www.tuv.com Test Report No.: 14012167 002 Date: 14.06.2006 Page 2 of 12 Test Summary Periodic Operation Device Result: Pass Radiated Emission of Carrier Frequency Result: Pass Spurious Radiated Emissions Result: Pass Bandwidth Measurement Result: Pass www.tuv.com Test Report No.: 14012167 002 Date: 14.06.2006 Page 3 of 12 Contents List of Test and Measurement Instruments.........................................................4 General Product Information ................................................................................5 Product Function and Intended Use.............................................................................................5 Ratings and System Details ..........................................................................................................5 Independent Operation Modes......................................................................................................6 Submitted Documents ...................................................................................................................6 Related Submittal(s) Grants ..........................................................................................................6 Test Set-up and Operation Mode..........................................................................7 Principle of Configuration Selection ............................................................................................7 Test Operation and Test Software ................................................................................................7 Special Accessories and Auxiliary Equipment ...........................................................................7 Countermeasures to achieve EMC Compliance..........................................................................7 Test Methodology ..................................................................................................8 Radiated Emission .........................................................................................................................8 Field Strength Calculation .............................................................................................................8 Test Results ...........................................................................................................9 Periodic Operation Device.....................Section 15.231(e).................................................9 Radiated Emission of Carrier Frequency....Section 15.231(b) ...............................................10 Spurious Radiated Emissions...................Section 15.231(b) ................................................11 Bandwidth Measurement.....................Section 15.231(c).................................................12 Appendix 1: Test Results Appendix 2: Test Setup Appendix 3: EUT External Photo Appendix 4: EUT Internal Photo Appendix 5: FCCID Label and Label Location Appendix 6: Block Diagram, Schematics and BOM Appendix 7: User Manual Appendix 8: Operational Description www.tuv.com Test Report No.: 14012167 002 Date: 14.06.2006 Page 4 of 12 List of Test and Measurement Instruments Kind of Equipment Manufacturer Type S/N Test Receiver Rohde & Schwarz ESVS30 842807/009 Biconical Antenna Rohde & Schwarz HK116 841489/015 Log.-Periodic Antenna Rohde & Schwarz HL223 841516/017 Double Ridge Horn Antenna EMCO 3115 9002-3347 Spectrum Analyzer Rohde & Schwarz FSP30 1093.4495K30 Active Loop Antenna EMCO 6502 9107-2651 www.tuv.com Test Report No.: 14012167 002 Date: 14.06.2006 Page 5 of 12 General Product Information Product Function and Intended Use The equipment under test (EUT) is a weather station transmitter operating at 433.9 MHz. The EUT senses and transmits information of wind direction and wind speed to the associated weather station receiver. The transmitter meets the requirement on periodic transmission as specified in Part 15.231 (e). For details, refer to Appendix 1 page 1. FCC ID: Q9PTS805 Ratings and System Details Transmitter Operated Frequency : 433.9 MHz Number of channel(s) : 1 Type of antenna : Integral antenna Power supply : Battery operated 3.0V (AA battery x 2) Port : none www.tuv.com Test Report No.: 14012167 002 Date: 14.06.2006 Page 6 of 12 Independent Operation Modes The basic operation model: - transmits information of wind direction and wind speed to the associated weather station receiver. For further information refer to User Manual Submitted Documents The submitted documents are listed as follow: - Circuit diagram - Block diagram - User manual - FCC ID label Related Submittal(s) Grants This is a single application for certification of the transmitter. www.tuv.com Test Report No.: 14012167 002 Date: 14.06.2006 Page 7 of 12 Test Set-up and Operation Mode Principle of Configuration Selection Emission: The test mode was configured on the equipment under test (EUT) to obtain the maximum emission. Test Operation and Test Software Test operation should refer to test methodology. - There was no special software to exercise the device. Special Accessories and Auxiliary Equipment The product has been tested together with the following additional accessories: - none Countermeasures to achieve EMC Compliance - none www.tuv.com Test Report No.: 14012167 002 Date: 14.06.2006 Page 8 of 12 Test Methodology Radiated Emission The radiated emission measurements were performed according to the procedures in ANSI C63.4-2003. The equipment under test (EUT) was placed at the middle of the 80 cm height turntable, and the turntable is 3 meters far from the measuring antenna. During the testing, the EUT was operated standalone and arranged for maximum emissions. The EUT was tested in three orthogonal planes. The measurement was performed with the EUT rotated 360ﾟ, the antenna height scanned between 1m and 4m, and the antenna rotated to repeat the measurements for both the horizontal and vertical antenna polarizations. Repeat the measurement steps until the maximum emissions we…

Text truncated - open the document above for the full version.

www.tuv.com Appendix 1 Prüfbericht - Nr.: Test Report No. 14012167 002 Seite 1 von 6 Page 1 of 6 Ref -20 dBm 130 kHz Att 10 dB 130 kHz A 130 kHz Center 433.988 MHz 130 kHz Span 1 MHz 130 kHz 100 kHz/ 130 kHz * 130 kHz RBW 100 kHz 130 kHzVBW 300 kHz 130 kHz SWT 2.5 ms 130 kHz 1 PK 130 kHz MAXH 130 kHz 130 kHz 130 kHz 130 kHz 130 kHz 130 kHz 130 kHz 130 kHz 130 kHz 130 kHz -120 -110 -100 -90 -80 -70 -60 -50 -40 -30 -20 130 kHz 1 Marker 1 [T1 ] -47.94 dBm 433.988000000 MHz 2 Delta 2 [T1 ] -20.20 dB -132.000000000 kHz 3 Delta 3 [T1 ] -20.14 dB 130.000000000 kHz DELTA MARKER 3 130 kHz Date: 26.APR.2006 17:56:20 - Bandwidth measurement: 20dB bandwidth = 130kHz + 132kHz =262kHz www.tuv.com Appendix 1 Prüfbericht - Nr.: Test Report No. 14012167 002 Seite 2 von 6 Page 2 of 6 Ref -20 dBm 33.1 s Att 10 dB 33.1 s A 33.1 s RBW 100 kHz 33.1 sVBW 300 kHz 33.1 s Center 433.988 MHz 33.1 s 5 s/ 33.1 s SWT 50 s 33.1 s MAXH 33.1 s * 33.1 s 1 PK 33.1 s 33.1 s 33.1 s 33.1 s 33.1 s 33.1 s 33.1 s 33.1 s 33.1 s 33.1 s -120 -110 -100 -90 -80 -70 -60 -50 -40 -30 -20 33.1 s 1 Marker 1 [T1 ] -47.97 dBm 6.500000 s 2 Delta 2 [T1 ] -0.08 dB 33.100000 s DELTA MARKER 2 33.1 s Date: 26.APR.2006 18:00:31 www.tuv.com Appendix 1 Prüfbericht - Nr.: Test Report No. 14012167 002 Seite 3 von 6 Page 3 of 6 Ref -20 dBm 480 ms Att 10 dB 480 ms A 480 ms RBW 100 kHz 480 msVBW 300 kHz 480 ms Center 433.988 MHz 480 ms 100 ms/ 480 ms SWT 1 s 480 ms MAXH 480 ms 1 PK 480 ms 480 ms 480 ms 480 ms 480 ms 480 ms 480 ms 480 ms 480 ms 480 ms -120 -110 -100 -90 -80 -70 -60 -50 -40 -30 -20 480 ms 1 Marker 1 [T1 ] -49.88 dBm 356.000000 ms 2 Delta 2 [T1 ] 0.08 dB 124.000000 ms 3 Delta 3 [T1 ] -0.04 dB 358.000000 ms 4 Delta 4 [T1 ] 0.02 dB 480.000000 ms DELTA MARKER 4 480 ms Date: 26.APR.2006 18:03:28 Part 15.231 (e) requirement Measured time (second(s)) Limit (second(s)) Duration of each transmission 0.48 ≤ 1 Duration of silent period 33.1-0.48 =32.62 ≥ 30 x 0.48 = 14.4, and ≥ 10 (shall be in any circumstances) www.tuv.com Appendix 1 Prüfbericht - Nr.: Test Report No. 14012167 002 Seite 4 von 6 Page 4 of 6 Ref -25 dBm 2.5 ms Att 10 dB 2.5 ms 2.5 ms 2.5 ms 2.5 ms 2.5 ms 2.5 ms 2.5 ms 2.5 ms 2.5 ms 2.5 ms * 2.5 ms * 2.5 ms A 2.5 ms RBW 3 MHz 2.5 msVBW 10 MHz 2.5 ms Center 433.99 MHz 2.5 ms 10 ms/ 2.5 ms SWT 100 ms 2.5 ms VIEW 2.5 ms 1 AP 2.5 ms -120 -110 -100 -90 -80 -70 -60 -50 -40 -30 2.5 ms 1 Marker 1 [T1 ] -44.13 dBm 2.500000 ms MARKER 1 2.5 ms Date: 12.MAY.2006 13:18:27 - The graph shows the pattern of coding during the signal transmission. - Within the pulse train, there are 70 short and 14 long ‘on’ signals. - www.tuv.com Appendix 1 Prüfbericht - Nr.: Test Report No. 14012167 002 Seite 5 von 6 Page 5 of 6 Ref -20 dBm 920 μs Att 10 dB 920 μs A 920 μs Center 433.878 MHz 920 μs 1 ms/ 920 μs RBW 3 MHz 920 μsVBW 10 MHz 920 μs SWT 10 ms 920 μs 1 PK 920 μs MAXH 920 μs SGL 920 μs 920 μs 920 μs 920 μs 920 μs 920 μs 920 μs 920 μs 920 μs 920 μs -120 -110 -100 -90 -80 -70 -60 -50 -40 -30 -20 920 μs 1 Marker 1 [T1 ] -47.30 dBm 2.460000 ms 2 Delta 2 [T1 ] 0.95 dB 920.000000 μs DELTA MARKER 2 920 μs Date: 3.JUL.2006 19:13:41 - The duration of long ‘on’ signal indicates 0.92ms. www.tuv.com Appendix 1 Prüfbericht - Nr.: Test Report No. 14012167 002 Seite 6 von 6 Page 6 of 6 Ref -20 dBm 440 μs Att 10 dB 440 μs A 440 μs Center 433.878 MHz 440 μs 1 ms/ 440 μs RBW 3 MHz 440 μsVBW 10 MHz 440 μs SWT 10 ms 440 μs MAXH 440 μs SGL 440 μs 440 μs 440 μs 440 μs 440 μs 440 μs 440 μs 440 μs 440 μs 440 μs 1 PK 440 μs -120 -110 -100 -90 -80 -70 -60 -50 -40 -30 -20 440 μs 1 Marker 1 [T1 ] -46.94 dBm 6.380000 ms 2 Delta 2 [T1 ] 0.79 dB 440.000000 μs DELTA MARKER 2 440 μs Date: 3.JUL.2006 19:14:33 -The duration of short ‘on’ signal indicates 0.44ms. - Therefore, the total ‘on’ time of one successful period (0.92ms x 14) + (0.44ms x 70) = 43.68ms. - Average factor: 20 log (43.68/100)=- 7.19dB

www.tuv.com Appendix 2 Prüfbericht - Nr.: Test Report No. 14012167 002 Seite 1 von 2 Page 1 of 2 Set up of radiated emission test Set up of radiated emission test www.tuv.com Appendix 2 Prüfbericht - Nr.: Test Report No. 14012167 002 Seite 2 von 2 Page 2 of 2 Set up of radiated emission test
