QJ8-SBS6600LBluetooth Stereo Speaker

User Manual English Bluetooth Stereo Speaker SBS-6600 SBS-6600R / SBS-6600L INTRODUCTION WELCOME FEATURES Bluetooth wireless technology is a short-range wireless technology that enables wireless data communication between digital devices like a mobile phone. Bluetooth wireless technology operates within a range of about 10m(30feet). You do not need to use a cable for connection. Bluetooth technology is an international standard supported by millions of companies all over the world. Thank you for purchasing the SBS-6600, the Bluetooth Stereo Speaker. We hope you will be satisfied with its operation. Please read the user manual carefully to start using the speakers and to make the best use of the speaker’s features. The distinctive wireless connection between two (left/right) completely independent speakers provides the ultimate in ease of setup and in freedom of movement. Type : Bluetooth Stereo Speaker *Play Time : up to 8 hours *Stand-by Time : up to 240 hours *Charging Time : approx. 3 ½ hours Bluetooth v2.0, A2DP, AVRCP Transmission Power Level : Class 2 (up to 10m) Rechargeable Li-Polymer Battery (2ea) Accessories included : AC Charger, Manual, Pouch *Performance may vary depending on device or environment. SPECIFICATIONS Impedance : 8 Ω Maximum Input Power : 40mW Audio Output : 1.2W/Channel SNR : 70dB Sound Frequency Response : 60 ~15,000 Hz Battery Capacity : 880 mAh /ea Weight : 265g (with battery) 1 2 CHARGE THE BATTERY RECHARGING Your SBS-6600 speakers have internal, no removable, and rechargeable batteries. Before you start using the speakers, the battery must be fully charged and the speakers must be paired with a compatible Bluetooth device like mobile phone. Warning: Do not attempt to charge the speakers with anything other than the AC Charger provided. The use of any other types of charger may invalidate any approval or warranty, and may damage the speakers. The fully charged battery has approximately 8 hours of play time or up to 100 hours of standby time. However, the play time and standby time may vary depending on mobile phones, products that use a Bluetooth connection, and/or playing conditions. Charging: 1. Connect the AC Charger to the speakers. 2. Connect the AC Charger to a wall outlet. The red indicator light is displayed during charging. 3. When the battery is fully charged, the red indicator light turns to the blue light. First-time use : Charge approximately for 3 ½ hours before using the speakers. When battery power is low, and the speakers’ blue indicator light located on the back of speakers turn to red light, the speakers’ batteries need to be recharged. During playing music, speakers are not charged but AC power is supplied. AC Charger 3 COMPATIBILITY OVERVIEW The SBS-6600 is compatible with most Bluetooth devices, such as mobile phones, PDAs, MP3 players and laptops that are compliant with the Bluetooth version 1.0, 1.2, or 2.0. Please make sure that your device has Bluetooth capability and supports Advanced Audio Distribution Profile (A2DP) and Audio Video Remote Control Profile (AVRCP). ① Multi Function Button (MFB) Power On/Off, Pairing, Pause/Stop/Play music ② Volume Buttons To adjust Volume up and down ③ FF/REW Buttons To search and select music (moves to the next or previous song) ④ On/Off Button To turn On/Off Slave speaker ⑤ Charging Jack To connect AC Charger to the internal speaker batteries (See rear side of speakers) ⑦ AC Charger⑧ Pouch ⑥ Charging indicator To provide visual indications about speaker’s charging status ③ ① ② ⑥ ⑧ ④ ⑤ Master Speaker Control several functions Slave Speaker Play music only ⑦ 4 BUTTON OPERATION Ta p Press Press and Hold about 1 second about 2 second about mor than 4 seconds Power On Press MFB on the master speaker Press On/Off button on the slave speaker Blue light flashes on master speaker Blue light remains solid on slave speaker Power Off Press and Hold MFB on the master speaker Press On/Off button Press and Hold MFB Red light flashes on Master Speaker and the lights are unlit on both speakers Paring Playing MusicTap MFB Tap MFB Press MFB Tap Volume Buttons Tap FF/REW Buttons Pause Music Stop Music Volume Up and Down FF/REW Blue light On and Red light flashes InstructionDuration of Press FunctionHow toIndicator Lights MFB On/Off Slave speaker Master speaker The speaker ID is now stored in the Bluetooth device’s memory. For details about device discovery please refer to user guide of your bluetooth product to be paired. Note : When the speakers are not paired with a device for 3 minutes the paring mode is automatically turned off. Please turn the speaker off and re-attempt paring procedure from turning the speaker on (Step 1). Re-pairing : 1. 2. Press and hold MFB for more than 5 seconds until you hear the tones and blue and red lights flash. You will hear tones twice at this time. (1st tone: when the speakers turn on, 2nd tone : when the speakers are in pairing mode) If the first step for repairing is successful please follow step 2 - 6 in pairing procedure. Pairing with Bluetooth Device : Press and hold the MFB for more than 5 seconds until you hear the tone twice and blue and red lights are flashing, then release. 1. Set your own Bluetooth device to discover the SBS-6600 speaker by following instruction guide of your bluetooth device. 2. Select “LANCE-6600” in the list of discovered devices and confirm. 3. When requested by the bluetooth device, enter the passkey “0000” and confirm. 4.Select the music you want to listen to on your Bluetooth device and enjoy the music. 7. When the speakers are connected to a paired device and are ready for use, the blue indicator light flashes slowly(every 4 seconds) on the master speaker. 5. Press On/Off button to turn on slave speaker for about 2 second. The slave speaker will be automatically paired and connected to a master speaker. 6. PAIRING 5 6 ENJOY THE MUSIC Pairing with Another Bluetooth Device : If you want to pair with another bluetooth device, first disconnect the s…

Text truncated - open the document above for the full version.

( Slave Section ) Sub RFChip Set AudioAmplifier PowerManagement Battery Charger & Supervisor Nordic ATMEL Wolfson codec Crystal SPI UART I2C Audio_IN I2C Nordic ATMEL Wolfson codec 16Mhz SPI UART I2C Audio_out Audio_IN I2S I2C I2C Ant

Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD21046 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission's Rules (47 C.F.R) and Section §552(b)(4) of the Freedom of Information Act, Samsin Innotec Co., Ltd., requests confidentiality for the following products: FCC ID Number Product Product designation / Model QJ8-SBS6600L Bluetooth stereo speaker / SBS-6600L For the product stated above, we request that the following information be held confidential: 1) Schematic diagrams 2) Bill of materials (Part List) No other items submitted as part of the equipment authorization filing process are deemed confidential. The above exhibits contain Samsin Innotec Co., Ltd. trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our products. This material is not customarily available to the general public and we request that it be withheld from public inspection. Sincerely, Won Kyu, Choi / Executive Director Samsin Innotec Co., Ltd. 252-23, Sarihyun-Dong, Ilsandong-Gu, Goyang-City, Kyonggi-Do, 411-530 Korea TEL: +82-31-900-9871, FAX: +82-31-900-9813

SK TECH CO., LTD. Page 1 of 2 SKTTRT-070426-013 FCC ID: QJ8-SBS6600L External Photographs of EUT <Photograph 1: EUT> SK TECH CO., LTD. Page 2 of 2 SKTTRT-070426-013 FCC ID: QJ8-SBS6600L <Photograph 2: Battery Charging AC Adaptor>

ID Label Location & Sample LABEL LOCATION: Label is permanently attached on the rear of the product. LABEL Drawing:

SK TECH CO., LTD. Page 1 of 4 SKTTRT-070426-013 FCC ID: QJ8-SBS6600L Internal Photographs of EUT <Photograph 1: Cover removed> SK TECH CO., LTD. Page 2 of 4 SKTTRT-070426-013 FCC ID: QJ8-SBS6600L SK TECH CO., LTD. Page 3 of 4 SKTTRT-070426-013 FCC ID: QJ8-SBS6600L <Photograph 2: RF Board> SK TECH CO., LTD. Page 4 of 4 SKTTRT-070426-013 FCC ID: QJ8-SBS6600L <Photograph 3: Power Board>

Antenna description Model Name - Manufacturer Samsin Innotec Co., Ltd. Antenna Location Internal (Wire Antenna) Max. Gain 2.65dBi Dimension (L) 80 mm Picture of the antenna Radiation Pattern

Operational Description Bluetooth device Main-RF Model SBS-6600R (right speaker) Sub-RF Model SBS-6600L (left speaker) Sub-RF < Normal operating configuration > This product is a wireless stereo speaker. The Model SBS-6600R has two transmitters; Main-RF in the SBS-6600R is a Bluetooth device and Sub-RF is another spread specturm transmitter. Main-RF pairs with a standard Bluetooth device and recieves audio signals, and then Sub-RF in the SBS-6600R transmits RF signals to SBS-6600L as left audio signals. Main-RF (CSR BC03): 2402 ~ 2480 MHz (1 MHz step, 79 channels): the channel is represented by a pseudo- random hopping sequence through the 79 channels. The channel is divided into time slots, with a nominal slot length of 625μs, where each slot corresponds to different RF hop frequencies. The nominal hop rate is 1600 hops/s. Sub-RF (NORDIC, NRF24Z1): 2404 ~ 2478 MHz (2 MHz step, 38 channels): each new transmission event begins on the next channel in the hopping sequence after the final channel used in the previous transmission event. Rating and Physical Characteristics Type designation Wireless portable stereo speaker Model name SBS-6600R (right speaker) SBS-6600L (left speaker) FCC ID FCC ID: QJ8-SBS6600R FCC ID: QJ8-SBS6600L Power source DC 3.7 V Li-polymer battery and/or AC/DC Adaptor DC 3.7 V Li-polymer battery and/or AC/DC Adaptor Local Oscillator or X-Tal X-Tal: 26 MHz, 16MHz X-Tal: 16MHz Main-RF: CSR, BC358239A RF chipset Sub-RF: NORDIC, NRF24Z1 Sub-RF: NORDIC, NRF24Z1 Main-RF: 2402 ~ 2480 MHz (1MHz step, 79 channels) Transmitting frequency Sub-RF: 2404 ~ 2478 MHz (2MHz step, 38 channels) Sub-RF: 2404 ~ 2478 MHz (2MHz step, 38 channels) Main-RF: chip antenna Antenna type Sub-RF: wire antenna Sub-RF: wire antenna Main-RF: FHSS (GFSK) Type of modulation Sub-RF: FHSS (GFSK) Sub-RF: FHSS (GFSK) Main-RF: < 4 dBm RF power output Sub-RF: < 4 dBm Sub-RF: < 4 dBm DC input for charging the battery DC input for battery charging External ports One AC/DC Adaptor for charging the batteries simultaneously - Manufacturer: E-TEK Electronics Manufactory Ltd. - Input: AC 100 – 240 V, 0.15 A, 50-60 Hz - Output: DC 5 V, 1.0 A

SK TECH CO., LTD. Page 1 of 32 SKTTRT-070426-013 FCC ID: QJ8-SBS6600L Certificate of Compliance Test Report No.: SKTTRT-070426-013 KOLAS No.: KT191 Applicant: Samsin Innotec Co., Ltd. Applicant Address: 252-23, Sarihyun-Dong, Ilsandong-Gu, Goyang-City, Kyonggi-Do, 411-530 Korea Manufacturer: Samsin Innotec Co., Ltd. Manufacturer Address: 252-23, Sarihyun-Dong, Ilsandong-Gu, Goyang-City, Kyonggi-Do, 411-530 Korea Device Under Test: Bluetooth stereo speaker FCC ID: QJ8-SBS6600L Model Name: SBS-6600L Serial number: Prototype Receipt No.: SKTEU07-0041 Date of receipt: Jan. 9, 2007 Date of Issue: April. 26, 2007 Location of Testing: SK TECH CO., LTD. 820-2, Wolmoon-Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea Test Procedure: ANSI C63.4, FCC Public Notice DA 00-705 (March 2000) Test Specification: 47CFR, Part 15 Rules FCC Equipment Class: DSS - Part 15 Spread Spectrum Transmitter Test Result: The above-mentioned device has been tested and passed. Tested & Reported by: Chang-Min, Moon 2007. 04. 26 Approved by: Jong-Soo, Yoon 2007. 04. 26 Signature Date Signature Date Other Aspects: - Abbreviations: · OK, Pass = passed · Fail = failed · N/A = not applicable ☞ ¾ This test report is not permitted to copy partly and entirely without our permission. ¾ This test result is dependent on only equipment to be used. ¾ This test result is based on a single evaluation of submitted samples of the above mentioned. ¾ This test report is the accredited testing items by Korea Laboratory Accreditation Scheme, which signed the ILAC-MRA. SK TECH CO., LTD. Page 2 of 32 SKTTRT-070426-013 FCC ID: QJ8-SBS6600L >> CONTENTS << 1. GENERAL ··························································································································· 4 2. TEST SITE ··························································································································· 4 2.1 Location ······················································································································ 4 2.2 List of Test and Measurement Instruments ································································· 5 2.3 Test Date ····················································································································· 5 2.4 Test Environment ········································································································ 5 3. DESCRIPTION OF THE EQUIPMENT UNDER TEST ·············································· 6 3.1 Rating and Physical Characteristics ··········································································· 6 3.2 Equipment Modifications ··························································································· 6 3.3 Submitted Documents ································································································· 6 4. MEASUREMENT CONDITIONS ··················································································· 7 4.1 Description of test configuration ················································································ 7 4.2 List of Peripherals ·······································································································7 4.3 Type of Used Cables ··································································································· 8 4.4 Uncertainty ················································································································· 8 5. TEST AND MEASUREMENTS ························································································ 9 5.1 ANTENNA REQUIREMENT ··················································································· 9 5.1.1 Regulation ············································································································ 9 5.1.2 Result ···················································································································9 5.2 MAXIMUM PEAK OUTPUT POWER ································································ 10 5.2.1 Regulation ·········································································································· 10 5.2.2 Test Procedure ··································································································· 10 5.2.3 Test Results ········································································································ 10 Table 1: Measured values of the Maximum Peak Output Power (Conducted) ······························· 10 5.3 CARRIER FREQUENCY SEPARATION ·····························································11 5.3.1 Regulation ···········································································································11 5.3.2 Test Procedure ····································································································11 5.3.3 Test Results ·········································································································11 Table 2: Measured values of the Carrier Frequency Separation (Conducted) ································· 11 5.4 20dB CHANNEL BANDWIDTH ············································································ 12 5.4.1 Regulation ·········································································································· 12 5.4.2 Test Procedure ··································································································· 12 5.4.3 Test Results ········································································································ 12 Table 3: Measured values of the 20dB Channel Bandwidth (Conducted) ······································ 12 SK TECH CO., LTD. Page 3 of 32 SKTTRT-070426-013 FCC ID: QJ8-SBS6600L 5.5 NUMBER OF HOPPING CHANNELS ································································· 13 5.5.1 Regulation ·······················································································…

Text truncated - open the document above for the full version.

SK TECH CO., LTD. Page 1 of 3 SKTTRT-070426-013 FCC ID: QJ8-SBS6600L Test set up photos <View of Conducted RF Test > SK TECH CO., LTD. Page 2 of 3 SKTTRT-070426-013 FCC ID: QJ8-SBS6600L <Radiated Emissions - Front View> <Radiated Emissions - Rear View> SK TECH CO., LTD. Page 3 of 3 SKTTRT-070426-013 FCC ID: QJ8-SBS6600L <Conducted Emissions - Front View> <Conducted Emissions - Rear View>
