 e-mail: [email protected] Test Report E128021.01 AeroScout Ltd. Page 3 of 35 FCC ACC M Ver 1.2 28 February 2011 TABLE OF CONTENTS 1. GENERAL INFORMATION ------------------------------------------------------------------------------- 4 1.1 Administrative Information ................................................................................. 4 1.2 List of Accreditations ......................................................................................... 5 1.3 Product Description ........................................................................................... 6 1.4 Test Methodology .............................................................................................. 6 1.5 Test Facility ....................................................................................................... 6 1.6 Measurement Uncertainty ................................................................................. 6 2. SYSTEM TEST CONFIGURATION --------------------------------------------------------------------- 8 2.1 Justification ........................................................................................................ 8 2.2 EUT Exercise Software ..................................................................................... 8 2.3 Special Accessories .......................................................................................... 8 2.4 Equipment Modifications ................................................................................... 8 2.5 Configuration of Tested System ........................................................................ 9 3. CONDUCTED AND RADIATED MEASUREMENT TEST SET-UP PHOTO ----------------10 4. CONDUCTED EMISSION FROM AC PORTS ------------------------------------------------------13 4.1 Test Specification ............................................................................................ 13 4.2 Test Procedure ................................................................................................ 13 4.3 Measured Data ................................................................................................ 13 4.4 Test Instrumentation Used, Conducted Measurement ................................... 17 5. AVERAGE FACTOR CALCULATION 125 KHZ TRANSMITTER ----------------------------18 5.1 Test Instrumentation Used .............................................................................. 20 6. FIELD STRENGTH OF FUNDAMENTAL 125 KHZ TRANSMITTER -------------------------21 6.1 Test Specification ............................................................................................ 21 6.2 Test Procedure ................................................................................................ 21 6.3 Measured Data ................................................................................................ 21 6.4 Test Instrumentation Used, Field Strength of Fundamental ........................... 23 7. SPURIOUS RADIATED EMISSION, 9 KHZ – 30 MHZ, 125 KHZ TRANSMITTER-------24 7.1 Test Specification ............................................................................................ 24 7.2 Test Procedure ................................................................................................ 24 7.3 Test Results..................................................................................................... 24 7.4 Test Instrumentation Used, Radiated Measurements ..................................... 26 7.5 Field Strength Calculation ............................................................................... 26 8. SPURIOUS RADIATED EMISSION 30-1000 MHZ, 125 KHZ TRANSMITTER ------------27 8.1 Test Specification ............................................................................................ 27 8.2 Test Procedure ................................................................................................ 27 8.3 Test Data ......................................................................................................... 27 8.4 Test Instrumentation Used, Radiated Measurements ..................................... 29 9. BANDWIDTH FOR 125 KHZ TRANSMITTER ------------------------------------------------------30 9.1 Test Specification ............................................................................................ 30 9.2 Test procedure ................................................................................................ 30 9.3 Test Results....................…
