QAM015ActiveBoard 300 Pro Series

activboard 300 pro range Installation Guide T P1741 I ssue 2 COPYRIGHT INFORMATION © 2010 Promethean Limited. All rights reserved. This guide is distributed with the product. It may only be reproduced for use within the institution in which the product is used. For use outside of your institution, no part of this guide may be reproduced, transmitted, stored in a retrieval system or translated into any other language without the prior permission of Promethean Limited. Please note that the content in this guide is protected under copyright law. Although every care has been taken in the compilation of this guide,Promethean Limited accepts no responsibility for errors or omissions, or for damages resulting from the use of information contained within the following pages. contents Welcome 4 Safety Information 4 Compliance 5 Install ation 6 4 Welcome safety information install the softWare Power Supply Unit The Activboard 300 Pro range is powered by a power supply unit branded Promethean and type DT6018 or DPS-60SB A. This is the only approved power supply unit. Do not connect any other power supply unit to the ActivBoard 300 Pro range. The power supply unit is supplied with a suitable mains input lead specific to your country. The power supply unit may also be supplied with more than one mains input lead, to accommodate countries with more than one type of mains outlet socket. Only use the mains lead which is compatible with your mains outlet socket. Do not attempt to modify the mains lead. If you are unsure of the electrical compatibility of your equipment, please contact Promethean or an authorised Promethean service agent before attempting to connect the power supply unit to the mains supply. The power supply unit does not contain any user serviceable parts and must not be opened. If you suspect that the power supply unit is faulty, you should contact an authorised Promethean service agent to obtain a replacement. Inspect the power supply unit for physical damage to the casing before use. If damage is apparent, take care to avoid contact with any potentially live parts. Disconnect the power supply unit from the mains supply at the wall socket and contact an authorised Promethean service agent for advice. The ActivBoard does not contain any user serviceable parts. You should not attempt, under any circumstances, to gain access to internal parts of the unit. If the ActivBoard is suspected to be faulty or damaged contact Promethean or an authorised Promethean service agent for advice. Environmental Considerations Operating Temperature Range: 0°C to +50°C Storage Temperature Range: -20°C to +70°C Humidity (non condensing) 0% to 90% Thank you for purchasing an ActivBoard from Promethean. We recommend using our ActivBoard with our latest software, ActivInspire Professional Edition, which can be downloaded from www.prometheanplanet.com. For more information on the ActivClassroom by Promethean and other products available please visit www.prometheanworld.com. Environmental Considerations Operating Temperature Range: 0 C to +50 C Storage Temperature Range: -20 C to +70 C Humidity (non condensing) 0% to 90% This document must be left with the product after installation. Please retain for your records. 5 install the softWare United States of America This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: This device may not cause harmful 1. interference. This device must accept any interference 2. received, including interference that may cause undesired operation. Changes or modifications to this equipment not expressly approved by Promethean may void the user’s authority to operate this equipment. For non-intentional radio parts, this equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/ TV technician for help. Canada This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including Interference that may cause undesired operation. Changes or modifications to this equipment not expressly approved by Promethean may void the user’s authority to operate this equipment. This device also complies with RSS-102 of Industry Canada. This Class B digital apparatus complies with Canadian ICES-003. Europe The radio interface on this product (when fitted) is intended for use with Promethean radio devices for operation in the following countries: Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovak Republic, Slovenia, Spain, Sweden, Switzerland, United Kingdom. Declaration of Conformity Statement Contact Promethean for a copy of the Declaration of Conformity for this product. compliance 6 150mm (6”) 600 - 950mm (23.6 - 37.4in) 587.5mm (23.1in) 1175mm (46.26in) 670m…

Text truncated - open the document above for the full version.

1 Radiated emissions test setup Power line conducted emissions arrangement

PART HOLE CRS. GEN. TOL. MATERIAL PROJECT DRAWN Amendment record FINISH APPROVED SCALE REV SHT OF DIAMETER FLATNESS STRAIGHTNESS SQUARENESS Ø ANGULARITY TOLERANCES UNLESS OTHERWISE STATED + - 1.00 0.25 0.25 0.25 THIRD ANGLE PROJECTION IN ACCORDANCE WITH BS308. DIMENSIONS IN MILLIMETRES. DO NOT SCALE DRAWING. REMOVE ALL SHARP EDGES CHECKED DRG. NO. STATUS + - 0.25 + - 0.25 R Goodall 31/03/09 1:1 AB3 87" PREMIUM LEVEL APPROVALS LABEL POLYESTER CVMWPT50 578 3 578 3001 MATT WHITE TC ADHESIVE - PERMANENT 1of1 RELEASED R B Lofthouse APPROVED 01/04/09APP_DATE Lower Philips Road Blackburn Lancs BB1 5TH Tel 01254 676921 Fax 01254 581574 Promethean Ltd A4 NOTE: LABEL DIMENSIONS 90mm X 50mm Corner radius - 2mm IMPORTANT: LABEL TO MANUFACTURED BY UL APPROVED SUPPLIER 15ZX I.T.E. Promethean Ltd Model Name: ActivBoard Model Number: PRM-AB387-03 Power: 18V 3.0A Designed and Developed in the UK Made in China F2 www.prometheanworld.com This device complies with part 15 of the FCC rules: Operation is subject to the following two conditions (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This Class B digital apparatus complies with Canadian ICES-003. FCC ID:QAM015

ENTRY BOARD PREMIUM/STD BOARD 11 22 33 44 55 66 A A B B C C D D D R A W N C H E C K E D A P P R O V E D P R O J D R G . N O . T I T L E M A T E R I A L F I N I S H P R O M E T H E A N L T D P r o m e t h e a n H o u s e L o w e r P h i l i p s R o a d B l a c k b u r n L a n c s B B 1 5 T H T e l 0 1 2 5 4 2 9 0 1 5 1 F a x 0 1 2 5 4 2 9 0 1 6 1 S T A T U S S H E E T o f R E V S C A L E D O N O T S C A L E D R A W I N G I F I N D O U B T A S K R E M O V E A L L S H A R P C O R N E R S T O L E R A N C E U O S L A B E L L O C A T I O N D R A W I N G 5 7 6 3 0 2 4 S 2 1 b m a l a n e y 1 5 7 6 S E E P A R T S R 1 1 R E L E A S E D N T S R G o o d a l l 2 3 / 0 4 / 2 0 0 9 R G o o d a l l 2 3 / 0 4 / 2 0 0 9 S E E P A R T S N T S 2 3 / 0 4 / 2 0 0 9 T H I S C O M P O N E N T M U S T B E R O H S C O M P L I A N T 2 1 2 L A B E L S I T E M Q T Y D E S C R I P T I O N 1 1 C O M P L I A N C E L A B E L 2 2 S E R I A L L A B E L
                                                 T H I S D R A W I N G S H O U L D B E U S E D A S A G U I D E F O R L O C A T I N G L A B E L S . 2 1 2

Overview AC3 and Hub cover removed Top ViewAC3PCB Underside View AC3PCB Top View Hub PCB Underside View Hub PCB Overview of Audio Amplifier Top View Audio Amplifier PCB Underside View Audio PCB Radio Section Screening cover removed otogr aphs

RADIO FREQUENCY RADIATION EXPOSURE MPE calculation: Test setup1: EUT222TRLUH281 Formula: S=EIRP/ 4π R 2 S = Power Density (mW/cm 2 ) EIRP = Radiated power (mW) R = distance for body (cm) Calculation: S=4.77mW/ 4 π 0.62mW/cm 2 S=0.987mW/cm 2 Notes: 1.The unit will be mounted at least0.58cm away from the body. 2.The carrier power EIRP 4.77mWwas theworst case peak level measured. 3.Antenna Gain of 0dBi stated by manufacturer. Limit The limit of Powerdensity for the General Population/ Uncontrolled Exposure is 1 mW/cm 2 . Result The EUT meet the 1 mW/cm 2 limit.

Total number of pages : 123 grepbl.doc Ver: g01/10 "TTR-000174WUS2.doc" TRaC RadioTest Report:TTR-000174WUS2 Applicant:Promethean Ltd Specification(s):CFR47 Part 15 July 2008 Apparatus :Activboard 300 Pro Series FCC ID:QAM015 Purpose of Test: Class II Permissive Change Authorised by: :Radio Product Manager Issue Date:22 nd October 2010 Authorised Copy Number: PDF Radio Test Report: TTR-000174WUS2 2 Contents Section 1:Introduction3 1.1General3 1.2Tests Requested By4 1.3Manufacturer4 1.4Apparatus Assessed4 1.6Notes Relating To The Assessment6 1.7Deviations from Test Standards6 Section 2:Measurement Uncertainty7 2.1Measurement Uncertainty Values7 Section 3:Modifications9 3.1Modifications Performed During Assessment9 Appendix A:Formal Emission Test Results10 A1Conducted Fundamental Carrier Power11 A2RF Antenna Conducted Spurious Emissions12 A3Radiated Electric Field Emissions Within The Restricted Band 15.20513 A3Radiated Electric Field Emissions Within The Restricted Band 15.20518 A4Power Line Conducted Emissions34 A520 dB Bandwidth and Channel Spacing38 A6Hopping frequencies39 A7Channel Occupancy40 A8Antenna Gain41 Appendix B:Supporting Graphical Data42 Appendix C:Additional Test and Sample Details106 Appendix D:Additional Information112 Appendix E:Calculation of the duty cycle correction factor113 Appendix F:Photographs and Figures114 Radio Test Report TTR-000174WUS2 3 Section 1:Introduction 1.1General This report contains an assessment of an apparatus against Electromagnetic Compatibility Standards based upon tests carried out on samples submitted to the Laboratory. TRaC Test performed by:Telecoms & Radio Moss View Nipe Lane Up Holland West Lancashire, WN8 9PY United Kingdom Telephone:+44 (0) 1695 556666 Fax:+44 (0) 1695 577077 Email:[email protected] Web site:http://www.tracglobal.com Tests performed by:S Hodgkinson, Radio Test Engineer Report author:S Hodgkinson, Radio Test Engineer This report must not be reproduced except in full without prior written permission from TRaC Telecoms & Radio. Radio Test Report TTR-000174WUS2 4 1.2Tests Requested By This testing in this report was requested by : Promethean Ltd Promethean House Lower Philips Road Blackburn Lancashire BB1 5TH 1.3Manufacturer Promethean Ltd Promethean House Lower Philips Road Blackburn Lancashire BB1 5TH 1.4Apparatus Assessed The following apparatus was assessed between 20 th August 2010 – 20 th September 2010: Activboard 300 Pro Series Models:- PRM-AB378-03 PRM-AB387-03 PRM-AB395-03 Equipment description The Promethean 300 Pro Series are available in three sizes 78”, 87”, 95 and have the following features: Stereo Amplifier Stereo Loudspeakers USB Hub USB Port 2.4GHz Radio Link 2 Pen Frequencies 18.0Vdc Power supply unit, model number DPS-605B A The cables for the Loudspeakers are pre installed into the outer case of the boards. The 300 Pro Series, testing was carried out with the audio amplifier and USB Hub and USB port exercised, and connected to the PC via a USB lead. When required the testingwas carried out with all of the boards connected to the PC via the 2.4GHz radio link. Radio Test Report TTR-000174WUS2 5 1.5EXAMINATIONS REQUIRED Full details of test results are contained within Appendix A. The following table summarises the assessment. EQUIPMENT TEST / EXAMINATIONS REQUIRED TEST/EXAMINATIONRULE PARTDETECTORAPPLICABILITY Intentional Emission Frequency:15.247PeakYes Intentional Emission Field Strength:--No Intentional Emission Band Occupancy:15.247(a)1PeakYes Intentional Emission EIRP (mW):15.247(b)1PeakYes Spurious Emissions – Conducted:--No Spurious Emissions – Conducted:15.247PeakYes Spurious Emissions – Radiated <1000MHz:15.209 ,15.247Quasi PeakYes Spurious Emissions – Radiated >1000MHz: 15.247 15.209 Peak average Yes Transmitter Carrier Frequency Separation:15.247(a)(1)PeakYes Transmitter Maximum Peak Power Output Power:15.247(b)(1)PeakYes Transmitter Band Edge Conducted Emissions:15.247(c)PeakYes Transmitter Band Edge Radiated Emission:15.247(c)PeakYes Extrapolation Factor:15.31(f)-Yes Maximum Frequency of Search:15.33-Yes Antenna Arrangements Integral:15.203-Yes Antenna Arrangements External Connector:15.204-Yes Restricted Bands:15.205-Yes Mod: Modification CFR: Code of Federal RegulationsANSI: American National Standards Institution REFE: Radiated Electric Field EmissionsPLCE: Power Line Conducted Emissions Radio Test Report TTR-000174WUS2 6 1.6Notes Relating To The Assessment With regard to this assessment, the following points should be noted: The results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. The apparatus was set up and exercised using the configurations, modes of operation and arrangements defined in this report only. Particular operating modes, apparatus monitoring methods and performance criteria required by the standards tested to have been performed except where identified inSection 1.7 of this test report (Deviations from Test Standards). For emissions testing, throughout this test report, “Pass” indicates that the results for the sample as tested were below the specified limit (refer also to Section 2, Measurement Uncertainty). Where relevant, the apparatus was only assessed using the monitoring methods and susceptibility criteria defined in this report. All testing with the exception of testing at the Open Area Test Site was performed under the following environmental conditions: Temperature: 19to 26C Humidity : 41to 57% All dates used in this report are in the format dd/mm/yy. 1.7Deviations from Test Standards There were no deviations from the standards tested to. Radio Test Report TTR-000174WUS2 7 Section 2:Measurement Uncertainty 2.1Measurement UncertaintyValues The following page contains the measurement uncertainties for measurements All statements of uncertainty are expanded standard uncertainty using a coverage factor of 1.96 to give a 95% confidence whe…
