Q6G-FS2E5WWireless Access Point

Guide de démarrage rapide Kurzanleitung Guida introduttiva Guía Rápida Quick Start Guide WatchGuard ® XTM 33 WatchGuard ® XTM 33 Wireless WatchGuard® Technologies, Inc. Eth 1Eth 0 English Internet Router / DSL Modem Congratulations! You have finished basic setup of your WatchGuard XTM device. You can use the Web UI to continue basic configuration and management tasks. Before you begin, we strongly recommend that you use the instructions below to upgrade your XTM device to the latest Fireware XTM OS. Download latest software • Go to www.watchguard.com/archive/softwarecenter.asp • Find and download the latest version of Fireware XTM OS. Upgrade your XTM 3 Series device with latest Fireware XTM OS • On the computer you use to connect to the XTM device, find and run the Fireware XTM OS installation package you downloaded from the WatchGuard web site. • C onnect to your XTM device with the Fireware XTM Web UI using the user name admin and the passphrase you set in the wizard. • S elect System > Upgrade OS. NOTE: The default location for the upgrade file is C:\Program Files\Common Files\WatchGuard\resources\ FirewareXTM\[version number\model]. The file name is xtm3_aa.sysa-dl. About WatchGuard System Manager (WSM) To extend the feature set and management capabilities of your XTM 3 Series device, you can download and install WatchGuard System Manager client and server software tools. WSM is available to you at no additional cost. It gives you access to additional features for your device: • F lexible, on- or off-line configuration editing with Policy Manager • A full suite of monitoring tools for your XTM device • WatchGuard Server Center - Log and Report Server - Use together with WSM for full-featured logging and reporting options - Quarantine Server - Use with spamBlocker to collect and isolate spam email - WebBlocker Server - Configure a local WebBlocker Server to control web site access - Management Server - Manage multiple Firebox and XTM devices from one UI To download the latest WatchGuard System Manager (WSM) software, go to www.watchguard.com/archive/softwarecenter.asp. For more information about how to configure your WatchGuard XTM 3 Series device, go to www.watchguard.com/help/documentation and open the current help system. Getting Started 1 2 • Make sure your computer is configured to use DHCP. When you connect it to the XTM 3 Series device, make sure your computer gets an IP address on the 10.0.1.0/24 network. Run the Web Setup Wizard • Open a web browser and type https://10.0.1.1:8080 to start the Web Setup Wizard. NOTE: Because the XTM device uses a self-signed certificate, you may see a certificate warning in your browser. It is safe to ignore the warning (Internet Explorer) or to add a certificate exception (Mozilla Firefox). • Log in with the user name admin and the passphrase readwrite. • Follow the instructions on the screen and complete the Wizard. NOTE: Your WatchGuard XTM device now has a basic configuration that allows outbound TCP, UDP, and ping traffic, and blocks all unrequested traffic from the external network. • Log in to the Fireware XTM Web UI with the user name admin and the configuration passphrase you set in the Wizard. Next Steps Connect your WatchGuard XTM 3 Series Device and Power it On Eth 1Eth 0 / 调制解调器 Eth 1Eth 0 Français Guide de démarrage rapideÉtapes suivantes Internet Routeur/modem DSL Bravo ! L’installation de base de votre appareil WatchGuard XTM est terminée. Vous pouvez maintenant utiliser l’interface utilisateur Web pour poursuivre les tâches de configuration et de gestion. Avant de démarrer, nous vous recommandons fortement de suivre les instructions indiquées ci-dessous pour mettre à jour votre appareil XTM avec le système d’exploitation Fireware XTM le plus récent. Téléchargez les derniers logiciels • Allez sur https://www.watchguard.com/archive/softwarecenter.asp. • Téléchargez la dernière version du système d’exploitation Fireware XTM et du logiciel WSM. Mettez à jour votre appareil XTM 3 Series avec le système d’exploitation Fireware XTM le plus récent. • Lancez, sur l’ordinateur sur lequel est branché votre appareil XTM, le package d’installation du système d’exploitation Fireware XTM que vous avez téléchargé depuis le site Internet de WatchGuard. • C onnectez-vous à votre appareil XTM avec l’interface utilisateur Web du Fireware XTM avec le n om d’utilisateur « admin » et le mot de passe de c onfiguration entré lors de l’installation. • S électionnez System > Upgrade OS. REMARQUE : l’emplacement par défaut du fichier de mise à jour est C:\Program Files\Common Files\ WatchGuard\resources\FirewareXTM\[numéro de la version\modèle]. Le nom du fichier est xtm3_aa.sysa-dl. À propos de WatchGuard System Manager (WSM) Pour accroître les fonctions et les capacités de gestion de votre appareil XTM 3 Series, vous pouvez télécharger et installer le client WatchGuard System Manager et les outils logiciels des serveurs. WSM est disponible sans supplément de prix. Il vous donne accès à des fonctions additionnelles pour votre appareil : • M odification flexible de la configuration en ligne ou hors ligne avec Policy Manager • Série complète d’outils de contrôle pour votre appareil XTM • Centre de serveurs WatchGuard - Serveur pour la production de journaux : à utiliser avec WSM pour avoir toutes les options de production de journaux et de rapports - Serveur de mise en quarantaine : à utiliser avec spamBlocker pour recueillir et isoler le spam - Serveur WebBlocker : configurez un serveur WebBlocker local afin de contrôler l’accès aux sites Internet - Serveur de gestion : gère de multiples appareils Firebox et XTM à partir d’une seule interface utilisateur Pour télécharger le tout dernier logiciel WatchGuard System Manager (WSM), rendez- vous sur www.watchguard.com/archive/softwarecenter.asp. Pour de plus amples informations sur la façon de configurer votre appareil WatchGuard XTM 3 Series, rendez-vous sur www.watchguard.com/help/documentation et ouvrez l…

Text truncated - open the document above for the full version.

WatchGuard XTM 2 Series Hardware Guide XTM 25, 25-W, 26, 26-W iiWatchGuard XTM 2 Series ADDRESS 505 Fifth Avenue South Suite 500 Seattle, WA 98104 SUPPORT www.watchguard.com/support U.S. and Canada +877.232.3531 All Other Countries +1.206.521.3575 SALES U.S. and Canada +1.800.734.9905 All Other Countries +1.206.613.0895 ABOUT WATCHGUARD WatchGuard offers affordable, all-in-one network and content security solutions that provide defense-in-depth and help meet regulatory compliance requirements. The WatchGuard XTM line combines firewall, VPN, GAV, IPS, spam blocking and URL filtering to protect your network from spam, viruses, malware, and intrusions. The new XCS line offers email and web content security combined with data loss prevention. WatchGuard extensible solutions scale to offer right-sized security ranging from small businesses to enterprises with 10,000+ employees. WatchGuard builds simple, reliable, and robust security appliances featuring fast implementation and comprehensive management and reporting tools. Enterprises throughout the world rely on our signature red boxes to maximize security without sacrificing efficiency and productivity. For more information, please call 206.613.6600 or visit www.watchguard.com . Copyright and Patent Information Copyright© 1998–2011 WatchGuard Technologies, Inc. All rights reserved. WatchGuard, the WatchGuard logo, Firebox, LiveSecurity, and any other mark listed as a trademark in the “Terms of Use” portion of the WatchGuard Web site that is used herein are either registered trademarks or trademarks of WatchGuard Technologies, Inc. and/or it’s subsidiaries in the United States and/or other countries. All other trademarks are the property of their respective owners. The Power Architecture and Power.org wordmarks and the Power and Power.org logos and related marks are trademarks and service marks licensed by Power.org. Printed in the United States of America. Part Number: 275-4131-001 Rev C Revised: October 19, 2011 U.S. Patent Nos. 6,493,752; 6,597,661; D473,879. Other Patents Pending. Notice to Users Information in this guide is subject to change without notice. Updates to this guide are posted at: http://www.watchguard.com/help/documentation/hardware.asp Companies, names, and data used in examples herein are fictitious unless otherwise noted. No part of this guide may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of WatchGuard Technologies, Inc. Complete copyright, trademark, patent, and licensing information can be found in the Copyright and Licensing Guide. You can find this document online at: http://www.watchguard.com/help/documentation/ Hardware Guide1 Hardware Specifications WatchGuard® XTM security appliances deliver unparalleled unified threat management, superior performance, ease of use, and value for your small organization or branch office. Our security subscriptions give you fully integrated protection from spyware, spam, viruses, worms, trojans, web-based exploits, and blended threats. From firewall and VPN protection to secure remote access, WatchGuard XTM devices support a broad range of network environments. This guide introduces the XTM 2 Series, a series of RoHS-compliant (lead-free) hardware products offered by WatchGuard. The WatchGuard® XTM 2 Series is a network security device for small organizations and branch offices. The XTM 2 Series product line includes: WatchGuard XTM 2 Series WatchGuard XTM 2 Series Wireless You can upgrade some XTM 2 Series or XTM 2 Series wireless devices to a higher model in the XTM 2 Series line for more capacity and performance with a simple software license key. Note This Hardware Guide applies to XTM 2 Series devices with model numbers XTM 25, 26, 25-W, and 26-W. If your device model number is XTM 21, 22, 23, 21-W, 22-W, or 23-W, your hardware is described in the XTM 2 Series Hardware Guide that applies to those models. Fireware XTM OS The XTM 2 Series devices support WatchGuard’s next generation UTM OS—Fireware® XTM. Each XTM 2 Series device includes Fireware XTM and delivers exceptional protection against today's sophisticated threats to make sure that your business stays connected. For more information on the features of Fireware XTM OS, see the current Fireware XTM WatchGuard System Manager Help or Fireware XTM Web UI Help. 2WatchGuard XTM 2 Series Hardware Specifications Package Contents CD-ROM with this Hardware Guide XTM 2 Series appliance Quick Start Guide Hardware warranty card AC adapter (12V/2A) with international plug kit Power cable clip, to attach to the cable and connect to the device. This decreases the tension on the power cable. 1 straight-through Ethernet cable 1 wall mount plate (wireless models only) Three antennas (wireless models only) Hardware Description Hardware Specifications Interface Specifications XTM 25, 26XTM 25-W, 26-W Wireless models ProcessorPower Architecture® Single CorePower Architecture® Single Core Memory: Flash256 MB256 MB Memory: RAM512 MB512 MB Power supply12V/2A12V/2A DimensionsD = 156mm (6.13”) W = 163mm (7.4”) H = 32mm (1.25”) D =203mm (8.0”) W = 273mm (10.75”) H = 32mm (1.25”) Antenna height = 127mm (5.0”) Weight1.3 U.S. pounds1.55 U.S. pounds (with antennas) Network interfaces • 5x GbE Copper RJ45, 1000Base-T, 100Base-TX, or 10 Base-T (10/ 100/1000Mbps) I/O interfaces •1 USB 2.0 • 1 RJ45 Serial Port Hardware Guide3 Hardware Specifications Front View The front panel of the device. Fail Over The Fail Over indicator is lit when there is a WAN failover from the primary external interface to the backup interface. After the external interface connection fails back to the primary external interface, the indicator is not lit. WAP The WAP indicator is lit when the XTM 2 Series wireless device is activated as a wireless access point or as a wireless client. Network interface status indicators The five network interfaces are labeled 4, 3, 2, 1, 0. T…

Text truncated - open the document above for the full version.

November 4, 2011 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Re: Agent Authorization Letter for FCC ID: Q6G-FS1E5W and Q6G-FS2E5W To Whom It May Concern: Please be advise that WatchGuard Technologies authorizes Suresh Kondapalli of TUV Rheinland of North America, 1279 Quarry Lane, Suite A, Pleasanton, CA 94566, USA to act on our behalf on all matters relating to applications for equipment authorization before the Federal Communications Commission, including signing of documents related to these matters. Sincerely, Denny Lim Sr. Hardware Engineer WatchGuard Technologies 505 5 th Ave S. Suite 500 Seattle, WA 98104 USA

November 4, 2011 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Re: FCC ID: Q6G-FS1E5W and Q6G-FS2E5W To Whom It May Concern: WatchGuard Technologies, certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This authorization is valid until further written notice from WatchGuard Technologies. Sincerely, Denny Lim Sr. Hardware Engineer WatchGuard Technologies 505 5 th Ave S. Suite 500 Seattle, WA 98104 USA

November 4, 2011 Subject: Confidentiality Request for FCC ID: Q6G-FS1E5W and Q6G-FS2E5W Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term Permanent Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Schematics Short Term Permanent User’s Manual WatchGuard Technologies has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 90 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, Denny Lim By: __________________________ ________________________ (Signature/Title) (Print name) WatchGuard Technologies 505 5 th Ave S. Suite 500 Seattle, WA 98104 USA

EXTERNAL PHOTOs EXHIBIT FCC ID:FS2E5W IC:4657A‐FS2E5W

Label on bottom side of the unit

INTERNAL PHOTOs EXHIBIT FCC ID:FS2E5W IC:4657A‐FS2E5W Radio module

Report Number: 31152150.002 Appendix A Page 1 of 5 EUT:Newcastle, Newport Model: FS1E5, FS1E5W, FS2E5, FS2E5W EMC / Rev 11/30/2011 FCCID: Q6G-FS2E5W; IC: 4657A-FS2E5W RF Exposure Exhibit EUT Name: NEWCASTLE, NEWPORT Model No.: FS1E5, FS1E5W, FS2E5, FS2E5W CFR 47 Part 15.247:2010 and RSS 210:2010 Prepared for: Denny Lim WatchGuard Technologies, Inc 505 Fifth Ave S, Suite 500 Seattle WA 98104 Tel: (206)-613-6600 Prepared by: TUV Rheinland of North America, Inc. 1279 Quarry Lane Pleasanton, CA 94566 Tel: (925) 249-9123 Fax: (925) 249-9124 http://www.tuv.com/ Report/Issue Date: November 16, 2011 Report Number: 31152150.002 Appendix A TUV Rheinland RF Exposure Limit 1279 Quarry Lane, Ste. A, Pleasanton, CA 95466 Tel: (925) 249-9123, Fax: (925) 249-9124 Report Number: 31152150.002 Appendix A Page 2 of 5 EUT:Newcastle, Newport Model: FS1E5, FS1E5W, FS2E5, FS2E5W EMC / Rev 11/30/2011 FCCID: Q6G-FS2E5W; IC: 4657A-FS2E5W Contents RF Exposure Exhibit ................................................................................................................. 1 1 Test Methodology .................................................................................................................... 3 1.1 RF Exposure Limit...................................................................................................................... 3 1.2 EUT Operating Condition .......................................................................................................... 3 1.2.1 Classification ........................................................................................................................................... 4 1.3 Test Results ............................................................................................................................... 4 1.3.2 Sample Calculation .................................................................................................................................. 5 TUV Rheinland RF Exposure Limit 1279 Quarry Lane, Ste. A, Pleasanton, CA 95466 Tel: (925) 249-9123, Fax: (925) 249-9124 Report Number: 31152150.002 Appendix A Page 3 of 5 EUT:Newcastle, Newport Model: FS1E5, FS1E5W, FS2E5, FS2E5W EMC / Rev 11/30/2011 FCCID: Q6G-FS2E5W; IC: 4657A-FS2E5W 1 Test Methodology In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Semi-Anechoic Chamber, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over- prediction for near field power density. We will take that as the worst case to specify the safety range. 1.1 RF Exposure Limit According to FCC 1.1310 table 1: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300 - 1500 ... ... F/300 6 1500 - 100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 300 - 1500 ... ... F/1500 6 1500 - 100,000 ... ... 1.0 30 F = Frequency in MHz 1.2 EUT Operating Condition The software provided by Manufacturer enabled the EUT to transmit data at lowest, middle and highest channel individually. Software provided enables to transmit on multi channels simultaneously. TUV Rheinland Test Results 1279 Quarry Lane, Ste. A, Pleasanton, CA 95466 Tel: (925) 249-9123, Fax: (925) 249-9124 Report Number: 31152150.002 Appendix A Page 4 of 5 EUT:Newcastle, Newport Model: FS1E5, FS1E5W, FS2E5, FS2E5W EMC / Rev 11/30/2011 FCCID: Q6G-FS2E5W; IC: 4657A-FS2E5W 1.2.1 Classification The antenna of the product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in user’s manual. So, this device is classified as a Mobile Device. 1.3 Test Results 1.3.1.1 Antenna Gain The transmitting antenna was integrated. The antenna gain was +2.0 dBi or 1.59 (numeric). 1.3.1.2 Output Power into Antenna & RF Exposure value at distance 20cm: Calculations for this report are based on highest power measurement. Limit for MPE (from FCC part 1.1310 table1) is 1.0 mW/cm 2 Band Mode Output Power Antenna gain (Max) EIRP Channels Available Channels Used Total EIRP dBm dBm W W dBm 2400 - 2483.5 OFDM 19.4 2.0 21.4 0.137 11 3 0.411 26.14 2401 - 2483.5 CCK 22.4 2.0 24.4 0.275 5150 - 5250 OFDM 15.4 2.0 17.4 0.055 4 3 0.164 22.15 5725 - 5850 OFDM 19.4 2.0 21.4 0.136 5 3 0.409 26.12 Totals: 9 0.985 29.93 The highest measured power is +29.93 dBm or 985 mW; average power. Using the Friss transmission formula, the EIRP is Pout*G, and R is 20cm. Pd= EIRP/(1600π) Pd = (985) / (1600π) = 0.196mW/cm2, which is 0.804 mW/cm2 below to the limit. As originally tested, the EUT was found to be compliant to the requirements of the test standard(s). TUV Rheinland Test Results 1279 Quarry Lane, Ste. A, Pleasanton, CA 95466 Tel: (925) 249-9123, Fax: (925) 249-9124 Report Number: 31152150.002 Appendix A Page 5 of 5 EUT:Newcastle, Newport Model: FS1E5, FS1E5W, FS2E5, FS2E5W EMC / Rev 11/30/2011 FCCID: Q6G-FS2E5W; IC: 4657A-FS2E5W 1.3.2 Sample Calculation The Friss transmission formula: Pd = (Pout*G) / (4*π*R 2 ) Where; Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale π ≈ 3.1416 R = distance between observation point and center of the radiator in cm Ref. :…

Text truncated - open the document above for the full version.

Report Number: 31152150.003 Page 1 of 100 EUT: Newcastle Newport Model: FS1E5, FS1E5W, FS2E5, FS2E5W EMC / Rev 12/1/2011 FCCID: Q6G-FS2E5W; IC: 4657A-FS2E5W Emissions Test Report EUT Name: Newcastle, Newport Model No.: FS1E5, FS1E5W, FS2E5, FS2E5W CFR 47 Part 15.407:2009 and RSS 210: 2010 Prepared for: Denny Lim WatchGuard Technologies, Inc 505 Fifth Ave S, Suite 500 Seattle, WA 98104 Tel: 206-613-6600 Prepared by: TUV Rheinland of North America, Inc. 1279 Quarry Lane Pleasanton, CA 94566 Tel: (925) 249-9123 Fax: (925) 249-9124 http://www.tuv.com/ Report/Issue Date: November 16, 2011 Report Number: 31152150.003 Statement of Compliance Report Number: 31152150.003 Page 2 of 100 EUT: Newcastle Newport Model: FS1E5, FS1E5W, FS2E5, FS2E5W EMC / Rev 12/1/2011 FCCID: Q6G-FS2E5W; IC: 4657A-FS2E5W Manufacturer: WatchGuard Technologies. Inc Requester / Applicant: 505 Fifth Ave S, Suite 500 Name of Equipment: Newcastle, Newport Model No. FS1E5, FS1E5W, FS2E5, FS2E5W Type of Equipment: Intentional Radiator Application of Regulations: CFR 47 Part 15.407:2009 and RSS 210: 2010 Test Dates: 30 August 2011 to 29 September 2011 Guidance Documents: Emissions: ANSI C63.10-2009 Test Methods: Emissions: ANSI C63.10-2009 The electromagnetic compatibility test and documented data described in this report has been performed and recorded by TUV Rheinland, in accordance with the standards and procedures listed herein. As the responsible authorized agent of the EMC laboratory, I hereby declare that the equipment described above has been shown to be compliant with the EMC requirements of the stated regulations and standards based on these results. If any special accessories and/or modifications were required for compliance, they are listed in the Executive Summary of this report. This report must not be used to claim product endorsement by NVLAP or any agency of the U.S. Government. This report contains data that are not covered by NVLAP accreditation. This report shall not be reproduced except in full, without the written authorization of TUV Rheinland of North America. Suresh Kondapalli Conan Boyle Test Engineer Date November 16, 2011 NVLAP Signatory Date November 16, 2011 INDUSTRY CANADA 500011-0 US5254 2932M-1 Table of Contents Report Number: 31152150.003 Page 3 of 100 EUT: Newcastle Newport Model: FS1E5, FS1E5W, FS2E5, FS2E5W EMC / Rev 12/1/2011 FCCID: Q6G-FS2E5W; IC: 4657A-FS2E5W 1 Executive Summary _______________________________________________________ 6 1.1 Scope______________________________________________________________________ 6 1.2 Purpose____________________________________________________________________ 6 1.3 Summary of Test Results _____________________________________________________ 7 1.4 Special Accessories __________________________________________________________ 7 1.5 Equipment Modifications _____________________________________________________ 7 2 Laboratory Information ____________________________________________________ 8 2.1 Accreditations & Endorsements _______________________________________________ 8 2.1.1 US Federal Communications Commission _______________________________________________ 8 2.1.2 NIST / NVLAP ____________________________________________________________________ 8 2.1.3 Canada – Industry Canada ___________________________________________________________ 8 2.1.4 Japan – VCCI _____________________________________________________________________ 8 2.1.5 Acceptance by Mutual Recognition Arrangement _________________________________________ 8 2.2 Test Facilities _______________________________________________________________ 9 2.2.1 Emission Test Facility ______________________________________________________________ 9 2.2.2 Immunity Test Facility ______________________________________________________________ 9 2.3 Measurement Uncertainty ____________________________________________________ 9 2.3.1 Sample Calculation – radiated & conducted emissions ____________________________________ 10 2.3.2 Measurement Uncertainty ___________________________________________________________ 10 2.4 Calibration Traceability _____________________________________________________ 11 3 Product Information ______________________________________________________ 12 3.1 Product Description ________________________________________________________ 12 3.2 Equipment Configuration ___________________________________________________ 12 3.3 Operating Mode ___________________________________________________________ 12 3.4 Unique Antenna Connector __________________________________________________ 13 3.4.1 Results _________________________________________________________________________ 13 4 Emissions ______________________________________________________________ 14 4.1 Output Power Requirements _________________________________________________ 14 4.1.1 Test Method _____________________________________________________________________ 14 4.1.2 Results _________________________________________________________________________ 15 4.2 Occupied Bandwidth _______________________________________________________ 30 4.2.1 Test Method _____________________________________________________________________ 30 4.2.2 Results _________________________________________________________________________ 31 4.3 Peak Excursion ____________________________________________________________ 38 4.3.1 Test Method _____________________________________________________________________ 38 4.3.2 Results _________________________________________________________________________ 39 4.4 Peak Power Spectral Density _________________________________________________ 44 4.4.1 Test Method _____________________________________________________________________ 44 4.4.2 Results _________________________________________________________________________ 45 Table of Contents Report Number: 31152150.003 Page 4 of 100 EUT: Newcastle Newport Model: FS1E5, FS1E5W, FS2E5, FS2E5W EMC / Rev 12/1/2011 FCCID: Q6G-FS2E5W; IC: 4657A-FS2E5W 4.5 Transmitter Spurious Emi…

Text truncated - open the document above for the full version.

Report Number: 31152150.002 Page 1 of 221 EUT: Newcastle, Newport Model: FS1E5, FS1E5W, FS2E5, FS2E5W EMC / Rev 12/12//2011 FCCID: Q6G-FS2E5W; IC: 4657A-FS2E5W Emissions Test Report EUT Name: NEWCASTLE, NEWPORT Model No.: FS1E5, FS1E5W, FS2E5, FS2E5W CFR 47 Part 15.247:2009 and RSS 210:2010 Prepared for: Denny Lim WatchGuard Technologies, Inc.. 505 Fifth Ave S, Suite 500 Seattle, WA 98104 Tel: 206-613-6600 Prepared by: TUV Rheinland of North America, Inc. 1279 Quarry Lane Pleasanton, CA 94566 Tel: (925) 249-9123 Fax: (925) 249-9124 http://www.tuv.com/ Report/Issue Date: November 16, 2011 Report Number: 31152150.002 Statement of Compliance Report Number: 31152150.002 Page 2 of 221 EUT: Newcastle, Newport Model: FS1E5, FS1E5W, FS2E5, FS2E5W EMC / Rev 12/12//2011 FCCID: Q6G-FS2E5W; IC: 4657A-FS2E5W Manufacturer: WatchGuard Technologies 505 Fifth Ave S, Suite 500 Seattle, WA 98104 Requester / Applicant: Denny Lim Name of Equipment: NEWCASTLE, NEWPORT Model No. FS1E5, FS1E5W, FS2E5, FS2E5W Type of Equipment: Intentional Radiator Application of Regulations: CFR 47 Part 15.247:2009 and RSS 210:2010 Test Dates: August 30 - September 26, 2011 Guidance Documents: Emissions: ANSI C63.10-2009 Test Methods: Emissions: ANSI C63.10-2009 The electromagnetic compatibility test and documented data described in this report has been performed and recorded by TUV Rheinland, in accordance with the standards and procedures listed herein. As the responsible authorized agent of the EMC laboratory, I hereby declare that the equipment described above has been shown to be compliant with the EMC requirements of the stated regulations and standards based on these results. If any special accessories and/or modifications were required for compliance, they are listed in the Executive Summary of this report. This report must not be used to claim product endorsement by NVLAP or any agency of the U.S. Government. This report contains data that are not covered by NVLAP accreditation. This report shall not be reproduced except in full, without the written authorization of TUV Rheinland of North America. Suresh Kondapalli November 16, 2011 Conan Boyle November 16, 2011 Test Engineer Date NVLAP Signatory Date Industry Canada 500011-0 US5254 2932M-1 Index of Tables Report Number: 31152150.002 Page 3 of 221 EUT: Newcastle, Newport Model: FS1E5, FS1E5W, FS2E5, FS2E5W EMC / Rev 12/12/2011 FCCID: Q6G-FS2E5W; IC: 4657A-FS2E5W 1 Executive Summary _______________________________________________________ 6 1.1 Scope ______________________________________________________________________ 6 1.2 Purpose ____________________________…

Text truncated - open the document above for the full version.
