QLM0130511MP3 & Multimedia Headset

USB plug to computer MP3 Samsung S5L840F Left Speaker Right Speaker Voltage Detector LCD Module 512MB NANDFlash Memory EL Backlight Driver 32.768MHz MP86 BLOCK DIAGRAM Power Supply 1.5V AAA Battery XTAL MIC Keys/Hold Switch

External Photo FCC ID : QLM0130511 External Photo - front External Photo - rear

Internal Photo FCC ID : QLM0130511 Internal Photo - 1 Internal Photo - 2 Internal Photo FCC ID : QLM0130511 Internal Photo - 3 Internal Photo - 4 Internal Photo FCC ID : QLM0130511 Internal Photo - 5 Internal Photo - 6 Internal Photo FCC ID : QLM0130511 Internal Photo - 7 Internal Photo - 8 Internal Photo FCC ID : QLM0130511 Internal Photo - 9 Internal Photo - 10 Internal Photo FCC ID : QLM0130511 Internal Photo - 11

MP86 Circuit description According to the circuit, the main core of MP86 is IC S5L840. It handles the MP3 decoding and control the accessory facilities, such as LCD. NAND flash K9F1G08U0M is used to store data. CODEC TLV320AIC23PW is used to decode digital signal to analog signal and transmit to speaker. On the other hand, analog signal from microphone is encoding to digital signal and enter IC S5L840 for further encoding. EL block of circuit diagram provides a high voltage source to drive the backlight. Power of circuit diagram is provide 2.8V voltage source to drive all IC. Select Country / Region | - Tip Semiconductor > Products > System LSI > Digital Media > Optical ASSP > Optical Player > S5L840F S5L840F General Description Features Ordering Information Production & Availability Material Data Declaration Sheet General Descri p tion S5L840F is a single chip digital audio player IC supporting various compressed audio format on Flash Memory Media. S5L840F provides 2Mbits of embedded NOR flash memo ry and 76Kbytes of SRAM requiring no external Features Supply Voltage Range - Supply Voltage (Core) : 1.8V - Supply Voltage (IO) : 3.0V X-tal Oscillator: 32.768 kHz 16bit RISC(CalmRISC16) & 24bit MAC with 4KB of Instruction Cache - 6KB of X Cache - 6KB of Y Cache 2Mbit NOR Flash, 76KB SRAM & 4KB Mask ROM IO DMA Supports SMC/MMC/SD/Memory Stick LCD Interface 2 Channels of IIS IIC / SPDIF Output / UART / SPI USB1.1 Device 5 channel 10bit ADC Real Timer Clock (RTC) General-Purpose Input /Output (GPIO) Ordering Information Device Package Operating Temperature S5L840F 128-TQFP-1414 160-FBGA-1212 - 40 °C - + 85°C S y stem LSI S y stem LSI Products New Products Technical Documents Su pp ort Part No. Decoder EOL Products SOC overview
