QKWFRF905Transceiver module

Guidelines when using the radio unit FRF905 in Fronius products • Range of validity: These guidelines have to be applied, when the concerning product is used in countries, in which a certification of a radio unit as prescribed by FCC 47 C.F.R. § 15.247, is ac- cepted for its use. All mentioned points have to be fulfilled. • Only the layouts with the belonging equipments, used in the radio device certification, may be used. • Usable frequencies: 902,4-927,6 MHz in the 0,4 MHz-scheme. At least 50 different frequencies must be used here, after a pseudo random principle, whereby each frequency may be used within any 20s-intervals for maximum 0,4s. • useable antennas: o internal antenna ANT-916-JJB-ST o external antennas over SMA-plugs: ANT-DB1-RMT-SMA-2mRG174 or PSKN3-890S • The following transmitting powers with the corresponding time on air and antennas have to be kept: Antenna maximum transmit- ting power [dBm] TOA each 100ms [%] 1 10 50 PSKN3-890S 6 100 ANT-DB1-RMT- SMA-2mRG174 10 100 ANT-916-JJB-ST 10 100 • The supply voltage must be within the range of 1,9 – 3,6 V (at minimum 30mA load capacity) • In the case of the use of an external antenna, the antenna plug may not be accessible from the outside (plug rises up from the equipment). If this is nevertheless absolutely necessary, an RP- SMA antenna plug (“unique antenna connector”) must be used. Accordingly the plug of the an- tenna, which can be attached (ANT-DB1-RMT-SMA-2mRG174 and/or PSKN3-890S), has also to be changed. • The inscription „Contains FCC ID: QKWFRF905“ has to be attached readably from the outside (and/or in a general manner) on the product Reference: [1] Data sheet of transceiver nRF905 V1.2 (download: http://www.nordicsemi.no ) 1 The TOA (time on air) is to be calculated as prescribed by [1] page 25. Measurement: Low-Hi-transition of the signal TX_EN to the Hi-Low-transition of the signal DR of the nRF905.

PRODUCT SPECIFICATION nRF905 Single Chip 433/868/915 MHz Radio Transceiver Main office: Nordic Semiconductor ASA - Vestre Rosten 81, N-7075 Tiller, Norway - Phone +4772898900 -Fax +4772898989 Revision: 1.1 Page 2 of 36 June 2004 ORDERING INFORMATION Type NumberDescriptionVersion nRF905 IC32L QFN 5x5mm- nRF905-EVKIT 433Evaluation kit 433MHz1.0 nRF905-EVKIT 868/915Evaluation kit 868/915MHz1.0 Table 2 nRF905 ordering information. BLOCK DIAGRAM SPI interface ShockBurst Demod Dataslicer Address decode CRC code/ decode GFSK filter RX - reg. Config-reg. TX - reg. TX - addr. PA LNA IF BBF Frequency Synthesiser Voltage regulators Crystal oscillator MOSI (11) MISO (10) SCK (12) CSN (13) TRX_CE (1) PWR_UP (2) TX_EN (32) CD (6) AM (7) DR (8) uPCLK (3) XC1 (14) XC2 (15) ANT1 (20) ANT2 (21) VDD_PA (19) VSS (5) VSS (16)VSS (18)VSS (21)VSS (24)VSS (27)VSS (28)VSS (29)VSS (30) VDD (4) VDD (17)VDD (25) DVDD_1V2 (31) IREF (23) Manchester encoder/ decoder VSS (26) VSS (9) Figure 1 nRF905 with external components.

Coverletter: FRONIUS International GmbH wants to get FCC-Certification for the following product: Fronius transceiver module working in the 915 MHz band under FCC 15.247 The unit will get the following FCC-ID: QKWFRF905 List of documents: Exhibit Thema File Exhibit 01 Label and placement label_05-112.pdf Exhibit 02 Not needed -------------------- Exhibit 03 External Photos extern_05-112.pdf Exhibit 04 Block Diagrams nRF905 Blockdiagramm.pdf * Exhibit 05 Schematic Diagrams FRF905 Schaltplan.pdf FRF905 layout.jpg Exhibit 06 Testreport 05-112.pdf Exhibit 07 Test Set-up Photos setup_05-112.pdf Exhibit 08 User Manual FCC guidelines for Fronius products.doc *Exhibit 09 Internal Photos intern_05-112.pdf Exhibit 10 Not needed -------------------- Exhibit 11 RF exposure issues RF exposure.doc *Exhibit 12 Operational Description 636658_nrf9x5_blaa.pdf Exhibit 13 Cover letter Request for confidentiality This file REQUEST FOR CONFIDENTIALITY.doc For the Exhibits marked with ‘*’ FRONIUS International GmbH requested Confidentiality according to 47 CFR 0.457 and 0.459 of the FCC rules because these are sensitive parts owned by this company and include much of Know-How or sensitive data, it will not be provided to the public. The labelling on some photos may not be the actual status. The correct labelling you can in Exhibit 1.

REQUEST FOR CONFIDENTIALITY for the following product: FCC-IDENTIFIER: QKWFRF905 List of confidental documents: Exhibit Subject Exhibit 05 Schematic Diagrams Exhibit 09 Internal Photos (without shielding) Exhibit 05 Layouts Exhibit 12 Brochures We want to have this documents confidential according to 47 CFR 0.457(d) of the FCC Rules, because this information is the own and an essential part of the know how of our company, it is considered as a trade secret and will not be provided to the public. Best regards Gerald Ortner Fronius International

RF exposure compliance issues: The unit uses a very low eirp level of not more than 10 mW. So it is excluded from routine RF exposure evaluation.
