AP 7181 Access Point Installation Guide Version 1.0.0.A March 12, 2010 68009287001 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1.1 Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 2 Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 2.1 Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 2.2 Deployment Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 2.3 Installation Methodology . . . . . . . . . . . . . . . . . . . . . . . . . . 4 2.4 Grounding Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . 4 2.5 Minimum Installation Requirements . . . . . . . . . . . . . . . . . 5 2.6 Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 2.7 Access Point Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 2.7.1 Site Surveys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 2.7.2 Root Node Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 2.7.3 Non Root Node Placement . . . . . . . . . . . . . . . . . . . . . . . 6 2.7.4 Mounting Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 2.7.5 Device Deployment Height . . . . . . . . . . . . . . . . . . . . . . . 7 2.8 Antenna Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 2.9 AP 7181 Power Options . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 2.9.1 Power Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Contents 2.10 Mounting an AP 7181 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 2.10.1 Pole Mounted Installations. . . . . . . . . . . . . . . . . . . . . . 10 2.11 Installing an AP 7181 . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 2.11.1 Required Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 2.11.2 AP 7181 Connections and Ports. . . . . . . . . . . . . . . . . . 11 2.11.3 LED Status Indicator Panel . . . . . . . . . . . . . . . . . . . . . 14 2.11.4 Removing the AP 7181 Kit from the Shipping Carton 15 2.11.4 Staging the Device Prior to Installation . . . . . . . . . . . . 17 2.12 Field Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 2.12.1 Bottom Mount Installation . . . . . . . . . . . . . . . . . . . . . . 25 2.12.2 Top Mount Installation. . . . . . . . . . . . . . . . . . . . . . . . . 33 2.13 Remote Panel Antenna Installation . . . . . . . . . . . . . . . . . 42 2.13.1 Preparing the AP 7181 . . . . . . . . . . . . . . . . . . . . . . . . . 45 2.13.2 Installing the Remote Panel Antenna . . . . . . . . . . . . . . 47 2.13.3 Installing the Blank Antenna Panel . . . . . . . . . . . . . . . 51 3 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 3.1 Initially Connecting to the Access Point . . . . . . . . . . . . . . 55 3.1.1 Connecting to the Access Point Using the WAN Port . . 56 3.1.2 Connecting to the Access Point Using the LAN Port . . 57 3.2 Basic Device Configuration . . . . . . . . . . . . . . . . . . . . . . . 59 3.2.1 Configuring Device Settings . . . . . . . . . . . . . . . . . . . . . 61 3.2.2 Configuring WLAN Security Settings . . . . . . . . . . . . . . 69 3.2.3 Creating a Secure Recovery WLAN . . . . . . . . . . . . . . . 71 3.2.4 Testing Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . 77 3.2.5 Creating a Mesh Point . . . . . . . . . . . . . . . . . . . . . . . . . . 78 3.3 Where to Go From Here? . . . . . . . . . . . . . . . . . . . . . . . . . 84 4 Regulatory Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . 85 4.1 Health and Safety Recommendations . . . . . . . . . . . . . . . 85 4.1.1 Warnings for the Use of Wireless Devices . . . . . . . . . . 85 4.1.2 Potentially Hazardous Atmospheres . . . . . . . . . . . . . . . 85 4.1.3 Reducing RF Exposure - Use Properly . . . . . . . . . . . . . 85 4.2 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85 4.3 FCC Regulatory Information . . . . . . . . . . . . . . . . . . . . . . 86 4.3.1 RF Exposure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86 4.3.2 Intentional and Unintentional Radiators . . . . . . . . . . . . 86 4.3 Canada Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . 86 5 Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87 MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners. © Motorola, Inc. 2010. All rights reserved. Introduction 1 1Introduction The purpose of this document is to provide installation and setup procedures for Motorola’s AP 7181 Access Point. The AP 7181 is a wireless broadband data system that uses mesh networking technology to support wide-area broadband data coverage. The system offers both 2.4 GHz 802.11b/g/n and 5.x GHz 802.11n Wi-Fi client access with 2.4 GHz 802.11 b/g/n and 5.x GHz 802.11a/ n meshing. The dual-band system supports industry standard client devices and features easily deployed fixed infrastructure nodes. The AP 7181 is also designed to meet the needs of large, distributed outdoor networks. The network can be configured and managed for optimal performance using the Wireless Manager (WM) network Management application. The most current versions of this manual and other AP 7181 documentation can be found at: http://motorola.wirelessbroadbandsupport.com/support/mesh/library 1.1 Document Conventions The following graphical alerts are used in this document to indicate notable situations: NOTETips, hints, or special requirements that you should take note of. CAUTIONCare is required. Disregarding a caution can result in data loss or equipment malfunction. WARNING!Indicates a condition or procedure that could result in personal injury or equipment damage. ! AP 7181 Access Point: Ins…

Text truncated - open the document above for the full version.

IN AP 7181 572962 B LABEL,7181,SERIAL NUMBER, LEAD-FREE / ROHS COMPLIANT TITLE UNITS SCALE: 1:1 PAGE 1 OF 4PREPARED BY: RTL MODELDRAWING NOREV MOTOROLA CONFIDENTIAL - DO NOT REDISTRIBUTE  MADE IN MEXICO N44 15 AP-7181-DC-US *6830KS0001 *000000000000* *000000000000* *000000000000* SN: ETH MAC: 2.4 RADIO MAC: 5.8 RADIO MAC: TAB -001 FCC ID: QJEMM718101 IC: 4602A-MM718101 Input: 41-58V 4 A Frequencies 2.4/5.8 GHz Input: 41-58V 4 A Frequencies 2.4/5.8 GHz I.T.E. E333002 2.75” ref 1.25” ref 1. When setting up Print Options, all scaling options, such as “Fit to Page”, must be uncheched in order for this file to print accurately. 2. See mechanical part drawing for general information. 5 AP7181 Label Specification Document Version: 0.4 Page 1 of 8 MNPG HW Development R. Greenway Motorola Confidential Proprietary WiBB / MNPG AP7181 Label Specification 5 AP7181 Label Specification Document Version: 0.4 Page 2 of 8 MNPG HW Development R. Greenway Motorola Confidential Proprietary Table of Contents 1.0 Summary_________________________________________________________ 3 2.0 System Components ________________________________________________ 3 3.0 Required Labels ___________________________________________________ 3 3.1 Unit Label ________________________________________________________ 3 3.2 Port Label – ______________________________________________________ 4 3.3 Status Indicator Label - 572977-001 ___________________________________ 4 3.4 Shipping Container Label - 54009265001 ______________________________ 4 3.5 Decorative (Pretty) Label - 54009284001 _______________________________ 4 3.6 Ground Symbol Label - 576701-001-00 ________________________________ 5 4.0 Images___________________________________________________________ 5 The information contained in this document is classified MOTOROLA CONFIDENTIAL PROPRIETARY. The use and divulgence of any part of this information can seriously affect the welfare and financial security of the company. The distribution of information to any individual not employed by MOTOROLA or to any organization is strictly prohibited. Any MOTOROLA employee receiving this document will be held strictly accountable for the discretion and judgment associated with the use of this information. COPYRIGHT ©2007 by MOTOROLA, INC. ALL RIGHTS RESERVED 5 AP7181 Label Specification Document Version: 0.4 Page 3 of 8 MNPG HW Development R. Greenway Motorola Confidential Proprietary 1.0 Summary This document contains the requirements for the AP7181 labeling. 2.0 System Components The MotoMesh AP7181 system consists of the following components. The detailed mechanical drawings are available in the PDM Intralink system:  AP7181 o Cast Aluminum Enclosure o Two Antenna Mounting Rings o Four Antenna Panels  Accessories o Power Cables o Mounting attachments o Ethernet Cable Glands 3.0 Required Labels 3.1 Unit Label The four AP7181 models will have different unit labels. This label will be printed in Reynosa. The unit label is required to contain the following information  MAC Address – Bar code  Serial Number – Bar code  Model Number and Name  Input Power  Regulatory numbers and logos o FCC - QJEMM718101 o IC - 4602AMM718101 o CE Mark - CE0980! o UL logo  Environmental logos o RoHs o WEEE o Recycle  Motorola Name or Logo  Made in Mexico  Hot surface marking – UL Requirement Table 1 - Unit label part numbers Description AC-US DC-US AC-INTL DC-INTL Model PLUX1000A PLUX1001A MLUX1035A MLUX1036A Label Kit 576628-002 576628-001 576628-003 576628-004 Artwork 576727-002 576727-001 576727-003 576727-004 5 AP7181 Label Specification Document Version: 0.4 Page 4 of 8 MNPG HW Development R. Greenway Motorola Confidential Proprietary 3.2 Port Label – AC Port Label 572958-001 DC Port Label 572958-002 The Port labels indicate the following  Input power port  Reset switch  GE1 – Gigabit Ethernet 1  GE2  Debug This label will be printed in Reynosa. The generic material is 219882 series labels 3.3 Status Indicator Label - 572977-001 The status indicator label will cover most of the light panel window and will allow the 6 light pipes to be seen. This label will be printed in Reynosa. The generic material is 219882 series labels 3.4 Shipping Container Label - 54009265001 The Shipping Container Label is required to contain the following information  MAC Address – Bar code  Serial Number – Bar code  Motorola Name This label will be printed in Reynosa. The generic material is 219882 series labels A second Shipping container label will be printed in Elgin and cover the one from Reynosa. Additional information on Elgin label  Sales Model number – Bar code 3.5 Decorative (Pretty) Label - 54009284001 The Shipping Container Label is required to contain the following information  Part number with Bar Code  Motorola Logo  Decorative AP7181 Logo 5 AP7181 Label Specification Document Version: 0.4 Page 5 of 8 MNPG HW Development R. Greenway Motorola Confidential Proprietary 3.6 Ground Symbol Label - 576701-001-00 This label will be removed with an ECN after the inventory of chassis that do not have the ground symbol in the casting is depleted. 4.0 Images Figure 1 - Label Images Artwork 576727-001 Label Received from Reynosa 3/15/10 576727-002 Label Received from Reynosa 3/15/10 5 AP7181 Label Specification Document Version: 0.4 Page 6 of 8 MNPG HW Development R. Greenway Motorola Confidential Proprietary 576727-003 Label Received from Reynosa 3/15/10 576727-004 5 AP7181 Label Specification Document Version: 0.4 Page 7 of 8 MNPG HW Development R. Greenway Motorola Confidential Proprietary Label Received from Reynosa 3/15/10 Figure 2 - Ground Label and Port Label 5 AP7181 Label Specification Document Version: 0.4 Page 8 of 8 MNPG HW Development R. Greenway Motorola Confidential Proprietary Figure 3 - Status Indicator Label and Unit Label

AP 7181 Internal Photos March 25, 2010 Mesh Networks Product Group 1064 Greenwood Blvd. Suite 400 Lake Mary, FL 32746 MOTOROLA CONFIDENTIAL PROPRIETARY

AP 7181 Internal Photos March 24, 2010 Mesh Networks Product Group 1064 Greenwood Blvd. Suite 400 Lake Mary, FL 32746 MOTOROLA CONFIDENTIAL PROPRIETARY

1 1 Pulse Finland Oy Takatie 6 90440 Kempele, Finland Tel: +358 207 935 500 Fax: +358 207 935 501 Domicile: Kempele Business ID: 1933992-8 [email protected] www.pulseeng.com/antennas W3811 C Datasheet. Version 1.4 Confidential. Preliminary (03/10) © 2006. All Rights Reserved. W3811C 2.4GHz and 5.xGHz Antenna Panel 2.4GHz Antenna Array Operating bandwidth 2400 – 2485 MHz Impedance at the connector 50 Ohms VSWR 1,85 : 1 MAX Dual Polarized Directional Antenna Array Beam Steering Down Tilt 5.xGHz Antenna Array Operating bandwidth 5470 - 5850 MHz Impedance at the connector 50 Ohms VSWR 1,85 : 1 MAX Dual Polarized Directional Antenna Array Cables and connectors Cable semi rigid hand formable or flexible. Plastic protective jacket. (For example Sucoform 141FEB or equivalent electrical and mechanical properties) Connector Huber+Suhner IP67 rated QMA right angle plug or equivalent 2 2 Pulse Finland Oy Takatie 6 90440 Kempele, Finland Tel: +358 207 935 500 Fax: +358 207 935 501 Domicile: Kempele Business ID: 1933992-8 [email protected] www.pulseeng.com/antennas W3811 C Datasheet. Version 1.4 Confidential. Preliminary (03/10) © 2006. All Rights Reserved. Mechanical specification Radome material PC Surface texture VDI 3400 Class 30 Colour Colour white RAL 9016 Height 386 mm Width 261 mm Depth 68 mm Mounting M6x12 BN 5653 (INOX A2) Packing cardboard size TBD. plastic bag Marking TBD Environmental conditions Operating temperature -40°C to +60°C Operating humidity 5% to 95%RH non-condensing Ingress protection IP67 Water-tight according to IEC 529, NEMA 4X Vibration and Shock Packaged: Based on ISTA 2A 2004 Unpackaged: Mil-Std-810 Procedure VI - 4" drop Unpackaged: Based on ETSI EN 300 019-2-4 V2.2.2(2003-04) Class 4M3 [4] Salt fog ASTM B117 rust resistance Flammability Rating UL94-HB 3 3 W3 81 1 C Datasheet . V ersion 1. 4 Confidential. Preliminary ( 0 3 / 10 ) © 2006. All Rights Reserved. 4 4 Pulse Finland Oy Takatie 6 90440 Kempele, Finland Tel: +358 207 935 500 Fax: +358 207 935 501 Domicile: Kempele Business ID: 1933992-8 [email protected] www.pulseeng.com/antennas W3811 C Datasheet. Version 1.4 Confidential. Preliminary (03/10) © 2006. All Rights Reserved. Radiation patterns 2.4GHz Horizontal polarization (HP), no beam tilt Gain Theta, Phi 0 Gain Phi, Phi 0 5 5 Pulse Finland Oy Takatie 6 90440 Kempele, Finland Tel: +358 207 935 500 Fax: +358 207 935 501 Domicile: Kempele Business ID: 1933992-8 [email protected] www.pulseeng.com/antennas W3811 C Datasheet. Version 1.4 Confidential. Preliminary (03/10) © 2006. All Rights Reserved. Gain Phi, Phi 90 Gain Theta, Phi 90 6 6 Pulse Finland Oy Takatie 6 90440 Kempele, Finland Tel: +358 207 935 500 Fax: +358 207 935 501 Domicile: Kempele Business ID: 1933992-8 [email protected] www.pulseeng.com/antennas W3811 C Datasheet. Version 1.4 Confidential. Preliminary (03/10) © 2006. All Rights Reserved. Gain Phi, Theta -90 Gain Theta, Theta -90 7 7 Pulse Finland Oy Takatie 6 90440 Kempele, Finland Tel: +358 207 935 500 Fax: +358 207 935 501 Domicile: Kempele Business ID: 1933992-8 [email protected] www.pulseeng.com/antennas W3811 C Datasheet. Version 1.4 Confidential. Preliminary (03/10) © 2006. All Rights Reserved. 2.4GHz Horizontal polarization (HP), beam tilt Gain Phi, Phi 90 2.4GHz Vertical polarization (VP), no beam tilt Gain Theta, Phi 0 8 8 Pulse Finland Oy Takatie 6 90440 Kempele, Finland Tel: +358 207 935 500 Fax: +358 207 935 501 Domicile: Kempele Business ID: 1933992-8 [email protected] www.pulseeng.com/antennas W3811 C Datasheet. Version 1.4 Confidential. Preliminary (03/10) © 2006. All Rights Reserved. Gain Phi, Phi 0 Gain Phi, Phi 90 9 9 Pulse Finland Oy Takatie 6 90440 Kempele, Finland Tel: +358 207 935 500 Fax: +358 207 935 501 Domicile: Kempele Business ID: 1933992-8 [email protected] www.pulseeng.com/antennas W3811 C Datasheet. Version 1.4 Confidential. Preliminary (03/10) © 2006. All Rights Reserved. Gain Theta, Phi 90 Gain Phi, Theta -90 10 10 Pulse Finland Oy Takatie 6 90440 Kempele, Finland Tel: +358 207 935 500 Fax: +358 207 935 501 Domicile: Kempele Business ID: 1933992-8 [email protected] www.pulseeng.com/antennas W3811 C Datasheet. Version 1.4 Confidential. Preliminary (03/10) © 2006. All Rights Reserved. Gain Theta, Theta -90 2.4GHz Vertical polarization (VP), beam tilt Gain Theta, Phi 90 11 11 Pulse Finland Oy Takatie 6 90440 Kempele, Finland Tel: +358 207 935 500 Fax: +358 207 935 501 Domicile: Kempele Business ID: 1933992-8 [email protected] www.pulseeng.com/antennas W3811 C Datasheet. Version 1.4 Confidential. Preliminary (03/10) © 2006. All Rights Reserved. 5.xGHz Horizontal polarization (HP) Gain Theta, Phi 0 Gain Phi, Phi 0 12 12 Pulse Finland Oy Takatie 6 90440 Kempele, Finland Tel: +358 207 935 500 Fax: +358 207 935 501 Domicile: Kempele Business ID: 1933992-8 [email protected] www.pulseeng.com/antennas W3811 C Datasheet. Version 1.4 Confidential. Preliminary (03/10) © 2006. All Rights Reserved. Gain Phi, Phi 90 Gain Theta, Phi 90 13 13 Pulse Finland Oy Takatie 6 90440 Kempele, Finland Tel: +358 207 935 500 Fax: +358 207 935 501 Domicile: Kempele Business ID: 1933992-8 [email protected] www.pulseeng.com/antennas W3811 C Datasheet. Version 1.4 Confidential. Preliminary (03/10) © 2006. All Rights Reserved. Gain Phi, Theta -90 Gain Theta, Theta -90 14 14 Pulse Finland Oy Takatie 6 90440 Kempele, Finland Tel: +358 207 935 500 Fax: +358 207 935 501 Domicile: Kempele Business ID: 1933992-8 [email protected] www.pulseeng.com/antennas W3811 C Datasheet. Version 1.4 Confidential. Preliminary (03/10) © 2006. All Rights Reserved. 5.xGHz Vertical polarization (VP) Gain Theta, Phi 0 Gain Phi, Phi 0 15 15 Pulse Finland Oy Takatie 6 90440 Kempele, Finland Tel: +358 207 935 500 Fax: +358 207 935 501 Domicile: Kempele Business ID: 1933992-8 [email protected] www.pulse…

Text truncated - open the document above for the full version.

Electromagnetic Compatibility Motorola, Inc. Intentional Radiators Mesh Wide Area Network AP 7181 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 7, June 2007 & ICES-003 MET Report: EMC27727-FCC247 Rev. 3 © 2010, MET Laboratories, Inc. Page 55 of 122 DOC-EMC702 2/18/2010 Electromagnetic Compatibility Criteria for Intentional Radiators § 15.247(b) RF Exposure RF Exposure Requirements: §1.1307(b)(1) and §1.1307(b)(2): Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. RF Radiation Exposure Limit: §1.1310: As specified in this section, the Maximum Permissible Exposure (MPE) Limit shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in Sec. 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of Sec. 2.1093 of this chapter. MPE Limit Calculation: EUT’s operating frequencies @ 2412-2462 MHz and 5745-5825 MHz Limit for Uncontrolled exposure: 1 mW/cm 2 or 10 W/m 2 Highest EIRP 2412-2462 MHz Highest EIRP 5745-5825 MHz Equation from page 18 of OET 65, Edition 97-01 Equation from page 18 of OET 65, Edition 97-01 S = PG / 4R 2 or R = √PG / 4S S = PG / 4R 2 or R = √PG / 4S where, S = PG / 4R 2 where, S = PG / 4R 2 P=23.96(248.8mW) P=23.96(248.8mW) G=12dBi(15.8) G=12dBi(15.8) S = 3931.04/ 4(20) 2 S = 3931.04/ 4(20) 2 S = 0.782 mW/cm 2 S = 0.782 mW/cm 2

Electromagnetic Compatibility Motorola, Inc. Cover P age Mesh Wide Area Network AP 7181 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 7, June 2007 & ICES-003 MET Report: EMC27727-FCC247 Rev. 3 © 2010, MET Laboratories, Inc. Page ii of vii DOC-EMC702 2/18/2010 Electromagnetic Compatibility Criteria Test Report for the Motorola, Inc. Mesh Wide Area Network AP 7181 Tested under the FCC Certification Rules contained in Title 47 of the CFR, Parts 15 Subpart B & ICES-003 for Class B Digital Devices & 15.247 Subpart C & RSS-210, Issue 7, June 2007 for Intentional Radiators MET Report: EMC27727-FCC247 Rev. 3 March 30, 2010 Prepared For: Motorola, Inc. 1064 Greenwood Blvd. Suite 400 Lake Mary, FL 32746 Prepared By: MET Laboratories, Inc. 914 W. Patapsco Ave. Baltimore, MD 21230 Electromagnetic Compatibility Motorola, Inc. Cover P age Mesh Wide Area Network AP 7181 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 7, June 2007 & ICES-003 MET Report: EMC27727-FCC247 Rev. 3 © 2010, MET Laboratories, Inc. Page iii of vii DOC-EMC702 2/18/2010 Electromagnetic Compatibility Criteria Test Report for the Motorola, Inc. Mesh Wide Area Network AP 7181 Tested under the FCC Certification Rules contained in Title 47 of the CFR, Parts 15 Subpart B & ICES-003 for Class B Digital Devices & 15.247 Subpart C & RSS-210, Issue 7, June 2007 for Intentional Radiators Shawn McMillen, Project Engineer Jennifer Warnell Electromagnetic Compatibility Lab Documentation Department Engineering Statement: The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of the FCC Rules Parts 15B, 15.247 and Industry Canada standards ICES-003, Issue 4 February 2004, RSS-210, Issue 7, June 2007 under normal use and maintenance. Shawn McMillen, Wireless Manager, Electromagnetic Compatibility Lab Electromagnetic Compatibility Motorola, Inc. Report S tatus Mesh Wide Area Network AP 7181 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 7, June 2007 & ICES-003 MET Report: EMC27727-FCC247 Rev. 3 © 2010, MET Laboratories, Inc. Page iv of vii DOC-EMC702 2/18/2010 Report Status Sheet Revision Report Date Reason for Revision  March 23, 2010 Initial Issue. 1 March 26, 2010 Rev 1 (Update Output Power, Spectral Density Sections) 2 March 29, 2010 Rev 2 (Update Power section & MPE) 3 March 30, 2010 Revised to reflect engineer corrections. Electromagnetic Compatibility Motorola, Inc. Table of Conte nts Mesh Wide Area Network AP 7181 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 7, June 2007 & ICES-003 MET Report: EMC27727-FCC247 Rev. 3 © 2010, MET Laboratories, Inc. Page v of vii DOC-EMC702 2/18/2010 Table of Contents I. Executive Summary .................................................................................................................................................1 A. Purpose of Test ...................................................................................................................................................2 B. Executive Summary ............................................................................................................................................2 II. Equipment Configuration .......................................................................................................................................3 A. Overview.............................................................................................................................................................4 B. References...........................................................................................................................................................5 C. Test Site ..............................................................................................................................................................5 D. Description of Test Sample.................................................................................................................................6 E. Equipment Configuration....................................................................................................................................8 F. Support Equipment .............................................................................................................................................8 G. Ports and Cabling Information ............................................................................................................................8 H. Mode of Operation..............................................................................................................................................8 I. Modifications ......................................................................................................................................................9 a) Modifications to EUT....................................................................................................................9 b) Modifications to Test Standard......................................................................................................9 J. Disposition of EUT .............................................................................................................................................9 III. Electromagnetic Compatibility Criteria for Unintentional Radiators ..............................................................10 § 15.107(a) Conducted Emissions Limits.............................................................................................................. 11 § 15.109(a) Radiated Emissions Limits.......................................................................…
