MOTOMESH 1.0 Mesh Wireless Router Users Guide September 2005 6881011Y53-O MOTOMESH 1.0 Mesh Wireless Router Users Guide 6881011Y53-O September 2005 ii This page intentionally left blank. MOTOMESH 1.0 Mesh Wireless Router Users Guide 6881011Y53-O September 2005 iii Copyrights The Motorola products described in this document may include copyrighted Motorola computer programs. Laws in the United States and other countries reserve for Motorola certain exclusive rights for copyrighted computer programs. Accordingly, any copyrighted Motorola computer programs contained in the Motorola products described in this document may not be copied or reproduced in any manner without the express written permission of Motorola. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication, estoppels or otherwise, any license under the copyrights, patents or patent applications of Motorola, except for the normal nonexclusive, royalty-free license to use that arises by operation of law in the sale of a product. Disclaimer Please note that certain features, facilities and capabilities described in this document may not be applicable to or licensed for use on a particular system, or may be dependent upon the characteristics of a particular mobile subscriber unit or configuration of certain parameters. Please refer to your Motorola contact for further information. Trademarks Motorola, the Motorola logo, and all other trademarks identified as such herein are trademarks of Motorola, Inc. All other product or service names are the property of their respective owners. Copyrights © 2005 Motorola, Inc. All rights reserved. No part of this document may be reproduced, transmitted, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, without the prior written permission of Motorola, Inc. MOTOMESH 1.0 Mesh Wireless Router Users Guide 6881011Y53-O September 2005 iv This page intentionally left blank. 6881011Y53-O September 2005 v Table of Contents Contents ............................................. . . . . Chapter 1: Product Introduction ............................................................................ 1-1 Mesh Wireless Router Defined ........................................................................................................................ 1-1 Additional MWR Features ............................................................................................................................................. 1-1 MWRs Role within a MOTOMESH Wireless Network....................................................................................... 1-2 Product Specifications...................................................................................................................................... 1-3 Chapter 2: MWR Device Installation ...................................................................... 2-1 Software Requirements......................................................................................................................................... 2-1 MWR Hardware Installation Notes ...................................................................................................................... 2-1 Equipment Specification .................................................................................................................................. 2-2 Optional Antennas ......................................................................................................................................................... 2-3 MWR Device Label ....................................................................................................................................................... 2-3 MWR MAC Address Table ........................................................................................................................................... 2-4 MWR Device Assembly .................................................................................................................................. 2-5 MWR Device Deployment and Installation ..................................................................................................... 2-6 Assembling the MWR Device ....................................................................................................................................... 2-6 Initial MWR Device Configuration Information............................................................................................................ 2-6 Device Connectivity Testing.......................................................................................................................................... 2-7 Chapter 3: Device Configuration............................................................................ 3-8 Accessing the Device Administration Web Pages ................................................................................................ 3-8 Administrator and User Account Information.................................................................................................. 3-9 Viewing the Device Administration Home Page as an Administrator................................................................3-10 Viewing the Device Administration Home Page as a Normal User............................................................... 3-11 Viewing the MWR Device Administration Configuration Page ........................................................................3-11 Device Settings Section.................................................................................................................................. 3-12 Bridge Addressing Section............................................................................................................................. 3-12 Additional Information about the Network DHCP Setting ....................................................................................…

Text truncated - open the document above for the full version.

Dated 8/31/05 Federal Communications Commissions Subject: Modular Approval for Radio Module; FCC ID: QJEAP30240705 Dear Application Examiner, Motorola, AP30-2.4 radio module, is seeking FCC authorization as a part 15 unlicensed modular transmitter approval. The requirements of the FCC public notice DA 00-1407 are met. The following requirements are fulfilled. 1. The modular transmitter must have its own RF shielding. The radio portion of this module is contained its own RF shielding. Please see photos provided with application. 2. The modular transmitter must have buffered modulation/data inputs. The module has buffered data inputs, buffers are integrated in chip 88E6060 referred to as U5 and ICL3221 referred to as U14 in the schematics. 3. The modular transmitter must have its own power supply regulation. The module incorporates voltage regulation for all voltages used within the module. These are referenced as: VR1 – AME8805AEGT VR2 – AME8805DEFT VR3 – AME8805AEGT VR4 - AME8807AEHA VR5 - AME8805DEFT VR6 - AME8807AEHA 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). This radio module will only be used in devices that are professionally installed. 5. The modular transmitter must be tested in a stand-alone configuration. The module was tested in a stand-alone configuration. Please see the test setup photos in the test report. 6. The modular transmitter must be labeled with its own FCC ID number. The module is labeled with its own FCC ID number. Please see label design and label location submitted with application. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. The module is compliant with all applicable FCC rules. Detail instructions are given in the Users Guide Manual submitted with application. 8. The modular transmitter must comply with any applicable RF exposure requirements. The module in compliant with all RF exposure requirements, please see MPE calculation provided with the application. Sincerely, Jeff Schmidt Motorola, Inc

The IAP7300 is the wireless gateway between a MOTOMESH mobile broadband network and the greater wired world. The Intelligent Access Point (IAP) acts as the transition point from the wireless network to the wired world. Each IAP offers a maximum burst data rate of up to 6 Mbps for voice, video and data communications. If greater network capacity is required, additional IAPs can be easily deployed – without the need for extensive RF or site planning. The location of IAPs is not critical due to the self-forming, self-healing and self-balancing nature of the MOTOMESH network. Motorola’s mesh networking technology enables users to wirelessly access critical broadband applications seamlessly – any time, and anywhere. Whether utilizing predeployed infrastructure, or an instant, ad hoc, broadband network formed with other users, Motorola’s mesh networking technology delivers real-time data to detect, prevent, respond. Licensed 4.9GHz and Unlicensed 2.4GHz The IAP7300 contains two standards compliant, 802.11 (Wi-Fi) radios and two of Motorola’s widely acclaimed Mesh Enabled Architecture (MEA) mobile broadband radios. One set of Wi-Fi and MEA radios operate in the unlicensed, 2.4GHz band and the other set operate in the licensed, 4.9GHz public safety band. Public Safety, Public Works and Public Access can all be given separate and dedicated wireless broadband access due to MOTOMESH’s multi- radio, multi-frequency architecture. The IAP’s dual, independent backhaul connections deliver public safety users added security by providing physical network separation from public and other, unrelated backhaul networks. Easy to Install and Deploy Flexible mounting hardware enables the IAP to be mounted on utility poles, traffic signals, billboards, buildings, etc. Innovative, weatherproof power and network connectors make reliable deployments quick and easy. IAPs automatically power up and integrate themselves into the MOTOMESH network, saving money and time. Stationary & Mobile Wireless Broadband When configured with its full complement of four radios, each IAP delivers maximum, continuous, symmetrical data rates ranging from 900 Kbps for mobile, 4.9GHz MEA users to 20 Mbps for stationary, 2.4GHz Wi-Fi users. Motorola’s exclusive, MEA radio technology supports seamless, mobile, broadband connectivity in both the licensed 4.9GHz and unlicensed 2.4GHz bands – even at speeds in excess of 150 mph. Fast and Accurate Position Location Depending on network confirguration, every MEA radio can provide quick and accurate position location information that does not require the use of GPS satellites. Location information is provided in standard NMEA0183 format, or through the MEA API. This location information can assist in the deployment of resources, creating a visual map of asset positions at an incident or across an entire city. Network Management and Monitoring MeshManager software allows the IAP7300 to be managed and upgraded over-the-air (OTA). The MeshManager application provides a single, comprehensive network management suite for controlling security policies, network provisioning, client administration and performance monitoring of all the components of a MOTOMESH network. IAP7300 Intelligent Access Point • for MOTOMESH Motorola, Inc. P.O. Box 948133 • Maitland, Florida 32794-8133 U.S.A. www.motorola.com/mesh • 407-659-5300 • Fax 407-659-5301 MOTOMESH, Mesh Enabled Architecture, MEA, MeshManager, MeshTray and Multi-Hopping are trademarks or registered trademarks of Motorola, Inc. MOTOROLA and the Stylized M Logo are registered in the U.S. Patent and Trademark Office. All other product or service names are the property of their registered owners. © Motorola, Inc. 2005 MOTOMESH Additional Network Features • Advanced Encryption Standard (AES) Support for Wi-Fi Clients • Layer 2 Multicast Support • Network Time Protocol (NTP) support • Differentiated Services using IP Quality of Service (QoS) Support • Over-the-Air Software Upgrade Support • MAC Access Control lists • Web (HTTP) based management interface • SNMP agent for remote management • Telnet interface with command-line management • Firmware Upgrades via Trivial File Transfer Protocol (TFTP) VMM7300 RADIO CHARACTERISTICS Output Power 24 dBm RF Modulation QDMA Operating Frequency (GHz) 4.94 - 4.99 Maximum Burst Data Rate 6 Mbps Spectrum Used 20MHz Antenna Type Omnidirectional, 7 dBi (magnetic mount antenna for vehicles) Antenna Connector N-Type NETWORK Network Managament Software MeshManager via SNMP Network Interface 10/100 Mbps Ethernet, RJ-45 connector Configurable Network Devices 3 assignable IP addresses – hub needed to connect more than one device SECURITY Virtual Private Network (VPN) Support for FIPS-140-2 compliant encryption (Padcom, RadioIP and NetMotion) Authentication 802.1X (Infrastructure/Client and Client/Client) POWER Power Requirements 5-15VDC Power Connector 12VDC power cable with in-line fuse • 15ft (4.57m) Power Consumption 10W maximum PHYSICAL Dimensions 8" x 5.5" x 2" (20.3cm x 13.9cm x 5.1cm) Weight 1.8 lbs (0.8kg) Packaging IP54 industrial PC enclosure ENVIRONMENTAL Temperature Range -35 to 55 °C Humidity 0 to 100%, non-condensing Certifications FCC Part 15 & 90, UL, CSA Vibration MIL: 810F, Method 514.5 Procedure 1, Category 24 TIA: TIA/EIA-603, Paragraph 3.3.4 AVAILABLE OPTIONS Antenna Omnidirectional, 0 dBi and 3 dBi R3-14-2041

Motorola, Inc. P.O. Box 948133 Maitland, Florida 32794-8133 U.S.A. 407-659-5300 • Fax 407-659-5301 www.motorola.com/mesh MOTOMESH, Mesh Enabled Architecture, MEA, MeshManager and Multi-Hopping are trademarks or registered trademarks of Motorola, Inc. MOTOROLA and the Stylized M Logo are registered in the U.S. Patent and Trademark Office. All other product or service names are the property of their registered owners. © Motorola, Inc. 2005 R3-40-2005A Over 65 Years of Understanding the Needs of Public Safety In today’s world, you need a solutions provider that understands what Mission Critical is all about: the lives and well-being of your employees and the citizens they protect. That’s why Motorola is a leading provider of interoperable communication systems for public safety, first responders and government agencies. Our experience, along with our skills, people, partnerships and alliances, allow us to build innovative, fully integrated technologies that let organizations like yours share vital information with ease and confidence. We’ve been doing it for 65 years, and we’ll be standing by our customers for years to come. We are committed to bringing all of our knowledge and technical expertise together, so you can focus on what you do best... to serve and protect the public. MOTOMESH The Multi-Radio Broadband Solution for Public Safety, Public Works and Public Access MOTOMESH NETWORK COMPONENTS IAP7300 / Intelligent Access Point The Intelligent Access point provides the wireless gateway between a MOTOMESH network and the wired world. If greater network capacity is required, additional IAPs can be easily deployed. The self-forming, self-healing and self-balancing routing inherent in a MOTOMESH network minimizes the need for expensive site planning. Dual independent backhaul connections keep Mission Critical bandwidth secure and separate from the public network. MWR7300 / Mesh Wireless Router The Mesh Wireless Router extends coverage and connectivity by meshing IAPs and users together. Data signals can hop through one or more MWRs to enable non-line-of-sight communications. MWRs also act as reference points for position location determination. WMC7300 & WMC6300 / Wireless Modem Card 4.9 GHz and 2.4GHz MEA wireless access cards allow any computing device that supports PC cards to access a MOTOMESH network. These cards also form instant broadband meshes between themselves and other MEA client devices when no MOTOMESH infrastructure is present. VMM7300 & VMM6300 / Vehicle Mounted Modem 4.9 GHz and 2.4GHz MEA wireless modems provide a mobile, high bandwidth radio, and feature a standard RJ-45 Ethernet port to support laptops, hubs, printers, IP video cameras or any other Ethernet-ready device. The VMM also forms an instant broadband mesh with any other MEA device. MeshManager / Network Management MeshManager provides a single, comprehensive network management suite for controlling security policies, network provisioning, client administration and performance monitoring for all of the devices in a MOTOMESH network. Motorola’s mesh networking technology enables users to wirelessly access critical broadband applications seamlessly – any time, and anywhere. Licensed 4.9GHz and Unlicensed 2.4GHz Every MOTOMESH access point contains two standards compliant 802.11 (Wi-Fi) radios and two of Motorola’s acclaimed Mesh Enabled Architecture (MEA) mobile broadband radios. One set of Wi-Fi and MEA radios operate in the unlicensed 2.4GHz band. The other operates in the 4.9GHz public safety band. Public Safety, Public Works and Public Access MOTOMESH is a wide area, multi-radio solution that offers the security, capacity and flexibility cities need. It can deliver mobile broadband access to diverse municipal agencies, as well as Wi-Fi access to the public. The MOTOMESH architecture supports up to four radio networks in a single access point and is built on Motorola’s proven MEA mobile broadband networking technology. State of the Art Mesh Networking By leveraging technology originally developed for battlefield communications, MOTOMESH supports high-speed data, video, and position location services for fixed and mobile users. Data links automatically self-form and self-heal between users and network infrastructure. Because every access point is meshed, backhaul, deployment and operational costs are greatly reduced. Municipalities of all sizes may realize a higher ROI than with traditional networks. With the MOTOMESH Multi-Radio Broadband Solution, Municipalities Can Now... Enhance Public Safety by giving First Responders secure and dedicated 4.9GHz mobile broadband connectivity to databases, reports, and video. Boost Municipal Worker efficiency by delivering photos, blueprints and GIS enhanced data to field personnel, while supporting on-line report filing from their vehicles and laptops. Provide residents and visitors with Wi-Fi access in local hotspots, public transportation, or across the entire city. Seamless Mobility – Even at High Speeds Seamless broadband data connectivity is available throughout the network to both stationary and mobile MEA users. This constant connectivity can be used to deliver real-time, remote monitoring of in-vehicle video – even when traveling in excess of 150 mph. Form Instant Tactical Data Networks The Multi-Hopping capabilities of the MEA network allow client devices to form instant, ad hoc broadband networks where no predeployed infrastructure exists. Each MEA radio acts as a router/ repeater for all other MEA devices in the network. MEA users can “hop” through neighboring devices to communicate with each other – or to reach distant network access points that can connect them to other data and voice networks. Fast and Accurate Position Location Depending on network configuration, patented position location technology is available to every MEA device. Using this technology, users know where they are and can instantly find out where any other user is, without having to rely on…

Text truncated - open the document above for the full version.

MPE Calculation for AP30-2.4 RF Exposure Requirements: §1.1307(b)(1) and §1.1307(b)(2): Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. RF Radiation Exposure Limit: §1.1310: As specified in this section, the Maximum Permissible Exposure (MPE) Limit shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in Sec. 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of Sec. 2.1093 of this chapter. MPE Limit Calculation: EUT’s operating frequencies @ 2412 – 2462 MHz; highest conducted power = 23.6 dBm (peak) therefore, Limit for Uncontrolled exposure: 1 mW/cm 2 or 10 W/m 2 EUT maximum antenna gain = 8.5 dBi. Equation from page 18 of OET 65, Edition 97-01 S = PG / 4πR 2 or R = vPG / 4πS where, S = Power Density P = Power Input to antenna (0.229 Watts) G = Antenna Gain (7.079 in numeric) R = distance to the center of radiation of the antenna (20 cm or 0.2 m) S = 0.229W*7.079dB / 4*3.14*(0.2m) 2 = 1.6212W / 0.5027m 2 = 3.225 W/m 2 Test Results: EUT complies with 20cm distance exposure.

By allowing data and video to hop through one or more Mesh Wireless Router (MWR), MOTOMESH enables robust, non-line-of-sight communications between users and the network. Mesh Wireless Routers also act as reference points for position location of users and vehicles within the MOTOMESH network. The MWR7300 requires only a power connection to operate, as data is transmitted 100% wirelessly between nodes. Direct network connectivity can also be provided to colocated IP devices, like video cameras or sensors, via two, built-in, Ethernet ports. Motorola’s mesh networking technology enables users to wirelessly access critical broadband applications seamlessly – any time, and anywhere. Whether utilizing predeployed infrastructure, or an instant, ad hoc, broadband network formed with other users, Motorola’s mesh networking technology delivers real-time data to detect, prevent, respond. Licensed 4.9GHz and Unlicensed 2.4GHz The MWR7300 contains two standards compliant, 802.11 (Wi-Fi) radios and two of Motorola’s widely acclaimed, Mesh Enabled Architecture (MEA) mobile broadband radios. One set of Wi-Fi and MEA radios operate in the unlicensed, 2.4GHz band and the other set operate in the licensed, 4.9GHz public safety band. Public Safety, Public Works and Public Access can all be given separate and dedicated wireless broadband access due to MOTOMESH’s multi- radio, multi-frequency architecture. Easy to Install and Deploy Flexible mounting hardware enables the MWR to be mounted on utility poles, traffic signals, billboards, buildings, etc. Innovative weatherproof power and network connectors make reliable deployments quick and easy. MWRs automatically power up and integrate themselves into the MOTOMESH network, saving money and time. Fast and Accurate Position Location Depending on network confirguration, every MEA radio can provide position location information that does not require the use of GPS satellites. MEA location information can assist in the deployment of resources, creating a visual map of asset positions at an incident, or across an entire city. Location information is generated quickly and accurately. Multiple IP Address Support The MWR features two high-speed Ethernet ports and supports a total of six IP addresses (three addresses per port). This allows a network of IP enabled devices to be directly addressed, accessed and managed over the MOTOMESH network. Additional devices can be supported by simply linking the connected devices through a NAT capable router. Network Management and Monitoring MeshManager software allows the MWR7300 to be managed and upgraded over-the-air (OTA). The MeshManager application provides a single, comprehensive network management suite for controlling security policies, network provisioning, client administration and performance monitoring of all the components of a MOTOMESH network. MWR7300 Mesh Wireless Router • for MOTOMESH The MWR7300 extends coverage and connectivity in a MOTOMESH network by meshing access points and users together. Motorola, Inc. P.O. Box 948133 • Maitland, Florida 32794-8133 U.S.A. www.motorola.com/mesh • 407-659-5300 • Fax 407-659-5301 MOTOMESH, Mesh Enabled Architecture, MEA, MeshManager, MeshTray and Multi-Hopping are trademarks or registered trademarks of Motorola, Inc. MOTOROLA and the Stylized M Logo are registered in the U.S. Patent and Trademark Office. All other product or service names are the property of their registered owners. © Motorola, Inc. 2005 MOTOMESH Additional Network Features • Advanced Encryption Standard (AES) Support for Wi-Fi Clients • Layer 2 Multicast Support • Network Time Protocol (NTP) support • Differentiated Services using IP Quality of Service (QoS) Support • Over-the-Air Software Upgrade Support • MAC Access Control lists • Web (HTTP) based management interface • SNMP agent for remote management • Telnet interface with command-line management • Firmware Upgrades via Trivial File Transfer Protocol (TFTP) MWR7300 RADIO CHARACTERISTICS 2.4 GHz 2.4 GHz 4.9 GHz 4.9 GHz 802.11 b/g MEA 802.11 MEA Output Power 23 dBm 24 dBm 23 dBm 24 dBm RF Modulation CCK/OFDM QDMA OFDM QDMA Operating Frequency (GHz) 2.412 - 2.462 2.40 - 2.48 4.945 - 4.85 4.50 - 4.65 Maximum Burst Data Rate 54 Mbps 6 Mbps 18 Mbps 6 Mbps Spectrum Used 20MHz 60MHz 10MHz 20MHz Antenna Type Omni, 8 dBi Omni, 8 dBi Omni, 11 dBi Omni, 11 dBi Antenna Connector N-Type N-Type N-Type N-Type Default System Configuration Standard Software Key Software Key Software Key NETWORK Network Managament Software MeshManager via SNMP Network Interface 2 port 10/100 Mbps Ethernet, ruggedized RJ-45 connector with surge suppression SECURITY Virtual Private Network (VPN) Support for FIPS-140-2 compliant encryption (Padcom, RadioIP and NetMotion) Encryption Support AES, WEP and WPA (802.11 b/g only) Authentication MEA: 802.1X (Infrastructure/Client and Client/Client) 802.11: 802.1X (Infrastructure/Client) POWER Power Requirements 90-264VAC, 47-63Hz single phase Power Connector AC, NEMA 5-15 power cord • 6 ft (1.83m) Power Consumption 30W PHYSICAL Dimensions 7" x 8" x 10" (17.8cm x 20.3cm x 25.4cm) Weight 12 lbs (5.4kg) Packaging Outdoor, all-weather enclosure Mounting 3" (7.62cm) diameter post mounting ENVIRONMENTAL Temperature Range -35 to 55 °C Humidity 0 to 100%, non-condensing Certifications FCC Part 15 & 90, UL, CSA AVAILABLE OPTIONS Mounting Lamp post mount bracket assembly Power AC photo cell adapter R3-14-2039

Item QuantityReferenceDescriptionVendorVendor Part Number 176 C1, C2, C9, C12, C14, C17, C20, C23, C26, C34, C36, C37, C38, C39, C40, C41, C42, C43, C52, C54, C65, C72, C76, C85, C91, C93, C98, C103, C109, C113, C123, C124, C126, C127, C129, C130, C133, C135, C136, C139, C140, C145, C150, C151, C154, C158, C163, C170, C192, C198, C210, C214, C230, C244, C246, C249, C252, C254, C258, C259, C260, C263, C264, C271, C272, C275, C277, C278, C281, C285, C286, , C291, C292, C298, C299, C300, C301, C302, C303, C305, C307 CAP,0402,X5R,0.1uF,+/- 10%, 10VTAIYO YUDENLMK105BJ104KV 214 C3, C5, C73, C99, C131, C143, C180, C248, C251, C253, C257, C270, C273, C280 CAP,1206,X5R,4.7uF,+/- 10%, 16VTAIYO YUDENEMK316BJ475KL 314 C7, C8, C10, C11, C28, C44, C50, C86, C171, C190, C239, C240, C268, C269 CAP,0805,X5R,2.2uF, +/- 10%, 10VTAIYO YUDENLMK212BJ225KG 437 C13, C15, C16, C18, C19, C21, C22, C24, C25, C27, C53, C55, C120, C125, C134, C137, C138, C144, C161, C162, C177, C182, C201, C209, C215, C245, C247, C250, C255, C261, C262, C265, C267, C274, C276, C304, C306 CAP,0402,X5R,0.01uF,+/- 10%, 25VTAIYO YUDENTMK105BJ103KV 516 C29, C30, C58, C66, C74, C88, C89, C90, C94, C95, C97, C100, C102, C105, C213, C218 CAP,0402,NPO,2.2pF,+/- 0.25pF, 50V PHYCOMP0402CG229C9B200 639 C32, C60, C64, C68, C70, C82, C92, C106, C107, C108, C114, C117, C155, C156, C159, C164, C165, C166, C172, C176, C178, C183, C189, C194, C195, C203, C205, C206, C208, C211, C216, C219, C221, C223, C227, C229, C235, C237, C242 CAP,0402,NPO,10pF, +/- 5%, 50VPHYCOMP0402CG100J9B200 75C45, C111, C112, C193, C57CAP,0402,NPO,0.5pF,+/- 0.1pF, 25V JOHANSON TECHNOLOGY 250R07C0R5BV4 81C46 CAP,0402,NPO,1.2pF, +/- 0.25pF, 50V PHYCOMP0402CG129C9B200 96C48, C59, C80, C96, C148, C212CAP,0603,X5R,1uF,+/- 10%, 10VTAIYO YUDENLMK107BJ105KA 1017 C49, C63, C67, C69, C83, C115, C116, C157, C160, C167, C179, C188, C197, C224, C225, C228, C236 CAP,0402,NPO,1pF,+/- 0.25pF,50VPHYCOMP0402CG109C9B200 113C62, C61, R94CAP,0402,NPO,47pF,+/- 5%, 50VPHYCOMP0402CG470J9B200 122C77, C71 CAP,1206,X5R,10uF,+/-10%, 6.3V, 1.6mm tall TAIYO YUDENJMK316BJ106KL 133C75, C110, C233CAP,0402,NPO,120pF,+/- 5%, 50VPHYCOMP0402CG121J9B200 147 C78, C152, C169, C181, C191, C220, C232 CAP,0402,NPO,22pF,+/- 5%, 50VPHYCOMP0402CG220J9B200 159 C79, C81, C118, C122, C147, C234, C238, C243, C266 CAP,0402,X7R,330pF,+/- 10%, 50VPHYCOMP04022R331K9B20D 162C119, C104CAP,0402,NPO,15pF,+/- 5%, 50VPHYCOMP0402CG150J9B200 173C128, C402, C403CAP,0402,NPO,100pF,+/- 5%, 50VPHYCOMP0402CG101J9B200 181C146 CAP,0402,NPO,1.8pF,+/- 0.25pF,50V PHYCOMP0402CG189C9B200 191 C168CAP,0603,NPO,15pF,+/- 2%, 50VKEMET0603C150G5GACTU 203C174, C217, C226 CAP,0402,NPO,1.5pF,+/- 0.25pF, 50V PHYCOMP0402CG159C9B200 211C175 CAP,0402,NPO,3.9pF,+/- 0.25pF, 50V PHYCOMP0402CG399C9B200 222C196, C204 CAP,0402,NPO,2.7pF,+/- 0.25pF, 50V PHYCOMP0402CG279C9B200 233C200, C231, C241CAP,0402,X7R,470pF,+/- 10%, 50VTAIYO YUDENUMK105BJ471KV 241C279CAP,TANTB,33uF,+/- 20%, 10VPANASONICECS-T1AX336R 251C282 CAP,1206,X5R,22uF,+/- 10%, 6.3V, 1.6mm tall TAIYO YUDENJMK316BJ226KL 2625 L15, L18, L22, R30, R31, R35, R37, R41, R51, R52, R81, R83, R86, R95, R96, R98, R119, C284, R163, R164, R165, R166, R40, R47, R170 RES,0402,0 OHMS, +/- 5%, 1/16WR. G. ALLEN COCR10B000JT 27DNPLED,TH,RT,3MM DOME,GR/YSUN LEDXNN1LUGY86M 283DS3, DS5, DS8LED,TH,RT,3MM DOME,GREENLUMEXSSF-LXH103GD 292D3, D1 DIO,SINGLE_SC-79,SCHOTTKY DETECTOR Skyworks SolutionsSMS7621-079 311F3 RF_SPEC,BAND PASS FILTER,5GHz TDKDEA205425BT-2028A4 321F4RF_SPEC,BALUN,5GHzTDKHHM1570B1 33DNPF7, F5DIPLEXER,SMD,6PINNTKLDG0UQD-3060C 341F8 RF_SPEC,BAND PASS FILTER,5GHz MURATALFB215G37SG8A185 351F10 RF_SPEC,BAND PASS FILTER,2.4GHz MURATALFB2H2G45SG7A204 361F12RF_SPEC,BALUN,2.4GHzTD…
