QDYRC-200Remote Control

User’s Manual Menix Co., Ltd. 1 Thank you for purchasing our CyberEye-Cam. For the best results,please review this manual first. These operating instructions should beretained for future reference.CONTENTSFEATURESCOMPONENTSNAME OF PARTSCAMERA RANGE AND ANGLEHOW TO USE REMOTE CONTROLLERSETUP MODE - MODE TO DELETE/KEEP THE SAVED IMAGES - MODE TO CHANGE DATES AND TIME - MODE TO SETUP RECORDING INTERVAL - MODE TO SETUP NUMBERS OF TAKING PICTURES HOW TO OPERATEHOW TO CHECK THE SAVED IMAGESSPECIFICATIONSWARRANTYNOTE: Menix Co., Ltd IS NOT RESPONSIBLE FOR ANY RADIO OR TVINTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THISEQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’SAUTHORITY TO OPERATE THE EQUIPMENT. 2 FEATUREIt will takes the images of criminals and saves them in Built-inMemory, and these images with time-stamp can be used to verify thecriminals and used as an evidence to the court of law. (1) Auto-detecting feature in case of break-in to the car (2) Emergency Image Capture ( In case of Taxi Robbery) (3) Images will be saved in Built-in Memory (Max. 42 images) (4) Time Stamp in the image (year/month/date/hour/min) (5) Can takes pictures in the night (Using IR LED) (6) Can adjust the Time interval between pictures (1~8 Seconds) (7) Foot Switch is provided (Emergency Use) 3 COMPONENTS(1) Remote Control (2) Main Body(3) Camera (4) Power Adaptor (12V)(5) Video Connection cordNAME OF PARTS(1) Camera (2) Camera Jack(+)(3) Camera Jack (- ) (4) Video Connector 4 (5) Switch (6) Power Jack(7) Remote controlCAMERA RANGE AND ANGLEHorizontal Range : 51 º Vertical Range : 41º 5 HOW TO USE REMOTE CONTROLLERThis device controls the Main body with radio-wave. When you press any button on the remote controller, the Red lamp will blink once and it willsend 311.06Mhz AM radio wave and it will operate the main body.(1) “ARMED” - Use to Arm(Activate) the main body. Increase the time, number (2) “OFF” - Use to Off(Deactivate) the main body. Decrease the time, number  (3) “EMERGENCY” - Takes the image in urgent situation Move to next step when adjusting time, number How to replace the Battery (Alkaline A23) SETUP MODE 2000. 7. 7. 14: 03 6 1. Connec t Power Adaptor to the Power Outlet (DC 12 V). 2. Connect to Power connecting jack by the side of main unit, please make sure to setswitch to “ON”. (See the diagram) 3. Withi n 5 seconds a fter setti ng switch to “ON”, press the “ARMED” b utto n o n theremote control. As you hear beeping sounds, this means that the code willauto matically be tra nsferred into the s yste m. 4. By pressing the “OFF” button, it makes a “beep” sound to confirm unit is off. 7 MODE TO DELETE/KEEP THE SAVED IMAGESThis mode is for deleting or keeping all saved images.(The cursor of initial screen is placed under the punctuation of “Exit”.)“Armed” button (DEL) : Delete all the Images.(All Saved images will be deleted and SETUP MODE changes to normal mode –You will see blue or black screen.)“OFF” button(Exit) : Go back to the normal mode(The saved images will be still kept, then SETUP MODE changes to normal mode –You will see blue or black screen)“Emergency” button : Move forward to next mode(Still keeping the saved images, it transfers to the Mode for Changing Date andTi me.) ! Cautions : Beware you will erase all images by pressing the “ARMED” button.Erased images cannot be recovered and they will be totally deleted from the system. 8 MODE TO CHANGING DATE AND TIME When this product is delivered to retail store, it is set for GMT plus 8 hours. Pleaseadjust the time accordingly by using remote control. To do this, follow theseinstructions.“ARMED” b utto n ( ! ) : To increase the Number “OFF” button ( " ): To decrease the Number “EMERGENCY” b utto n ( # ) : To move Cursor * How to change date and time (Example) 2001/01/31/12:00 to 2002/02/30/10:01 Caution : The date and time may appear as 2000/01/01/12:00 in case of long time 1/31/12:00 To change “Minute”, press “ARMED” buttonone time.,And then press “EMERGENCY” button forMode To C hange “hour” 2001/01/31/12:01 To change “Hour”, press “OFF” button2 times.And then press “EMERGENCY” button forMode to change “date”.. 2001/01/31/10:01 To change “Date”, press “OFF” buttonOne time.And then press “EMERGENCY” button for Modeto change “Month”. 2001/01/30/10:01 To change “Month”, press “ARMED” button onetime.And then press “EMERGENCY” button forMode to change “Year”. To change “Year”, press “ARMED” button onetime. 2001/02/30/10:012002/02/30/10:01 A ll set up do ne 9 power failure. Then please reset the date and time as per instructions above.When the time setup is done, please press “EMERGENCY” button to go to Mode toset up for Recording Interval. 10 MODE TO SET UP FOR RECORDING INTERVALThis mode is to set up for the recording intervals when an intruder is sensed oremer genc y sw itc h is pressed. (For exa mple, If yo u se t the recording interval for “4”seconds, it will record a picture every 4 seconds when something is sensed. Thesystem allows you to adjust and set a time interval of 1 ~ 8 seconds.)HOW TO ADJUST THE RECORDING INTERVALOne second is added by pressing “ARMED” button and one second will be reducedby pressing “OFF” button.REC Interval : 04(It is set to 4 seconds when delivered)(EX) : To set to 3 seconds for recording interval, press “OFF” button one time.REC Interval : 03(EX) : To set to 6 seconds for recording interval, press “ARMED” button three times.REC Interval : 06After all set up is done, press “EMERGENCY” b utto n to go to the Mode to set upfor the number of taking picture. 11 MODE TO SET UP FOR THE NUMBER OF TAKINGPICTUREThis mode is to set up for the number of picture taking w hen the “Emergency”button (or Foot Switch) is pressed one time. (For example, If you set up to “3”, itwill take 3 pictures and stop. The System allows you to adjust the number of picturesyo u req uire.REC Picture : 03It is set to 3 pictures when delivered.(Ex) To set up “2” picture, press “OFF” button one time.REC Picture : 02( Set up is done)(Ex) To…

Text truncated - open the document above for the full version.

RC-200311.06MHz POWER (DC 12V BATTERY) S/W UNIT MAIN CONTROL (U1 PIC12C508) Internal Clock 4MHz RF AMP (Q1:2SC4713K) LOOP ANT SAW FILTER (R311M) POWER UNIT (ZD1 : 5V)

FCC ID. : QDYRC-200 File No. : E025R-021 ONETECH Testing & Evaluation Lab. [ Top View of the EUT ] FCC ID. : QDYRC-200 File No. : E025R-021 ONETECH Testing & Evaluation Lab. [ Bottom View of the EUT ]

FCC ID. : QDYRC-200 ONETECH Testing & Evaluation Lab. IDENTIFICATION LABEL: PROPOSED FCC ID LABEL Due to the product size, only the FCC ID shall be permanently affixed to the rear side of the equipment and other information shall be placed in the instruction manual. FCC ID : OSLOKA-510T FCC ID : QDYRC-200 MENIX CO., LTD. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operations. Made in Korea FCC ID AREA

FCC ID. : QDYRC-200 File No. : E025R-021 ONETECH Testing & Evaluation Lab. [ Inside View after Top Cover Open ] FCC ID. : QDYRC-200 File No. : E025R-021 ONETECH Testing & Evaluation Lab. [ Upper Cover Inside View of the Enclosure Cover ] FCC ID. : QDYRC-200 File No. : E025R-021 ONETECH Testing & Evaluation Lab. [ Top View of the Main Board ] FCC ID. : QDYRC-200 File No. : E025R-021 ONETECH Testing & Evaluation Lab. [ Bottom View of the Main Board ]

Operation Description This device is a transmitter for operating of security system (Receiver). It has 3 buttons (or Switch) and it sends 3 different output data. When you press the button (or Switch), data will be come out from U1(PIC12C508)’s 7 th pin And it will be amplified in RFTRQ1(2SC4713K) after SAW(311.062Mhz). It use PCB LOOP Antenna. It uses DC 12V Battery (A23) for its power.
