Q6U-YTL051-XYZBlackDiamond3

Power and audio cable Adapter Meet your BD3BD3 FunctionsBD3 Accessories Remote controller 1 Bass Resonant Tube 2 Remote controller storage slot 3 Power and Audio Line in 4 Diamond shape lighting 5 Speaker Power on/off Effect Mode (Press to switch effects) Music Sync Mode (Press to switch effects) Mute Volume control (Maximum with beep) Lighting brightness control Lighting effect on/off Bluetooth control Flow color/ Mono color Select Flow speed or 7 fixed colors Bluetooth/line-in switch 1 4 5 2 3 Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Radiation Exposure Statement: The product comply with the FCC portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available.

Report No.: 120913E02 1 of 4 CONSTRUCTION PHOTOS OF EUT Report No.: 120913E02 2 of 4 Report No.: 120913E02 3 of 4 Report No.: 120913E02 4 of 4

FCC ID： ：： ：Q6U-YTL051-XYZ LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

Report No.: 120913E02 2 of 10 Report No.: 120913E02 3 of 10 Report No.: 120913E02 4 of 10 Report No.: 120913E02 5 of 10

Report No.: SA120913E02 1 of 5 Report Format Version 5.0.0 RF EXPOSURE REPORT REPORT NO.: SA120913E02 MODEL NO.: YTL051, YTL051-XYZ (X: Null, A~Z; 2 th Y: Null 0~9; Z: Null, 0~9) FCC ID: Q6U-YTL051-XYZ RECEIVED: Sep. 13, 2012 TESTED: Sep. 24, 2012 ISSUED: Oct. 24, 2012 APPLICANT: Yantouch Corporation ADDRESS: Rm. 303, 4F-1., No.5, Xin’an Rd., Hsinchu Science Park, Hsinchu City 300, Taiwan (R.O.C.) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA120913E02 2 of 5 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD .................................................................................... 3 1. CERTIFICATION .............................................................................................. 4 2. EVALUATION RESULT ................................................................................... 5 Report No.: SA120913E02 3 of 5 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA120913E02 Original release Oct. 24, 2012 Report No.: SA120913E02 4 of 5 Report Format Version 5.0.0 1. CERTIFICATION PRODUCT: BlackDiamond3 BRAND NAME: Yantouch MODEL NO.: YTL051, YTL051-XYZ (X: Null, A~Z; 2 th Y: Null, 0~9; Z: Null, 0~9) TEST SAMPLE: R&D SAMPLE APPLICANT: Yantouch Corporation TESTED DATE: Sep. 24, 2012 STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: YTL051) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Sep. 21, 2012 ( Lori Chung, Specialist ) APPROVED BY : , DATE: Sep. 21, 2012 ( May Chen, Deputy Manager ) Report No.: SA120913E02 5 of 5 Report Format Version 5.0.0 2. EVALUATION RESULT No SAR Evaluation Required if power is below the following threshold: Tunable Range F(GHz) Low F(GHz) High 60/f SAR Limitation (mW) 2.402 2.480 24.19 Maximum measured transmitter power: Pout Conducted (dBm) Pout Conducted (mW) Maximum Antenna Gain (dBi) Pout EIRP (mW) -0.09 0.979 1.13 1.27 Threshold for no SAR evaluation is 24.19 mW Maximum TX Power is 0.979 mW Conducted and 1.27 mW EIRP Conclusion: No SAR evaluation required since maximum Transmitter Pout (both conducted and EIRP) is below FCC threshold --- END ---

Report No.: RF120913E02 1 of 64 Report Format Version 5.0.0 FCC TEST REPORT REPORT NO.: RF120913E02 MODEL NO.: YTL051, YTL051-XYZ (X: Null, A~Z; 2 th Y: Null 0~9; Z: Null, 0~9) FCC ID: Q6U-YTL051-XYZ RECEIVED: Sep. 13, 2012 TESTED: Sep. 17 to Oct. 19, 2012 ISSUED: Oct. 24, 2012 APPLICANT: Yantouch Corporation ADDRESS: Rm. 303, 4F-1., No.5, Xin’an Rd., Hsinchu Science Park, Hsinchu City 300, Taiwan (R.O.C.) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, Taiwan, R.O.C. TEST LOCATION (2): No.49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF120913E02 2 of 64 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ........................................................................................................ 4 1 CERTIFICATION ................................................................................................................ 5 2 SUMMARY OF TEST RESULTS ......................................................................................... 6 2.1 ME ASUREMENT UNCERTAINTY ..................................................................................... 7 3 GENERAL INFORMATION ................................................................................................. 8 3.1 GENERAL DESCRIPTION OF EUT .................................................................................... 8 3.2 DESCRIPTION OF TEST MODES .....................................................................................10 3.3 TEST MODE APPLICABLITY AND TESTED CHANNEL DETAIL: ...................................... 11 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS .....................................................13 3.5 DESCRIPTION OF SUPPORT UNITS ...............................................................................14 3.6 CONFIGURATION OF SYSTEM UNDER TEST.................................................................15 4 TEST PROCEDURES AND RESULTS ..............................................................................16 4.1 CONDUCTED EMISSION MEASUREMENT .....................................................................16 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT....................................................16 4.1.2 TEST INSTRUMENTS .......................................................................................................16 4.1.3 TEST PROCEDURES .......................................................................................................17 4.1.4 DEVIATION FROM TEST STANDARD ..............................................................................17 4.1.5 TEST SETUP ....................................................................................................................18 4.1.6 EUT OPERATING CONDITIONS .......................................................................................18 4.1.7 TEST RESULTS (MODE 1) ...............................................................................................19 4.1.8 TEST RESULTS (MODE 2) ...............................................................................................21 4.2 RADIATED EMISSION MEASUREMENT ..........................................................................23 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT ........................................................23 4.2.2 TEST INSTRUMENTS .......................................................................................................24 4.2.3 TEST PROCEDURES .......................................................................................................25 4.2.4 DEVIATION FROM TEST STANDARD ..............................................................................25 4.2.5 TEST SETUP ....................................................................................................................26 4.2.6 EUT OPERATING CONDITIONS .......................................................................................26 4.2.7 TEST RESULTS ................................................................................................................27 4.3 NUMBER OF HOPPING FREQUENCY USED ..................................................................34 4.3.1 LIMIT OF HOPPING FREQUENCY USED ..........................................…

Text truncated - open the document above for the full version.

Report No.: 120724E01 1 of 3 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (MODE 1) Report No.: 120724E01 2 of 3 CONDUCTED EMISSION TEST (MODE 2) Report No.: 120724E01 3 of 3 RADIATED EMISSION TEST
