QK3-WL0002Mini-PCI Wireless LAN Module

Fujitsu Australia Ltd

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Apr 03, 2003
Application Purpose: Original Equipment
Date of Application: Apr 03, 2003
Equipment Note: Mini-PCI Wireless LAN Module
Frequency Range: 2412.00000000 - 2462.00000000
Company: Fujitsu Australia Ltd
Country: Australia

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

54Mbps 802.11g Wireless LAN Card User’s Manual Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of the seller. The seller provides this documentation without warranty, term, or condition of any kind. The seller may make improvements or changes in the product(s) and/or the program(s) described in this documentation at any time. Other product and company names herein may be trademarks of their respective owners.  2002 All rights reserved. Rev: 01 January 2003 I Contents About This Manual............................................................................................................................................V Chapter 1 Introduction....................................................................................................................................1 Wireless LAN Basics.......................................................................................................................................2 Local Area Network (LAN).........................................................................................................................................................................2 Ad-Hoc Mode.................................................................................................................................................................................................3 Infrastructure Mode.....................................................................................................................................................................................4 Roaming..........................................................................................................................................................................................................5 Chapter 2 Installing the Wireless LAN Card....................................................................................................7 System Requirements......................................................................................................................................7 Installing Wireless LAN Driver and Software......................................................................................................8 Chapter 3 Using Broadcom Wireless Configuration Utility............................................................................11 Accessing Broadcom Wireless Configuration Utility...........................................................................................12 Notice When Assessing Broadcom Utility under Windows XP...........................................................................................................12 Wireless Networks Tab...................................................................................................................................15 Connecting to an Existing Wireless Network.........................................................................................................................................15 Configuring a New Wireless Network Connection...............................................................................................................................17 54Mbps 802.11g Wireless LAN Card II Configuring an Existing Wireless Network Connection......................................................................................................................20 Specifying a Network Type to Access......................................................................................................................................................21 Link Status Tab..............................................................................................................................................22 Statistics........................................................................................................................................................25 Site Monitor....................................................................................................................................................26 Advanced Site Monitor...............................................................................................................................................................................29 Diagnostics Tab.............................................................................................................................................32 Information Tab..............................................................................................................................................35 Chapter 4 Windows XP Wireless Zero Configuration Utility..........................................................................37 Connecting to an Access Point or Wireless LAN Card........................................................................................................................37 Viewing Wireless Connection Status.......................................................................................................................................................39 Configuring Your Wireless Properties....................................................................................................................................................40 Chapter 7 Troubleshooting............................................................................................................................47 Radio Interference..........................................................................................................................................47 Card Not Detected..........................................................................................................................................48 Cannot Connect to Another Wireless LAN Card............................................................…

Text truncated - open the document above for the full version.

Block Diagram

Askey Computer CORP. NO.119, CHIENKANG RD., CHUNG-HO HSIN-TIEN, TAIPEI, TAIWAN, R.O.C TEL: 886-2-2228-7588 FAX: 886-2-3234-9340 http: www.askey.com.tw WLL3010-D50 OVERVIEW 1. Specifications Host Interfaces Mini PCI Form factor Type III B Chipset Broadcom BCM 4306 & BCM 2050 Operation Voltage 3.3VDC Network Standards IEEE 802.11b (Wi-Fi™) standard and IEEE 802.11g draft standard (54G) Modulation Techniques DBPSK,DQPSK,CCK,16QAM,64QAM Modulation Technology OFDM,DSSS Data Rate 802.11b: 11, 5.5, 2, 1 Mbps 802.11g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps Network Architectures Infrastructure and Ad Hoc Operating Frequencies 2.4-2.497 GHz Operating Channels 802.11b: 14 for Japan, 802.11g: 13 for Japan RF Output Power 15 dBm maximum output power (14 dBm nominal ± 1 dBm over operating temperature Receiver sensitivity (PER <10%) -80dBm @ 6Mbps Antenna Type Hardware diversity support: transmit and receive on Main and Auxiliary antenna connectors. Range 802.11b: 11 Mbps up to 180m LOS, 60m indoors; 1 Mbps up to 570m LOS, 125m indoors 802.11g: 54 Mbps up to 50m LOS, 20m indoors; 18 Mbps up to 150m LOS, 75m indoors Power Consumption Tx peak: 550 ma @ 3.3VDC; Rx peak: 350 ma @ 3.3VDC; Idle: 225mA @ 3.3VDC Security Hardware 64/128-bit WEP engine; WEP weak-key avoidance, TKIP, hardware AES engine supporting CCM and OCB, 802.1x, SSN Delay Tolerance 802.11b: Multipath R.M.S Delay Spread @ 1% FER: 11 Mbps > 250 nsec; 5.5 Mbps > 300 nsec Client Utility Automatic location profile, site monitor, current link status, and diagnostics Software Support Microsoft WHQL certified for Windows XP, 2000, and ME. Linux and VxWorks embedded drivers. LED Indicators WLAN Activity Monitor, WLAN Radio Status Indicators Switch Manual radio on/off disables transmit and receive to comply with aviation in-flight restrictions Temperatures Operates from 0 to 70 Storage from -40 to 90 Humidity (non-condensing) 5 to 95% Certifications Wi-Fi; FCC part 15C/15.247; ETS 300 328-2; UL; IEC60950; EN 301 489-1,17; prEN50371 ;CE Mark; TELEC 1 Askey Computer CORP. NO.119, CHIENKANG RD., CHUNG-HO HSIN-TIEN, TAIPEI, TAIWAN, R.O.C TEL: 886-2-2228-7588 FAX: 886-2-3234-9340 http: www.askey.com.tw 2. Pin Assignment 1 NC 43 RESERVED 85 AD[08] 2 NC 44 AD[26] 86 C/BE[0]# 3 NC 45 C/BE[3]# 87 AD[07] 4 NC 46 AD[24] 88 3.3V 5 NC 47 AD[23] 89 +3.3V 6 NC 48 IDSEL 90 AD[06] 7 NC 49 GND 91 AD[05] 8 NC 50 GND 92 AD[04] 9 NC 51 AD[21] 93 NC 10 NC 52 AD[22] 94 AD[02] 11 LED_RESERVED 53 AD[19] 95 AD[03] 12 LED_RESERVED 54 AD[20] 96 AD[00] 13 ENABLE/DISABLE 55 GND 97 NC 14 NC 56 PAR 98 ENABLE/DISABLE 15 NC 57 AD[17] 99 AD[01] 16 NC 58 AD[18] 100NC 17 NC 59 C/BE[2]# 101GND 18 NC 60 AD[16] 102GND 19 3.3V 61 IRDY# 103NC 20 INTA# 62 GND 104M66EN 21 NC 63 +3.3V 105NC 22 NC 64 FRAME# 106NC 23 GND 65 CLKRUN# 107NC 24 3.3VAUX 66 TRDY# 108NC 25 CLK 67 SERR# 109NC 26 RST# 68 STOP# 110NC 27 GND 69 GND 111NC 28 3.3V 70 3.3V 112NC 29 REQ# 71 PERR# 113NC 30 GNT# 72 DEVSEL# 114GND 31 3.3V 73 C/BE[1]# 115NC 32 GND 74 GND 116NC 33 AD[31] 75 AD[14] 117NC 34 PME# 76 AD[15] 118NC 35 AD[29] 77 GND 119NC 36 RESERVED 78 AD[13] 120NC 37 GND 79 AD[12] 121NC 38 AD[30] 80 AD[11] 122MPCIACT# 39 AD[27] 81 AD[10] 123NC 40 3.3V 82 GND 1243.3VAUX 41 AD[25] 83 GND 42 AD[28] 84 AD[09] 3. block Diagram 2

Cover Letter(s)

FUJITSU AUSTRALIA LIMITED ACN 001 011 427 5 Lakeside Drive Burwood East, Victoria 3151 Australia Tel (+61 3) 9845 4300 Fax (+61 3) 9845 4600 ENGINEERING SERVICES, TELECOMMUNICATIONS Federal Communications Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21045 26 th March 2003 Reference:FCC ID: QK3-WL0002 Subject:Request for Confidentiality for FCC Certification Application - M030233F Company:Fujitsu Australia Ltd Test Sample:Mini-PCI Wireless LAN Module (Broadcom) Product Type Low power transmitter (intentional radiator) Pursuant to Rule 47 CFR, Chapter 1, Section 0.457(d)(1)(ii), Fujitsu Australia Ltd, requests that prior to the equipment authorization grant for the Mini-PCI Wireless LAN Module (Broadcom), the entire application be classified and deemed confidential by the Federal Communications Commission (FCC) and as such be withheld from public inspection. As per 47 CFR, Chapter 1, Section 0.457, the exhibits tendered for the purpose of this grant, contain details of trade secrets and technical data that is not made available to competitors and the general public. This information is treated in a confidential manner by Fujitsu Australia Ltd and guarded from disclosure to our competitors. The exhibits outlined below are not routinely made available Fujitsu Australia Ltd staff, with such access granted only to those specifically involved with this particular project. They contain information detailing the unique technology and circuitry of the product that would be of significant benefit to our competitors. All employees treat this technical data in a confidential manner. The manufacture of this product has taken place after an extensive research and development process that has seen the company invest a considerable amount of time and money. The time and effort taken has enabled the product to meet the specific demands of the competitive market for which it is intended and it would be therefore detrimental to allow competitors easy access to design and development details. Apart from a limited number of employees, the information has previously only been disclosed to the Test House responsible for conducting testing and authorized to act as our agent during the certification process. Pursuant to 47CFR Chapter 1, Section 0.459, Fujitsu Australia Ltd requests post-grant confidentiality for the following items, ensuring that this material continue to be withheld from public inspection following the grant of this authorization. Exhibit - PCB Layouts47 CFR 2.1033, Complete technical PCB Layouts Exhibit - Schematics47 CFR 2.1033, Complete technical schematic circuit diagrams Exhibit - Antenna InformationDetailed technical antenna information Sincerely Yours, ___________________ Praveen Rao Senior Compliance Engineer, Fujitsu Australia Ltd.

Cover Letter(s)

Response to TCB findings Hello Donna, We have identified these issues following our review of the application: 1. Please submit a new FCC Form 731 with the correct frequency range and power level. Also the equipment code should be DTS. Response – new form 731 submitted. 2. Please provide a letter detailing how this module complied with the 8 points detailed in FCC Public Notice DA 00-1407. See attached. Response – module letter submitted. 3. The user's manual must have a caution against modification of device (15.21). Please make an addition for this to the user's manual. Response – revised manual submitted. 4. Please provide a detailed calculation (similar to 4.1.3 in the report) for the 4.4 Peak output power summation of 3 MHz steps resulting in the final value of 29.4 dBm at 2412 MHz in section 4.4.2 of the report. Response – revised test report submitted. 5. 10% voltage variation shown in section 4.4.3 is inadequate. Please provide 85%-115% as required by 15.31(e) Response – revised test report submitted. 6. Please provide a band-edge field strength measurement at 2483.5MHz with the devices operating in the highest channel allowed in North America in both OFDM and DSSS modes. Response - The field strength at 2483.5 MHz when the EUT is operating at its highest channel (2462 MHz), is <38 dBuV/m (noise floor)and is > 20 dB below the maximum field strength of the in-band carrier. 7. Please provide a statement or plots documenting compliance with the 15.247(c) requirement that all out-of-band emission in any 100kHz bandwidth are 20 dB below the in-band emissions. Response – revised test report submitted. 8. For the section 4.6 (Peak PSD) please describe the calculation performed to convert the radiated data into peak PSD results similar to section 4.1.3 of the report. Response – revised test report submitted. 9. Please confirm what RF exposure category is being applied as the report indicates mobile (>20cm) but the corrected manual states portable (<20cm). Response – revised manual submitted. Best Regards, Yunus Faziloglu Reviewing Engineer Curtis-Straus TCB

Cover Letter(s)

EMC Technologies Pty Ltd 57 Assembly Drive, Tullamarine Vic 3043 Australia Ph: +613 9335 3333 Fax: +613 9338 9260 www.emctech.com.au MODULAR APPROVAL REQUEST LETTER FCC ID: QK3-WL0002 Industry Canada ID: IC-337H-WL0002 Test Sample: Mini-PCI Wireless LAN Module Wireless Module: Broadcom Model Number: WLL3010 Tested for: Fujitsu Australia Ltd Report/Submission No. M030233_RFWL EMC Technologies Pty Ltd attests that the Mini-PCI Wireless LAN module (Broadcom), model WLL3010, complies with the requirements of FCC Public Notice DA00-1407. All listed requirements have been met and compliance is shown in the following statements. 1. "The modular transmitter must have its own RF Shielding".: The radio portion of this module has been shielded, please see exhibit - Appendix B2 (EUT Photographs). 2. "The modular transmitter must have buffered modulation/data inputs".: The EUT has buffered data inputs, it is integrated in chip BCM4306. 3. "The modular transmitter must have its own power supply regulation".: The chips IF converter and RF/IF converter which will influence the frequency radiation, have to be 1.8V DC powered. The Mini-PCI interface provides a 3.3VDC, so there are regulators in front of these chips. The part number of this regulator is LM2612. 4. "The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).": The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas have been submitted for review. Refer to Test Report Number M030233_RFWL and the following exhibits - Appendix B1(Test Setup Photos), Appendix I (Antenna Details (Inverted F)) and Appendix J (Antenna Details (Monopole)). 5. "The modular transmitter must be tested in a stand-alone configuration:.: The Broadcom module by itself is already certified - FCC ID: H8NWLL3010. Module complies in stand-alone configuration. 6. "The modular transmitter must be labeled with its own FCC ID number: FCC ID for Broadcom module displayed in Exhibit - Appendix D (FCC ID Labelling). EMC Technologies Pty Ltd ABN 82 057 105 549 57 Assembly Drive Tullamarine Victoria Australia 3043 Ph: + 613 9335 3333 Fax: + 613 9338 9260 email: [email protected] Page 2 of 2 EMC Technologies Pty Ltd 57 Assembly Drive, Tullamarine Vic 3043 Australia Ph: +613 9335 3333 Fax: +613 9338 9260 www.emctech.com.au 7. "The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements".: The EUT is compliant with all applicable FCC rules. Detailed instructions for maintaining compliance are given in the Users Manual. Refer to exhibit - Appendix K (Broadcom User Manual). 8. "The modular transmitter must comply with any applicable RF exposure requirements".: The EUT is compliant with all applicable RF exposure requirements. RF exposure is addressed in Test Report Number M030233_RFWL. Please do not hesitate to contact me if you require any additional information. Best Regards Chris Zombolas Technical Director EMC Technologies Pty Ltd

External Photos

EMC Technologies Report No. M030233FWL Page 1 of 2 APPENDIX B2 TEST SAMPLE Test Sample - Wireless LAN Module (Broadcom) EMC Technologies Report No. M030233FWL Page 2 of 2 Test Sample - Wireless LAN Module (Broadcom)

ID Label/Location Info

APPR. CHECK DATE EDIT FMV WORD FDCC-4967-2 2001.3 TITLE 1 CUST DESIG. DESCRIPTION DESIG. CHECK APPR. DRAW. NO. 15 54g Wireless LAN Card (Mini PCI for 11ch) Purchase Specification L0CP024081-XX FUJITSU LIMITED S H E E T The label is printed on Mylar material and fixed to the unit Label FCC ID: QK3-WL0002 IC-337H-WL0002 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation FCC ID: QK3-WL0002 IC-337H-WL0002 CE! Bottom Panel of the Notebook WLAN MODULE LABEL LCD Screen side

Internal Photos

Operational Description

Test Report

EMC Technologies Pty. Ltd. - Global Product CertificationFCC Class B Job No:M030233F Test Date: 03/03/03 GRAPH No. 1 r:\pcf\030233F_1.PCF Melbourne- 57 Assembly Drv Tullamarine, 3043, Vic, Australia Ph+(613) 9335 3333 Fax+(613) 9338 9260Sydney---- 16,6 Gladstone Rd Castle Hill, 2154, NSW, Australia Ph+(612) 9899 4599 Fax+(612) 9899 4019Fujitsu Australia Limited Lifebook - Rialto (E4010) Conducted Emissions - Active Line Conducted Emissions (dBuV) M030233c Limits: Legend: Source: _ FCC_BQPN FCC PART 15 CLASS B CONDUCTED QP LIMITS (2002) _ FCC_BAVN FCC PART 15 CLASS B CONDUCTED AVERAGE LIMIT (2002) __ Active Line 8 9 10 Ver 5.5 Build 71conducted lab 3 using L-22 25A LISN t:L0220104 c1:C1610503 c2:C1520503 p:NONE a:L0171103Site ID: Room#3,57 Assembly Drv. Tullamarine, VIC Test Officer:Chieu Huynh Peaks:No Freq Peak Qp Val FCC_BQPN dL1 Av Val FCC_BAVN dL2 (MHz) (dBuV) (dBuV) (dB) (dBuV) (dBuV) (dB) 1 .49 43.0 44.8 56.2 -11.4 36.7 46.2 -9.5 2 .36 48.6 46.6 58.8 -12.2 37.6 48.8 -11.2 3 .42 45.6 42.3 57.4 -15.1 34.7 47.4 -12.7 4 .29 52.1 47.0 60.6 -13.6 33.8 50.6 -16.8 5 .22 56.6 50.9 62.9 -12.0 34.9 52.9 -18.0 6 4.82 38.2 36.6 56.0 -19.4 27.8 46.0 -18.2 7 11.55 42.9 37.9 60.0 -22.1 30.6 50.0 -19.4 8 .57 44.1 43.3 56.0 -12.7 26.2 46.0 -19.8 9 .50 44.9 44.6 56.0 -11.4 25.7 46.0 -20.3 Frequency (MHz) 1 10 .15 30 10 20 30 40 50 60 70 v ^ 1 ~ * v ^ 2 ~ * v ^ 3 ~ * v ^ 4 ~ * v ^ 5 ~ * v ^ 6 ~ * v ^ 7 ~ * v ^ 8 ~ * v ^ 9 ~ * EMC Technologies Pty. Ltd. - Global Product CertificationFCC Class B Job No:M030233F Test Date: 03/03/03 GRAPH No. 2 r:\pcf\030233F_2.PCF Melbourne- 57 Assembly Drv Tullamarine, 3043, Vic, Australia Ph+(613) 9335 3333 Fax+(613) 9338 9260Sydney---- 16,6 Gladstone Rd Castle Hill, 2154, NSW, Australia Ph+(612) 9899 4599 Fax+(612) 9899 4019Fujitsu Australia Limited Lifebook - Rialto (E4010) Conducted Emissions - Neutral Line Conducted Emissions (dBuV) M030233c Limits: Legend: Source: _ FCC_BQPN FCC PART 15 CLASS B CONDUCTED QP LIMITS (2002) _ FCC_BAVN FCC PART 15 CLASS B CONDUCTED AVERAGE LIMIT (2002) __ Neutral Line 11 12 13 Ver 5.5 Build 71conducted lab 3 using L-22 25A LISN t:L0220104 c1:C1610503 c2:C1520503 p:NONE a:L0171103Site ID: Room#3,57 Assembly Drv. Tullamarine, VIC Test Officer:Chieu Huynh Peaks:No Freq Peak Qp Val FCC_BQPN dL1 Av Val FCC_BAVN dL2 (MHz) (dBuV) (dBuV) (dB) (dBuV) (dBuV) (dB) 1 .48 49.2 47.2 56.3 -9.1 42.3 46.3 -4.0 2 .55 49.8 46.4 56.0 -9.6 41.2 46.0 -4.8 3 .62 46.8 46.1 56.0 -9.9 40.2 46.0 -5.8 4 .34 50.4 47.9 59.1 -11.2 43.3 49.1 -5.8 5 .28 50.8 48.8 60.9 -12.1 44.6 50.9 -6.3 6 .42 47.0 44.8 57.4 -12.6 31.9 47.4 -15.5 7 4.50 38.4 36.5 56.0 -19.5 26.9 46.0 -19.1 8 10.76 42.8 39.2 60.0 -20.8 28.4 50.0 -21.6 Frequency (MHz) 1 10 .15 30 10 20 30 40 50 60 70 v ^ 1 ~ * v ^ 2 ~ * v ^ 3 ~ * v ^ 4 ~ * v ^ 5 ~ * v ^ 6 ~ * v ^ 7 ~ * v ^ 8 ~ * EMC Technologies Pty. Ltd. - Global Product CertificationFCC Class B Job No:M030233F Test Date: 03/03/03 GRAPH No. 3 r:\pcf\030233F_3.PCF Melbourne- 57 Assembly Drv Tullamarine, 3043, Vic, Australia Ph+(613) 9335 3333 Fax+(613) 9338 9260Sydney---- 16,6 Gladstone Rd Castle Hill, 2154, NSW, Australia Ph+(612) 9899 4599 Fax+(612) 9899 4019Fujitsu Australia Limited Lifebook - Ginger Conducted Emissions - Active Line Conducted Emissions (dBuV) M020235c Limits: Legend: Source: _ FCC_BQPN FCC PART 15 CLASS B CONDUCTED QP LIMITS (2002) _ FCC_BAVN FCC PART 15 CLASS B CONDUCTED AVERAGE LIMIT (2002) __ ALine1 7 8 9 Ver 5.5 Build 71conducted lab 3 using L-22 25A LISN t:L0220104 c1:C1610503 c2:C1520503 p:NONE a:L0171103Site ID: Room#3,57 Assembly Drv. Tullamarine, VIC Test Officer:Chieu Huynh Peaks:No Freq Peak Qp Val FCC_BQPN dL1 Av Val FCC_BAVN dL2 (MHz) (dBuV) (dBuV) (dB) (dBuV) (dBuV) (dB) 1 .56 48.1 46.7 56.0 -9.3 40.6 46.0 -5.4 2 .42 46.7 45.6 57.4 -11.8 39.5 47.4 -7.9 3 .21 50.7 49.3 63.1 -13.8 43.3 53.1 -9.8 4 .29 49.5 48.2 60.6 -12.4 40.3 50.6 -10.3 5 .49 41.7 40.4 56.2 -15.8 33.0 46.2 -13.2 6 .58 46.9 45.7 56.0 -10.3 31.7 46.0 -14.3 7 2.95 38.5 35.5 56.0 -20.5 28.1 46.0 -17.9 8 24.71 44.2 37.7 60.0 -22.3 31.1 50.0 -18.9 Frequency (MHz) 1 10 .15 30 20 30 40 50 60 70 v ^ 1 ~ * v ^ 2 ~ * v ^ 3 ~ * v ^ 4 ~ * v ^ 5 ~ * v ^ 6 ~ * v ^ 7 ~ * v ^ 8 ~ * EMC Technologies Pty. Ltd. - Global Product CertificationFCC Class B Job No:M030233F Test Date: 03/03/03 GRAPH No. 4 r:\pcf\030233F_4.PCF Melbourne- 57 Assembly Drv Tullamarine, 3043, Vic, Australia Ph+(613) 9335 3333 Fax+(613) 9338 9260Sydney---- 16,6 Gladstone Rd Castle Hill, 2154, NSW, Australia Ph+(612) 9899 4599 Fax+(612) 9899 4019Fujitsu Australia Limited Lifebook - Ginger Conducted Emissions - Neutral Line Conducted Emissions (dBuV) M020235c Limits: Legend: Source: _ FCC_BQPN FCC PART 15 CLASS B CONDUCTED QP LIMITS (2002) _ FCC_BAVN FCC PART 15 CLASS B CONDUCTED AVERAGE LIMIT (2002) __ NLine1 10 11 12 Ver 5.5 Build 71conducted lab 3 using L-22 25A LISN t:L0220104 c1:C1610503 c2:C1520503 p:NONE a:L0171103Site ID: Room#3,57 Assembly Drv. Tullamarine, VIC Test Officer:Chieu Huynh Peaks:No Freq Peak Qp Val FCC_BQPN dL1 Av Val FCC_BAVN dL2 (MHz) (dBuV) (dBuV) (dB) (dBuV) (dBuV) (dB) 1 .56 47.3 45.5 56.0 -10.5 37.2 46.0 -8.8 2 .50 44.9 43.2 56.0 -12.8 36.1 46.0 -9.9 3 .28 48.9 47.2 60.7 -13.5 40.5 50.7 -10.2 4 .43 45.0 43.8 57.3 -13.5 37.0 47.3 -10.3 5 .65 43.9 42.4 56.0 -13.6 33.6 46.0 -12.4 6 .58 47.1 45.7 56.0 -10.3 33.3 46.0 -12.7 7 .21 49.8 47.3 63.0 -15.7 40.2 53.0 -12.8 8 2.80 39.7 37.3 56.0 -18.7 31.2 46.0 -14.8 9 14.46 43.2 39.6 60.0 -20.4 32.4 50.0 -17.6 Frequency (MHz) 1 10 .15 30 20 30 40 50 60 70 v ^ 1 ~ * v ^ 2 ~ * v ^ 3 ~ * v ^ 4 ~ * v ^ 5 ~ * v ^ 6 ~ * v ^ 7 ~ * v ^ 8 ~ * v ^ 9 ~ *

Test Report

Page 1 of 30 EMI TEST REPORT for CERTIFICATION to FCC PART 15.247 & RSS 210 FCC ID: QK3-WL0002 Industry Canada ID: IC-337H-WL0002 Test Sample: Mini-PCI Wireless LAN Module Wireless Module: Broadcom Model Number: WLL3010 Tested for: Fujitsu Australia Ltd Report Number: M030233_RFWL (Replacement for Report Number M030233FWL) Issue Date: 9 th May 2003 EMC Technologies Pty Ltd reports apply only to the specific samples tested under stated test conditions. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. EMC Technologies Pty Ltd shall have no liability for any deductions, inferences or generalisations drawn by the client or others from EMC Technologies Pty Ltd issued reports. This report shall not be used to claim, constitute or imply product endorsement by EMC Technologies Pty Ltd. The tests, calibrations or measurements covered by this document have been performed in accordance with NATA requirements which include the requirements of ISO/IEC 17025 and are traceable to national standards of measurement. This document shall not be reproduced, except in full. NATA Accredited Laboratory Number: 5292 EMC Technologies Pty Ltd ABN 82 057 105 549 57 Assembly Drive Tullamarine Victoria Australia 3043 Ph: + 613 9335 3333 Fax: + 613 9338 9260 email: [email protected] FCC ID: QK3-WL0002 IC: 337H-WL0002 Report No. M030233_RFWL Page 2 of 30 This Laboratory is accredited by the National Association of Testing Authorities, Australia. The tests reported herein have been performed in accordance with its terms of accreditation for FCC Part 15.This document shall not be reproduced, except in full. EMI TEST REPORT FOR CERTIFICATION to FCC Part 15.247/RSS-210 EMC Technologies Report No. M030233_RFWL Issue Date: 9 th May 2003 CONTENTS 1.0 SUMMARY of TEST RESULTS 2.0 GENERAL INFORMATION 3.0 TEST CONFIGURATION 4.0 CONDUCTED EMI MEASUREMENTS 5.0 RADIATED EMI MEASUREMENTS 6.0 COMPLIANCE STATEMENT APPENDIX A: MEASUREMENT INSTRUMENT DETAILS APPENDIX B: TEST SAMPLE PHOTOGRAPHS APPENDIX C: EUT SPECIFICATION (BLOCK DIAGRAM) APPENDIX D: FCC ID LABELLING APPENDIX E: TEST SAMPLE SCHEMATICS APPENDIX F: PCB LAYOUTS APPENDIX G: GRAPHS of EMI MEASUREMENTS APPENDIX H: CHANNEL BANDWIDTH PLOTS APPENDIX I: ANTENNA INFORMATION (INVERTED F) APPENDIX J: ANTENNA INFORMATION (MONOPOLE) APPENDIX K: USER MANUAL FCC ID: QK3-WL0002 IC: 337H-WL0002 Report No. M030233_RFWL Page 3 of 30 This Laboratory is accredited by the National Association of Testing Authorities, Australia. The tests reported herein have been performed in accordance with its terms of accreditation for FCC Part 15.…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Rao Praveen(Senior Compliance Engineer)

[email protected]0061-3-9845-4423Fax: 0061-3-9845-4423

Test Firm

EMC Technologies Pty. Ltd.Chris Zombolas

[email protected]61-3-9365-1000Fax: 61-3-9331-7455

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	32.00 mW

Modular Type

Limited Single Modular Approval

Confidentiality

Long Term

Grant Notes

Grant Conditions-Power output listed is conducted. Limited modular approval. This module is restricted to installation in the grantee�s notebook computers using the antennas detailed in the documents filed with this grant. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. The maximum antenna gain listed in this filing is 0.67 dBi.
