Q5K12529T49 MHz Toy Transmitter

Operation Description (KR-1252) 49.860 MHz The EUT is a transmitter for R/C Thunder Spin Turbo Ball operating at 49.860 MHz and is controlled by a crystal. The EUT is powered by 1 x 9V battery. There are two control levers on the EUT. Different combinations of the controls enable the EUT to transmit different radio signals for the receiver to move forward, backward and to perform spinning actions. The brief circuit description is listed as follows: - U1 and associated circuit act as encoder - Q2 and associated circuit act as RF amplifier - T1 and associated circuit act as oscillator - Z1 and associated circuit act as voltage regulator - Q1 and associated circuit act as modulator

TEST REPORT Report No. : AF026083-001 Date : 2005 November 15 Page 1 of 11 FCC ID: Q5K12529T This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Application No. : LF220916(9) Applicant : K&B International Limited 406 Empire Centre 67 Mody Road, TST East Hong Kong Sample Description : One(1) submitted sample(s) stated to be R/C Thunder Spin Turbo Ball of Model No. KR-1252 Rating : 1 x 9V battery No. of submitted sample : One (1) piece(s) Date Received : 2005 November 04 Test Period : 2005 November 04 – 2005 November 15 Test Requested : FCC Part 15 Certification. Test Method : FCC Rules and Regulations Part 15 – July 2004 ANSI C63.4 – 2003 Test Result : See attached sheet(s) from page 2 to 11. Conclusion : The submitted sample was found to comply with requirement of FCC Part 15 Subpart C. For and on behalf of CMA Industrial Development Foundation Limited Authorized Signature : ____________________________________________________ Danny Chui EMC Engineer - EL. Division TEST REPORT Report No. : AF026083-001 Date : 2005 November 15 Page 2 of 11 FCC ID: Q5K12529T This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Table of Contents 1 General Information ..................................................................................................................................3 1.1 General Description ...........................................................................................................................3 1.2 Location of the test site......................................................................................................................4 1.3 List of measuring equipment .............................................................................................................5 2 Description of the radiated emission test...................................................................................................6 2.1 Test Procedure ...................................................................................................................................6 2.2 Test Result .........................................................................................................................................6 2.3 Radiated Emission Measurement Data ..............................................................................................7 3 Description of the Line-conducted Test ....................................................................................................8 3.1 Test Procedure ...................................................................................................................................8 3.2 Test Result .........................................................................................................................................8 3.3 Graph and Table of Conducted Emission Measurement Data...........................................................8 4 Photograph.................................................................................................................................................9 4.1 Photographs of the Test Setup for Radiated Emission and Conduction Emission ............................9 4.2 Photographs of the External and Internal Configurations of the EUT ..............................................9 5 Supplementary document ........................................................................................................................10 5.1 Bandwidth........................................................................................................................................10 5.2 Duty cycle........................................................................................................................................10 6 Appendices ..............................................................................................................................................11 TEST REPORT Report No. : AF026083-001 Date : 2005 November 15 Page 3 of 11 FCC ID: Q5K12529T This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Test Result : 1 General Information 1.1 General Description The equipment under test (EUT) is a transmitter for R/C Thunder Spin Turbo Ball operating at 49.860 MHz and is controlled by a crystal. The EUT is powered by 1 x 9V battery. There are two control levers on the EUT. Different combinations of the controls allow the EUT to transmit radio signals for the receiver to more forward, backward and to perform spinning actions. The brief circuit description is listed as follows: - U1 and associated circuit act as encoder - Q2 and associated circuit act as RF amplifier - T1 and associated circuit act as oscillator - Z1 and associated circuit act as voltage regulator - Q1 and associated circuit act as modulator TEST REPORT Report No. : AF026083-001 Date : 2005 November 15 Page 4 of 11 FCC ID: Q5K12529T This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Test Result : 1.2…

Text truncated - open the document above for the full version.

CMA Testing and Certification Laboratories Job No.: J00044785 WF-EL-EMC-15 Edition 3 2005 Mar 29 Page of Bandwidth Plot Bandwidth 1

CMA Testing and Certification Laboratories Job No.: J00044785 WF-EL-EMC-15 Edition 3 2005 Mar 29 Page of Duty Cycle Duty Cycle 1 Duty Cycle 2 CMA Testing and Certification Laboratories Job No.: J00044785 WF-EL-EMC-15 Edition 3 2005 Mar 29 Page of Duty Cycle 3
