Q3HTAGHGS1000AEROSCOUT WI-FI HUGS TAG

Hugs® Wi-Fi Tag User Sheet Part Number: TAG-HGS-1000 © 2013 Stanley Healthcare. All Rights Reserved. 07/2013. 0980-031 Rev 01. Stanley Healthcare130 Turner Street, Waltham, MA 02453 Phone: +1-888-622-6992Email: [email protected] www.stanleyhealthcare.com Storage Store Hugs Tags at room temperature. Warranty Stanley Healthcare’s products are warranted against defects in materials and workmanship and shall perform in accordance with published specifications for a period of one year. Stanley Healthcare reserves the right to change specifications without notice. Limitation of Liability This Product has been designed for use to assist in the prevention of infant abduction and/or mother/ infant mismatching incidents. The range, accuracy, function and performance of this Product may vary from the published specifica- tions due to many factors, including, but not limited to, site impairments from structural effects, metal objects in the vicinity, placement of the receiver and transmitter, interference from other electrical devices, atmospheric effects, installation, and maintenance. There may be other factors, which also affect per- formance of this Product. Stanley Healthcare (“Stanley”) does not guarantee that this Product will detect 100% of infant abduc- tions and/or mother/infant mismatch incidents, nor does Stanley guarantee that this Product will be free from returning false reports of infant abductions and/ or mother/infant mismatch incidents. Monthly testing and maintenance of this Product, as described in the Product documentation, is essential to verify the system is operating correctly and to ensure that the probability of detecting an alarm and/ or locating the transmitter are maximized. The failure to undertake regular testing and main- tenance will increase the risk of system failure and failure to detect infant abductions and/or mother/ infant mismatch incidents. The failure to undertake regular testing and maintenance will increase the risk of false reports of infant abductions and/or mother/ infant mismatch incidents. Stanley hereby disclaims all warranties, express or implied, arising out of or in connection with any of its Products of the use or performance thereof, including but not limited to, where allowable by law, all other implied warranties or conditions of merchantability, fitness for a particular purpose, and those arising by statute or otherwise in law or from a course of dealing or usage of trade. Stanley’s liability to you or anyone claiming through or on behalf of you with respect to any claim or loss arising out of the use or misuse of Stanley’s Product, defective products or materi- als, improper installation or maintenance of Stanley’s Product or products or the system in which they are incorporated, or alleged to have resulted from an act or omission of Stanley or any person, negligent or otherwise, shall be limited to the following, at Stanley’s sole option: a) the repair or replacement of defective Product or materials supplied by Stanley during the warranty period as set out in the Product documentation; or, at the option of Stanley, b) a refund of the purchase price of the Product supplied by Stanley. In no event shall Stanley be liable for general, specific, indirect, consequential, incidental, exemplary or punitive damages or any losses or expenses suffered by you or anyone else, whether or not Stanley, or its employees, officers, agents, resellers or installers has been informed of the risk of such loss or expense and whether or not such losses or expenses were foreseeable. Statements Federal Communication Commission (FCC) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: a) Reorient or relocate the receiving antenna. b) Increase the separation between the equipment and receiver. c) Connect the equipment to an outlet on a cir- cuit different from that to which the receiver is connected. d) Consult the dealer or an experienced radio/ TV technician. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interfer- ence 2) This device must accept any interference received, including interference that may cause undesired operation. WARNING! Changes or modifications to this unit not expressly approved by the party respon- sible for compliance could void the user’s author- ity to operate the equipment. This device complies with FCC Rules Part 15 and with Industry Canada licence-exempt RSS standard(s). Operation is subject to two con- ditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference that may be received or that may cause undesired operation. Le present appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisee aux deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioelectrique subi, meme si le brouillage est susceptible d’en compromettre le fonctionnement. Instructions for the Hugs® Wi-Fi Tag Hugs® Wi-Fi Tag User Sheet Introduction The Hugs Wi-Fi Tag with BabySense™ functionality is part of the Hugs infant pro- tectio…

Text truncated - open the document above for the full version.

10 Oppenheimer St. Park Tamar, Rehovot, Israel, 76701 Tel: 972-8-936-3136 Fax: 972-8-936-5977 www.aeroscout.com Date: 29/05/2013 To: Timco Engineering Inc. To Whom It May Concern We hereby authorize Mr. Shaike Raz of I.T.L. (Product Testing) Ltd (ITL) to act on our behalf regarding the FCC Certification Process for the following application: Model: TAG-HGS-1000 FCC ID: Q3HTAGHGS1000 Thank you, Sincerely, Signature: Reuven Amsalem VP HW R&D

10 Oppenheimer St. Park Tamar, Rehovot, Israel, 76701 Tel: 972-8-936-3136 Fax: 972-8-936-5977 www.aeroscout.com Date: 29/05/2013 To: Timco Engineering Inc. To Whom It May Concern We hereby authorize Mr. Shaike Raz of I.T.L. (Product Testing) Ltd (ITL) to sign FORM 731 on our behalf for the following application: Model: TAG-HGS-1000 FCC ID: Q3HTAGHGS1000 Thank you, Sincerely, Signature: Reuven Amsalem VP HW R&D

10 Oppenheimer St. Park Tamar, Rehovot, Israel, 76701 Tel: 972-8-936-3136 Fax: 972-8-936-5977 www.aeroscout.com Date: 29/05/2013 Ref: TAG-HGS-1000 FCC ID: Q3HTAGHGS1000 Confidentiality Request To: Federal Communications Commission Confidentiality Request regarding application for certification of FCC ID: Q3HTAGHGS1000 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: a. CONF APPENDIX TAG-HGS-1000 Schem.pdf b. CONF APPENDIX TAG-HGS-1000 PartsLst.pdf c. CONF APPENDIX TAG-HGS-1000 BlkDia.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Signature: Reuven Amsalem VP HW R&D

10 Oppenheimer St. Park Tamar, Rehovot, Israel, 76701 Tel: 972-8-936-3136 Fax: 972-8-936-5977 www.aeroscout.com Date: 29.05.2013 Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: The AeroScout TAG-HGS-1000, FCC ID: Q3HTAGHGS1000, and label are so small that it cannot include the statement specified in FCC Part 15 Sub-part A, Section 15.19 (a) (3) “This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference that may cause undesired operation." Due to this reason, we are using the provisions of Part 15 Sub-part A, Section 15.19 (a) (5) and this statement appears in a prominent location in the user manual. Please contact me if there is any information you may need. Sincerely, Reuven Amsalem VP R&D AeroScout Ltd.

10 Oppenheimer St. Park Tamar, Rehovot, Israel, 76701 Tel: 972-8-936-3136 Fax: 972-8-936-5977 www.aeroscout.com Operational Description TAG-HGS-1000 Tag1000 (TAG-HGS-1000) is an Active RFID tag platform which designed by AeroScout to use in Hugs infant protection RTLS system. The Tag based on Wi-Fi 802.11 transceiver (2.4GHz) and LF receiver (125KHz) which are working corporately to build the real time location system (RTLS). AeroScout TAG-HGS-1000 Tags contain on-board motion sensors. The motion sensor can be configured to trigger alerts. It also enables different transmission intervals for tags when they are stationary or in motion – which reduces unnecessary network traffic and conserves battery life. AeroScout TAG-HGS-1000 Tags also contains on-board Buzzer that provides Audio indications on preconfigured trigger Alarms. TAG-HGS-1000 Tags also contain Strap (Band) trigger capabilities which provide Wi-Fi indication if tag attached properly to the infant and when Strap is cut. The tag is working from 4.2V-2.9V DC supply on-board rechargeable battery. The tag includes LED which indicates when the LF/Wi-Fi is operated.

10 Oppenheimer St. Park Tamar, Rehovot, Israel, 76701 Tel: 972-8-936-3136 Fax: 972-8-936-5977 www.aeroscout.com Date: 29/05/2013 Ref: TAG-HGS-1000 FCC ID: Q3HTAGHGS1000 Tune up procedure To: Federal Communications Commission Subject: TAG-HGS-1000 FCC ID: Q3HTAGHGS1000 - Tune up procedure No manual tune-up procedure required. Thank you, Signature: Printed Name: Reuven Amsalem VP HW R&D AeroScout Ltd.

Test Report E128921.00 AeroScout Ltd. Page 1 of 59 FCC ACC M Ver 1.2 28 February 2011 DATE: 23 July 2013 I.T.L. (PRODUCT TESTING) LTD. FCC Radio Test Report for AeroScout Ltd. Equipment under test: Wi-Fi HUGS Tag TAG-HGS-1000 Written by: _____________________________ R. Pinchuck, Documentation Approved by: _____________________________ A. Sharabi, Test Engineer Approved by: _____________________________ I. Raz, EMC Laboratory Manager This report must not be reproduced, except in full, without the written permission of I.T.L. (Product Testing) Ltd. This report relates only to items tested. Test Report E128921.00 AeroScout Ltd. Page 2 of 59 FCC ACC M Ver 1.2 28 February 2011 Measurement/Technical Report for AeroScout Ltd. Wi-Fi HUGS Tag TAG-HGS-1000 FCC ID: Q3HTAGHGS1000 IC: 5115A-TAGHGS1000 23 July 2013 This report concerns: Original Grant: X Class I Change: Class II Change: Equipment type: Spread Spectrum/Digital Device 2400-2483.5 MH Limits used: 47CFR15 Section 15.247 Measurement procedure used is ANSI C63.4-2003. Application for Certification Applicant for this device: prepared by: (different from "prepared by") Ishaishou Raz Reuven Amsalem ITL (Product Testing) Ltd. 3 Pekeris St., Einstein Entrance Kfar Bin Nun Rechovot 76702 D.N. Shimshon 99780 Israel Israel Tel: +972-8-936-9393 e-mail [email protected] Fax: +972-8-936-5977 e-mail: [email protected] Test Report E128921.00 AeroScout Ltd. Page 3 of 59 FCC ACC M Ver 1.2 28 February 2011 TABLE OF CONTENTS 1. GENERAL INFORMATION ------------------------------------------------------------------------------- 5 1.1 Administrative Information ................................................................................. 5 1.2 List of Accreditations ......................................................................................... 6 1.3 Product Description ........................................................................................... 7 1.4 Test Methodology .............................................................................................. 7 1.5 Test Facility ....................................................................................................... 7 1.6 Measurement Uncertainty ................................................................................. 7 2. SYSTEM TEST CONFIGURATION --------------------------------------------------------------------- 8 2.1 Justification ........................................................................................................ 8 2.2 EUT Exercise Software ..................................................................................... 8 2.3 Special Accessories .......................................................................................... 8 2.4 Equipment Modifications ................................................................................... 8 2.5 Configuration of Tested System ........................................................................ 9 3. RADIATED MEASUREMENT TEST SET-UP PHOTO -------------------------------------------10 4. 6 DB MINIMUM BANDWIDTH --------------------------------------------------------------------------12 4.1 Test procedure ................................................................................................ 12 4.2 Results table .................................................................................................... 14 4.3 Test Equipment Used. ..................................................................................... 15 5. 26 DB MINIMUM BANDWIDTH-------------------------------------------------------------------------16 5.1 Test procedure ................................................................................................ 16 5.2 Results table .................................................................................................... 18 5.3 Test Equipment Used. ..................................................................................... 19 6. MAXIMUM TRANSMITTED PEAK POWER OUTPUT -------------------------------------------20 6.1 Test procedure ................................................................................................ 20 6.2 Results table .................................................................................................... 22 6.3 Test Equipment Used. ..................................................................................... 23 7. BAND EDGE SPECTRUM -------------------------------------------------------------------------------24 7.1 Test procedure ................................................................................................ 24 7.2 Results table .................................................................................................... 25 7.3 Test Equipment Used. ..................................................................................... 26 8. RADIATED EMISSION, 9 KHZ – 30 MHZ -----------------------------------------------------------27 8.1 Test Specification ............................................................................................ 27 8.2 Test Procedure ................................................................................................ 27 8.3 Measured Data ................................................................................................ 27 8.4 Test Instrumentation Used, Radiated Measurements ..................................... 28 8.5 Field Strength Calculation ............................................................................... 29 9. SPURIOUS RADIATED EMISSION 30 – 25000 MHZ --------------------------------------------30 9.1 Radiated Emission 30-25000 MHz .................................................................. 30 9.2 Test Data ......................................................................................................... 31 9.3 Test Instrumentation Used, Radiated Measurements Above 1 GHz .............. 38 10. TRANSMITTED POWER DENSITY -------------------…
