User Manual AWR-D7000 Digital Portable Radio Thank you for purchasing this AWR-D7000 Digital two-way radio by Advanced Wireless Communications (AWC). This product is designed and developed according to FCC/IC/EU and advanced international standards. Our products are tested using strict and rigorous test procedures with advanced test instruments and equipment to internationally recognized standards. Thank you! This manual should be read to ensure that the user understands the operation of the AWR-D7000. Please read the Safety Information Manual before use. Safety Instructions Please observe the following safety tips to prevent fire, accidents, personal injury or equipment damage. • Do not modify the radio or its charger in any way. • Do not expose the radio to direct sunlight for extended periods of time, leave near heaters or other heat sources. • Do not store or use unprotected radios for prolonged periods in areas of high dust or excessive moisture. • Users may experience signal interference if the unit is used near devices such as TV or electric generators. • If the unit emits smoke or you notice a strange smell, immediately turn off the power, and send it to the closest repair station. • The radios are small but contain high power components. It is not uncommon to notice slight warming of the handset. This is normal and the unit may be continued to be used. If there is any problem with the radio, please contact Advanced Wireless Communications or your local distributor. Turn on Turn the Volume/Power knob clockwise to turn the radio on. (Some radios are programmed to emit a tone when powered on). Turn off Turn the Volume/Power knob counter clockwise to turn the radio off, you will hear a sound when the radio is turning off. Volume adjustment Press and hold down the squelch key off momentarily to hear a continuous beep and turn the volume/power knob to adjust. Three way to choose channel 1 Channel knob: rotate the “channel control” to choose the needed channel. 2. Channel button: choose the channel you need. Transmit and receive Press PTT button, the radio will enter the transmit state, the red light will turn on, the LCD display (if equipped) will indicate transmit. Release PTT button, the radio will enter the receive state, the green light will turn on when receiving voice / data, and the LCD display (if equipped) will indicate receive. Advanced Wireless Communications Radio Quality Warranty and Liability The warranty range and limitation Advanced Wireless Communications (AWC) is committed to quality and stands behind its products. AWC will, during the warranty period specified for each product, repair or replace components that fail as a result of poor workmanship or materials. This warranty does not cover improper use or intentional damage. The warranty policy does not include the following conditions: 1. Defects or damages caused by working in abnormal or unusual situations. 2. Defect or damages caused by misuse, accident, or water submersion. 3. Defect or damages caused by unauthorized installation, repair, tampering or adjustment. 4. Warranty does not extend to cosmetic scratches or damages as a result of normal use or misuse. 5. This warranty is void if: (a) The product information label on the back aluminum case is removed, or if the serial number is tampered with, changed or cannot be identified. (b) If the battery case is damage, tampered with or unsealed. General Items This warranty policy establishes the liability limits for which AWC is responsible. AWC has the right to decide, in their sole discretion, whether to repair, replace, or refund the purchase price of any equipment subject to this warranty. There are no other options available under this warranty. This express warranty is the complete agreement. OTHER THAN AS EXPRESSLY SET OUT IN THESE TERMS OR ADDITIONAL TERMS, NEITHER AWC NOR ITS SUPPLIERS OR DISTRIBUTORS MAKE ANY SPECIFIC PROMISES ABOUT THE SERVICES OR PRODUCTS. CONTENTS Unpacking and device check ..............................................................1 Accessories ....................................................................................1 Battery information .............................................................................2 Battery protection ...........................................................................2 Battery usage .................................................................................3 Battery charge ................................................................................3 Preparation .........................................................................................4 Installing the battery .......................................................................4 Assemble the antenna ....................................................................4 Assemble the belt clip .....................................................................5 Disassemble the belt clip ................................................................5 Insert the earphone ........................................................................5 Function key .......................................................................................6 Charging the battery .......................................................................7 Charger indicator ............................................................................7 LED indicator of transceiver ...........................................................7 Function and basic operation .............................................................8 Turning your radio on and off ..........................................................8 Switch channel ...............................................................................8 Push-to-talk operation ....................................................................8 Digital channel information .................................................................12 Time out timer (TOT) ........…

Text truncated - open the document above for the full version.

2021-05-08 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: Q9SAWRD7000N Product Name: Two Way Radio Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description  BOM  Tune up These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this May 08, 2021 By: Kenneth J Coons Signature Printed Title: President On behalf of : Northfield Telecommunications, Inc. d/b/a Advanced Wireless Communications Telephone: 952-469-0122

External Photos of the EUT

7

Internal Photos of the EUT

Page: 1 of 17 TEST REPORT Report No..................................: CHTEW21040131 Report Verification: Project No.................................： SHT2103083201EW FCC ID ............................................. : Q9SAWRD7000N Applicant’s name ........................... : Northfield Telecommunications, Inc. d/b/a Advanced Wireless Communications Address ............................................. : 20809 Kensington Blvd, Lakeville, Minnesota, United States 55044 Test item description .................... : Two Way Radio Trade Mark ....................................... : AWC Model/Type reference ....................... : AWR-D7000N Listed Model(s) ................................. : - Standard ......................................... : FCC CFR Title 47 Part 15 Subpart B Date of receipt of test sample...........: Apr.12, 2021 Date of testing..............................: Apr.12, 2021- Apr.22, 2021 Date of issue.................................: Apr.23, 2021 Result .................. ........................: PASS Compiled by ( position+printed name+signature) .. : File administrators Echo Wei Supervised by ( position+printed name+signature) .. : Project Engineer Cheng Xiao Approved by ( position+printed name+signature) .. : RF Manager Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely corresponds to the test sample. Report No.: CHTEW21040131 Page: 2 of 17 Issued: 2021-04-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) Contents 1. TEST STANDARDS AND REPORT VERSION ............................................ 3 1.1. Test Standards 3 1.2. Report version 3 2. TEST DESCRIPTION ..................................................................... 4 3. SUMMARY ............................................................................... 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Radio Specification Description 6 3.4. Testing Laboratory Information 6 4. TEST CONFIGURATION ................................................................. 7 4.1. EUT operation mode 7 4.2. Support unit used in test configuration 7 4.3. Environmental conditions 7 4.4. Statement of the measurement uncertainty 7 4.5. Equipments Used during the Test 8 5. TEST CONDITIONS AND RESULTS ..................................................... 9 5.1. Conducted Emissions 9 5.2. Radiated Emissions 12 6. TEST SETUP PHOTOS OF THE EUT ................................................... 16 7. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ................................... 17 Report No.: CHTEW21040131 Page: 3 of 17 Issued: 2021-04-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 1. TEST STANDARDS AND REPORT VERSION 1.1. Test Standards The tests were performed according to following standards: FCC CFR Title 47 Part 15 Subpart B - Unintentional Radiators ANSI C63.4: 2014 – American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40GHz 1.2. Report version Revision No. Date of issue Description N/A 2021-04-23 Original Report No.: CHTEW21040131 Page: 4 of 17 Issued: 2021-04-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 2. TEST DESCRIPTION Test Item Section in CFR 47 Result Test Engineer Conducted Emissions 15.107(a) Pass Quanhai Deng Radiated Emissions 15.109(a) Pass Hongtao Meng Note: The measurement uncertainty is not included in the test result. Report No.: CHTEW21040131 Page: 5 of 17 Issued: 2021-04-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 3. SUMMARY 3.1. Client Information Applicant: Northfield Telecommunications, Inc. d/b/a Advanced Wireless Communications Address: 20809 Kensington Blvd, Lakeville, Minnesota, United States 55044 Manufacturer: Northfield Telecommunications, Inc. d/b/a Advanced Wireless Communications Address: 20809 Kensington Blvd, Lakeville, Minnesota, United States 55044 3.2. Product Description Main unit Name of EUT: Two Way Radio Trade Mark: AWC Model/Type reference: AWR-D7000N Listed Model(s) - Power supply: DC7.4V for battery Hardware version: V8 Software version: V3.02.01.032 Ancillary unit Battery information: Model: AWB-D7000/7500 DC 7.4V 1800mAh/13.3Wh Rapid charger information: Model: BC-7000 Input: DC 12V/1000mA Output: DC 600mA Adapter information: Model: DSA-12PFT-12 FUS 120100 Input: 100-240Va.c.,50/60Hz 0.5A Output: 12Vd.c.,1A Report No.: CHTEW21040131 Page: 6 of 17 Issued: 2021-04-23 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 3.3. Radio Specification Description Support Frequency Range: 400MHz~470MHz Rated Output Power: High Power: 4.5W Low Power: 1.5W Modulation Type: Analog: FM Digital : 4FSK Supported Digital Protocol: DMR Channel Separation: Analog: 12.5kHz Digital : 6.25kHz 12.5kHz Emission Designator: Analog: 11K0F3E Digital: 7K60FXW, 7K60FXD Support data rate: 9.6kbps Antenna Type: External Antenna Gain: 0dBi 3.4. Testing Laboratory Information Laboratory Name Shenzhen Huatongwei International Inspection Co., Ltd. Laboratory Location 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, …
