QIXFOXENGSM/GPRS/GPS-Tracking-Unit

THIS DOCUMENT IS AVAILABLE AT HTTP://WWW.FALCOM.DE/ . FOX-IN/FOX-EN Hardware manual Version: 1.0.8; Modified: Tuesday 11 September 2012 FOX-IN/EN HARDWARE MANUAL VERSION 1.0.8 Table of contents 1 INTRODUCTION.................................................................................6 1.1 General......................................................................................................................6 1.2 Circuit concept.........................................................................................................7 1.3 Related documents..................................................................................................8 2 SECURITY.......................................................................................9 2.1 General information.................................................................................................9 2.2 Exposure to RF energy............................................................................................9 2.3 Driving.......................................................................................................................9 2.4 Electronic devices..................................................................................................10 2.5 Vehicle electronic equipment...............................................................................10 2.6 Medical electronic equipment...............................................................................10 2.7 Aircraft.....................................................................................................................10 2.8 Children...................................................................................................................10 2.9 Blasting areas.........................................................................................................10 2.10 Potentially explosive atmospheres....................................................................10 2.11 Safety for Lithium-Polymer Batteries................................................................11 2.11.1 Safety precautions while charging the battery..................................................11 2.11.2 Safety precautions while discharging Lithium-Polymer battery.......................11 2.12 Non-ionizing radiation.........................................................................................11 3 SAFETY STANDARDS.......................................................................12 4 TECHNICAL DATA...........................................................................13 4.1 Product features.....................................................................................................13 4.1.1 Power consumption for FOX-IN/EN(CH-B1)......................................................15 4.1.2 Operating temperatures......................................................................................15 4.1.3 GSM/GPRS engine features..............................................................................16 4.1.4 GPS engine features..........................................................................................17 4.2 NMEA data message..............................................................................................18 5 FOX-IN/EN APPLICATION INTERFACE................................................19 5.1 Power supply..........................................................................................................19 5.1.1 Power supply pins (1 and 2) on the 8-pin connector..........................................19 5.1.2 Automatic shutdown...........................................................................................19 5.1.3 Power saving......................................................................................................20 5.2 Determining the External Equipment Type.........................................................20 6 HARDWARE INTERFACES..................................................................21 6.1 8pin double row connector, pin assignments.....................................................22 6.1.1 8-pin connector pinout........................................................................................22 6.1.2 Special pin description (Pins 4, 5, 6)..................................................................23 6.1.2.1 How to use I/O pins (4, 5, 6) as analog inputs.......................................................................23 6.1.2.2 How to use I/O pins (4, 5, 6) as digital Inputs.......................................................................25 6.1.2.3 How to use I/O pins (4, 5, 6) as digital outputs......................................................................26 This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 2 of 41 FOX-IN/EN HARDWARE MANUAL VERSION 1.0.8 6.1.2.4 How to use IGN pin(pin 3)......................................................................................................27 6.1.2.5 Serial Port 0 - Serial communication signals (RxA and TxA).................................................28 6.2 Inserting the SIM card into the SIM holder inside the device............................28 6.2.1 How to enter the PIN of the inserted SIM card:..................................................29 6.3 LED indicators........................................................................................................30 6.4 Mounting.................................................................................................................30 6.5 10pin mini-USB (option)........................................................................................31 6.5.1 FOX-IN/EN-AU (AU-option)................................................................................31 6.5.2 FOX-IN/EN-US (US option)................................................................................33 6.5.2.1 I/O-Dongle (IOBOX…

Text truncated - open the document above for the full version.

€FnLcoM WIRELESS COMMUNICATIONS GMBH Falcom Wireless Communications GmbH Federal Communications Commission Authorization and Evaluation Division Eq uipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 7t16t2012 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC lD: QIXFOXEN including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C. 862. Sincerely, 6HALCoM WIRELESS COMMUNICATIONS GMBH Gewerbering 6 . 98704 Langewiesen Fon:03677 I 8A42-0.Fax 03677 I 8042-215 lnlernel: www.falcom.de Dr. Gerdld Buch Manager Hardware Department Geschöftsf ührer: Jeon-Luc Guerin Prokurist: Chorles Choussonnier Tel.: 03677 /80 42-0 Fox:03677 /BO 42-21 5 www.folcom.de Anschrift: Amtsgericht Jeno Gewerbering 6 HRB 506246 98704 TANGEWIESEN Sitz: Longewiesen Steuer-Nr. : 1 56 / 1 OB /04443 USt-lD: DE275519395

.-. L I FI-ALCOM WIRfLESS COMMUNICATIONS GMBH Falcom Wireless Communications GmbH Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 711612012 Req uesi for Cortfidentia lity Company name: Falcom Wireless Gommunications GmbH FCC lD: QIXFOXEN FGG Part 15 Gertification Gentlemen, ln accordance with CFR 47 S 0.459, Falcom hereby requests confidentiality of following attachments: (1 ) schematic diagrams, (2) detailed block diagrams, (3) detailed operational descriptions, (4) parts lists. These documents contain detailed system and equipment description and related information about the product which Falcom considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, Falcom considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. äFaLCoM WIRELESS COMMUNICATIONS GMBH Gewerbering 6 . 98704 Langewieser [:on: 03677 I 8042-0.Fü(.03677 I 8042-215 lnternet: www.{alcom.de Sincerely, Geschöftsf ührer: Jeon-Luc Guerin Prokurist: Chorles Choussonnier Iel.:03677 /BO 42-0 Fox:.03677 lBO 42-21 5 www.folcom.de Anschrift: Amtsgericht.Jeno Gewerbering 6 HRB 506246 98704LANGEWIESEN Silz:Longewiesen Steuer-Nr. : 1 56 / 1 0B / 0 4443 USt-lD: DE2755l9395

.-. L I FFALCOM WIRELESS COMMUNICATIONS GMBH Falcom W ireless Communications GmbH Federal Communications Commission Eq uipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 7t16t2012 Request for $hort Term Confidentiality, intended to allow importation I d istribution of a utho rized eq u ipment wh i le maintain ing confidentiality hefore product launeh Gompany name: Falcom Wireless Communication GmbH FGG lD: QIXFOXEN FGG Part 15 Certification Gentlemen, ln accordance with 0.457 and 0.459 of CFR 47 , Falcom hereby requests for 'Short Term Confidentiality' of all o Extemal Photos, . Test Setup Photos, o User's Manual, o lnternal Photos, r Parts / Tune-Up Procedures attachments for the subject application. These documents contain detailed system and equipment description and related information about the product which Falcom considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, Falcom considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. trnALCoM \ryIRELESS COMMUNICATIONS GMBH Gewerbering 6 .98704 Langewiesen Fon: 03677 / 8042-0 . Fax: 03677 I 8042-213 lnternet: rw"w.falcom.de Manager Hardware Department Geschöftsführer: Jeon-Luc Guerin Prokurist: Chorles Choussonnier Iel.:03677 /80 42-O Fox:03677 /BO 42-21 5 www.folcom.de Anschrift: Amtsgericht Jeno Gewerbering 6 HRB 506246 98704 LANGEWIESEN Sitz: Longewiesen Steuer-Nr. : 1 56 / 1 Og /04443 USt-lD: DE275519395

.-. L I HI.ALCOM WIRELESS COMMUNICATIONS GMBH Declaration concerninq Antenna Specification It is hereby declared that the product Model No.: FOX-EN FCC lD: QIXFOXEN fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCG recommendations for external antenna type described below: Model No. of antenna:CTi GPS08B Type of antenna: quarter wave planar antenna with a unique connector Gain of the antenna: 2 dBi Frequency range: 824-1990 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Falcom Wireless Communication GmbH Address: Gewerbering 6 City: Langewiesen ZIP / Postal code:98704 Country: Germany Place: Langewiesen Date: 16.07.2012 Signature: t "/ rf\ ) \ t-,r:-,C{ $'.-r}r--- Dr.\rald Buch FnALcoM WIRELESS COMMUNICATIONS GMBH Gewerbering 6' 98704 Langewiesen Fon: 03677 I 8042-0' Fax: 03677 | 8042-215 lnternel: www,falcom.de Geschöftsführer: Tel.:03677 l8O 42-O Anschrift: Amtsgericht Jeno Sleuer-Nr.: 156/108/04443 Jeon-Luc Guerin Fox:03677/80 42-21 5 Gewerbering 6 HRB 506246 Prokurist: www.folcom.de 98704 LANGEWIESEN Sitz: Longewiesen USt-lD: DE275519395 Chqrles Choussonnier

Test Report No.: G0M-1206-2043-TFC091M-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 12 RF-EXPOSURE ASSESSMENT REPORT FCC 47 CFR Part 2.1091 Industry Canada RSS-102 RF-Exposure evaluation of mobile equipment Report Reference No. .................... : G0M-1206-2043-TFC091M-V01 Testing Laboratory ........................ : Eurofins Product Service GmbH Address ............................................ : Storkower Str. 38c 15526 Reichenwalde Germany Accreditation .................................... : A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Filed Test Laboratory, Reg.-No.: 96970 IC OATS Filing assigned code: 3470A Applicant’s name ........................... : Falcom Wireless Communications GmbH Address ............................................ : Gewerbering 6 98704 Langewiesen GERMANY Test specification: Standard ........................................... : 47 CFR 1.1310 / 47 CFR 2.1091 / 47 CFR 2.1093 OET Bulletin 65:1997 Equipment under test (EUT): Product description Tracking Solution Model No. FOX-EN Hardware version 3 Firmware / Software version 10.00.003 FCC-ID: QIXFOXEN IC: N/A Test result Passed Test Report No.: G0M-1206-2043-TFC091M-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 12 REPORT INDEX 1 EQUIPMENT (TEST ITEM) DESCRIPTION 4 1.1 Reference Documents 5 1.2 Radiation Sources 6 2 RESULT SUMMARY 7 3 RF-EXPOSURE CLASSIFICATIONS 8 4 ASSESSMENT 9 4.1 MPE Assessment – 47 CFR 2.1091 / RSS-102 9 Test Report No.: G0M-1206-2043-TFC091M-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 12 1 Equipment (Test item) Description Description Tracking Solution Model FOX-EN Serial number 30580(113)26200001 Hardware version 3 Software / Firmware version 10.00.003 FCC-ID QIXFOXEN IC N/A Equipment type End product Test Report No.: G0M-1206-2043-TFC091M-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 12 1.1 Reference Documents Document type Document No. Issued by Date FCC 22H/24E Test Report G0M-1206-2043-TFC224M-V01 Eurofins Product Service GmbH 2012-09-26 Test Report No.: G0M-1206-2043-TFC091M-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 12 1.2 Radiation Sources Mode # Description GSM/GPRS 850 Frequency range [MHz] 824.0 - 849.0 Channels 124 Transmission modes Packet Switched (GPRS) Modulations GMSK Maximum radiated power [dBm e.i.r.p.] 32.79 Maximum transmission duty cycle [%] 25 (Multislot Class 10) Antenna 1 gain [dBi] 2.0 Antenna 1 diameter [cm] ~10 GSM/GPRS 1900 Frequency range [MHz] 1850.0 - 1910.0 Channels 299 Transmission modes Packet Switched (GPRS) Modulations GMSK Maximum radiated power [dBm e.i.r.p.] 31.38 Maximum transmission duty cycle [%] 25 (Multislot Class 10) Antenna 1 gain [dBi] 2.0 Antenna 1 diameter [cm] ~10 Test Report No.: G0M-1206-2043-TFC091M-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 12 2 Result Summary FCC 47 CFR Part 2.1091, IC RSS-102 Product Specific Standard Section Requirement Result Remarks 47 CFR 2.1091 Maximum permissible exposure @ 20cm below limit PASS RSS-102 2.5.2 Maximum permissible exposure @ 20cm below limit PASS Remarks: Test Report No.: G0M-1206-2043-TFC091M-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 12 3 RF-Exposure Classifications Device Types Fixed A fixed device is defined as a device physically secured at one fixed location and cannot be easily re-located. Mobile A mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structure(s) and the body of the user or nearby persons. (47 CFR 2.1091) Portable A portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. (47 CFR 2.1093) Exposure Categories Occupational / Controlled Limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational/controlled limits apply provided he or she is made aware of the potential for exposure. General population / uncontrolled Exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or cannot exercise control over their exposure. Test Report No.: G0M-1206-2043-TFC091M-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 9 of 12 4 Assessment 4.1 MPE Assessment – 47 CFR 2.1091 / RSS-102 MPE Assessment acc. to 47 CFR 2.1091 / IC RSS-102 Verdict: PASS Assessment according to reference Reference Method FCC OET Bulletin 65 / RSS-102 & Safety Code 6 Device type mobile Exposure category General public IC Limits – Occupational / Controlled Exposure Frequency range [MHz] Electric field strength [V/M] Magnetic field strength [A/M] Power density [W/m 2 ] Averaging time [min] 0.003 – 1.0 600 4.9 N/A 6 1 – 10 600/f 4.9/f N/A 6 10 – 30 60 4.9/f N/A 6 30 – 300 60 0.163 10.0* 6 300 – 1500 3.54·f 0.5 0.0094·f 0.5 f/30 6 1500 - 15000 137 0.364 50 6 15000 - 150000 137 0.364 50 616000/f 0.5 150000 - 300000 0.354·f 0.5 9.4·10 -4 ·f 0.5 3.33·10 -4 ·f 616000/f 0.5 IC Limits – General Population / Uncontrolled Exposure Frequency range [MHz] Electric field strength [V/M] Magnetic field strength [A/M] Power density [W/m 2 ] Averaging time [min] 0.003 – 1.0 280 2.19 N/A 6 1 – 10…

Text truncated - open the document above for the full version.

Test Report No.: G0M-1206-2043-TFC224M-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany FCC TEST REPORT FCC 47 CFR Part 22H Cellular Telephones Operating in the Bands 824-849MHz and 869-894MHz FCC 47 CFR Part 24E 2GHz Personal Communication Services Report Reference No. .................... : G0M-1206-2043-TFC224M-V01 Testing Laboratory ........................ : Eurofins Product Service GmbH Address ............................................ : Storkower Str. 38c 15526 Reichenwalde Germany Accreditation .................................... : A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Filed Test Laboratory, Reg.-No.: 96970 IC OATS Filing assigned code: 3470A Applicant’s name ........................... : Falcom Wireless Communications GmbH Address ............................................ : Gewerbering 6 98704 Langewiesen GERMANY Test specification: Standard ........................................... : 47 CFR Part 22H, 47 CFR Part 24E Equipment under test (EUT): Product description Tracking Solution Model No. FOX-EN Hardware version Rev 02c Firmware / Software version 10.00.003 FCC-ID: QIXFOXEN IC: N/A Test result Passed Seite 1 von 103 Test Report No.: G0M-1206-2043-TFC224M-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany REPORT INDEX 1 EQUIPMENT (TEST ITEM) DESCRIPTION 4 1.1 Photos – Equipment External 6 1.2 Photos – Equipment internal 7 1.3 Photos – Test setup 8 1.4 Supporting Equipment Used During Testing 9 1.5 Test Modes 10 1.6 Test Equipment Used During Testing 11 1.7 Sample emission level calculation 12 2 RESULT SUMMARY 13 3 TEST CONDITIONS AND RESULTS 14 3.1 Test Conditions and Results – Effective radiated power / Equivalent isotropic radiated power 14 3.2 Test Conditions and Results – Transmitter radiated emissions 16 ANNEX A Transmitter radiated power 18 ANNEX B Transmitter radiated spurious emissions 31 Seite 3 von 103 Test Report No.: G0M-1206-2043-TFC224M-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1 Equipment (Test item) Description Description Tracking Solution Model FOX-EN Serial number 30580(113)26200001 Hardware version Rev 02c Software / Firmware version 10.00.003 FCC-ID QIXFOXEN IC N/A Equipment type End product Equipment classification Mobile Device (Human Body distance > 20 cm) Radio type Transceiver Radio technology GSM850 / GSM1900 Operating frequency range GSM850 : TX = 824 - 849 MHz, RX = 869 - 894 MHz GSM1900 : TX = 1850 - 1910 MHz, RX = 1930 - 1990 MHz Assigned frequency band Cell. Service Block A & B : 824 - 849 MHz & 869 - 894 MHz Broadband PCS : 1850 - 1910 MHz & 1930 - 1990 MHz Main test frequencies GSM850 F LOW CH : 128 UL: 824.2 MHz CH : 128 DL: 869.2 MHz F MID CH : 188 UL: 836.2 MHz CH : 188 DL: 881.2 MHz F HIGH CH : 251 UL: 848.8 MHz CH : 251 DL: 893.8 MHz Main test frequencies GSM1900 F LOW CH : 512 UL: 1850.2 MHz CH : 512 DL: 1930.2 MHz F MID CH : 661 UL: 1880.0 MHz CH : 661 DL: 1960.0 MHz F HIGH CH : 810 UL: 1909.8 MHz CH : 810 DL: 1989.8 MHz Supported transmission modes GSM, GPRS Modulations GSM, GPRS : GMSK Multislot class 10 Number of antennas 1 Radio module Type GSM/GPRS module Model GE865 Manufacturer Telit HW Version 3 SW Version 10.00.003 FCC-ID Rl7GE865 IC 1314-GE865 Antenna Type external dedicated Model FAL-ANT12 Manufacturer CTi Gain 2dBi Seite 4 von 103 Test Report No.: G0M-1206-2043-TFC224M-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Manufacturer FMO Electronics GmbH In den Folgen 39 98704 Langewiesen GERMANY Power supply V NOM 12 V DC V MIN N/A V MIN N/A AC/DC-Adaptor Model N/A Vendor N/A Input N/A Output N/A Seite 5 von 103 Test Report No.: G0M-1206-2043-TFC224M-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.1 Photos – Equipment External EUT TOP EUT BOTTOM EUT SIDE VIEW EUT ANTENNA Seite 6 von 103 Test Report No.: G0M-1206-2043-TFC224M-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.2 Photos – Equipment internal EUT PCB TOP EUT PCB BOTTOM Seite 7 von 103 Test Report No.: G0M-1206-2043-TFC224M-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.3 Photos – Test setup Radiated Emissions Seite 8 von 103 Test Report No.: G0M-1206-2043-TFC224M-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.4 Supporting Equipment Used During Testing Product Type* Device Manufacturer Model No. Comments SIM Communication Tester Rohde & Schwarz CMU200 *Note: Use the following abbreviations: AE : Auxiliary/Associated Equipment, or SIM : Simulator (Not Subjected to Test) CABL : Connecting cables Seite 9 von 103 Test Report No.: G0M-1206-2043-TFC224M-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.5 Test Modes Mode # Description GSM850 General conditions: EUT powered by laboratory power supply. External GSM and GPS antenna connected. Active call to communication tester. Radio conditions: Mode = transmit Connection = packet switched (GPRS) Modulation = GMSK Slot configuration = 2 up / 1 down Power level = Maximum (Gamma 3) GSM1900 General conditions: EUT powered by laboratory power supply. External GSM and GPS antenna connected. Active call to communication tester. Radio conditions: Mode = transmit Connection = packet switched (GPRS) Modulation = GMSK Slot configuration = 2 up / 1 down Power level = Maximum (Gamma 0) Seite 10 von 103 Test Report No.: G0M-1206-2043-TFC224M-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.6 Test Equipment Used During Testing Radiated power Description Manufacturer Model Identifier Cal. Date Cal. Due Fully-anechoic chamber Frankonia AC 3 EF00199 - - Spectrum Analyzer R&S FSIQ 26 EF00242 2012-05 2013-05 Biconical Antenna R&S HK 116 EF00012 2010-01 2013-01 LPD Antenna R&S HL 223 EF00187 2011-02 2014-02 LPD Antenna R&S HL 025 EF00327 2010-02 20…

Text truncated - open the document above for the full version.
