Q6G-AP430CRWireless Access Point

Quick Start Guide WatchGuard ® AP AP430CR Pole Mount Clamps Wall Mount Screws ACTIVATE YOUR AP GO TO: watchguard.com/activate MOUNT THE AP CONNECT THE AP 32 1 WALL MOUNT Plug one end of the Ethernet cable from your network into the LAN 1 (PoE+) port on the bottom of the AP. Make sure the other end of the Ethernet cable is connected to your network through a hub, switch, or injector with PoE+ (802.3at) power enabled. Access Point connected to PoE+ injector Access Point connected to switch with PoE+ power POLE MOUNT PoE+ Ground Screw Wall and Pole Mount Screws DEG DIM REVDESCCRIPTIONLOCATIONSIGNDATE APeter 11-May-21 A0 UNITSCALESHEETMODEL No. AP430CR MM0,3331 of 1PART NAME POLE MOUNT APPROVEDCHECKEDDESIGNEDPART No.REVA TonyPeacePeter 11-May-2111-May-2111-May-21 ANGLE ABCD 0-50.020.050.100-300.1 5-100.050.100.1531-600.3 10-500.100.150.2061-900.5 50-1000.150.200.25 100-0.15%0.20%0.25% ADDRESS: 505 Fifth Avenue South, Suite 500, Seattle, WA 98104 U.S. SALES: 1.800.734.9905 • INTERNATIONAL SALES: +1.206.613.0895 WEB: www.watchguard.com © 2021 WatchGuard Technologies, Inc. All rights reserved. WatchGuard, the WatchGuard Logo, Fireware, and LiveSecurity are registered trademarks of WatchGuard Technologies, Inc. in the United States and/or other countries. All other trademarks and tradenames are the property of their respective owners. P.N. 352-4430-001 Rev A 051021 1.877.232.3531 (U.S. and Canada) WATCHGUARD TECHNICAL SUPPORT +1.206.613.0456 (all other countries) www.watchguard.com/support TOP REAR CHECK AP LED STATUS NOTICES: All WatchGuard products are designed and tested to meet strict safety requirements. These requirements include product safety approvals and other global compliance standards. Please read these instructions carefully before operating the product, and refer to them as needed to ensure the continued safe operation of your product. Additional information, including a full list of safety approvals, global compliance standards, and certifications can be found in the Hardware Guide for this device located on the WatchGuard website: https://www.watchguard.com/wgrd-help/documentation/hardware-guides For patent information, please visit http://www.watchguard.com/patents Safety Warning If protective earthing is used as a safeguard, the instructions shall require connection of the equipment protective earthing conductor to the installation protective earthing conductor (for example, by means of a power cord connected to a socket-outlet with earthing connection). To meet safety and electromagnetic interference (EMI) requirements, you must make sure the power source is connected to earth ground before you connect power to the AP. Power Adapter Requirements This product is intended to be supplied by a Listed Power Adapter or DC power source marked “L.P.S.” (or Limited Power Source or PS2) rated 12V DC, 2A minimum, maximum ambient temperature (Tma)=40°C, or supplied by a Listed PoE Adapter marked “L.P.S.” (or Limited Power Source or PS2) rated 48V DC, 0.6A minimum, maximum ambient temperature (Tma)=40°C. For more information regarding approved power sources, please contact WatchGuard Technologies. POWER REQUIREMENTS • PoE+ (802.3at) (48V DC, 0.6A) CONFIGURE THE AP 5 GO TO: watchguard.com/start Declaration of Conformity WatchGuard Technologies Inc. hereby declares that the product(s) listed below conform to the European Union directives and standards identified in this declaration. Product (s): 802.11 a/b/g/n/ac/ax Access Point, AP430CR EU Directive(s): Low Voltage (2014/35/EU) Electromagnetic Compatibility (2014/30/EU) Energy-related Products (2009/125/EC) RoHS (2011/65/EU and 2015/863/EU RoHS) WEEE Directive 2012/19/EU The Radio Equipment Directive (2014/53/EU) Common Standard(s): EN 62368-1:2014+A11:2017 Safety for ITE EN 55024:2010 EN 55024: 2010+A1:2015 Immunity for ITE EN 55032:2015+A11:2020 EN 55035: 2017/A11:2020 EN 61000-3-2:2014 Harmonics EN 61000-3-3:2013 Flicker Wireless Standard(s): EN 62311:2008 EN 301 489-1 v2.2.3 (2019-11) EMC and Radio Spectrum Matters EN 301 489-17 v3.1.1 (2017-02) EMC and Radio Spectrum Matters EN 300 328 v2.2.2 (2019-07) Radio Spectrum Matters EN 301 893 v2.1.1 (2017-05) Broadband Radio Access Networks EN 50385: 2017 This device complies with Directive 2014/53/EU issued by the Commission of the European Community. Manufacturer / Hersteller: WatchGuard Technologies 505 5th Ave S. Suite 500, Seattle, WA 98104 USA Radio Equipment / Funkanlage: 802.11 a/b/g/n/ac/ax Access Point Type Designation / Typenbezeichnung: AP430CR Specifications / Technische Daten: 802.11a,b,g,n,ac,ax (2.4Ghz & 5GHz) Intended Purpose / Verwendungszweck: Indoor access point Equipment Class / Betriebsmittel der Klasse: Class II Operating temperature 0° C to 40° C The above device compli es with the essential requirements and other relevant provisions to Directive 2014/53/EU when used for its intended purpose. This equipment may be operated in the USA, Canada, & Europe Union. Warning! This is a Class B product. In a domestic environment this product may ca use radio interference in which case the user may be required to take adequate measures. Frequency range (MHz) Max. Transmit Power (W) Bluetooth 0.00794 WLAN Wi-Fi 802.11x; 2, 4 GHz 0.09418 WLAN Wi-Fi 802.11x; 5 GHz 0.86896 Restrictions: France (i) les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux; (ii) De plus, les utilisateurs devraient aussi être avisés que les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5 250-5 350 MHz et 5 650-5 850 MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL. Die oben genannten Gerät entspricht den grundlegenden Anforderungen und anderen relevanten Bestimmungen der Richtlinie 2014/53/EU, wenn f…

Text truncated - open the document above for the full version.

Professional installation instruction 1. Installation personal This product is designed for specific application and needs to be installed by a qualified personal who has RF and related rule knowledge. The general user shall not attempt to install or change the setting. 2. Installation location The product shall be installed at a location where the radiating antenna can be kept 40cm from nearby person in normal operation condition to meet regulatory RF exposure requirement. 3. External antenna Use only the antennas which have been approved by the applicant. The non-approved antenna(s) may produce unwanted spurious or excessive RF transmitting power which may lead to the violation of FCC/IC limit and is prohibited. 4. Installation procedure Please refer to user’s manual for the detail. 5. Warning Please carefully select the installation position and make sure that the final output power does not exceed the limit set force in relevant rules. The violation of the rule could lead to serious federal penalty. Instructions d'installation professionnelle 1. Installation Ce produit est destine a un usage specifique et doit etre installe par un personnel qualifie maitrisant les radiofrequences et les regles s'y rapportant. L'installation et les reglages ne doivent pas etre modifies par l'utilisateur final. 2. Emplacement d'installation En usage normal, afin de respecter les exigences reglementaires concernant l'exposition aux radiofrequences, ce produit doit etre installe de facon a respecter une distance de 40cm entre l'antenne emettrice et les personnes. 3. Antenn externe. Utiliser uniiquement les antennes approuvees par le fabricant. L'utilisation d'autres antennes peut conduire a un niveau de rayonnement essentiel ou non essentiel depassant les niveaux limites definis par FCC/IC, ce qui est interdit. 4. Procedure d'installation Consulter le manuel d'utilisation. 5. Avertissement Choisir avec soin la position d'installation et s'assurer que la puissance de sortie ne depasse pas les limites en vigueur. La violation de cette regle peut conduire a de serieuses penalites federales.

WatchGuard AP430CR Hardware Guide WatchGuard AP430CR Ruggedized Access Point WatchGuardTechnologies,Inc.2 AboutThisGuide Informationinthisguideissubjecttochangewithoutnotice.Companies,names,anddatausedin exampleshereinarefictitiousunlessotherwisenoted.Nopartofthisguidemaybereproducedor transmittedinanyformorbyanymeans,electronicormechanical,foranypurpose,withouttheexpress writtenpermissionofWatchGuardTechnologies,Inc. Guiderevised:5/17/2021 Copyright,Trademark,andPatentInformation Copyright©1998–2021WatchGuardTechnologies,Inc.Allrightsreserved.Alltrademarksortradenames mentionedherein,ifany,arethepropertyoftheirrespectiveowners. Completecopyright,trademark,patent,andlicensinginformationcanbefoundintheCopyrightand LicensingGuide,availableonlineathttps://www.watchguard.com/wgrd-help/documentation/overview. AboutWatchGuard WatchGuard®Technologies,Inc.isagloballeaderinnetwork security,providingbest-in-classUnifiedThreatManagement,Next GenerationFirewall,secureWi-Fi,andnetworkintelligence productsandservicestomorethan75,000customersworldwide. Thecompany’smissionistomakeenterprise-gradesecurity accessibletocompaniesofalltypesandsizesthroughsimplicity, makingWatchGuardanidealsolutionforDistributedEnterprises andSMBs.WatchGuardisheadquarteredinSeattle,Washington, withofficesthroughoutNorthAmerica,Europe,AsiaPacific,and LatinAmerica.Tolearnmore,visitWatchGuard.com. Foradditionalinformation,promotionsandupdates,follow WatchGuardonTwitter,@WatchGuardonFacebook,oronthe LinkedInCompanypage.Also,visitourInfoSecblog,Secplicity, forreal-timeinformationaboutthelatestthreatsandhowtocope withthematwww.secplicity.org. Address 505FifthAvenueSouth Suite500 Seattle,WA98104 Support www.watchguard.com/support U.S.andCanada+877.232.3531 AllOtherCountries+1.206.521.3575 Sales U.S.andCanada+1.800.734.9905 AllOtherCountries+1.206.613.0895 WatchGuardTechnologies,Inc.3 Contents WatchGuardAP430CRHardwareGuide6 AccessPointManagement6 AboutYourHardware7 HardwareSpecifications7 EnvironmentalRequirements8 HardwareDescription9 BottomPanelConnections9 TopPanelConnections10 SidePanelConnections10 MountandConnecttheAccessPoint11 WallMountInstallation12 PoleMountInstallation13 AntennaInstallation14 ConnecttheGroundWire15 ConnecttheAccessPoint16 HowtoAssembletheWeatherproofConnector17 HowtoDisassembletheWeatherproofConnector18 EthernetPowerInjector(Optional)19 Notices21 SafetyWarning21 PowerAdapterRequirements21 FCCCertification21 CE Notice22 IndustryCanadaCertification22 EU DeclarationofConformity24 BrazilANATEL27 4WatchGuardTechnologies,Inc. MexicoNOM27 JapanStatement27 JapanVCCI ClassBStatement27 TaiwanNCC Statement27 RoHSStatement27 WEEEStatement28 REACHCertificateofCompliance28 WatchGuardTechnologies,Inc.5 WatchGuardAP430CRHardwareGuide WatchGuardAP430CRHardwareGuide TheWatchGuardAP430CRisaruggedizedaccesspointwithanIP67waterproofrating.TheAP430CR featuresan802.11ax2x22.4GHzdualradioand4x45GHzdualconcurrentradiothatsupportsupto1148 Mbpsdatarateonthe2.4GHzbandand2402Mbpsonthe5GHzband. TheAP430CRalsohasathird2x2dualbandradioforsecurityscanning,andanintegratedBluetooth (BLE) radio. PowerisprovidedbyaPoE+(PoweroverEthernet)powersource. AccessPointManagement YoucanmanageyourAP430CRwithWatchGuardCloud,apowerfulcloud-basedenterprisewireless managementsolutionforaccesspointconfiguration,security,andmonitoring. FormoreinformationonhowtosetupyouraccesspointwithWatchGuardCloud,see watchguard.com/start. WatchGuardTechnologies,Inc.6 AboutYourHardware HardwareSpecifications HardwareDescription Processor [email protected],Enterprise chipwithI-Tempsupport RAM nFlash:NORFlash8MB,FlashNAND256MB nRAM:DDR4512MBx2 RadioModel n2.4GHzQualcommIronQCN5124-12x2i-tempradio n5GHzQualcommIronQCN5154-14x4i-tempradio nScanradio:QualcommQCA9892i-tempdualband11ac2x2radio nBluetooth:QualcommCSR8811A12Bluetooth4.0 RadioTypeand FrequencyBand nRadio1:2.4GHz2x2802.11b/g/n/ax nRadio2:5GHz4x4802.11a/n/ac/ax nRadio3(Scan): Dualband802.11ac2x2radio AntennasnWi-Fi:4x4/5dBi2.4/5GHzdualbandN-typeomnidirectionalantennas nScanRadio:2x4/5dBi2.4/5GHzdualbandN-typeomnidirectional antennas nBLE: 1x4dBi2.4GHzexternalantenna EthernetInterfacesn1x5GbEEthernetport(AquantiaAQR114C) n1xGbEEthernetport(QCAAR8033) PowerInterfacenPoE54VDC802.3at PowerConsumption25.44W MTBF (MeanTimeBetween Failures) 151,258hoursat25 ̊C/77 ̊F Dimensions267.1mmx217.65mmx53.7mm(10.5”x8.6”x2.1”) Weight1.759kg(3.87lbs) WatchGuardAP430CRHardwareGuide 7WatchGuardTechnologies,Inc. WatchGuardAP430CRHardwareGuide EnvironmentalRequirements TosafelyinstallyourWatchGuardaccesspoint,werecommendthatyou: nInstallthedeviceindoors nMakesurethedevicehasadequateclearanceforairflowandcooling Otherenvironmentalrequirements: OperatingTemperature-30°Cto60°C(-22°Fto140°F) OperatingHumidity5%to95%non-condensing Non-operatingTemperature-40°Cto85°C(-40°Fto185°F) Non-operatingHumidity5%to95%,non-condensing WatchGuardTechnologies,Inc.8 HardwareDescription BottomPanelConnections 2.4/5GHz AntennaconnectorsforthedualbandWi-Firadios. 2.4/5GHzScan Antennaconnectorforthedualbandsecurityscanningradio. LAN1(POE+) TheLAN1portisa5GbEportthatconnectstheaccesspointtoawiredLANconnectionthrougha switchorhub.ThisportalsoprovidesPoE+(802.3at)powerfortheaccesspoint. LAN2 TheLAN2portisa1GbELANportthatyoucanuseasawiredextensionforanSSIDorforlink aggregation. ResetButton TheresetbuttonislocatedabovetheLAN2port.Youmustremovetheweatherproofconnectorto accesstheLAN 2portandtheresetbutton. Toresettheaccesspointtofactory-defaultsettings: nRemovetheweatherproofconnectorfromtheLAN2port. nUseapapercliporothersmallobjecttopresstheresetbuttonabovetheLAN2port. nPressandholdtheresetbuttonforupto10seconds.Whenyoureleasetheresetbutton,allLEDs willgoofftoindicatethattheaccesspointhasrebooted. WatchGuardAP430CRHardwareGuide 9WatchGuardTechnologies,Inc. WatchGuardAP430CRHardwareGuide TopPanelConnections 5GHz/BLE AntennaconnectorfortheBluetooth(BLE)radio. 2.4/5GHzScan Antennaconnectorforthedualbandsecurityscanningradio. 5GHz Antennaconnec…

Text truncated - open the document above for the full version.

WatchGuard Technologies, Inc. 505 Fifth Avenue South, Suite 500 Seattle WA United States 98104 Date: May 4, 2021 We, WatchGuard Technologies, Inc. declare that the device does not support channel 12 ~ 13 in 2.4GHz band and any non-US channels in all the operational mode(s) for the following product. FCC ID: Q6G-AP430CR If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! -------------------------------------------------------- Jay Lindenauer / Vice President Product Delivery Tel: +1 206.876.8103 E-mail: [email protected]

WatchGuard Technologies, Inc. 505 Fifth Avenue South, Suite 500 Seattle WA United States 98104 P R O F E S S I O N A L I N S T A L LA T I O N A T T E S T A T I O N Date: 2021-05-05 FCC ID: Q6G-AP430CR We, WatchGuard Technologies, Inc. hereby declare that requirements of KDB 353028 D01 Antennas Part 15 Transmitters v01 have been met and shown on the following questions. Further we declare that the info listed below are correct and represent the product in consideration under this filing. 1. Professional installation must be justified. Description: These access points are designed for commercial settings. The management system and deployment of the access points requires specific training. Those selling and deploying WatchGuard access points must be trained WatchGuard partners. 2. Professional installation does not permit use of any antenna with the transmitter; the permitted types of antenna specified as below. Description: External antennas are used with this antenna. Only antennas provided with the product or WatchGuard SKU XXXX are to be used with this product. 3. The applicant should address the following items when justifying professional installation. (1) To qualify for professional installation, please explain why the hardware is not readily available to average consumer. Description: WatchGuard does not sell through retail outlets; nor are our systems designed to be installed or deployed by end-users. WatchGuard sells through a two-tier distribution system which requires our partners who sell to Small and Medium-sized Businesses to be authorized WatchGuard resellers and trained in the use and installation of our products. (2) Marketing — Applicant must ensure device cannot be sold via retail to the general public or by mail order. Description: WatchGuard does not sell through retail outlets; nor are our systems designed to be installed or deployed by end-users. WatchGuard sells through a two-tier distribution system which requires our partners who sell to Small and Medium-sized Businesses to be authorized WatchGuard resellers and trained in the use and installation of our products. WatchGuard Technologies, Inc. 505 Fifth Avenue South, Suite 500 Seattle WA United States 98104 (3) Applicant must show that device intended use is not for consumers and general public. Description: The product is designed to be managed and deployed by trained personnel. The administration and performance of these systems are designed for more complex business environments. The target environments serve Small and Medium-sized businesses which require more greater security and protections, network segmentation, auditing/reporting, and comprehensive wireless coverage. (4) Explain what is unique, sophisticated, complex, or specialized about the equipment that REQUIRES it to be installed by a professional installer? Description: The installation of WatchGuard commercial access points requires the installation and setup by trained personnel to ensure placement of the access points adequately cover the workspace or public access space in terms of radiation pattern and bandwidth; the setup of guest networks (Captive Portal) for access in public spaces (e.g. retailer, restaurant, lobby), logging setup for auditing purposes, and alarms to alert personnel when there is an event affecting availability or security. The management system is specifically designed to scale to manage 100s of devices which bring inherit complexity even when only a few devices are being installed. 4. Other professional installation requirements (1) Installation must be controlled. Description: WatchGuard sells through a two-tier distribution system which requires our partners who sell to Small and Medium-sized Businesses to be authorized WatchGuard resellers and trained in the use and installation of our products. (2) Installed by licensed professionals. Description: WatchGuard resellers are trained in the use and installation of our products. Professionals do not require specific licensing. (3) Installation requires special training. Description: WatchGuard provides training to resellers on the installation and administration of WatchGuard products. If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! -------------------------------------------------------- Jay Lindenauer / Vice President Product Delivery Tel: +1 206.876.8103 E-mail: [email protected]

WatchGuard Technologies, Inc. 505 Fifth Avenue South, Suite 500 Seattle WA United States 98104 Date: 2021-05-04 FCC ID: Q6G-AP430CR To the attention of Federal Communications Commission Authorization and Evaluation Division Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Operational Description Software Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, -------------------------------------------------------- Jay Lindenauer / Vice President Product Delivery Tel: +1 206.876.8103 E-mail: [email protected]

WatchGuard Technologies, Inc. 505 Fifth Avenue South, Suite 500 Seattle WA United States 98104 Date: 2021-05-04 FCC ID: Q6G-AP430CR A U T H O R I Z A T I O N L E T T E R To Whom It May Concern: WatchGuard Technologies, Inc. hereby authorizes Andrea Hsia / Supervisor of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (“BV CPS Taoyuan”), to act on its behalf in all matters relating to the Federal Communication Commission (“FCC”) application for equipment authorization in connection with the FCC ID listed above, including signing of all documents relating to these matters. Any and all acts carried out by Andrea Hsia/Supervisor of BV CPS Taoyuan on WatchGuard Technologies, Inc.’s behalf, within the scope of the powers granted herein, shall have the same effect as acts of its own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, -------------------------------------------------------- Jay Lindenauer / Vice President Product Delivery Tel: +1 206.876.8103 E-mail: [email protected]

Reference No.: BDYS-WTW-P21030161-1 Page 1/4 CONSTRUCTION PHOTOS OF EUT Reference No.: BDYS-WTW-P21030161-1 Page 2/4 Reference No.: BDYS-WTW-P21030161-1 Page 3/4 Reference No.: BDYS-WTW-P21030161-1 Page 4/4

Label sample & Label location

Reference No.: BDYS-WTW-P21030161-2 Page 1/10 CONSTRUCTION PHOTOS OF EUT Reference No.: BDYS-WTW-P21030161-2 Page 2/10 Reference No.: BDYS-WTW-P21030161-2 Page 3/10 Reference No.: BDYS-WTW-P21030161-2 Page 4/10 Reference No.: BDYS-WTW-P21030161-2 Page 5/10 Reference No.: BDYS-WTW-P21030161-2 Page 6/10 Reference No.: BDYS-WTW-P21030161-2 Page 7/10 Reference No.: BDYS-WTW-P21030161-2 Page 8/10 Reference No.: BDYS-WTW-P21030161-2 Page 9/10 Reference No.: BDYS-WTW-P21030161-2 Page 10/10

Report No.: SABDYS-WTW-P21030161 Page No. 1 / 7 Report Format Version: 6.1.1 RF Exposure Report Report No.: SABDYS-WTW-P21030161 FCC ID: Q6G-AP430CR Test Model: AP430CR Received Date: Mar. 11, 2021 Test Date: Mar. 18 ~ Apr. 19, 2021 Issued Date: May 03, 2021 Applicant: WatchGuard Technologies, Inc. Address: 505 Fifth Avenue South, Suite 500 Seattle WA United States 98104 Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, Taiwan FCC Registration / Designation Number: 788550 / TW0003 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: SABDYS-WTW-P21030161 Page No. 2 / 7 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 3 Calculation Result of Maximum Conducted Power ........................................................................... 6 Report No.: SABDYS-WTW-P21030161 Page No. 3 / 7 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued SABDYS-WTW-P21030161 Original release May 03, 2021 Report No.: SABDYS-WTW-P21030161 Page No. 4 / 7 Report Format Version: 6.1.1 1 Certificate of Conformity Product: Wireless Access Point Brand: WatchGuard Test Model: AP430CR Sample Status: Engineering sample Applicant: WatchGuard Technologies, Inc. Test Date: Mar. 18 ~ Apr. 19, 2021 Standards: FCC Part 2 (Section 2.1091) References Test Guidance: KDB 447498 D01 General RF Exposure Guidance v06 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s RF characteristics under the conditions specified in this report. Prepared by : , Date:May 03, 2021 Pettie Chen / Senior Specialist Approved by : , Date:May 03, 2021 Bruce Chen / Senior Project Engineer Report No.: SABDYS-WTW-P21030161 Page No. 5 / 7 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1500 ... ... f/1500 30 1500-100,000 ... ... 1.0 30 f = Frequency in MHz ; *Plane-wave equivalent power density 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 40cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SABDYS-WTW-P21030161 Page No. 6 / 7 Report Format Version: 6.1.1 3 Calculation Result of Maximum Conducted Power Frequency Band (MHz) Max Average Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) WLAN 2G traffic radio (Radio 1): CDD Mode 2412-2462 26.28 8.51 40 0.150 1 5G traffic radio (Radio 2): CDD Mode 5180-5240 22.81 12.52 40 0.170 1 5745-5825 28.79 13.02 40 0.755 1 2G traffic radio (Radio 1): Beamforming Mode 2412-2462 22.71 8.51 40 0.066 1 5G traffic radio (Radio 2): Beamforming Mode 5180-5240 16.79 12.52 40 0.042 1 5745-5825 22.77 13.02 40 0.189 1 Scanning radio (Radio 3): CDD Mode 2412-2462 24.98 8.51 40 0.111 1 5180-5240 23.09 9.51 40 0.091 1 5745-5825 23.65 10.01 40 0.116 1 BT LE 2402-2480 6.83 5.5 40 0.001 1 Note: 1. Directional gain: 2G traffic radio: Dire…

Text truncated - open the document above for the full version.

Report No.: RFBDYS-WTW-P21030161-2 Page No. 1 / 35 Report Format Version: 6.1.2 FCC Test Report Report No.: RFBDYS-WTW-P21030161-2 FCC ID: Q6G-AP430CR Test Model: AP430CR Received Date: Mar. 11, 2021 Test Date: Mar. 17 ~ Apr. 19, 2021 Issued Date: May 03, 2021 Applicant: WatchGuard Technologies, Inc. Address: 505 Fifth Avenue South, Suite 500 Seattle WA United States 98104 Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, Taiwan FCC Registration / Designation Number: 788550 / TW0003 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to…

Text truncated - open the document above for the full version.
