WorldPenScan WiFi MSE10 User Manual WorldPenScan WiFi is a portable pen scanner, it works with a computer, mobile phone, Tablet or Chromebook to provide data input, lookup and translation functions. ● How to use: 1. Press and hold the power button on the side of the pen scanner for 3 seconds to turn it on. 2. Follow the instructions to set up the WiFi network 3. Connect to computer or mobile phone to use ➢ Connect to mobile phone: If you want to use it with mobile phone, Please use the camera of the mobile phone to scan the QR code on the pen to connect, and then you can start scanning after connecting. ➢ Connecting to computer: If you want to use it with computer, please click the keyboard icon on the bottom right of the QR code on the scanning pen to switch to the manual connection mode, and follow the instructions to open the URL on the computer and enter the Pen ID to connect, and then you can start scanning after connecting. ● Settings: You can swipe from left to right on the screen to switch to the settings. In the settings, you can set the UI language, WiFi, Pen holding mode, automatic sleep and automatic shutdown. ● Warning: FCC This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. CE Bluetooth 4.2 BR+EDR: Operate Frequency Bands : 2402-2480MHz Max. output power: 6.93dBm Bluetooth 4.2 BLE: Operate Frequency Bands : 2402-2480MHz Max. output power: 7.27dBm 2.4G Wifi: Operate Frequency Bands : 2412-2472MHz Max. output power: 11.3dBm EU declaration of conformity Shenzhen TwoMonkeys Technology Co.,Ltd. hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/53/EU.

PenPower Technology Ltd. TCBJ FORM-4 Issued by: TCB Administrator Revision 6 12/06/10 2022.12.16 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, PenPower Technology Ltd. hereby authorize Shenzhen LGT Test Service Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature Name: Kevin Chang/Manager

PenPower Technology Ltd. TCBJ FORM-4 Issued by: TCB Administrator Revision 6 12/06/10 2022.12.16 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (FCC ID: QIC-MSE10) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. required to be submitted with this application be permanently withheld from public review. Please contact me if there is any information you may need. Sincerely, Signature Name: Kevin Chang/Manager

Label & Location

FCC ID:QIC-MSE10 RF EXPOSURE EVALUATION METHOD SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID:QIC-MSE10 BT The Worst Case Mode 2402-2480MHz Detector PEAK GFSK 4.5±1dBm π/4-DQPSK 5±1dBm 8DPSK 5±1dBm Remark: The worst case gain of the antenna is 2.5dBi. 2.5dBi logarithmic terms convert to numeric result is nearly 1.78 2.4024.495.53.5481338921.09983 2.4025.4463.9810717061.23403 2.4025.5863.9810717061.23403 Limit Maximum Peak Conducted Output Power (dBm) frequency (GHz) Tune up Power (dBm) Tune up Power (mW) Result Threshold at which no SAR required is 1.0998≤ 3.0 for 1-g SAR, Separation distance is 5mm. BLE The Worst Case Mode 2402-2480MHz Detector PEAK 2402MHz 4±1dBm 2440MHz 3±1dBm 2480MHz 3±1dBm Remark: The worst case gain of the antenna is 2.5dBi. 2.5dBi logarithmic terms convert to numeric result is nearly 1.78 2.4024.5553.162277660.98023 2.443.8442.5118864320.78473 2.482.2542.5118864320.79113 Limit Maximum Peak Conducted Output Power (dBm) frequency (GHz) Tune up Power (dBm) Tune up Power (mW) Result Threshold at which no SAR required is 0.9802≤ 3.0 for 1-g SAR, Separation distance is 5mm. FCC ID:QIC-MSE10 2.4G wifi The Worst Case Mode 2412-2462MHz Detector PEAK b 8.8±1dBm g 8±1dBm n20 8±1dBm n40 8±1dBm Remark: The worst case gain of the antenna is 2.5dBi. 2.5dBi logarithmic terms convert to numeric result is nearly 1.78 2.4129.739.89.549925862.96633 2.4128.6297.9432823472.46733 2.4128.9497.9432823472.46733 2.4428.7897.9432823472.48264 Limit Maximum Peak Conducted Output Power (dBm) frequency (GHz) Tune up Power (dBm) Tune up Power (mW) Result Threshold at which no SAR required is 2.9663≤ 3.0 for 1-g SAR, Separation distance is 5mm.
