THIS DOCUMENT IS AVAILABLE AT HTTP://WWW.FALCOM.DE/ TANGO55/i & 56/i Hardware description Version 1.03, 01/12/2005 TANGO55/I & TANGO56/I VERSION 1.03 Table of contents 0 INTRODUCTION.........................................................................5 0.1 THE DIFFERENCES BETWEEN TANGO55/I & TANGO56/I MODEMS............................................5 0.2 USED ABBREVIATIONS..............................................................................................................7 0.3 RELATED DOCUMENTS.............................................................................................................9 1 SECURITY................................................................................10 1.1.1 GENERAL............................................................................................................................10 1.1.2 EXPOSURE TO RF ENERGY.............................................................................................10 1.1.3 EFFICIENT MODEM OPERATION.....................................................................................10 1.1.4 ANTENNA CARE AND REPLACEMENT............................................................................10 1.1.5 DRIVING..............................................................................................................................11 1.1.6 ELECTRONIC DEVICES.....................................................................................................11 1.1.7 VEHICLE ELECTRONIC EQUIPMENT..............................................................................11 1.1.8 MEDICAL ELECTRONIC EQUIPMENT..............................................................................11 1.1.9 AIRCRAFT...........................................................................................................................11 1.1.10 CHILDREN........................................................................................................................11 1.1.11 BLASTING AREAS...........................................................................................................12 1.1.12 POTENTIALLY EXPLOSIVE ATMOSPHERES................................................................12 1.1.13 NON-IONISING RADIATION ............................................................................................12 1.2 SAFETY STANDARDS..............................................................................................................13 2 TECHNICAL DATA...................................................................14 2.1 TECHNICAL SPECIFICATIONS OF GSM/GPRS ENGINE..............................................................14 2.2 POWER CONSUMPTION FOR TANGO55, ONLY........................................................................17 2.3 OPERATING TEMPERATURES...................................................................................................17 2.4 AIR INTERFACE OF THE TANGO55 GSM/GPRS ENGINE, ONLY...............................................18 2.5 AIR INTERFACE OF THE TANGO56 GSM/GPRS ENGINE, ONLY...............................................18 2.6 DETERMINING THE EXTERNAL EQUIPMENT TYPE.....................................................................19 3 GSM/GPRS APPLICATION INTERFACE................................20 3.1 DESCRIPTION OF OPERATING MODES......................................................................................20 3.1.1 Normal mode operation .......................................................................................................20 3.1.1.1 GSM/GPRS SLEEP........................................................................................................................20 3.1.1.2 GSM IDLE.......................................................................................................................................20 3.1.1.3 GSM TALK......................................................................................................................................20 3.1.1.4 GPRS IDLE.....................................................................................................................................20 3.1.1.5 GPRS DATA...................................................................................................................................20 3.1.2 Power down.........................................................................................................................21 3.1.3 Alarm mode.........................................................................................................................21 4 HARDWARE INTERFACES.....................................................22 4.1 INTERFACES ON THE TANGO55/I & TANGO56/I....................................................................22 4.1.1 Interface A (4-pin connector, power supply)........................................................................22 4.1.2 Interface B (9-pin D-SUB connector)...................................................................................23 4.1.3 Interface C (8-pin RJ45 connector).....................................................................................23 4.1.4 Interface D (antenna interface)............................................................................................24 4.1.5 Interface E (SIM interface)...................................................................................................24 4.1.6 Interface F (Optical indicator interface) ...............................................................................25 4.2 FUNCTIONAL DESCRIPTION.....................................................................................................25 4.2.1 Ignition line...........................................................................................................................26 4.2.2 Serial handling.....................................................................................................................26 This co…

Text truncated - open the document above for the full version.

ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, Germany Registration number: G0M20506-9605-P-2224 Page 1 of 10 Appendix A. Pictures ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, Germany Registration number: G0M20506-9605-P-2224 Page 2 of 10

ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, Germany Registration number: G0M20506-9605-P-2224 Page 3 of 10 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, Germany Registration number: G0M20506-9605-P-2224 Page 4 of 10 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, Germany Registration number: G0M20506-9605-P-2224 Page 5 of 10 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, Germany Registration number: G0M20506-9605-P-2224 Page 6 of 10 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, Germany Registration number: G0M20506-9605-P-2224 Page 7 of 10

___________________________________________________________________________________ ETS Handelsregister: Bankverbindung: Electronic Technology Systems Dr. Genz GmbH Amtsgericht Frankfurt/Oder HRB 5151 Sparkasse Oder-Spree Storkower Strasse 38c Geschäftsführung: Dr. Dietmar Genz BLZ 170 550 50 D-15526 Reichenwalde b. Berlin Norbert Kaspar Kto. Nr. 3105165974 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH RF Exposure Calculation Applicant: FALCOM GmbH FCC ID: QIXTANGO56I The internal / external antennas used for this mobile transmitter must provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. A safety statement concerning minimum separation distances from enclosure of the Tango 56i will be integrated in the user’s manual to provide end-users with transmitter operating conditions for satisfying RF exposure compliance. The appropriate Max conducted power can be drawn from the test report no. G0M20506- 9605-P-2224. For transmitter operating in the 824-849 MHz range, paragraph 1.1310 Table 1 limits maximum permissible exposure (MPE) to 0.549 mW/cm² for uncontrolled environments and 2.75 mW/cm² for controlled environments. For transmitter operating in the 1850-1910 MHz range, paragraph 1.1310 Table 1 limits maximum permissible exposure (MPE) to 1 mW/cm² for uncontrolled environments and 5 mW/cm² for controlled environments. The far field on-axis power flux density (W/m²) is calculated using the following formula: S = Power density (mW/cm²) ERP = effective radiated power (mW) EIRP = isotropically radiated power (mW) r = Distance in cm Calculations ___________________________________________________________________________________ ETS Handelsregister: Bankverbindung: Electronic Technology Systems Dr. Genz GmbH Amtsgericht Frankfurt/Oder HRB 5151 Sparkasse Oder-Spree Storkower Strasse 38c Geschäftsführung: Dr. Dietmar Genz BLZ 170 550 50 D-15526 Reichenwalde b. Berlin Norbert Kaspar Kto. Nr. 3105165974 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ___________________________________________________________________________________ ETS Handelsregister: Bankverbindung: Electronic Technology Systems Dr. Genz GmbH Amtsgericht Frankfurt/Oder HRB 5151 Sparkasse Oder-Spree Storkower Strasse 38c Geschäftsführung: Dr. Dietmar Genz BLZ 170 550 50 D-15526 Reichenwalde b. Berlin Norbert Kaspar Kto. Nr. 3105165974 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH

ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH FCC - TEST - REPORT FCC RULES PARTS 22 and 24 FCC ID: QIXTANGO56I Test report no.: G0M20506-9605-P-2224 Certificate 1983-01 ELECTRONIC TECHNOLOGY SYSTEMS STORKOWER STRASSE 38C, D-15526 REICHENWALDE B. BERLIN DR. GENZ GMBH PHONE +49-33631-888 00 FAX +49-33631-888 660 ETS Dr. Genz GmbH, Germany Registration number: G0M20506-9605-P-2224 Page 1 of 41 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH TABLE OF CONTENTS 1 General information 1.1 Notes 1.2 Testing laboratory 1.3 Details of approval holder 1.4 Application details 1.5 Test item 1.6 Test standards 2 Technical test 2.1 Summary of test results 2.2 Test environment 2.3 Test equipment utilized 2.4 General Test Procedure 3 Test Results 4 RF Power Output, FCC 2.1046 4.1 Test Procedure 4.2 Test Results 5 Radiated Power FCC 22.913, FCC 24.232 5.1 Test Procedure 5.2 Test Results 6 Modulation Deviation Limiting, FCC 2.1047, 22.915(b)(c) 6.1 Test Procedure 6.2 Test Results 7 Audio Filter Characteristics, FCC 22.915(d) 7.1 Test Procedure 7.2 Test Results 8 Emission Limitations, , FCC 2.1049 8.1 Test Procedure 8.2 Test Results 9 Occupied Bandwidth FCC 22.917(b)(d); FCC 2.1049 9.1 Test Procedure 9.2 Test Results 10 Out of Band Emissions at Antenna Terminals, FCC 24.238(a) 10.1 Test Procedure 10.2 Test results 11 Field Strength of Spurious Radiation, FCC 2.1053, 24.236 11.1 Test Procedure 11.2 Test Results ETS Dr. Genz GmbH, Germany Registration number: G0M20506-9605-P-2224 Page 2 of 41 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 12 Line Conducted Emissions, FCC 15.207 12.1 Test Procedure 12.2 Test Results 13 Frequency Stability vs Temperature, FCC 2.1055, 22.355, 24. 235 13.1 Test Procedure 13.2 Test Equipment 14 Frequency Stability vs Voltage, FCC 2.1055, 22.355, 24.235 14.1 Test Procedure 14.2 Test Equipment ETS Dr. Genz GmbH, Germany Registration number: G0M20506-9605-P-2224 Page 3 of 41 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.5. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH. Tester: 18.08.2005 M. Handrik Date ETS-Lab. Name Signature Technical responsibility for area of testing: 18.08.2005 N. Kaspar Date ETS Name Signature ETS Dr. Genz GmbH, Germany Registration number: G0M20506-9605-P-2224 Page 4 of 41 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.2 Testing laboratory 1.2.1 Location ELECTRONIC TECHNOLOGY SYSTEM DR. GENZ GMBH (ETS) Storkower Straße 38c D-15526 Reichenwalde b. Berlin Germany Telephone : +49 33631 888 00 Telefax : +49 33631 888 66 1.2.2 Details of accreditation status A CCREDITED TESTING LABORATORY DAR-REGISTRATION NUMBER: TTI-P-G 126/96 A CCREDITED COMPETENT BODY DAR-REGISTRATION NUMBER: BPT-ZE-026/96 FCC FILED TEST LABORATORY REG. NO. 96970 BLUETOOTH QUALIFICATION TEST FACILITY (BQTF) ACCREDITED BY: BLUETOOTH QUALIFICATION REVIEW BOARD (BQRF) I NDUSTRY CANADA FILED TEST LABORATORY REG. NO. IC 3470 A2LA ACCREDITED Certificate Number: 1983-01 1.3 Details of approval holder Name : FALCOM GmbH Street : Gewerbering 6 Town : 98704 Langewiesen Country : Germany Telephone : +49(0)3677 8042-0 Fax : +49(0)3677 8042-215 Contact : Herr Ralf Leipoldt E-Mail : [email protected] ETS Dr. Genz GmbH, Germany Registration number: G0M20506-9605-P-2224 Page 5 of 41 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.4 Application details Date of receipt of application : 27.06.2005 Date of receipt of test item : 27.06.2005 Date of test : 08.07.2005 – 11.07.2005 1.5 Test item Description of test item : Embedded GSM Module Type identification : Tango 56i Serial number : Test model without serial number. Photos : See annex A. Technical data Frequency range Tx – GSM 850 : 824.2 – 848.80 MHz Frequency range Tx – PCS : 1850.2 – 1909.8 MHz Frequency range Rx - GSM 850 : 869.2 – 893.8 MHz Frequency range Rx - PCS : 1930.2 – 1989.8 MHz Antenna transmitter : external antenna Antenna Gain : 1 dBi (max) Power supply : 12 V DC Operating mode : duplex Type of modulation : GMSK (GSM modulation) Emission : GXW Manufacturer: (if applicable) Name : Street : Town : Country : ETS Dr. Genz GmbH, Germany Registration number: G0M20506-9605-P-2224 Page 6 of 41 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.6 Test standards Technical standard : FCC Parts 22, 24, 2, 15 Additional information : Because of using the GSM 850 as an alternative technology in 850 MHz band, not all test cases of FCC Part 22 are required. This device contains 900 MHz GSM and 1800 MHz DCS functions that are not operational in U.S. Territories. This filing is only applicable for 1900 MHz PCS operations 2 Technical test 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course : of the tests performed. or The deviations as specified in 2.5 were ascertained in the course of the tests … performed. 2.2 Test environment Temperature : 23 o C Relative humidity content : 20 ... 75 % Air pressure : 86 ... 103 kPa ETS Dr. Genz GmbH, Germany Registration number: G0M20506-9605-P-2224 Page 7 of 41 ELECTRONIC TECHNOLOGY SYST…
