QC8-RDL3000RMFWhite Space Device with Geo-location - Fixed

RDL-3000 M2M Solutions 70-00184-02-00 Proprietary Redline Communications © 2013 Page 1 of 10 February 20, 2013 RDL-3000 Family Broadband Wireless Systems RDL-3000-RMF Fixed TVBD Radio Module Product Manual 1 Product Overview ................................................................... 4 2 Conditions of Use ................................................................... 5 3 Module Installation and Service ............................................ 6 4 Final Product Requirements .................................................. 7 5 Regulatory Notices ................................................................. 8 RDL-3000 FAMILY RDL-3000-RMF PRODUCT MANUAL 70-00184-02-00 Proprietary Redline Communications © 2013 Page 2 of 10 February 20, 2013 Copyright Information All rights reserved February 20, 2013. The information in this document is proprietary to Redline Communications Inc. This document may not in whole or in part be copied, reproduced, or reduced to any medium without prior consent in writing from Redline Communications Incorporated. Contact Information Contact Information: Redline Communications Inc. 302 Town Centre Blvd. Markham, ON Canada L3R 0E8 Web site: http://www.rdlcom.com Email: Inquiries: [email protected] Support: [email protected] Training: [email protected] Document Control: 70-00184-02-00-RDL-3000-RMF_Product_Manual-20130220b.doc Disclaimer The statements, configurations, technical data, and recommendations in this document are believed to be accurate and reliable, but are presented without express or implied warranty. Additionally, Redline makes no representations or warranties, either expressed or implied, regarding the contents of this product. Redline Communications shall not be liable for any misuse regarding this product. The information in this document is subject to change without notice. No part of this document shall be deemed to be part of any warranty or contract unless specifically referenced to be part of such warranty or contract within this document. RDL-3000 FAMILY RDL-3000-RMF PRODUCT MANUAL 70-00184-02-00 Proprietary Redline Communications © 2013 Page 3 of 10 February 20, 2013 TABLE OF CONTENTS 1 Product Overview ................................................................... 4 2 Conditions of Use ................................................................... 5 2.1 General Conditions ............................................................................................ 5 2.2 Country of Use ................................................................................................... 5 2.3 Product Labeling ................................................................................................ 5 3 Module Installation and Service ............................................ 6 3.1 Installation Into a Final Product ........................................................................ 6 3.2 Module Servicing ............................................................................................... 6 3.3 Professional Installation .................................................................................... 6 3.4 Safety Precautions ............................................................................................. 6 3.5 Radio Frequency Safety .................................................................................... 6 4 Final Product Requirements .................................................. 7 4.1 Frequency Bands ............................................................................................... 7 4.2 Antenna Use and Transmit Power .................................................................... 7 4.3 Certified Antennas ............................................................................................. 7 5 Regulatory Notices ................................................................. 8 FCC Notices: Deployment in USA .................................................................. 8 LIST OF TABLES Table 1: Transmit Power ................................................................................................. 7 Table 2: Approved Antennas ........................................................................................... 7 RDL-3000 FAMILY RDL-3000-RMF PRODUCT MANUAL 70-00184-02-00 Proprietary Redline Communications © 2013 Page 4 of 10 February 20, 2013 1 Product Overview The RDL-3000 Radio Module RDL-3000-RMF Fixed TVBD is comprised of a proprietary Media Access Control (MAC) protocol engine and Time Division Duplexing (TDD)/ Orthogonal Frequency Division Duplexing (OFDM) digital radio. The RDL-3000-RMF module is not designed for stand-alone operation. The module is sold as one component of a packaged system which includes a suitable housing for the module connectors for required external components including a power supply and antenna system. This is afterwards referred to as the 'final product'. The final product may be designed and manufactured by Redline or a licensed third party. Frequency settings within the specified frequency ranges are software keyed to be compliant with specific regulatory agency requirements in the region of deployment. RDL-3000-RMF: 473 - 695 MHz Important: Read this entire document prior to installing or operating the RDL-3000-RMF module. RDL-3000 FAMILY RDL-3000-RMF PRODUCT MANUAL 70-00184-02-00 Proprietary Redline Communications © 2013 Page 5 of 10 February 20, 2013 2 Conditions of Use 2.1 General Conditions The RDL-3000-RMF is not provided for sale to the general public. The RDL-3000-RMF contains a proprietary radio interface and can not be directly connected to any standard telecommunications or computer devices. This manual is provided as supplement to technical and operational documentation and training provided by Redline and its agents. Any operation or use of the RDL-3000-RMF in any manner not expressly specified within this manual or approved in writing by Redline (or its agents) is ex…

Text truncated - open the document above for the full version.

RDL-3000 M2M Solutions 70-00184-02-00 Proprietary Redline Communications © 2013 Page 1 of 12 April 24, 2013 RDL-3000 Family Broadband Wireless Systems RDL-3000-RMF Fixed TVBD Radio Module Product Manual 1 Product Overview ................................................................... 4 2 Conditions of Use ................................................................... 5 3 Module Installation and Service ............................................ 7 4 Final Product Requirements .................................................. 9 5 Regulatory Notices ............................................................... 11 RDL-3000 FAMILY RDL-3000-RMF PRODUCT MANUAL 70-00184-02-00 Proprietary Redline Communications © 2013 Page 2 of 12 April 24, 2013 Copyright Information All rights reserved April 24, 2013. The information in this document is proprietary to Redline Communications Inc. This document may not in whole or in part be copied, reproduced, or reduced to any medium without prior consent in writing from Redline Communications Incorporated. Contact Information Contact Information: Redline Communications Inc. 302 Town Centre Blvd. Markham, ON Canada L3R 0E8 Web site: http://www.rdlcom.com Email: Inquiries: [email protected] Support: [email protected] Training: [email protected] Document Control: 70-00184-02-00-RDL-3000-RMF_Product_Manual-20130424a.doc Disclaimer The statements, configurations, technical data, and recommendations in this document are believed to be accurate and reliable, but are presented without express or implied warranty. Additionally, Redline makes no representations or warranties, either expressed or implied, regarding the contents of this product. Redline Communications shall not be liable for any misuse regarding this product. The information in this document is subject to change without notice. No part of this document shall be deemed to be part of any warranty or contract unless specifically referenced to be part of such warranty or contract within this document. RDL-3000 FAMILY RDL-3000-RMF PRODUCT MANUAL 70-00184-02-00 Proprietary Redline Communications © 2013 Page 3 of 12 April 24, 2013 TABLE OF CONTENTS 1 Product Overview ................................................................... 4 2 Conditions of Use ................................................................... 5 2.1 General Conditions ............................................................................................ 5 2.2 Country of Use ................................................................................................... 5 2.3 Product Labeling ................................................................................................ 6 Module Label ................................................................................................. 6 External Label ................................................................................................ 6 3 Module Installation and Service ............................................ 7 3.1 Installation Into a Final Product ........................................................................ 7 3.2 Module Servicing ............................................................................................... 7 3.3 Professional Installation .................................................................................... 8 3.4 Safety Precautions ............................................................................................. 8 3.5 Radio Frequency Safety .................................................................................... 8 4 Final Product Requirements .................................................. 9 4.1 Frequency Bands ............................................................................................... 9 4.2 Antenna Use and Transmit Power .................................................................. 10 4.3 Certified Antennas ........................................................................................... 10 5 Regulatory Notices ............................................................... 11 FCC Notices: Deployment in USA ................................................................ 11 LIST OF TABLES Table 1: Transmit Power ............................................................................................... 10 Table 2: Approved Antennas ......................................................................................... 10 RDL-3000 FAMILY RDL-3000-RMF PRODUCT MANUAL 70-00184-02-00 Proprietary Redline Communications © 2013 Page 4 of 12 April 24, 2013 1 Product Overview The RDL-3000 Radio Module RDL-3000-RMF Fixed TVBD is comprised of a proprietary Media Access Control (MAC) protocol engine and Time Division Duplexing (TDD)/ Orthogonal Frequency Division Duplexing (OFDM) digital radio. The RDL-3000-RMF module is not designed for stand-alone operation. The module is sold as one component of a packaged system which includes a suitable housing for the module connectors for required external components including a power supply and antenna system. This is afterwards referred to as the 'final product'. The final product may be designed and manufactured by Redline or a licensed third party. Frequency settings within the specified frequency ranges are software keyed to be compliant with specific regulatory agency requirements in the region of deployment. RDL-3000-RMF: 470 - 608 and 614 - 698 MHz band Important: Read this entire document prior to installing or operating the RDL-3000-RMF module. RDL-3000 FAMILY RDL-3000-RMF PRODUCT MANUAL 70-00184-02-00 Proprietary Redline Communications © 2013 Page 5 of 12 April 24, 2013 2 Conditions of Use 2.1 General Conditions The RDL-3000-RMF is not provided for sale to the general public. The RDL-3000-RMF contains a proprietary radio interface and can not be directly connected to any standard telecommunications or computer devices. This manual is provided as supplement to technical and operati…

Text truncated - open the document above for the full version.

Confidential and Proprietary © 2013. Redline Communications Inc. 1 1.0 TVWS Quickstart This guide is intended to provide a very quick introduction to establishing an RF link between an RDL- 3000 UHF sector and subscriber. The units have been shipped mostly pre-configured, with only some site-specific parameters remaining. As shipped, the units are configured as follows: Radio Mode Radio MAC Radio S/N Management IP Sector Controller 00:09:02:14:B4:FB 182PC13030002 192.168.45.64 Subscriber 00:09:02:14:B5:02 182PC13030003 192.168.45.65 1.1 Physical Connectivity  Before powering up the radios, make sure to connect each radio’s RF ports to the other radio’s corresponding port. Make sure there is at least 60dBm of attenuation inline.  Connect each radio to the output port of the PoE injector via Ethernet cable.  Connect the sector controller PoE injector’s input port into your local area network, ensuring that there is a valid route through your network to the internet (for WSDB access). 1.2 Configuring network connectivity  Configure your PC’s network interface to an IP address within the radios’ subnet (e.g. 192.168.45.100 / 255.255.255.0).  Connect your PC to the sector controller’s PoE injector input port, and verify ping connectivity to the sector’s IP address (listed above).  Open Internet Explorer and browse to the sector’s IP address. Note that if you’re using Internet Explorer 10, you’ll need to place your browser into compatibility mode. o To place IE10 in compatibility mode, browse to the page you’re trying to view, then click the small “broken page” icon next to the address bar’s “refresh” button. o  The login credentials are “admin”/”admin”.  The next step is to configure the radio’s internet access. To do this, you need to provide your network’s default gateway and DNS server IP addresses, accessed in the System Configuration menu. Confidential and Proprietary © 2013. Redline Communications Inc. 2  o DNS Server 2 is optional. o If your DHCP server provides this information, you can use DHCP instead of providing this information yourself. However, you’ll need some way to determine what IP address your DHCP server has provided the radio. You IT department should be able to help out there.  Press “Apply and Save All” to activate your changes. If you’ve changed your IP address (or activated DHCP) you’ll need to browse to the radio’s new IP address, as these changes take effect immediately after activation.  That’s it for the sector controller. Repeat these steps on the subscriber station, then proceed to section 1.2. 1.3 Configuring WSDB Access – Sector Controller  Configure the radio’s registration information as appropriate to your location.  If the unit has a GPS antenna connected and has a fix on a sufficient number of satellites, the “Use GPS” checkbox will be enabled. This will automatically populate the Lat/Long fields. o You can view information on the current GPS status in the “System Status” menu. Click on the “GPS Status” link to open a new window.  Make sure to “Apply and Save” your changes.  Once you have everything configured, wait 60 seconds and then navigate to the “WSDB Status” menu. Check to make sure that “Server Connectivity Status” shows “SUCCESS”. If so, you should see a color-coded indication of available channels in the bottom half of the page. o If “Server Connectivity Status” shows FAILURE, check the system log for an indication of the reason for the failure.  In the displayed channel list, red channels are unavailable for use at your location, blue channels are available, and the green one is the currently selected channel.  Navigate to the “Wireless” page, and select a non-red channel from the dropdown list. Confidential and Proprietary © 2013. Redline Communications Inc. 3  1.4 Configuring WSDB Access – Subscriber  Repeat the same steps as in the previous section, making sure to select the same channel as was selected in the sector controller. Confidential and Proprietary © 2013. Redline Communications Inc. 4 2.0 Hardware Testing / RDL-3000 Backup Unit In regards to third Hardware Testing & Backup unit (S/N 160PC13030002, MAC 00-09-02-14-B5-04, IP 192.168.45.69)  Note about debug/engineering mode which is provided to FCC for testing purposes, but is not provided to end customers  Before applying POE power, ensure all ports are terminated into a 50-ohm load  Login to GUI using MSIE web browser using admin/admin  select desired power and center frequency  select the desired RF1, RF2 or RF1&RF2 configuration  Click Apply For Part 15, Subpart H tests, continuous transmit mode is required. To do this:  DUT must be in SC (Sector Controller) mode  Using Windows CMD window or a Telnet program, telnet into the DUT (“telnet 192.168.45.69” for example) and login as debug/debug  Enter command: “dbg txloop 1”  Before adjusting other system parameters (such as frequency) from the GUI, disable continuous Tx mode with “dbg txloop 0” Note that in the customer software the following restrictions are made:  Channels 36, 37, and 38 are disallowed  Tx power for all channels is limited to +18dBm, except channels 35 and 39 which are limited to +16dBm  On channel 35, the center frequency is moved down by 0.5MHz  On channel 39, the center frequency is moved up by 0.5MHz

Timco Engineering, Inc. TCB Application Form 731 Rev 21 March 09 Shaded areas are REQUIRED Item 1. Applicant’s complete, legal business name: REDLINE COMMUNICATIONS, INC. Applicant’s FCC Registration Number (FRN): 0007-0285-33 Item 2. Applicant’s mailing address: fill in fields, as appropriate Line 1: 302 TOWN CENTRE BLVD. KDB Tracking #: Line 2: SUITE 100 P.O. Box: City: MARKHAM State: ONTARIO Country (if foreign address): CANADA Zip/Postal Code: L3R 0E8 Item 3. Applicant Contact Person: Must be the same as the FCC Grantee Contact listed in the FCC database. The Name in the FCC Database will be on the Certification. https://fjallfoss.fcc.gov/oetcf/eas/reports/GranteeSearch.cfm First Name: ROD Last Name: CRONIN Title: DIRECTOR, PRODUCT MANAGEMENT Telephone: 905-479-8344 X2377 E-mail: [email protected] Fax No.: 905-479-5331 Item 4. FCC ID consisting of: Grantee Code: QC8 Equipment Product Code (14 characters maximum): -RDL3000RMF include “dashes” (-) where appropriate Item 5. Application Contact: All questions regarding the application will be directed to this contact. The Original Grant and Invoice will be sent to this contact. Firm Name: REDLINE COMMUNICATIONS, INC. Telephone: 905-479-8344 X2377 Ext: Fax: No.: 905-479-5331 First Name: ROD Middle Initial: Last Name: CRONIN Address Line 1: 302 TOWN CENTRE BLVD. P.O. Box: Address Line 2: SUITE 100 City: MARKHAM State: ONTARIO Country (if foreign address): CANADA Zip/Postal Code: L3R 0E8 E-mail: [email protected] Item 6. Test Firm Used to Take Measurements: Firm Name: TIMCO ENGINEERING, INC. Telephone: 888 4722424 Ext.: Fax No.: 352 472 2030 First Name: Sid Middle Initial: Last Name: Sanders Address Line 1: 849 NW SR 45 P.O. Box: Address Line 2: PO Box 370 City: Newberry State: Florida Country (if foreign address): USA Zip/Postal Code: 32669 E-mail: [email protected] FCC Registered Test Site Number. Required for Part 15 and 18 applications. Item 7. * Does this application include a request for SHORT-TERM confidentiality for any portion(s) of the data contained in this application pursuant to FCC DA 04-1705 dated 6/15/2004? * Does this application include a request for confidentiality for any portion(s) of the data contained in this application pursuant to 47 CFR 0.459 of the Commission Rules? SHORT-TERM request: Yes No PERMANENT request: Yes No Item 8. *Is this application for modular approval? Yes No Modular Type: (only complete if you answered Yes to Item 8) Single Modular Approval Limited Single Modular Approval Split Modular Approval Limited Split Modular Approval Item 9. *Is this application for software defined radio authorization? Yes No Item 10. Equipment Class: WGF Enter a brief description of the product being marketed. White Space Device with Geo-location - Fixed For Timco Use Only Job Number 208AUT13 Scope Date Filed Conf. # Grant Note Item 11. *Application is for: Original Equipment Change in identification of presently authorized equipment: Original FCC ID Grant Date (MM/DD/YYYY) Class II permissive change or modification of presently authorized equipment Class III permissive change to software defined radio Note: this may only be filed for applications pertaining to Software Defined Radio Item 12. Is the equipment in this application: * (a) a composite device subject to an additional equipment authorization? * (b) part of a system that operates with, or is marketed with, another device that requires an equipment authorization? If either of the above questions is answered “Yes” complete section 12 (c). Yes No Yes No (c) The related application: has been granted under the FCC ID(s) listed to the right is in the process of being filed under the FCC ID(s) listed to the right is pending with the FCC under the FCC ID(s) listed to the right has a mix of pending and granted statuses under the FCC ID(s) listed to the right i. ii. iii. iv. FCC ID: FCC ID: FCC ID: FCC ID: Item 13. * Equipment will be operated under FCC Rule Part(s): 15H Item 14. EQUIPMENT SPECIFICATIONS: Where applicable Frequency range in MHz Low Freq High Freq Rated RF power output IN WATTS Frequency tolerance %, Hz, ppm Emission Designator (See 47 CFR 2.201 and 2.202) FCC Rule Part (for Multiple Rules) Grant Notes (Example- CC, MO) 473.00 599.00 0.124 MO 623.00 695.00 0.124 MO Equipment Authorization Waiver * Is there an equipment authorization waiver associated with this application? Yes No If there is an equipment authorization waiver associated with this application, has the associated waiver been approved and all information uploaded? Yes No (Continued on Next Page) Read each certification carefully before answering and signing this application WILLFUL FALSE STATEMENTS MADE ON THIS FORM ARE PUNISHABLE BY FINE AND/OR IMPRISONMENT (U.S. CODE, TITLE 18, SECTION 1001), AND/OR REVOCATION OF ANY STATION LICENSE OR CONSTRUCTION PERMIT (U.S. CODE, TITLE 47, SECTION 312 (a) (1)), AND/OR FORFEITURE (U.S. TITLE 47, SECTION 503). Item 15. APPLICANT/AGENT CERTIFICATION: I certify that I am authorized to sign this application. All of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. In accepting a Grant of Equipment Authorization issued by the TCB, under the authority of the FCC, as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. Authorizing an agent to sign this application is done solely at the applicant’s discretion; however, the applicant remains responsible for all statements in …

Text truncated - open the document above for the full version.

February 15, 2013 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Applicant: Redline Communications Inc. FCC ID: QC8-RDL3000RMF RE: Limited Modular Transmitter Approval for RDL-3000-RMF To whom it may concern: Pursuant to the FCC Rules, Part 15 Section 15.212 Modular transmitters and KDB 966369 D01 Module Certification Guide v01r03, Redline Communications, Inc. hereby requests Limited Modular Transmitter Approval for the above listed FCC submittal. This letter affirms that Redline Communications Inc. shall retain complete control over the final installation of the module and will ensure compliance of the end product to all applicable FCC regulations. The module will not be distributed, marketed or sold to the general public and Redline will not make this module available as standalone product. It will be installed in the devices produced by Redline Communications Inc. and its authorized partners. According to the requirements of section 15.212 of FCC rules please note the following statements: 1. Limited Modular Transmitter Approval is being requested since the modular transmitter doesn’t have its own RF shielding. The module has been tested in a stand-alone configuration and complies with all of the FCC requirements at the module level. 2. The input to the module is an Ethernet interface. All modulation and protocol elements are contained within module. There are no other modulation or data inputs to the module that may result in non-compliant operation. 3. The modular transmitter has its own power supply regulation and filtering. 4. The modular transmitter complies with the antenna requirements of Section 15.203 and 15.204(c). The module does not incorporate an integrated antenna, however uses unique MCX RF connectors for antenna connection. The module has been tested with the intended antennas. Approval for additional antenna will be obtained through a Class II permissive change. The modular transmitter will be installed by professional installers trained by Redline Communications. Redline Communications will retain complete control over the final installation of the module ensuring that only approved antenna type will be used with this module. The list of approved antennas is included in the user manual. 5. The modular transmitter has been tested in a stand-alone configuration. It complies with Part 15 Subpart H regardless of the device / enclosure into which it will be installed. 6. The modular transmitter will be labeled with its own FCC ID: QC8- RDL3000RMF, and the chassis of the device / enclosure into which the module is installed will display a label referring to the enclosed module “Contains FCC ID: QC8-RDL3000RMF”. 7. The modular transmitter operates under Part 15 Subpart H to which it has been tested. Users do not have access to controls that may cause the module to operate outside its normal mode of operation. 8. The modular transmitter has been evaluated with the intended antenna and complies with all applicable RF exposure requirements. RF exposure warnings and separation distances are included in the user manual. Sincerely, Rod Cronin Director, Product Management Ph: 905.479.8344 x2377 [email protected]

Redline Communications Inc. Confidential Page 2 of 4 Exhibit A Redline Communications Inc. CONFIDENTIALITY AGREEMENT This Confidentiality Agreement (“Agreement”) is made and entered into by and between Redline Communications Inc. (“RCI”), a Canadian corporation, located at 302 Town Centre Blvd. Suite 100, Markham, Ontario, L3R 0E8 together with and on behalf of its various affiliated companies, and ______________________ [Insert Company Name and Address Here] (“Company”), a [Insert Country of Incorporation Here – Contracting party can tell you what this is. If they don’t know, you can leave blank] corporation. Witnesseth: WHEREAS, RCI and Company desire to explore and discuss the potential mutual benefits from joint business arrangements or activities involving______[Insert the reason for the disclosure e.g: relating to the manufacturing of certain Redline products. If you are unsure, call or see me] _______________ , which explorations and discussions are herein referred to as the “Discussions”; AND WHEREAS, in connection with the Discussions, RCI and Company will acquire certain confidential information relating to each other’s businesses, including, without limitation, technical information, know-how, business methods and processes; AND WHEREAS, RCI and Company desire to set forth their understanding with respect to such confidential information during and after the Discussions; NOW THEREFORE for valuable consideration (the receipt and sufficiency of which is hereby acknowledged) RCI and Company agree as follows: 1. Confidential Information. “Confidential Information” shall mean any business, marketing, sales, financial (including pricing) or technical information, including, without limitation, any information relating to present or future business affairs, operations, methods, techniques, operations, financial condition, reports, research, product plans, products, developments, processes, models, designs, drawings, formulae, markets, software (including source and object code), algorithms, business plans or agreements with third parties and all other information of any kind which may reasonably be deemed confidential or proprietary, disclosed by one party (the “Disclosing Party”) to the other (the “Receiving Party”), whether such information is in written, oral, graphic or machine-readable form and which is designated or identified as “confidential”, “proprietary” or in some other manner prior to the disclosure, to indicate its confidential nature. Oral disclosures will be confirmed in written format 30 days following the disclosure. Notwithstanding the foregoing, “Confidential Information” shall not include information which: (a) has been or becomes published or is now or is in the future in the public domain through no action of the Receiving Party; (b) prior to disclosure hereunder, is within the legitimate possession of the Receiving Party as evidenced by competent written proof; (c) subsequent to disclosure hereunder, is lawfully received from a third party having rights therein without restriction of the third party’s rights to disseminate the information and without notice of any restriction against its further disclosure; or (d) is independently developed or acquired by the Receiving Party through persons who have not had, either directly or indirectly, access to or knowledge of such Confidential Information. 2. Nondisclosure. The Confidential Information shall (a) be kept conf…

Text truncated - open the document above for the full version.
