QKWRF5000IRadio frequency identification system

BLOCK DIAGRAM RFID MODULE RF5000I Texas Instr. TSM3705A +5V GND 4MHz RXOUT TXCTL 134,2kHz transmission loop antenna V1.0A transponder card Texas Instr. RI-TRP-R4FF not part of the EUT !

Coverletter: FRONIUS International GmbH wants to get the FCC-Certification for the following product: Fronius RFID module RF5000i included into remote controller RCU5000i. The unit will get the following FCC-ID: QKWRF5000I List of documents:: Exhibit Thema File Exhibit 01 Label and placement position.pdf rating.pdf Exhibit 02 Not needed -------------------- Exhibit 03 External Photos 02-225externalphotos.pdf Exhibit 04 Block Diagrams block.pdf * Exhibit 05 Schematic Diagrams RCU5000_V12A_RFID.pdf Exhibit 06 Testreport 02-225.pdf Exhibit 07 Test Set-up Photos 02-225testsetup.pdf Exhibit 08 User Manual instructions.pdf Exhibit 09 Internal Photos 02-225internalphotos.pdf Exhibit 10 Not needed -------------------- Exhibit 11 Not needed -------------------- * Exhibit 12 Operational Description functional_description.pdf Exhibit 13 Cover letter Request for confidentiality This file CONFIDENTIALITY.PDF For the Exhibits marked with ‘*’ Fronius International GmbH requested Confidentiality according to 47 CFR 0.457(d) of the FCC rules because these are sensitive parts owned by this company and include much of Know-How or sensitive data, it will not be provided to the public. The labelling on some photos is not the actual status. The correct labelling you can see on the photos and diagrams in Exhibit 1.

REQUEST FOR CONFIDENTIALITY for the following product: FCC-IDENTIFIER: QKWRF5000I List of confidental documents: Exhibit Subject Exhibit 05 Schematic Diagrams Exhibit 12 Operational Description We want to have this documents confidential according to 47 CFR 0.457(d) of the FCC Rules, because this information is the own and an essential part of the know how of our company, it is considered as a trade secret and will not be provided to the public. Best regards i.V. Peter Mair Fronius International

area for rating plate (including information about RFID module)
