QIPPVS8Dual-Band CDMA-2000/EV-DO RF Module

 PVS8 Version:00.003 DocId:PVS8_HIO_v00.003 Hardware Interface Overview GENERAL NOTE THE USE OF THE PRODUCT INCLUDING THE SOFTWARE AND DOCUMENTATION (THE "PROD- UCT") IS SUBJECT TO THE RELEASE NOTE PROVIDED TOGETHER WITH PRODUCT. IN ANY EVENT THE PROVISIONS OF THE RELEASE NOTE SHALL PREVAIL. THIS DOCUMENT CON- TAINS INFORMATION ON CINTERION PRODUCTS. THE SPECIFICATIONS IN THIS DOCUMENT ARE SUBJECT TO CHANGE AT CINTERION'S DISCRETION. CINTERION WIRELESS MODULES GMBH GRANTS A NON-EXCLUSIVE RIGHT TO USE THE PRODUCT. THE RECIPIENT SHALL NOT TRANSFER, COPY, MODIFY, TRANSLATE, REVERSE ENGINEER, CREATE DERIVATIVE WORKS; DISASSEMBLE OR DECOMPILE THE PRODUCT OR OTHERWISE USE THE PRODUCT EXCEPT AS SPECIFICALLY AUTHORIZED. THE PRODUCT AND THIS DOCUMENT ARE PROVIDED ON AN "AS IS" BASIS ONLY AND MAY CONTAIN DEFICIENCIES OR INADEQUACIES. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, CINTERION WIRELESS MODULES GMBH DIS- CLAIMS ALL WARRANTIES AND LIABILITIES. THE RECIPIENT UNDERTAKES FOR AN UNLIMITED PERIOD OF TIME TO OBSERVE SECRECY REGARDING ANY INFORMATION AND DATA PRO- VIDED TO HIM IN THE CONTEXT OF THE DELIVERY OF THE PRODUCT. THIS GENERAL NOTE SHALL BE GOVERNED AND CONSTRUED ACCORDING TO GERMAN LAW. Copyright Transmittal, reproduction, dissemination and/or editing of this document as well as utilization of its con- tents and communication thereof to others without express authorization are prohibited. Offenders will be held liable for payment of damages. All rights created by patent grant or registration of a utility model or design patent are reserved. Copyright © 2012, Cinterion Wireless Modules GmbH Trademark Notice Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. CDMA2000 is a registered certification mark of the Telecommuni- cations Industry Association. All other registered trademarks or trademarks mentioned in this document are property of their respective owners. PVS8_HIO_v00.003Page 2 of 362012-06-27 Confidential / Preliminary PVS8 Hardware Interface Overview 2  Document Name: PVS8 Hardware Interface Overview Version: 00.003 Date: 2012-06-27 DocId: PVS8_HIO_v00.003 Status Confidential / Preliminary PVS8 Hardware Interface Overview Contents 36 PVS8_HIO_v00.003Page 3 of 362012-06-27 Confidential / Preliminary  Contents 1Introduction ................................................................................................................. 6 1.1Related Documents ........................................................................................... 6 1.2Terms and Abbreviations ................................................................................... 6 1.3Regulatory and Type Approval Information ....................................................... 9 1.3.1Directives and Standards ...................................................................... 9 1.3.2SAR requirements specific to portable mobiles .................................. 11 1.3.3SELV Requirements ........................................................................... 12 1.3.4Safety Precautions .............................................................................. 12 2Product Concept ....................................................................................................... 14 2.1Key Features at a Glance ................................................................................ 14 2.2PVS8 System Overview ................................................................................... 16 3Application Interface................................................................................................. 17 3.1Operating Modes ............................................................................................. 18 3.2Power Supply ................................................................................................... 19 3.3USB Interface................................................................................................... 20 3.4Serial Interface ASC0 ...................................................................................... 21 3.5Analog Audio Interface..................................................................................... 23 3.6Digital Audio Interface ...................................................................................... 23 4GPS Receiver............................................................................................................. 24 5Antenna Interfaces.................................................................................................... 25 5.1CDMA Antenna Interface ................................................................................. 25 5.1.1Antenna Installation ............................................................................ 26 5.2GPS Antenna Interface .................................................................................... 27 6Mechanics, Mounting and Packaging ..................................................................... 29 6.1Mechanical Dimensions of PVS8 ..................................................................... 29 7Sample Application................................................................................................... 31 8Reference Approval .................................................................................................. 33 8.1Reference Equipment for Type Approval ......................................................... 33 8.2Compliance with FCC and IC Rules and Regulations ..................................... 34 9Appendix.................................................................................................................... 35 9.1List of Parts and Accessories........................................................................... 35 PVS8 Hardware Interface Overview Ta b l e s 36 PVS8_HIO_v00.003Page 4 of 362012-06-27 Confidential / Preliminary  Tables Table 1:Directives ...…

Text truncated - open the document above for the full version.

Cinterion Wirefess Modules GmbH· SIemensdamm 50 • 13629 Bertln • Germany Name Th.orsten Liebig Federal Communication Commission Department Manager Approval Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Phone +49 30 31102-8241 Fax +493031102-8305 Columbia, MD 21048 E-Mail [email protected] Your letter 01 Our reference Date 30 May 2012 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission's Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, Cinterion requests confidentiality for the following products: FCC 1'0 Number Product Title/Model QIPPVS8 Cinterion Wireless Module PVS8 For the product stated above, we request that the following information be held confidential: 1. Circuit diagrams, BOM, and PCBs submitted as Equipment Authorization Electronic Filing attachment: "schematics". 2. Block diagram submitted as Equipment Authorization Electronic Filing attachment: "blockdiagram" . 3. Operational' description submitted as Equipment Authorization Electronic Filing attachment: "operational description" (highly technical / not addressed to the public) 4. Tune Up Information submitted as Equipment Authorization Electronic Filing attachment: "Tune Up Info" The above exhibits contain Cinterion trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our mobile handset. This material is not customarily available to the general pubHc and we request that it be withheld from public inspection. If you have any questions, please feel free to contact me at the address shown below. Sincerely, ___ ~~ Thorsten liebig C ' . ApprovalManager / jf!UO~ U ~~ Registered office: Managing d"ectors: Commercial register. Reg. no .: Cinterion Wireless Modules GmbH Norbert Muhrer, Sebastian Gallois Amtsgericht München. HRB 172715 St.-Martin-Straße 53 WEEE-Reg.-Nr. OE 58893809 81669 München Germany

-= Cintenon Wireless Modules GmbH· Siemensdamm 50· 13629 Berlin • Germany Name Thorsten Liebig Department Manager Approval Federal Communication Commission 7435 Oakland Mills Road Phone +49 30 31102-8241 Columbia, MD 21048 Fax +493031102-8141 E-Mail [email protected] Your letter of Our reference Date 08 June 2012 Request for Single Modular Approval for QIPPVS8 To Whom It May Concern: We, Cinterion Wireless Modules GmbH, hereby requests for single modular approval ace to FCC KOB 996369 "Transmitter Module Equipment Authorization Guide" BrandfTrade/Manufacturer's name: Cinterion Wireless Module PVS8 Model name: PVS8 FCC certification number: QIPPVS8 Cinterion confirms that the product complies with the requirements ace to FCC KOB 996369 identified below: 1. The modular transmitter has its own RF shielding. 2. The module has buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal 3. The module has its own power supply regulation on the module. 5. The modular transmitter is tested in a stand-alone configuration. 6. The modular transmitter is labelled with its own FCC 10 number. Labelling ,instructions for host devices are stated in the integration manual. 7. The modular transmitter is comply with any specific rul'es or operating requirements that ordinarily apply to a complete transmitter and the manufacturer provide adequate instructions along with the module to explain any such requirements 8. The modular transmitter complies with RF exposure requirements for mobile and fixed host devices in its final configuration. fJ Thorsten Liebig (Manager Approval) Registered office: Managing directors: Commercial register, Reg. no.: Cinterion Wireless Modules GmbH Norlbert Muhrer. Sebastien Gallois Amtsgericht München. HRB 172715 SI. -Martin-Slraße 53 WEEE-Reg.-Nr. OE 58893809 81569 München Germany

Cinterion Wireless Modules GmbH· Siemensdamm 50 • 13629 Berlin • Germany Federal Communication Commission Name Thorsten Liebig Equipment Authorization Division, Application Department Manager Approval Processing Branch 7435 Oakland Mills Road Phone +493031102-8241 Columbia, MD 21048 Fax +493031102-8305 E-Mail [email protected] Your letter 01 Our relerence Date 30 May 2012 Request for Short Term Confidentiality FCC ID: QIPPVS8 To Whom It May Concern: In accordance w,ith §0.459(d) of CFR 47 and Public Notice DA 04-1705, Cinterion requests The following item 1. User Guide / Installation Manual 2. Internal Photographs be held short term confidential until 31 sI of July 2012 These items contain detailed system and equipment description and related information about the product which Cinterion considers to be proprietary, confidential and a custom design wh ich otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Cinterion also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Sincerely Thorsten Liebig Manager Approval Registered office: Managing directers: Commercial register, Rag. no.: Cinterion Wireless Modules GmbH Nerbert Muhrer, Sebaslien Gallois Amtsgericht MOncnen, HRB 17271 5 St .-Martln- Straße 53 WEEE-Reg.-Nr. OE 56693609 61669 München Germany

Cinterion Wireless Module PVS8 PVS8 Top side PVS8 Bottom Side

Cinterion Wireless Module PVS8 Label PVS8 Label PVS8 Label location

Cinterion Wireless Module PVS8 PVS8 Top side PVS8 Bottom Side

7 layers AG Aufsichtsratsvorsitzender Registergericht registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Ralf Mertens USt-IdNr VAT No.: Phone: +49 (0) 2102 749 0 Vorstand Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H.-J. Meckelburg TAX No. 147/5869/0385 www.7Layers.com Mr. René Houx 2012-07-03 Phone +49 (0) 2102 749 318 Fax +49 (0) 2102 749 350 e-Mail: [email protected] Maximum Permissible Exposure for product: Cinterion Wireless Module PVS8 Dear Mr. Liebig, please find enclosed your Maximum Permissible Exposure calculations for the Cinterion Wireless Module PVS8. Best Regards René Houx (Project Manager) Cinterion Wireless Modules GmbH Mr. Thorsten Liebig Siemensdamm 50 13629 Berlin Germany MDE_CINTE_1209 - 2 - Maximum Permissible Exposure (as specified in Table 1B of 47 CFR 1.1310 – Limits for Maximum Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure) Frequency range (MHz)Power density (mW/cm²) 300 – 1500 f/1500 1,500 – 100000 1.0 General Comment Calculations 850 MHz band Maximum average output power at Antenna terminal: 23.10 dBm (Max RMS power = 23.10 dBm – 0.00 dBm duty cycle) Maximum output power at Antenna terminal: 29.30 dBm (Max peak power = 29.30 dBm) Prediction distance R: 20 cm Prediction frequency: 824.70 MHz MPE limit S: 0.5498 mW/cm² Equation OET bulletin 65, page 18, edition 97-01: S = P*G / (4πR²) S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the centre of radiation of the antenna Maximum permissible antenna gain (Table 1B of 47 CFR 1.1310): 11.31 dBi Maximal permissible antenna gain considering output power limitation of 7 Watts ERP (FCC §22.931). G=10*log(7000)-29.30+2.15 11.30 dBi Prediction The maximum allowed MPE value of 0. 5498 mW/cm² will be reached in a distance of 20 cm in case that an antenna with an antenna gain of 11.31 dBi is used. Considering the max output power of 7 Watts ERP (FCC §22.931) for mobile stations the maximum antenna gain is 11.30 dBi, which is lower than 11.31 dBi. For mobile stations the antenna gain is limited to 11.30dBi in accordance to the FCC regulations. - 3 - Calculations 1900 MHz band Maximum average output power at Antenna terminal: 23.72 dBm (Max RMS power = 23.72 dBm – 0.00 dBm duty cycle) Maximum output power at Antenna terminal: 28.66 dBm (Max peak power = 29.66 dBm) Prediction distance R: 20 cm Prediction frequency: 1880.00 MHz MPE limit S: 1 mW/cm² Equation OET bulletin 65, page 18, edition 97-01: S = P*G / (4πR²) S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the centre of radiation of the antenna Maximum permissible antenna gain (Table 1B of 47 CFR 1.1310): 13.29 dBi Maximum permissible antenna gain for mobile / portable stations: 4.40 dBi (Considering 2 Watts EIRP FCC §24.235: G=10*log(2000)-29.66) Prediction The maximum allowed MPE value of 1 mW/cm² will be reached in a distance of 20 cm in case that an antenna with an antenna gain of 13.29 dBi is used. Considering the max output power of 2 Watts EIRP (FCC §24.235) for mobile / portable stations the maximum antenna gain is 4.40 dBi, which is lower than 13.29 dBi. For mobile and portable stations the antenna gain is limited to 4.40 dBi in accordance with the FCC regulations.

Final Report on Cinterion Wireless Module PVS8 MDE_CINTE_1209_FCC22a_V1 acc. Title 47 CFR chapter I part 22 subpart H Report Reference: June 27, 2012 Date: Test Laboratory: 7Layers AG Borsigstr. 11 40880 Ratingen Germany Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7Layers AG Aufsichtsratsvorsitzender Registergericht registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Ralf Mertens USt-IdNr  VAT No.: Phone: +49 (0) 2102 749 0 Vorstand Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H.-J. Meckelburg TAX No. 147/5869/0385 www.7Layers.com Reference: MDE_CINTE_1209_FCC22a_V1 acc. Title 47 CFR chapter I part 22 subpart H 1Administrative Data 1.1Project Data Mr. Pascal Jordan Project Responsible: 2012/06/27 Date Of Test Report: 2012/03/13 Date of first test: 2012/05/24 Date of last test: 1.2Applicant Data Company Name: Cinterion Wireless Modules GmbH Siemensdamm 50 Street: 13629 Berlin City: Germany Country: Contact Person: Mr. Thorsten Liebig Manager Approval Function: Approvals & Standardization Department: +49 (30) 31102-8241 Phone: +49 (160) 7074027 Mobile: [email protected] E-Mail: 1.3Test Laboratory Data The following list shows all places and laboratories involved for test result generation: 7 layers DE Company Name : 7 layers AG Street : Borsigstrasse 11 City : 40880 Ratingen Country : Germany Contact Person : Mr. Michael Albert Phone : +49 2102 749 201 Fax : +49 2102 749 444 E Mail : [email protected] Laboratory Details Accreditation InfoLab IDIdentificationResponsible DAkkS-Registration no. D-PL-12140-01-01Radiated Emissions Lab 1Mr. Robert Machulec Mr. Andreas Petz DAkkS-Registration no. D-PL-12140-01-01Radio Lab Lab 2Mr. Robert Machulec Mr. Andreas Petz Page 2 of 91 Reference: MDE_CINTE_1209_FCC22a_V1 acc. Title 47 CFR chapter I part 22 subpart H 1.4Signature of the Testing Responsible Marco Kullik responsible for tests performed in: Lab 1, Lab 2 1.5Signature of the Accreditation Responsible Accreditation scope responsible person responsible for Lab 1, Lab 2 Page 3 of 91 Reference: MDE_CINTE_1209_FCC22a_V1 acc. Title 47 CFR chapter I part 22 subpart H 2Test Object Data 2.1General OUT Description The following section lists all OUTs (Object's Under Test) involved during testing. OUT: PVS8 Type / Model / Family: Cinterion Wireless Module PVS8 Product Category: Module Manufacturer: Cinterion Wireless Modules GmbH Company Name: Street: Siemensdamm 50 City: 13629 Berlin Country: Germany Contact Person: Mr. Thorsten Liebig Function: Manager Approval Department: Approvals & Standardization Phone: +49 (30) 31102-8241 Mobile: +49 (160) 7074027 E-Mail: [email protected] ValueParameter name Parameter List: not specified (dBi) Antenna gain 1900 band not specified (dBi) Antenna gain 850 band 4.2 (V) DC Power Supply 1013 (824.7MHz) for BC0, 1175 (1908.75MHz) for BC1highest channel 384 (836.5MHz) for BC0, 25 (1851.25MHz) for BC1lowest channel 777 (848.3MHz) for BC0, 600 (1880.0MHz) for BC1mid channel OUT: PXS8 Type / Model / Family: Cinterion Wireless Module PXS8 Product Category: Module Manufacturer: Cinterion Wireless Modules GmbH Company Name: Street: Siemensdamm 50 City: 13629 Berlin Country: Germany Contact Person: Mr. Thorsten Liebig Function: Manager Approval Department: Approvals & Standardization Phone: +49 (30) 31102-8241 Mobile: +49 (160) 7074027 E-Mail: [email protected] ValueParameter name Parameter List: Parameter for Scope FCC_v2: not specified (dBi) Antenna gain 1900 band not specified (dBi) Antenna gain 850 band 4.2 (V) DC Power Supply Page 4 of 91 Reference: MDE_CINTE_1209_FCC22a_V1 acc. Title 47 CFR chapter I part 22 subpart H 251 (848.8MHz) for GSM850, 810 (1909.8MHz) for GSM1900, 4233 (846.6MHz) for FDD5, 9538 (1907.6MHz) for FDD2, 1013 (824.7MHz) for BC0, 1175 (1908.75MHz) for BC1 highest channel 128 (824.2MHz) for GSM850, 512 (1850.2MHz) for GSM1900, 4132 (826.4MHz) for FDD5, 262 (1852.4MHz) for FDD2, 384 (836.5MHz) for BC0, 25 (1851.25MHz) for BC1 lowest channel 190 (836.6MHz) for GSM850, 661 (1880.0MHz) for GSM1900, 4183 (836.6MHz) for FDD5, 9400 (1880MHz) for FDD2, 777 (848.3MHz) for BC0, 600 (1880.0MHz) for BC1 mid channel 2.2Detailed Description of OUT Samples Sample : b01 OUT Identifier PXS8 Sample Description Sample #02 Serial No. S30960-S2600-A100-1 HW Status B2 SW Status Rev. 00.100 Date of Receipt 2012/03/02 Low VoltageLow Temp. 3.3 V-10 °C High Temp.High Voltage 4.2 V+55 °C Normal Temp.Nominal Voltage 4.2 V+23 °C Sample : PVS8 OUT Identifier PVS8 Sample Description PVS8 sample #01 HW Status B2 SW Status REVISION 00.120 Low VoltageLow Temp. 3.3 V-10 °C High Temp.High Voltage 4.2 V+55 °C Normal Temp.Nominal Voltage 4.2 V+23 °C Page 5 of 91 Reference: MDE_CINTE_1209_FCC22a_V1 acc. Title 47 CFR chapter I part 22 subpart H 2.3OUT Features Features for OUT:PVS8 Allowed ValuesDesignationDescriptionSupported Value(s) Features for scope: FCC_v2 AC The OUT is powered by or connected to AC Mains CDMA2000 _800 EUT supports CDMA2000 in band 824.7MHz - 848.3MHz (BC0) CDMA2000 _1900 EUT supports CDMA2000 in band 1851.25MHz - 1908.75MHz (BC1) CDMA2000 _EV- DO_800 EUT supports CDMA2000 EV-DO in band 824.7MHz - 848.3MHz (BC0) CDMA2000 _EV- DO_1900 EUT supports CDMA2000 EV-DO in band 1851.25MHz - 1908.75MHz (BC1) DC The OUT is powered by or connected to DC Mains PantC permanent fixed antenna connector, which may be built-in, designed as an indispensable part of the equipment Features for OUT:PXS8 Allowed ValuesDesignationDescriptionSupported Value(s) Features for scope: FCC_v2 AC The OUT is powered by or connected to AC Mains CDMA2000 _800 EUT supports CDMA2000 in band 824.7MHz - 848.3MHz (BC0) CDMA2000 _1900 EUT supports CDMA2000 in band 1851.25MHz - 1908.75MHz (BC1) CDMA2000 _EV- DO_800 EUT supports CDMA2000 EV-DO in band 824.7MHz - …

Text truncated - open the document above for the full version.

Final Report on Cinterion Wireless Module PVS8 MDE_CINTE_1209_FCC24a_V1 acc. Title 47 CFR chapter I part 24 subpart E Report Reference: June 27, 2012 Date: Test Laboratory: 7Layers AG Borsigstr. 11 40880 Ratingen Germany Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7Layers AG Aufsichtsratsvorsitzender Registergericht registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Ralf Mertens USt-IdNr  VAT No.: Phone: +49 (0) 2102 749 0 Vorstand Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H.-J. Meckelburg TAX No. 147/5869/0385 www.7Layers.com Reference: MDE_CINTE_1209_FCC24a_V1 acc. Title 47 CFR chapter I part 24 subpart E 1 Administrative Data 1.1 Project Data Mr. Pascal Jordan Project Responsible: 2012/06/27 Date Of Test Report: 2012/03/13 Date of first test: 2012/06/04 Date of last test: 1.2 Applicant Data Company Name: Cinterion Wireless Modules GmbH Siemensdamm 50 Street: 13629 Berlin City: Germany Country: Contact Person: Mr. Thorsten Liebig Manager Approval Function: Approvals & Standardization Department: +49 (30) 31102-8241 Phone: +49 (160) 7074027 Mobile: [email protected] E-Mail: 1.3Test Laboratory Data The following list shows all places and laboratories involved for test result generation: 7 layers DE Company Name : 7 layers AG Street : Borsigstrasse 11 City : 40880 Ratingen Country : Germany Contact Person : Mr. Michael Albert Phone : +49 2102 749 201 Fax : +49 2102 749 444 E Mail : [email protected] Laboratory Details Accreditation InfoLab IDIdentificationResponsible DAkkS-Registration no. D-PL-12140-01-01Radiated Emissions Lab 1Mr. Robert Machulec Mr. Andreas Petz DAkkS-Registration no. D-PL-12140-01-01Radio Lab Lab 2Mr. Robert Machulec Mr. Andreas Petz Page 2 of 90 Reference: MDE_CINTE_1209_FCC24a_V1 acc. Title 47 CFR chapter I part 24 subpart E 1.4Signature of the Testing Responsible Marco Kullik responsible for tests performed in: Lab 1, Lab 2 1.5Signature of the Accreditation Responsible Accreditation scope responsible person responsible for Lab 1, Lab 2 Page 3 of 90 Reference: MDE_CINTE_1209_FCC24a_V1 acc. Title 47 CFR chapter I part 24 subpart E 2 Test Object Data 2.1 General OUT Description The following section lists all OUTs (Object's Under Test) involved during testing. OUT: PVS8 Type / Model / Family: Cinterion Wireless Module PVS8 Product Category: Module Manufacturer: Cinterion Wireless Modules GmbH Company Name: Street: Siemensdamm 50 City: 13629 Berlin Country: Germany Contact Person: Mr. Thorsten Liebig Function: Manager Approval Department: Approvals & Standardization Phone: +49 (30) 31102-8241 Mobile: +49 (160) 7074027 E-Mail: [email protected] ValueParameter name Parameter List: not specified (dBi) Antenna gain 1900 band not specified (dBi) Antenna gain 850 band 4.2 (V) DC Power Supply 1013 (824.7MHz) for BC0, 1175 (1908.75MHz) for BC1highest channel 384 (836.5MHz) for BC0, 25 (1851.25MHz) for BC1lowest channel 777 (848.3MHz) for BC0, 600 (1880.0MHz) for BC1mid channel OUT: PXS8 Type / Model / Family: Cinterion Wireless Module PXS8 Product Category: Module Manufacturer: Cinterion Wireless Modules GmbH Company Name: Street: Siemensdamm 50 City: 13629 Berlin Country: Germany Contact Person: Mr. Thorsten Liebig Function: Manager Approval Department: Approvals & Standardization Phone: +49 (30) 31102-8241 Mobile: +49 (160) 7074027 E-Mail: [email protected] ValueParameter name Parameter List: Parameter for Scope FCC_v2: not specified (dBi) Antenna gain 1900 band not specified (dBi) Antenna gain 850 band 4.2 (V) DC Power Supply Page 4 of 90 Reference: MDE_CINTE_1209_FCC24a_V1 acc. Title 47 CFR chapter I part 24 subpart E 251 (848.8MHz) for GSM850, 810 (1909.8MHz) for GSM1900, 4233 (846.6MHz) for FDD5, 9538 (1907.6MHz) for FDD2, 1013 (824.7MHz) for BC0, 1175 (1908.75MHz) for BC1 highest channel 128 (824.2MHz) for GSM850, 512 (1850.2MHz) for GSM1900, 4132 (826.4MHz) for FDD5, 262 (1852.4MHz) for FDD2, 384 (836.5MHz) for BC0, 25 (1851.25MHz) for BC1 lowest channel 190 (836.6MHz) for GSM850, 661 (1880.0MHz) for GSM1900, 4183 (836.6MHz) for FDD5, 9400 (1880MHz) for FDD2, 777 (848.3MHz) for BC0, 600 (1880.0MHz) for BC1 mid channel Page 5 of 90 Reference: MDE_CINTE_1209_FCC24a_V1 acc. Title 47 CFR chapter I part 24 subpart E 2.2 Detailed Description of OUT Samples Sample : a01 OUT Identifier PXS8 Sample Description Sample #01 Serial No. S30960-S2600-A100-1 HW Status B2 SW Status Rev. 00.100 Date of Receipt 2012/02/15 Low VoltageLow Temp. 3.3 V-10 °C High Temp.High Voltage 4.2 V+55 °C Normal Temp.Nominal Voltage 4.2 V+23 °C Sample : b01 OUT Identifier PXS8 Sample Description Sample #02 Serial No. S30960-S2600-A100-1 HW Status B2 SW Status Rev. 00.100 Date of Receipt 2012/03/02 Low VoltageLow Temp. 3.3 V-10 °C High Temp.High Voltage 4.2 V+55 °C Normal Temp.Nominal Voltage 4.2 V+23 °C Sample : e01 OUT Identifier PXS8 Sample Description Sample #05 Serial No. S30960-S2600-A100-1 HW Status B2 SW Status Rev. 00.100 Date of Receipt 2012/06/04 Low VoltageLow Temp. 3.3 V-10 °C High Temp.High Voltage 4.2 V+55 °C Normal Temp.Nominal Voltage 4.2 V+23 °C Page 6 of 90 Reference: MDE_CINTE_1209_FCC24a_V1 acc. Title 47 CFR chapter I part 24 subpart E Sample : PVS8 OUT Identifier PVS8 Sample Description PVS8 sample #01 HW Status B2 SW Status REVISION 00.120 Low VoltageLow Temp. 3.3 V-10 °C High Temp.High Voltage 4.2 V+55 °C Normal Temp.Nominal Voltage 4.2 V+23 °C Page 7 of 90 Reference: MDE_CINTE_1209_FCC24a_V1 acc. Title 47 CFR chapter I part 24 subpart E 2.3 OUT Features Features for OUT: PVS8 Allowed ValuesDesignationDescriptionSupported Value(s) Features for scope: FCC_v2 AC The OUT is powered by or connected to AC Mains CDMA2000 _800 EUT supports CDMA2000 in band 824.7MHz - 848.3MHz (BC0) CDMA2000 _1900 EUT supports CDMA2000 in band 1851.25…

Text truncated - open the document above for the full version.

Test Laboratory: Borsigstr. 11 Germany 7Layers AG 40880 Ratingen Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7Layers AG Aufsichtsratsvorsitzender Registergericht registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Ralf Mertens USt-IdNr VAT No.: Phone: +49 (0) 2102 749 0 Vorstand Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H.-J. Meckelburg TAX No. 147/5869/0385 www.7Layers.com Photo Report on Test Setups Report Reference: MDE_CINTE_1209_FCC_Photo_Setups_22-24 Test report Reference: MDE_CINTE_1209_FCC_Photo_Setups_22-24 Page 2 of 2 Photo 1: Test setup for radiated measurements (Enclosure, fully-anechoic chamber, 30 MHz – 10/20 GHz §22/24)
