QIIRY1012WGBIndustrial Image Processing Unit

1012WGB User manual © Copyright 2014, Rayence Co. Ltd. All pages of this document contain proprietary and confidential information of Rayence Corporation and are intended for exclusive use by Rayence Corporation personnel or customers. Copying, disclosure to others or other use is prohibited without the express written authorization from Rayence Corporation. Please report any violations of requirement to Rayence Corporation. Attention For improvement of product performance, supplementation, or follow-up of information; the contents of this manual are subject to change without separate prior notice. Please note that our company has neither responsibility for any accidents nor obligation to do free repair service for any damage of the equipment due to user's mistake, which resulted from failure to follow the contents in this manual. Make sure to be familiar with the safety precautions and usage procedures. Also note that the product may slightly differ from the contents of this manual depending on specification. The following marks are used for the effective use of the product in this manual. Attention, consult accompanying documents. This is used to emphasize essential information. Be sure to read this information to avoid incorrect operation. This indicates hazardous situation which, if not heeded, may result in minor or moderate injury to you or others, or may result in machine damage. This indicates a potentially hazardous situation which, if not heeded, could result in death or serious injury to you or others. Federal Law restricts this device to sale by or the order of a radiologist or any other practitioners licensed by the law of the state in which that person practices to use or order the use of the device. Contents 1. Introduction...................................................................................... 1 (1) Overview .......................................................................................... 1 (2) Product features .............................................................................. 1 (3) Product component ........................................................................ 2 (4) Components Description ............................................................... 4 (5) Warning ............................................................................................ 9 (6) Caution ........................................................................................... 11 2. Notes for Using the Detector ........................................................ 13 (1) Handling ......................................................................................... 13 (2) Handle Assembly .......................................................................... 13 (3) Before Exposure............................................................................ 14 (4) During Exposure ........................................................................... 14 (5) Disinfection and Cleaning ............................................................ 14 (6) Others ............................................................................................. 14 3. Technical Features ........................................................................ 15 (1) Mechanical Features ..................................................................... 15 (2) Electrical Features ........................................................................ 15 (3) Environmental requirement ......................................................... 18 (4) PC Requirements .......................................................................... 19 4. Installation ..................................................................................... 20 (1) Program setup ............................................................................... 20 (2) Connection (Manual Trigger) ....................................................... 21 (3) Connection (Auto Trigger) ............................................................ 29 (4) IP set up ......................................................................................... 34 (5) Checking Connection ................................................................... 35 5. Calibration ...................................................................................... 36 (1) General Principle ........................................................................... 36 (2) Calibration ...................................................................................... 38 6. Image Acquisition Test.................................................................. 43 (1) Get Image ....................................................................................... 43 (2) View Images ................................................................................... 44 7. Operation ........................................................................................ 49 (1) Recommend ................................................................................... 49 (2) Switching power on / off ............................................................... 49 (3) Storage ........................................................................................... 49 8. Radio Frequency compliance ........................................................ 50 (1) FCC Notice (U.S.A) ........................................................................ 50 (2) IC Notice (CANADA) ...................................................................... 52 (3) R&TTE Notice (European Union) ................................................. 53 9. Maintenance .................................................................................. 54 (1) Maintenance ................................................................................... 54 (2) Cleaning ......................................................................................... 54 (3) Inspection ....................................…

Text truncated - open the document above for the full version.

Company Letter head. WIFI Channel 12 & 13 Declaration Letter To whom it may concern : We have declared below featured for FCC equipment authorization in regard to 802.11b/g/n channel 12 & 13 operating capability for FCC ID : QIIRY1012WGB Please check Product hardware does not have the capability to operate on channel 12 & 13 Product hardware has the capability to operate on channel 12 & 13. However , these 2 channels will be disabled via software and user will not able to enable these 2 channels Product hardware has the capability to operate on channel 12 & 13. And meeting KDB 594280 D01 requirement. Pls explain detail here. Others Pls explain detail here. Company Name: Rayence Co., Ltd. Address : 1F, 2F, 3F, #402, 14, Samsung 1ro 1-gil, Hwaseong-si, Gyeonggi-do, 445-170, Korea Name / Title : Namyoung Ha / Assistant Manager Signature : Phone : +82‐31‐8015‐6465 Email : [email protected] Date : Sep 1, 2015

Rayence Co., Ltd. 1F, 2F, 3F, #402, 14, Samsung 1ro 1-gil, Hwaseong-si, Gyeonggi-do, South Korea, 445-170 Date: August 25, 2015 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA RE: Request of Confidentiality for FCCID: QIIRY1012WGB To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Rayence Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Rayence Co., Ltd. temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Schematics 3 Part Lists 4 Operation Description SHORT-TERM 5 Internal Photos 6 External Photos 7 Test-Setup Photos 8 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Namyoung Ha Assistant Manager

Rayence Co., Ltd. 1F, 2F, 3F, #402, 14, Samsung 1ro 1-gil, Hwaseong-si, Gyeonggi-do, South Korea, 445-170 Date: August 25, 2015 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA Letter of Authorization We, the undersigned, hereby authorize Harvey Sung of DT&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCCID: QIIRY1012WGB including signing of all documents relating to these matters. Any and all acts carried out by DT&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Rayence Co., Ltd. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Namyoung Ha Assistant Manager

Rayence Co., Ltd. 1F, 2F, 3F, #402, 14, Samsung 1ro 1-gil,Hwaseong-si, Gyeonggi-do, South Korea, 445-170 Date: Sep 1, 2015 Attestation Letter for FCC ID: QIIRY1012WGB To whom it may concern: We hereby declare that The company Rayence Co., Ltd as being manufacturer of model 1012WGB hereby states that the model uses a certified module with 2.4GHz & 5GHz bands (FCC ID: PPD-AR5BHB116 -> QIIRY1012WGB). Modular Test report Information, 1. DTS test report - Tested site: SPORTON International Inc. - Report Date & number: FR080603A 2. NII Test report - Tested site: SPORTON International Inc. - Report Date & number: FR080603B Best regards, Sincerely, Namyoung Ha Assistant Manager Rayence Co., Ltd. 1F, 2F, 3F, #402, 14, Samsung 1ro 1-gil,Hwaseong-si, Gyeonggi-do, South Korea, 445-170 Date: Sep 1, 2015 Attestation Letter for FCC ID: QIIRY1012WGB To whom it may concern: We hereby declare that The company Rayence Co., Ltd product 1012WCA (FCC ID: QIIRY1012WGB) in the RF module (FCC ID: PPD-AR5BHB116) does not use DFS band. Best regards, Sincerely, Namyoung Ha Assistant Manager Rayence Co., Ltd. 1F, 2F, 3F, #402, 14, Samsung 1ro 1-gil, Hwaseong-si, Gyeonggi-do, South Korea, 445-170 Date: Sep 1, 2015 Attestation for MODULE INCORPORATION To whom it may concern: We hereby declare that The company Rayence Co., Ltd declare that the equipment under FCC authorization processing FCC ID : QIIRY1012WGB is incorporate Radio transmitter module which has been authorized by FCC as single modular transmitter, FCC ID : PPD-AR5BHB116. The end product (FCC ID : QIIRY1012WGB) will use the in original certified transmitter module and will keep the original authorization condition except the change in antenna of the module during the final end product assembly. Due to the change in antenna of the radio module, the host product FCC authorization is required. For the host product testing, we leveraged the modular report for the conducted test data because the original operating condition is applied to the end product without any changes such as max. RF output power and frequencies and other radio characteristics. So, we concluded that the conducted test items of the radio module were considered as the same result in the end product. Radio module FCC ID : PPD-AR5BHB116 All other characteristics related with radiated was evaluated in the final end product condition. Best regards, Sincerely, Namyoung Ha Assistant Manager Rayence Co., Ltd. 1F, 2F, 3F, #402, 14, Samsung 1ro 1-gil, Hwaseong-si, Gyeonggi-do, South Korea, 445-170 Date: Sep 1, 2015 Attestation for MODULE INCORPORATION To whom it may concern: We hereby declare that The modular test reports allow for a maximum gain of the PIFA antenna to be 3.0dBi/3.62dBi in the 2.4GHz band and 4.76dBi in the 5GHz bands. This host device uses a PCB antenna with a gain of -4.61dBi in the 2.4GHz band and -7.51dBi in the 5.2GHz bands, therefore the limits used for the output power and power spectral density in the modular test reports allow use of these antennas with equal or lower gain. Radiated spurious emissions were tested for the host system so the different antenna type is covered by the system level tests. Best regards, Sincerely, Namyoung Ha Assistant Manager

FCCID: QIIRY1012WGB IC: 10742A-1012WGB Copyright Ⓒ 2015, DT&C Co., Ltd. Page 1 / 3 View 1 FCCID: QIIRY1012WGB IC: 10742A-1012WGB Copyright Ⓒ 2015, DT&C Co., Ltd. Page 2 / 3 View 2 FCCID: QIIRY1012WGB IC: 10742A-1012WGB Copyright Ⓒ 2015, DT&C Co., Ltd. Page 3 / 3 View 3

FCC ID : QIIRY1012WGB IC : 10742A-1012WGB Copyright Ⓒ 2015, DT&C Co., Ltd. SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase - The FCC label shown is representative of the label that will appear on the radio when in production. Other information may also be included on this label.

FCCID: QIIRY1012WGB IC: 10742A-1012WGB Copyright Ⓒ 2015, DT&C Co., Ltd. View 1 FCCID: QIIRY1012WGB IC: 10742A-1012WGB Copyright Ⓒ 2015, DT&C Co., Ltd. View 2 FCCID: QIIRY1012WGB IC: 10742A-1012WGB Copyright Ⓒ 2015, DT&C Co., Ltd. View 3 FCCID: QIIRY1012WGB IC: 10742A-1012WGB Copyright Ⓒ 2015, DT&C Co., Ltd. View 4 FCCID: QIIRY1012WGB IC: 10742A-1012WGB Copyright Ⓒ 2015, DT&C Co., Ltd. View 5 FCCID: QIIRY1012WGB IC: 10742A-1012WGB Copyright Ⓒ 2015, DT&C Co., Ltd. View 6 FCCID: QIIRY1012WGB IC: 10742A-1012WGB Copyright Ⓒ 2015, DT&C Co., Ltd. View 7 FCCID: QIIRY1012WGB IC: 10742A-1012WGB Copyright Ⓒ 2015, DT&C Co., Ltd. View 8 FCCID: QIIRY1012WGB IC: 10742A-1012WGB Copyright Ⓒ 2015, DT&C Co., Ltd. View 9 <ANT>

Applicant : Rayence Co., Ltd. FCC ID: QIIRY1012WGB TUNE-UP PROCEDURE There are no user accessible adjustments or tuning in this device. All necessary adjustments and tuning are performed during manufacture of the product. Any adjustments or tuning after service or repair are done as part of that process as special equipment is required to perform such adjustments. WLAN - Target Power (Burst Average Power) Band & Mode Modulated Average[dBm] Ant. 1 Ant. 2 MIMO Ch Low Ch Mid Ch High Ch Low Ch Mid Ch High Ch Low Ch Mid Ch High DTS IEEE 802.11b (2.4 GHz) Maximum 15.5 16.5 13.5 16.5 17.0 15.0 19.0 20.0 17.5 Nominal 14.5 15.5 12.5 15.5 16.0 14.0 18.0 19.0 16.5 IEEE 802.11g (2.4 GHz) Maximum 11.0 17.0 10.5 11.0 17.5 11.0 14.0 20.0 14.0 Nominal 10.0 16.0 9.5 10.0 16.5 10.0 13.0 19.0 13.0 IEEE 802.11n HT20 (2.4 GHz) Maximum 10.5 17.0 11.5 11.0 17.0 10.0 14.0 20.0 14.0 Nominal 9.5 16.0 10.5 10.0 16.0 9.0 13.0 19.0 13.0 IEEE 802.11n HT40 (2.4 GHz) Maximum 8.5 13.5 9.0 8.5 13.0 10.0 11.5 16.0 12.5 Nominal 7.5 12.5 8.0 7.5 12.0 9.0 10.5 15.0 11.5 Band & Mode Modulated Average[dBm] Ant. 1 Ant. 2 MIMO Ch Low Ch Mid-1 Ch Mid-2 Ch High Ch Low Ch Mid-1 Ch Mid-2 Ch High Ch Low Ch Mid-1 Ch Mid-2 Ch High Ch Mid Ch Mid Ch Mid U-NII-1 IEEE 802.11a (5.2 GHz) Maximum 11.5 11.5 11.5 12.5 11.5 12.0 12.0 12.5 14.5 14.5 14.5 15.5 Nominal 10.5 10.5 10.5 11.5 10.5 11.0 11.0 11.5 13.5 13.5 13.5 14.5 IEEE 802.11n HT20 (5.2 GHz) Maximum 12.5 12.5 12.5 14.0 12.0 12.0 12.0 12.5 15.5 15.5 15.5 16.5 Nominal 11.5 11.5 11.5 13.0 11.0 11.0 11.0 11.5 14.5 14.5 14.5 15.5 IEEE 802.11n HT40 (5.2 GHz) Maximum 10.0 - - 15.0 8.5 - - 13.0 12.0 - - 17.0 Nominal 9.0 14.0 7.5 - - 12.0 11.0 - - 16.0

Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page66 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page67 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page68 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page69 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page70 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page71 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page72 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page73 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page74 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page75 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page76 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page77 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page78 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page79 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page80 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page81 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Attachment 3. – SAR SYSTEM VALIDATION Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page82 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. SAR System Validation Per FCC KDB 865664 D02v01r01, SAR system validation status should be documented to confirm measurement accuracy. The SAR systems (including SAR probes, system components and software versions) used for this device were validated against its performance specifications prior to the SAR measurements. Reference dipoles were used with the required tissue- equivalent media for system validation, according to the procedures outlined in FCC KDB 865664 D01v01r04 and IEEE 1528-2013.Since SAR probe calibrations are frequency dependent, each probe calibration point was validated at a frequency within the valid frequency range of the probe calibration point, using the system that normally operates with the probe for routine SAR measurements and according to the required tissue-equivalent media. A tabulated summary of the system validation status including the validation date(s), measurement frequencies, SAR probes and tissue dielectric parameters has been included. Table Attachment 3.1 SAR System Validation Summary SAR System Freq. [MHz] Date Probe SN Probe Type Probe CAL. Point PERM. COND. CW Validation MOD. Validation (εr) (σ) Sensi- tivity Probe Linearity Probe Isortopy MOD. Type Duty Factor PAR F 2450 2014-11-03 3933 EX3DV4 2450 Head 37.910 1.815 PASS PASS PASS OFDM N/A PASS F 5200 2014-11-05 3933 EX3DV4 5200 Head 36.160 4.783 PASS PASS PASS OFDM N/A PASS F 2450 2014-11-04 3933 EX3DV4 2450 Body 52.420 2.008 PASS PASS PASS OFDM N/A PASS F 5200 2014-11-06 3933 EX3DV4 5200 Body 48.810 5.112 PASS PASS PASS OFDM N/A PASS NOTE: While the probes have been calibrated for both a CW and modulated signals, all measurements were performed using communication systems calibrated for CW signals only. Modulations in the table above represent test configurations for which the measurement system has been validated per FCC KDB Publication 865664 D01v01r04 for scenarios when CW probe calibrations are used with other signal types.SAR systems were validated for modulated signals with a periodic duty cycle, such as GMSK, or with a high peak to average ratio (>5 dB), such as OFDM according to KDB 865664.

Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page52 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Attachment 2. – Dipole Calibration Data Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page53 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page54 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page55 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page56 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page57 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page58 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page59 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page60 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page61 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page62 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page63 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page64 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page65 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd.

Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WGB Date of issue: Jun. 02. 2015 TRF-RF-601(00)120709 Page2 / 82 Copyright Ⓒ 2015, DT&C Co., Ltd. Table of Contents 1. DESCRIPTION OF DEVICE .......................................................................................................... 5 1.1 Guidance Applied ................................................................................................................... 6 1.2 Device Overview .................................................................................................................... 6 1.3 Nominal and Maximum Output Power Specifications ............................................................ 6 1.4 DUT Antenna Locations ......................................................................................................... 7 1.5 SAR Test Exclusions Applied ................................................................................................. 7 1.6 Power Reduction for SAR ...................................................................................................... 7 1.7 Device Serial Numbers .......................................................................................................... 7 2. INTROCUCTION ........................................................................................................................... 8 3. DESCRIPTION OF TEST EQUIPMENT ....................................................................................... 9 3.1 SAR MEASUREMENT SETUP .............................................................................................. 9 3.2 EX3DV4Probe Specification ................................................................................................ 10 3.3 Probe Calibration Process ................................................................................................... 11 3.3.1E-Probe Calibration .......................................................................................................... 11 3.4 Data Extrapolation ................................................................................................................ 12 3.5 SAM Twin PHANTOM .......................................................................................................... 13 3.6 Device Holder for Transmitters ............................................................................................. 13 3.7 Brain & Muscle Simulation Mixture Characterization ........................................................... 14 3.8 SAR TEST EQUIPMENT ..................................................................................................... 15 4. TEST SYSTEM SPECIFICATIONS ............................................................................................. 16 5. SAR MEASUREMENT PROCEDURE ........................................................................................ 17 5.1 Measurement Procedure ...................................................................................................... 17 6. RF EXPOSURE LIMITS .............................................................................................................. 18 7. FCC MEASUREMENT PROCEDURES...................................................................................... 19 7.1 Measured and Reported SAR .............................................................................................. 1 9 7.2 SAR Testing with 802.11 Transmitters ................................................................................. 19 7.2.1 General Device Setup ..................................................................................................... 19 7.2.2 Initial Test Position Procedure ......................................................................................... 19 7.2.3 2.4 GHz SAR Test Requirements ................................................................................. 20 7.2.4 OFDM Transmission Mode and SAR Test Channel Selection ........................................ 20 7.2.5 Initial Test Configuration Procedure ................................................................................ 20 7.2.6 Subsequent Test Configuration Procedures .................................................................... 20 7.2.7 Simultaneous Transmission of MIMO Chains ................................................................. 21 8. RF CONDUCTED POWERS ....................................................................................................... 22 8.1 WLAN Conducted Powers ................................................................................................... 22 9. SYSTEM VERIFICATION ............................................................................................................ 27 9.1 Tissue Verification ................................................................................................................ 27 9.2 Test System Verification ....................................................................................................... 28 10. SAR TEST RESULTS ............................................................................................................... 29 10.1 Head SAR Results ............................................................................................................. 29 10.2 Body SAR Results .............................................................................................................. 30 10.3 SAR Test Notes .................................................................................................................. 31 11. SAR MEASUREMENT VARIABILITY ....................................................................................... 32 11.1 Measurement Variability ..................................................................................................... 32 11.2 Measurement Uncertainty .................................................................................................. 32 1…

Text truncated - open the document above for the full version.

Report No.: DRRFCC1506-0048 FCC ID: QIIRY1012WCB Date of issue: Jun. 02, 2015 Copyright Ⓒ 2015, DT&C Co., Ltd. SAR Plots  Verification Plots  SAR Test Plots DT&C Co., Ltd. DUT: Dipole 2450 MHz; Type: D2450V2; Serial: D2450V2 - SN:920 Communication System: CW (0); Frequency: 2450 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2450 MHz; σ = 1.843 S/m; ε r = 40.186; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: Probe: EX3DV4 - SN3933; ConvF(7.99, 7.99, 7.99); Calibrated: 9/22/2014; ; Electronics: DAE4 Sn1453 Phantom: ELI v5.0_2013_10_08; Type: QDIVA001BB; Serial: 1223 Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) Test Date: 2015-05-15; Ambient Temp: 21.3; Tissue Temp:21.9 2450 MHz System Verification Area Scan (61x81x1): Interpolated grid: dx=12mm, dy=12mm Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Power Drift = 0.02 dB Peak SAR (extrapolated) = 29.1 W/kg SAR(1 g) = 13.4 W/kg; SAR(10 g) = 6.05 W/kg 0 dB = 20.8 W/kg DT&C Co., Ltd. DUT: Dipole 2450 MHz; Type: D2450V2; Serial: D2450V2 - SN:920 Communication System: CW (0); Frequency: 2450 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2450 MHz; σ = 1.843 S/m; ε r = 40.186; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: Probe: EX3DV4 - SN3933; ConvF(7.99, 7.99, 7.99); Calibrated: 9/22/2014; ; Electronics: DAE4 Sn1453 Phantom: ELI v5.0_2013_10_08; Type: QDIVA001BB; Serial: 1223 Measurement SW: DASY52, Version 52.8 (8); SEMCAD X Version 14.6.10 (7331) Test Date: 2015-05-15; Ambient Temp: 21.3; Tissue Temp:21.9 2450 MHz System Verification Area…
