Q5TBT450RX0508ABluetooth Stereo Headphone

Bluetooth ® Stereo Headphone P/N: BT450Rx User Manual BLUETAKE 1 BLUETOOTH STEREO HEADPHONE KIT – USER MANUAL English Retail Box Contains Please make sure you have received the following items: n Bluetooth Stereo Headphone (BT450Rx) o AC Power Adapter (Output: DC 5V / 500 mA) p Y-splitter Power Cable q Nonwoven Fabrics Pouch r User Manual BLUETOOTH STEREO HEADPHONE KIT – USER MANUAL 2 English Bluetooth Stereo Headphone: (A) Left Side Speaker (B)Right Side Speaker (C) Ear Clip (D)Power/Call Button (E) Foam Ear Pad (F)Status LED Indicator (G) Charge Socket (H)Remote Control Roller (I) Microphone 3 BLUETOOTH STEREO HEADPHONE KIT – USER MANUAL English Status LED Indicator Chart Bluetooth Stereo Headphone Status LED Pattern Beep Power on Blue 1 beep Connected Blue 1 beep Pairing Mode Red + Blue (alternate) 2 beeps Incoming Phone Call Red + Blue (alternate) 2 beeps every 2 seconds Battery Low Red 2 beeps every 60 seconds BLUETOOTH STEREO HEADPHONE KIT – USER MANUAL 4 English User Control Interface Chart (Headphone) Power/Call Button Action Function Press & Hold 2 sec Power On Press Once Answer/Make/End a Call, Voice Dial Press & Hold 3 sec Power Off Remote Control Roller Action Function Roll Up Volume Up Roll Down Volume Down Roll Up & Hold 2 sec Next Music Track Roll Down & Hold 2 sec Previous Music Track Press Once Play/Pause Music Press & Hold 2 sec Reject a Call Press & Hold 2 sec, together with Power/Call Button Pairing Mode 5 BLUETOOTH STEREO HEADPHONE KIT – USER MANUAL English Power/Call Button Remote Control Roller BLUETOOTH STEREO HEADPHONE KIT – USER MANUAL 6 English Power On/Off i-PHONO mini < If this is the first time you use the i-PHONO mini headphone and stereo transmitter, please refer to the next lesson to FULLY charge both the devices in advance. > Power On: Press the Power/Call Button and hold 3 seconds and the Status LED Indicator will begin to flash blue light. Power Off: Press the Power/Call Button and hold 2 seconds. Status LED Indicator Power/Call Button Press and Hold 2 sec. 7 BLUETOOTH STEREO HEADPHONE KIT – USER MANUAL English Charging i-PHONO mini Before you start to charge the i-PHONO mini headphone and stereo transmitter, please POWER OFF the both two devices.. Step-1: Plug the AC power adapter in to the interior outlet. Step-2: Connect the AC power adapter with the Y-splitter power cable. Step-4: Open the soft rubber cover which is attached to the headphone’s left side speaker. Then, Plug the flat-squared terminal of the Y-splitter Power Cable into the chare socket of the headphone. Please refer to the following chart to know the charging status: Charging LED Indicator (Y-splitter Power Cable) for Headphone Red Charging Mode Green Fully Charged BLUETOOTH STEREO HEADPHONE KIT – USER MANUAL 8 English Charging LED Indicator 9 BLUETOOTH STEREO HEADPHONE KIT – USER MANUAL English Pairing the Headphone Step-1: Power on the headphone. (If the headphone is already on, please disconnect all Bluetooth services between the headphone and other devices in advance.) Step-2:. Press Remote Control Roller together with Power/Call Button and hold this position 2 seconds. If the headphone is in the pairing mode, the headphone’s Status LED Indicator will begin to flash red and blue light alternately. Remote Control Roller Press and Hold 2 sec. Status LED Indicator Press and Hold 2 sec. Power/Call Button BLUETOOTH STEREO HEADPHONE KIT – USER MANUAL 10 English Wearing the Headphone Before you start to charge the i-PHONO mini headphone and stereo transmitter, please POWER OFF the both two devices.. Step-1: Swing and open the ear clip. Step-2: Hold the headphone’s main part and wear it on you ear from front to back, from top to down. Step-3: Adjust the suitable position to fit both sides of your ears. 11 BLUETOOTH STEREO HEADPHONE KIT – USER MANUAL English Using with the Bluetooth-enabled Computer You can use the i-PHONO mini headphone’s stereo (A2DP) and remote control (AVRCP) functions with the Bluetooth-enabled computer which answers the following requirements: z Windows XP O.S. only z Both Bluetooth hardware (embedded chipset or USB adapter) and software support A2DP (Advanced Audio Distribution Profile) and AVRCP (Audio Video Remote Control Profile) The following instruction used BLUETAKE BT007Si Bluetooth USB Adapter and IVT BlueSoleil Bluetooth Software v1.4.9.2 to demonstrate the general procedure. <Pairing> Step-1: Follow “Pairing” procedure to make the i-PHONO mini headphone enter to the pairing mode. Step-2: Open the Bluetooth software and search the i-PHONO mini headphone. Then, you will find out a headphone (headset) icon named “iPHONO mini”. Select the device to pair with the computer. Step-3: Afterward a dialogue box will prompt you for a passkey or PIN. Enter 0000 (a sequence of four zeros) in the dialog box and then click on “OK” or “Confirm”. After the pairing is completed, the headphone (headset) icon will be marked. Step-4:. Double click on the marked headphone (headset) icon, and then you can discover the Bluetooth service (function) provided by the i-PHONO mini headphone. BLUETOOTH STEREO HEADPHONE KIT – USER MANUAL 12 English Step-5 Connect the computer to the headphone by double-clicking on the A2DP icon which is usually named “Bluetooth AV Service”, “A2DPsink” or “Audio Sink”. After the connection is established, the headphone (headset) icon in the Bluetooth software window should be charged its color and the Status LED Indicator of headphone should be flash blue light alternately . Now, the i-PHONO mini headphone is ready to apply the stereo application with the paired computer. Thereafter, you only need to follow up the instruction from Step-4 if you want to operate the same application. 13 BLUETOOTH STEREO HEADPHONE KIT – USER MANUAL English < Listen to Music and Remote Control > After you connected the i-PHONO mini headphone with the paired computer via the Bluetooth AV service (A2DP), you can listen to the stereo music played from the computer. Step-1: Make …

Text truncated - open the document above for the full version.

RF_160, Issue 01 Declaration of Authorization We Name: Bluetake Technology Co., Ltd. Address: 5F, NO.27, Lane 155, Sec.3, Pei Shen Rd., Shen Keng Shiang City: Taipei Hsien Country: Taiwan Declare that: Name: SGS Taiwan Ltd. Address: 134, Wu Kung Rd., Wuku Industrial Zone City: Taipei County Country: Taiwan is authorized to apply for Certification of the following product(s): Product description: Bluetooth Stereo Headphone Type designation: BT450Rx Trademark: BLUETAKE on our behalf. Date: Sep. 22, 2005 City: Taipei Hsien Name: Mr. Shicheng Huang Signature:

Report No EF/2005/80017 ID: Q5TBT450RX0508A Issue Date: Sep. 21, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw APPENDIX 2 EXTERNAL PHOTOGRPHS OF EUT Report No EF/2005/80017 ID: Q5TBT450RX0508A Issue Date: Sep. 21, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw All View of EUT Front View of EUT Report No EF/2005/80017 ID: Q5TBT450RX0508A Issue Date: Sep. 21, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Back View of EUT Top View of EUT

Report No EF/2005/80017 ID: Q5TBT450RX0508A Issue Date: Sep. 21, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw APPENDIX 2 EXTERNAL PHOTOGRPHS OF EUT Report No EF/2005/80017 ID: Q5TBT450RX0508A Issue Date: Sep. 21, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw All View of EUT Front View of EUT Report No EF/2005/80017 ID: Q5TBT450RX0508A Issue Date: Sep. 21, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Back View of EUT Top View of EUT

FCC ID LABEL FORMAT AND LOCATION Applicant: Bluetake Technology Co., Ltd. FCC ID: Q5TBT450RX0508A

FCC ID LABEL FORMAT AND LOCATION Applicant: Bluetake Technology Co., Ltd. FCC ID: Q5TBT450RX0508A

Report No EF/2005/80017 ID: Q5TBT450RX0508A Issue Date: Sep. 21, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw APPENDIX 3 INTERNAL PHOTOGRPHS OF EUT Report No EF/2005/80017 ID: Q5TBT450RX0508A Issue Date: Sep. 21, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Open View of EUT Open View of EUT – 1 Report No EF/2005/80017 ID: Q5TBT450RX0508A Issue Date: Sep. 21, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Internal of EUT – 1 Internal of EUT – 2 Report No EF/2005/80017 ID: Q5TBT450RX0508A Issue Date: Sep. 21, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Internal of EUT – 3 Internal of EUT – 4

Report No EF/2005/80017 ID: Q5TBT450RX0508A Issue Date: Sep. 21, 2005 Page: 1 of 57 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF Product Name: Bluetooth Stereo Headphone Brand Name: BLUETAKE Model Name: BT450Rx FCC ID: Q5TBT450RX0508A Report No.: EF/2005/80017 Issue Date: Sep. 21, 2005 FCC Rule Part: §15.247 Prepared for: Bluetake Technology Co., Ltd. 5F, No. 27, Lane 155, Sec. 3, Pei Shen Rd., Shen Keng Shiang, 222, Taipei, Taiwan Prepared by: SGS Taiwan Ltd. No. 134, Wu Kun g Rd., Wuku Industrial Zone, Taipei County, Taiwan. Note: This report shall not be reproduced except in full, without the written approval of SGS Taiwan Ltd. This document may be altered or revised by SGS Taiwan Ltd. personnel only, and shall be noted in the revision section of the document. Report No EF/2005/80017 ID: Q5TBT450RX0508A Issue Date: Sep. 21, 2005 Page: 2 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw VERIFICATION OF COMPLIANCE Applicant: Bluetake Technology Co., Ltd. 5F, No. 27, Lane 155, Sec. 3, Pei Shen Rd., Shen Keng Shiang, 222, Taipei, Taiwan Equipment Under Test: Bluetooth Stereo Headphone Brand Name: BLUETAKE FCC ID Number: Q5TBT450RX0508A Model No.: BT450Rx Model Difference: N/A File Number: EF/2005/80017 Date of test: Aug. 31, 2005 ~ Sep. 19, 2005 Date of EUT Received: Aug. 30, 2005 We hereby certify that: The above equipment was tested by SGS Taiwan Ltd. The test data, data evaluation, test proce- dures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2003) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247 The test results of this report relate only to the tested sample identified in this report. Test By: Date Sep. 21, 2005 Sky Wang Prepared By: Date Sep. 21, 2005 Eva Kao Approved By: Date Sep. 21, 2005 Vincent Su Report No EF/2005/80017 ID: Q5TBT450RX0508A Issue Date: Sep. 21, 2005 Page: 3 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Version Version No. Date 00 Sep. 21, 2005 Report No EF/2005/80017 ID: Q5TBT450RX0508A Issue Date: Sep. 21, 2005 Page: 4 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Table of Contents 1. GENERAL INFORMATION .........................................................................................................7 1.1. Product Description ............................................................................................................................7 1.2. Related Submittal(s) / Grant (s) ..........................................................................................................7 1.3. Test Methodology ...............................................................................................................................7 1.4. Test Facility.........................................................................................................................................7 1.5. Special Accessories .............................................................................................................................7 1.6. Equipment Modifications....................................................................................................................7 2. SYSTEM TEST CONFIGURATION ............................................................................................8 2.1. EUT Configuration .............................................................................................................................8 2.2. EUT Exercise ......................................................................................................................................8 2.3. Test Procedure.....................................................................................................................................8 2.4. Configuration of Tested System..........................................................................................................9 3. SUMMARY OF TEST RESULTS ...............................................................................................10 4. DESCRIPTION OF TEST MODES ............................................................................................10 5. CONDUCTED EMISSION TEST................................................................................................11 5.1. Standard Applicable ..........................................................................................................................11 5.2. EUT Setup........................................................…

Text truncated - open the document above for the full version.

Report No EF/2005/80017 ID: Q5TBT450RX0508A Issue Date: Sep. 21, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw APPENDIX 1 PHOTOGRPHS OF SET UP Report No EF/2005/80017 ID: Q5TBT450RX0508A Issue Date: Sep. 21, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Radiated Emission Set up Photo Report No EF/2005/80017 ID: Q5TBT450RX0508A Issue Date: Sep. 21, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Conducted Emission Set up Photo Conducted Emission Set up Photo
